SERVICE MANUAL

MODEL
..............
PFM-50C1
PFM-50C1E
PFM-50C1/50C1E FLAT PANEL DISPLAY
SU-P50C
RM-971
DEST.
CHASSIS NO.
.........
....................
WORLD
WORLD
FLAT PANEL DISPLAY STAND
REMOTE COMMANDER
MODEL
..............
SU-P50C
RM-971
DEST.
CHASSIS NO.
.........
....................
WORLD
WORLD
FLAT PANEL DISPLAY

Advertisement

Table of Contents

   Related Manuals for Sony PFM-50C1

   Summary of Contents for Sony PFM-50C1

  • Page 1: Service Manual

    SERVICE MANUAL MODEL MODEL DEST. CHASSIS NO. DEST. CHASSIS NO..................PFM-50C1 SU-P50C WORLD WORLD PFM-50C1E RM-971 WORLD WORLD PFM-50C1/50C1E FLAT PANEL DISPLAY SU-P50C FLAT PANEL DISPLAY STAND RM-971 REMOTE COMMANDER FLAT PANEL DISPLAY...
  • Page 2 Pour toute réparation faire appel à une personne compétente uniquement. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. PFM-50C1/50C1E...
  • Page 3 équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant. ADVARSEL! Lithiumbatteri-Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. 1 (P) PFM-50C1/50C1E...
  • Page 4 For more information regarding recycling of re- chargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/ Caution: Do not handle damaged or leaking Lithium-Ion batteries. 2 (P) PFM-50C1/50C1E...
  • Page 5: Table Of Contents

    White Balance Adjustment ............... 2-20 2-4. AD Calibration Adjustment ..............2-20 2-5. Sub Color and Sub Hue Adjustments ............2-21 2-6. Video Decoder Adjustment ............... 2-21 2-7. Watch Error Adjustment ................2-22 2-8. Power Supply Block Adjustment .............. 2-22 PFM-50C1/50C1E...
  • Page 6 Q (3/3) ....................... 7-7 B (1/8) ..................... 7-12 B (2/8) ..................... 7-13 B (3/8) ..................... 7-14 B (4/8) ..................... 7-15 B (5/8) ..................... 7-16 B (6/8) ..................... 7-17 B (7/8) ..................... 7-18 B (8/8) ..................... 7-19 H1 ......................7-23 PFM-50C1/50C1E...
  • Page 7 APS-184 (2/4) ..................7-29 APS-184 (3/4) ..................7-30 APS-184 (4/4) ..................7-31 Printed Wiring Boards QA ......................7-3 Q ........................ 7-8 B ......................7-10 H1 ......................7-23 H2 ......................7-23 S ......................7-24 SP ......................7-24 APS-184 ....................7-26 PFM-50C1/50C1E...
  • Page 9: Service Information

    Section 1 Service Information 1-1. Board Layout SWITCHING REGULATOR (APS-184) QA (PFM-50C1) SIGNAL JOINT PKG (RU) SIGNAL JOINT PKG (MU) COLLECTION JOINT PKG SCAN JOINT PKG (A) SIGNAL JOINT PKG (LU) SCAN JOINT-JOINT PKG SCAN JOINT PKG (B) COMMON JOINT...
  • Page 10: Disassembly

    1-2. Disassembly 1-2-1. QA Board Removal PFM-50C1 QA board Remove blank panel [Loosen two panel stopper screws.] PFM-50C1E Blank panel CN3009 Two screws (+PS 3 x 6) PFM-50C1/50C1E...
  • Page 11: Rear Cover Removal

    (+PSW 6 x 20) (+PS 3 x 8) 4 Two screws 2 Four knobs (+PSW 4 x 8) 5 Six screws (+PS 3 x 8) 7 Eighteen screws (+BVTP 4 x 16) 8 Rear cover Conductive cushion Top side Main chassis PFM-50C1/50C1E...
  • Page 12: Q Board Removal

    1-2-3. Q Board Removal 1 Q/B shield cover CN3002 CN3003 CN3001 CN3006 CN3011 2 Seven screws CN3012 (+PSW 3 x 8) CN3008 CN3005 4 Q board CN3007 Conductive cushion Main chassis Top side 3 Six hexagon screws PFM-50C1/50C1E...
  • Page 13: B Board Removal

    CN401 CN1004 CN1006 2 Six screws CN1005 3 B board (+PSW 3 x 8) Lithium battery removal CN708 Remove the lithium battery in the direction of arrow. Conductive cushion Lithium battery (CR-1220) Battery holder Main chassis Top side CN1001 PFM-50C1/50C1E...
  • Page 14: Dc Fan (r) Assy Removal

    1-2-5. DC Fan (R) Assy Removal 2 DC fan 1 Four screws (+PSW 4 x 8) 3 Four screws (+BVTP 3 x 10) 5 Fan bracket (R) 4 Purse lock From Q board Conductive cushion Top side Main chassis PFM-50C1/50C1E...
  • Page 15: Ac Inlet Block Assy And Sp Board Removal

    0 Purse lock (+PSW 4 x 8) 4 Two screws 2 Screw (+BVTP 3 x 10) (+PSW 4 x 8) CN9001 9 AC inlet CN9001 5 SP board 8 Ferrite core !- Bottom bracket Top side Main chassis Conductive cushion PFM-50C1/50C1E...
  • Page 16: P Block Assy, S Board, Switching Regulator And Dc Fan (b) Removal

    1 Six screws (+PSW 4 x 8) !] Power bracket 4 Three screws 3 P block assy (+BVTP 3 x 10) CN1501 CN1501 CN1501 5 Three S boards From Q board Main chassis Top side CN9003 Conductive cushion CN9002 PFM-50C1/50C1E...
  • Page 17: Bezel Complete Assy Removal

    Before starting removal, be sure to remove the operation button assy from the bezel complete assy. Be very careful not to damage the flexible wires Top side in the top, bottom, right and left. Place the removed panel on the conductive cushion. Main chassis Bezel complete assy Conductive cushion PFM-50C1/50C1E...
  • Page 18: H1 Board Removal

    1-2-9. H1 Board Removal 1 Six screws (+BVTP 4 x 16) 3 Two screws (+BVTP 3 x 10) 4 Earth plate 5 H1 board 2 Filter (V) holder assy Bezel complete assy Conductive cushion Top side 1-10 PFM-50C1/50C1E...
  • Page 19: B Block Assy And Panel Assy Removal

    Before starting removal, be sure to remove the operation button assy from the bezel complete assy. Be very careful not to damage the flexible wires in the top, bottom, right and left. Place the removed panel on the conductive cushion. 1-11 PFM-50C1/50C1E...
  • Page 20: Q/b Bracket Assy Removal

    Before starting removal, be sure to remove the operation button assy from the bezel complete assy. Be very careful not to damage the flexible wires in the top, bottom, right and left. Place the removed panel on the conductive cushion. 1-12 PFM-50C1/50C1E...
  • Page 21: Plasma Display Panel Removal

    Before starting removal, be sure to remove the operation button assy from the bezel complete assy. Be very careful not to damage the flexible wires in the top, bottom, right and left. Place the removed panel on the conductive cushion. Plasma display panel Conductive cushion 1-13 PFM-50C1/50C1E...
  • Page 22: Common Pkg Board Removal

    (+PSW 3 x 8) (+PSW 3 x 8) 4 Common joint PKG (L) board 2 Common joint PKG (U) board CN11 CN12 6 Common PKG board CN104 Main chassis Conductive cushion CN7304 CN7303 Top side CN1 to CN4 CN7302 CN7301 1-14 PFM-50C1/50C1E...
  • Page 23: Digital Pkg Board Removal

    To remove the Digital PKG board, remove the P block assy beforehand. CN101 1 Screw (+PSW 3 x 8) 2 Five screws (+PSW 3 x 8) 3 Digital PKG board CN801 CN904 to CN906 CN751 Main chassis CN901 to CN903 Top side Conductive cushion 1-15 PFM-50C1/50C1E...
  • Page 24: Collection Joint Pkg Board Removal

    To remove the collection joint PKG board, remove the AC inlet block assy, B block assy, panel assy, P block and Digital PKG board beforehand. CN10 2 Collection joint PKG board 1 Five screws (+PSW 3 x 8) Main chassis Top side Conductive cushion 1-16 PFM-50C1/50C1E...
  • Page 25: Scan Pkg Board Removal

    To remove the scan PKG board, remove the DC fan (R) assy beforehand. 1 Ten screws CN12 (+PSW 3 x 8) CN11 2 Remove the scan PKG board in the direction of the arrow. CN105 CN10 Main chassis Top side Conductive cushion 1-17 PFM-50C1/50C1E...
  • Page 26: Scan Joint Pkg (a) And (b) Boards Removal

    Before starting removal, be sure to remove the operation button assy from the bezel complete assy. Be very careful not to damage the flexible wires in the top, bottom, right and left. Place the removed panel on the conductive cushion. 1-18 PFM-50C1/50C1E...
  • Page 27: Signal Joint Pkg (ru), (mu), (lu) Board Removal

    !- Remove the signal joint PKG (RU) board in the direction of the arrow C. 9 Signal joint PKG (MU) board 7 Remove the signal joint PKG (LU) board in the direction of the arrow B. Main chassis Top side Conductive cushion 1-19 PFM-50C1/50C1E...
  • Page 28: Signal Joint Pkg (rl), (ml), (ll) Board Removal

    !- Remove the signal joint PKG (RL) board in the direction of the arrow C. 7 Remove the signal joint PKG (LL) board in the direction of the arrow B. 9 Signal joint PKG (ML) board Top side Main chassis Conductive cushion 1-20 PFM-50C1/50C1E...
  • Page 29: Service Position

    2 Four screws (+PSW 6 x 20) 6 Insert the four knobs 4 Main chassis into the holes of the stand. 5 Two stands Main chassis Direction of the two suspensions. 7 The stand is attached inside the PDP panel. 1-21 PFM-50C1/50C1E...
  • Page 30: Service Position Of B Board

    1 Q/B shield cover !/ Insert the four knobs into the holes of the stand. 8 Main chassis 9 Two suspensions Main chassis Direction of installation of the two suspensions. !- The stand is attached outside the PDP panel. 1-22 PFM-50C1/50C1E...
  • Page 31: Packaging Of The Plasma Display Panel When It Is Shipped To Nec Corporation

    * The glass surface must face downward. 5 Lid 9 Cushion (upper, lower) 9 Cushion (upper, lower) 4 Plasma display panel unit 8 Individual packing carton 3 Packing metal 0 Cushion (left, right) 6 Eight screws 7 Carton (lower) 1-23 PFM-50C1/50C1E...
  • Page 32: Warning On Power Connection

    1-5. Warning on Power Connection Use the proper power cord for your local power supply. PFM-50C1/50C1E United States, Continental United Kingdom, Ireland, Japan Canada Europe Australia, New Zealand Plug type VM0233 COX-07 636 _ a) VM1296 Female end VM0089 COX-02 VM0310B...
  • Page 33: Electrical Adjustments

    The electrical adjustments can be performed using the remote White Balance When PDP is replaced. commander RM-971 supplied with the PFM-50C1/50C1E. The remote commander has the Service Mode. Select the Service Mode to perform the electrical adjustments as listed below.
  • Page 34 (various setup values of the user the factory except user adjustment value. (Adjustment menu”. data of 2-3. White Balance Adjustment) Because it initializes the serial number and accumula- tive operation hours, do not execute this command. PFM-50C1/50C1E...
  • Page 35 C Out Level Receive the NTSC signal and adjust color. The color adjustment of PAL and SECAM signals are performed upon completion of the NTSC signal adjustment, and use step c) Sub Color. Adjustment range is from 0 to 63. PFM-50C1/50C1E...
  • Page 36 Video” and “Sub Brt Video”, and from 0 to 63 for “Cb Offset Video” and “Cr Offset Video”. White Balance Adjustment Refer to section “2-3. White Balance Adjustment ”. AD Calibration Adjustment Refer to section “2-4. AD Calibration Adjustment”. PFM-50C1/50C1E...
  • Page 37 I/O Block Temp :It indicates the temperature that is measured by the temperature sensor attached on top of the Q block assy. Left Temp : It indicates the temperature that is measured by the temperature sensor attached near the fan (large). PFM-50C1/50C1E...
  • Page 38 PDP panel, and enter the Vs and Va values in the equations (1) and (3). Reset : You can return the Uvrs and Uvra to their default value. Change the menu item from [Cancel] to [OK] and press [ENTER]. PFM-50C1/50C1E...
  • Page 39 This mode is prepared for the case that the signal PROGRAM5 Editing specification is already known. You can make adjust- PROGRAM6 ment and edit data of all items but the modified data PROGRAM7 PROGRAM8 are not reflected to the actual picture images. PROGRAM9 PROGRAM10 PROGRAM11 PROGRAM12 PFM-50C1/50C1E...
  • Page 40 This setup value becomes the default value of the user menu “Total H Pixel”. You should set in a way that number of H. Total Pixels is equal or more than sum of (H. Active Pixel +H. Sync Pixel +H. BP Pixel). PFM-50C1/50C1E...
  • Page 41 It sets the picture quality mode. Select the desired below. mode from “Standard”, “Vivid”, “Use1”, “User2” or Wcp = Clamp Width/(Horizontal sync frequency x H. “User3”. Total Pixel) [seconds] This setting becomes the default value of the “Picture Mode” of user menu. PFM-50C1/50C1E...
  • Page 42 You can judge coincidence of the preset data with the input signal using the sync signal polarity of horizontal/vertical frequencies. If the same sync signal data exists within a preset area, the specification that has the smaller preset number has priority. 2-10 PFM-50C1/50C1E...
  • Page 43 P/S Temp : Temperature inside the power supply block is displayed. NO ACK DEV : Status whether the communication with the respective devices that are controlled by the C bus, is established or not, is displayed. 2-11 PFM-50C1/50C1E...
  • Page 44 3.3 V, analog system 6 V) error Power Off : Power-off sequence error e) Operation Time Accumulative operating hours are indicated. (In units of hour) f) Software Version Software version is indicated. g) PLD Version PLD version is indicated. 2-12 PFM-50C1/50C1E...
  • Page 45 Area 10 0x0A80 to 0x0A9F PROGRAM25 0x0540 to 0x055F 0x0AA0 to 0x0ABF PROGRAM26 0x0560 to 0x057F 0x0AC0 to 0x0ADF PROGRAM27 0x0580 to 0x059F 0x0AE0 to 0x0AFF PROGRAM28 0x05A0 to 0x05BF PROGRAM29 0x05C0 to 0x05DF PROGRAM30 0x05E0 to 0x05FF 2-13 PFM-50C1/50C1E...
  • Page 46 0x0FC0 to 0x0FDF 0x1540 to 0x155F 0x0FE0 to 0x0FFF 0x1560 to 0x157F Area 21 0x1000 to 0x101F Area 32 0x1580 to 0x159F 0x1020 to 0x103F 0x15A0 to 0x15BF 0x1040 to 0x105F 0x15C0 to 0x15DF 0x1060 to 0x107F 0x15E0 to 0x15FF 2-14 PFM-50C1/50C1E...
  • Page 47 0x1A40 to 0x1A5F 0x1FC0 to 0x1FDF 0x1A60 to 0x1A7F 0x1FE0 to 0x1FFF Area 10 0x1A80 to 0x1A9F 0x1AA0 to 0x1ABF 0x1AC0 to 0x1ADF 0x1AE0 to 0x1AFF Area 11 0x1B00 to 0x1B1F 0x1B20 to 0x1B3F 0x1B40 to 0x1B5F 0x1B60 to 0x1B7F 2-15 PFM-50C1/50C1E...
  • Page 48 1600 x 1200 Progressive 2160 1600 852 x 480 38 PFM 852x480@60 31.469 60 Progressive 33.74 1072 852 1024 x 1024 39 PFM 1024x1024@60 67.5 Progressive 85.05 1260 1024 40 PFM 1280x768@56 1280 x 768 Progressive 77.04 1712 1280 2-16 PFM-50C1/50C1E...
  • Page 49 MFID_IPC_MATRIX_293M NORMAL 1066 1024 3 STANDARD MFID_IPC_MATRIX_293M NORMAL 1066 1024 8 STANDARD MFID_IPC_MATRIX_293M NORMAL 1072 1024 3 STANDARD MFID_IPC_MATRIX_293M NORMAL 1250 1200 3 STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M FULL 1125 1024 5 STANDARD MFID_IPC_MATRIX_293M FULL STANDARD MFID_IPC_MATRIX_293M FULL 2-17 PFM-50C1/50C1E...
  • Page 50 720 x 483 15.625 50 Interlace 28.322 1000 750 113 105 67 SDTV PAL60 720 x 483 15.734 59.94 Interlace 28.322 132 54 OTHERS 640 x 480 31.469 59.94 Progressive 25.175 NO_SYNC 640 x 480 31.469 59.94 Progressive 25.175 2-18 PFM-50C1/50C1E...
  • Page 51 MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL STANDARD MFID_IPC_MATRIX_293M NORMAL 2-19 PFM-50C1/50C1E...
  • Page 52: White Balance Adjustment

    1) Connect the RGB signal VGA (640 x 480 /60) all white 90 IRE to INPUT1. 4) Set the video signal to the NTSC all gray 20 IRE. 5) Adjust [Sub Brt Video] until the G detection value becomes the setup value. (Setup value = 51 ± 3) 2-20 PFM-50C1/50C1E...
  • Page 53: Sub Color And Sub Hue Adjustments

    5. Repeat steps 3 and 4 until the detection values of R, G and B are within the range (± 5 %) of tolerance error. 6. Set [Cal Mode] of [AD Converter] of the Service Mode menu to [Off]. 2-21 PFM-50C1/50C1E...
  • Page 54: Watch Error Adjustment

    4. Connect the positive probe (+) of a digital VOM to TP2 (Vd). 5. Adjust RV601 (Vd ADJ) so that the VOM reading becomes the Vd value ± 0.5 V in the top right of the back of the panel. 2-22 PFM-50C1/50C1E...
  • Page 55: Troubleshooting

    CN9002 and CN9003 to the PDP If no images appears through the above conditions are panel. The three types of power voltage that are 5 V, satisfied, the PDP unit will be defective. 65 V and 170 V are supplied. PFM-50C1/50C1E...
  • Page 56: Self Diagnosis Function

    If the abnormal condition exceeds the allowable limit, it forcibly activates the shutdown operation and picture will not be displayed any more. At this time, the Standby indicator flashes to indicate that the PDP unit is in the error mode as shown in Section 3-1. PFM-50C1/50C1E...
  • Page 57 S board installed in the top of the Q block assembly, is dis- played. If temperature exceeds 71dC, the Standby indicator flashes at the interval of 0.4 seconds continuously. If temperature exceeds 76dC, the shutting-down is activated. PFM-50C1/50C1E...
  • Page 58 Bit 4 : 3D Combfilter power voltage and detecting abnormal Bit 5 : Chroma Decoder oscillation Bit 6 : PDP (No Use for PFM-50C1/E) Bit 7 : Tuner (No Use for PFM) Service Mode Bit 8 : Auto Wide Decoder...
  • Page 59 6 V) does not start up, the “NG” indication is displayed. If any one of these power supplies does not start up, the shutting-down operation is activated and this indication is stored in log after the PDP unit returns to the normal operation. PFM-50C1/50C1E...
  • Page 61: Semiconductors

    144pin QFP UPC358G2-E2 TOP VIEW UPC358G2-T2 CXA8038AP 120pin QFP MAX202CSE MAX202CSE-T IP00C713 MC74HC4052F SN74LV4053APWR PQ30RV21 TC74HC4052AF(EL) TOP VIEW 8pin SOP TOP VIEW BA05FP-E2 BA12FP-E2 256pin QFP TOP VIEW L88M05T-FA-TL 16pin SOP CXD2057M-T6 MB90098APF-A-130-BND- PST9229NL TEA6422DT TOP VIEW 28pin SOP PFM-50C1/50C1E...
  • Page 62 2SJ278MY UN2111-TX 2SJ278MYTR UN2211 UN2211-TX 5pin CHIP TOP VIEW TA78L018AP(TPE6) 100pin QFP XC18V02VQ44C 2SJ377(TE16L) 2SB1132-P 2SB1132-T100-QR TOP VIEW 44pin QFP Z8622912SSC-00TR TA78M09F (TE16L) TA78M09F(TE16L) 2SB1240TV2QR 2SD1862TV2QR TOP VIEW 2SK1590-T1B 2SK2158-T2B 18pin SOP TA8776N 2SK2370(2) TOP VIEW 2SK3235 30pin DIP PFM-50C1/50C1E...
  • Page 63 MA157-TX FRH10A15 MA3130WA-TX ANODE GATE DRAIN D25XB60 SOURCE DTA144EE DTA144EE-TL 1SS355TE-17 HN1D03FU-TE85L DTC144EE-TL DTZ10B HN1D03FU-TE85R HRU0103ATRF HZU3.3BTRF HZU30BTRF HZU6.2BTRF MA111-(K8).S0 MA111-TX MA113-(TX) 02CZ12-TE85L DAN202K MA113-TX DAN202K-T-146 RD3.3SB M1MA152WK-T1 RD3.3SB-T1 RD30SB-T1 RD5.6SB-T1 HZU6.8BTRF RD6.2SB HZU7.5BTRF RD6.2SB-T1 ANODE ANODE CATHODE CATHODE PFM-50C1/50C1E...
  • Page 64 Diode M1MA152WA-T1 UDZS-TE17-5.6B ANODE ANODE CATHODE CATHODE MA3075WA-(TX) MMDL914T1 ANODE CATHODE NSQ03A06-TE16L ANODE CATHODE SLR-325MCT31 ANODE CATHODE SLR-325VCT31 ANODE CATHODE PFM-50C1/50C1E...
  • Page 65: Spare Parts

    Ne les remplacer que par une pièce portant le numéro spécifié. 2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts common- ality and improvement. Parts List has the present standardized repair parts.
  • Page 66: Exploded Views

    Cover 5-2. Exploded Views +PSW 6x20 +PS 3x8 +PSW 4x8 +PS 3x8 +BVTP 4x16 +PS 3x8 +PSW 4x8 PFM-50C1 +BVTP 3x12 +PSW 4x8 +PSW 4x8 +PSW 3x8 PFM-50C1E +PS 3x8 +BVTP 3x10 +BVTP 4x16 +PSW 4x8 +PSW 3x8 +BVTP 2x5...
  • Page 67 7-682-648-09 s SCREW +PS 3X8 (EP-FE/ZNBK/CM2) 7-682-948-09 s SCREW +PSW 3X8 7-682-961-09 s SCREW +PSW 4X8 (EP-FE/ZNBK/CM2) 7-685-852-01 s SCREW +BVTP 2X5 (EP-FE/CU,NI,CR) 7-685-647-79 s SCREW +BVTP 3X10 (EP-FE/ZNBK/CM2) 7-685-648-79 s SCREW +BVTP 3X12 (EP-FE/ZNBK/CM2) 7-685-663-79 s SCREW +BVTP 4X16 (EP-FE/ZNBK/CM2) PFM-50C1/50C1E...
  • Page 68 +PS 3x8 +PSW 3x12 +PS 3x8 +PSW 4x8 +PSW 3x16 +BVTP 3x10 +PSW 3x16 +PSW 4x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 4x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x10 +PSW 3x10 +PS 3x8 +PS 2x6 Top side PFM-50C1/50C1E...
  • Page 69 7-628-253-20 s SCREW +PS 2X6 7-682-648-09 s SCREW +PS 3X8 (EP-FE/ZNBK/CM2) 7-682-948-09 s SCREW +PSW 3X8 7-682-950-09 s SCREW +PSW 3X12 (EP-FE/ZNBK/CM2) 7-682-952-01 s SCREW +PSW 3X16 (EP-FE/ZNBK/CM2) 7-682-961-09 s SCREW +PSW 4X8 (EP-FE/ZNBK/CM2) 7-685-647-79 s SCREW +BVTP 3X10 (EP-FE/ZNBK/CM2) PFM-50C1/50C1E...
  • Page 70 +PSW 4x8 +PSW 4x16 +PSW 4x16 +BVTP 3x10 +PSW 4x16 +PS 3x8 +BVTP 3x10 +BVTP 3x10 +PSW 3x16 +PSW 3x16 +PSW 4x16 +BVTP 3x10 +BVTP 3x10 +PSW 3x16 +PSW 3x16 +PSW 4x16 +BVTP 3x10 +PSW 3x16 +PSW 4x16 Top side PFM-50C1/50C1E...
  • Page 71 4-089-617-01 o PLATE, POSITIONING 8-330-030-56 s MOUNTED CIRCUIT BOARD S Screws/Washers 7-682-648-09 s SCREW +PS 3X8 (EP-FE/ZNBK/CM2) 7-682-952-01 s SCREW +PSW 3X16 (EP-FE/ZNBK/CM2) 7-682-961-09 s SCREW +PSW 4X8 (EP-FE/ZNBK/CM2) 7-685-647-79 s SCREW +BVTP 3X10 (EP-FE/ZNBK/CM2) 7-685-663-79 s SCREW +BVTP 4X16 (EP-FE/ZNBK/CM2) PFM-50C1/50C1E...
  • Page 72: Plasma Display

    Plasma Display +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 +PSW 3x8 Top side PFM-50C1/50C1E...
  • Page 73 9-885-023-04 o SIGNAL JOINT PKG (ML) 9-885-023-05 o SIGNAL JOINT PKG (RU) 9-885-023-06 o SIGNAL JOINT PKG (RL) 9-885-023-07 o COLLECTION JOINT PKG 9-885-023-08 o SCAN JOINT PKG (A) 9-885-023-09 o SCAN JOINT PKG (B) Screws/Washers 7-682-948-09 s SCREW +PSW 3X8 PFM-50C1/50C1E...
  • Page 74 Packing 5-10 PFM-50C1/50C1E...
  • Page 75 4-088-237-01 o CUSHION (MIDDLE) 4-088-238-01 o CUSHION (LOWER) 4-089-578-01 o MANUAL, INSTRUCTION (JAPANESE, ENGLISH, FRENCH, SPANISH, GERMAN, ITALIAN, SIMPLIFIED CHINESE) 4-089-597-01 o HOLDER, CABLE 4-089-688-01 s BAG, PROTECTION 4-978-977-01 s LID, BATTERY CASE See Page 1-24. Warning on Power Connection 5-11 PFM-50C1/50C1E...
  • Page 76 FLAT PANEL DISPLAY STAND +PSW 5x14 +PSW 5x14 Part No. SP Description 4-087-329-01 s BRACKET, HOOK 4-087-524-01 o CLAMPER, CORD Screws/Washers 7-682-973-39 s SCREW +PSW 5X14 5-12 PFM-50C1/50C1E...
  • Page 77: Electrical Parts List

    1-163-009-11 s CAPACITOR,CERAMIC 1000PF/50V C187 1-163-009-11 s CAPACITOR,CERAMIC 1000PF/50V C308 1-163-005-11 s CAPACITOR CHIP CERAMIC 470PF C201 1-163-021-91 s CAPACITOR, CERAMIC 0.01MF/50V C309 1-163-009-11 s CAPACITOR,CERAMIC 1000PF/50V C202 1-137-991-21 s CAPACITOR,ELECT 3900MF C310 1-163-037-11 s CAPACITOR,CHIP CERAMIC 0.022MF 5-13 PFM-50C1/50C1E...
  • Page 78 1-163-021-91 s CAPACITOR, CERAMIC 0.01MF/50V D125 8-719-914-43 s DIODE DAN202K C606 1-164-645-11 s CAPACITOR,CERAMIC 1000PF/500V D126 8-719-988-61 s DIODE 1SS355TE-17 C607 1-163-037-11 s CAPACITOR,CHIP CERAMIC 0.022MF D151 8-719-988-61 s DIODE 1SS355TE-17 C608 1-163-021-91 s CAPACITOR, CERAMIC 0.01MF/50V D152 8-719-988-61 s DIODE 1SS355TE-17 5-14 PFM-50C1/50C1E...
  • Page 79 D502 8-719-988-61 s DIODE 1SS355TE-17 PH110 8-749-924-80 o PHOTO COUPLER PS2561L1-1-V D601 8-719-060-28 s DIODE HZU7.5BTRF PH111 8-749-924-80 o PHOTO COUPLER PS2561L1-1-V D602 8-719-079-01 s DIODE FRH10A15 PH901 8-749-924-80 o PHOTO COUPLER PS2561L1-1-V D603 8-719-060-28 s DIODE HZU7.5BTRF 5-15 PFM-50C1/50C1E...
  • Page 80 8-729-045-62 s TRANSISTOR 2SK2158-T2B R144 1-216-081-00 s RESISTOR,CHIP 22K 1/10W(2012) Q405 8-729-421-22 s TRANSISTOR UN2211 R145 1-216-073-00 s RESISTOR,CHIP 10K 1/10W(2012) Q406 8-729-045-62 s TRANSISTOR 2SK2158-T2B R147 1-216-001-00 s RESISTOR, CHIP 10 1/10W(2012) Q407 8-729-421-22 s TRANSISTOR UN2211 5-16 PFM-50C1/50C1E...
  • Page 81 1-216-057-00 s RESISTOR CHIP 2.2K 1/10W(2012) R286 1-216-049-11 s RESISTOR, CHIP 1K 1/10W(2012) R226 1-216-079-00 s RESISTOR CHIP 18K 1/10W(2012) R287 1-216-073-00 s RESISTOR,CHIP 10K 1/10W(2012) R227 1-216-061-00 s RESISTOR CHIP 3.3K 1/10W(2012) R288 1-216-065-91 s RESISTOR,CHIP 4.7K 1/10W(2012) 5-17 PFM-50C1/50C1E...
  • Page 82 1-216-081-00 s RESISTOR,CHIP 22K 1/10W(2012) R350 1-216-065-91 s RESISTOR,CHIP 4.7K 1/10W(2012) R438 1-216-065-91 s RESISTOR,CHIP 4.7K 1/10W(2012) R351 1-216-105-91 s RESISTOR,CHIP 220K 1/10W(2125) R439 1-216-086-00 s RESISTOR,CHIP 36K 1/10W(2012) R352 1-216-049-11 s RESISTOR, CHIP 1K 1/10W(2012) R440 1-216-065-91 s RESISTOR,CHIP 4.7K 1/10W(2012) 5-18 PFM-50C1/50C1E...
  • Page 83 1-240-560-21 s RES, PRECISION 39K (2012) 1-537-864-11 o PIN, POST R623 1-208-794-11 s RESISTOR,CHIP 3.3K 1/10W(2012) 1-537-864-11 o PIN, POST R624 1-216-667-11 s RESISTOR,CHIP 4.7K 1/10W(2012) R625 1-216-073-00 s RESISTOR,CHIP 10K 1/10W(2012) VDR101 1-801-071-11 s VARISTOR VDR105 1-801-071-11 s VARISTOR 5-19 PFM-50C1/50C1E...
  • Page 84 1-164-315-11 s CAPACITOR,CERAMIC 470PF/50V CH C233 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 1-163-233-91 s CAPACITOR,CHIP CERAMIC 18PF/50 C234 1-109-982-11 s CAPACITOR,CHIP CERAMIC 1MF/10V 1-126-394-11 s CAPACITOR,ELECT 10MF/16V(CHIP) C235 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C236 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 5-20 PFM-50C1/50C1E...
  • Page 85 1-128-304-11 s CAPACITOR, CHIP ELECT 330MF C422 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C617 1-128-304-11 s CAPACITOR, CHIP ELECT 330MF C423 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C618 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C424 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C619 1-126-392-11 s CAPACITOR,CHIP ELECT100MF/6.3V 5-21 PFM-50C1/50C1E...
  • Page 86 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C848 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C1241 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C849 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C7022 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C850 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C7027 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF 5-22 PFM-50C1/50C1E...
  • Page 87 1-779-339-21 s CONNECTOR, FFC/FPC 30P IC601 8-759-837-36 s IC CXD9606Q IC603 8-759-676-70 s IC MSM56V16160F-10TS-K CN1002 1-764-080-21 s PIN, CONNECTOR (PC BOARD) 8P IC604 8-759-549-00 s IC SN74LV123APWR CN1003 1-764-078-11 s PIN, CONNECTOR (PC BOARD) 3P IC801 6-700-681-01 s IC IP00C713 5-23 PFM-50C1/50C1E...
  • Page 88 8-729-216-22 s TRANSISTOR 2SA1162-G 1-216-809-11 s RESISTOR,CHIP 100 1/10W 1608 8-729-928-19 s TRANSISTOR 2SA1774R 1-216-805-11 s RESISTOR,CHIP 47 1/10W 1608 1-216-809-11 s RESISTOR,CHIP 100 1/10W 1608 8-729-928-19 s TRANSISTOR 2SA1774R 1-216-864-11 s CONDUCTOR, CHIP (1608) 8-729-927-99 s TRANSISTOR 2SC4617R 5-24 PFM-50C1/50C1E...
  • Page 89 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R217 1-216-824-11 s RESISTOR, CHIP 1.8K 1/10W 1608 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R218 1-216-824-11 s RESISTOR, CHIP 1.8K 1/10W 1608 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R219 1-216-824-11 s RESISTOR, CHIP 1.8K 1/10W 1608 5-25 PFM-50C1/50C1E...
  • Page 90 1-216-823-11 s RESISTOR, CHIP 1.5K 1/10W R612 1-216-801-11 s RESISTOR,CHIP 22 1/10W (1608) R401 1-216-827-11 s RESISTOR, CHIP 3.3K 1/10W 1608 R613 1-216-801-11 s RESISTOR,CHIP 22 1/10W (1608) R402 1-216-864-11 s CONDUCTOR, CHIP (1608) R614 1-216-801-11 s RESISTOR,CHIP 22 1/10W (1608) 5-26 PFM-50C1/50C1E...
  • Page 91 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R7276 1-216-864-11 s CONDUCTOR, CHIP (1608) R1035 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R7278 1-216-864-11 s CONDUCTOR, CHIP (1608) R1041 1-216-805-11 s RESISTOR,CHIP 47 1/10W 1608 R7279 1-216-864-11 s CONDUCTOR, CHIP (1608) 5-27 PFM-50C1/50C1E...
  • Page 92 1-234-371-11 s RES, NETWORK 47X4 (1005) RB1009 1-234-371-11 s RES, NETWORK 47X4 (1005) RB1010 1-234-371-11 s RES, NETWORK 47X4 (1005) RB1011 1-234-371-11 s RES, NETWORK 47X4 (1005) RB1012 1-234-371-11 s RES, NETWORK 47X4 (1005) RB1013 1-234-371-11 s RES, NETWORK 47X4 (1005) 5-28 PFM-50C1/50C1E...
  • Page 93 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C3062 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C3063 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C3064 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C3065 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C3066 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C3067 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B 5-29 PFM-50C1/50C1E...
  • Page 94 1-127-573-11 s CAPACITOR,CERAMIC 1MFB(2012) C3197 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C3130 1-124-779-00 s CAPACITOR,ELECT 10MF/16V C3198 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C3131 1-124-779-00 s CAPACITOR,ELECT 10MF/16V C3199 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C3132 1-124-779-00 s CAPACITOR,ELECT 10MF/16V C3200 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 5-30 PFM-50C1/50C1E...
  • Page 95 8-719-083-60 s DIODE UDZSTE-174.7B IC3020 8-759-327-60 s IC TC7W125FU-TE12R D3022 8-719-083-60 s DIODE UDZSTE-174.7B IC3022 8-759-351-01 s IC TEA6422DT D3023 8-719-921-40 s DIODE MTZJ4.7C IC3023 8-759-673-52 s IC MM74HC32MTCX D3024 8-719-921-40 s DIODE MTZJ4.7C D3025 8-719-083-60 s DIODE UDZSTE-174.7B 5-31 PFM-50C1/50C1E...
  • Page 96 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 R3093 1-218-869-11 s RESISTOR,CHIP 8.2K 1/10W(1608) R3024 1-216-805-11 s RESISTOR,CHIP 47 1/16W 1608 R3094 1-218-839-11 s RESISTOR,CHIP 470 1/10W (1608) R3025 1-216-813-11 s RESISTOR, CHIP 220 1/16W 1608 R3095 1-218-825-11 s RESISTOR,CHIP 120 1/10W (1608) 5-32 PFM-50C1/50C1E...
  • Page 97 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R3162 1-216-809-11 s RESISTOR,CHIP 100 1/16W 1608 R3163 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) R3164 1-218-668-11 s RESISTOR,CHIP 100 1/16W (1608) R3168 1-216-825-11 s RESISTOR,CHIP 2.2K 1/16W 1608 R3169 1-216-825-11 s RESISTOR,CHIP 2.2K 1/16W 1608 5-33 PFM-50C1/50C1E...
  • Page 98 1-247-843-11 s RESISTOR CARBON (SMALL) 3.3K R9517 1-249-411-11 s RES,CARBON 330 1/4W SMALL R9518 1-249-437-11 s RESISTOR,CARBON 47K 1/4W SMALL R9519 1-249-437-11 s RESISTOR,CARBON 47K 1/4W SMALL R9520 1-247-843-11 s RESISTOR CARBON (SMALL) 3.3K R9521 1-249-411-11 s RES,CARBON 330 1/4W SMALL 5-34 PFM-50C1/50C1E...
  • Page 99: Block Diagrams

    Q3028 J3006 IC3009 SIRCS V IN (OUT) D5V-2 MUTE CONT MUTE LINE MUTE V AMP Q3015,3027 Q3014 Q403 A5V-3 BUFF SIRCS OUT SIRCS Q3030 Q3029 SYNC SW Q406 IC3016 SIRCS IN SIRCS 1 A12V Q3032 SOG DUTY1 SOG DUTY2 PFM-50C1/50C1E...
  • Page 100 CS SC SC PLL IC7101 A5V-4 PROGRAM ROM SRX 4W IC401 IC402 STX 4W 3.3V 3.3V SCK 4W CCLK CS OSD DONE INITX CS PLD SDATA V MUTE SDATA PSCK PSCK IC7003 SYS HS SYS VS D3.3V-2 ALARM ALARM PFM-50C1/50C1E...
  • Page 101: B (3/3), Q (2/2), H1, H2, S

    BUFF D3.3V-2 VOL+ Q203 Q204 IC204 BUFF IC202 BUFF BUFF FSCI FSCO Q215,218 Q201 Q202 CN101 IC1016 IC1016 FSCI POWER POWER POWER SUPPLY THERMO TEMP Q214 BUFF BUFF Q216 Q213 IC207 SYNC IC1017 STBY 3.3V STBY COMF SW 3.3V PFM-50C1/50C1E...
  • Page 102: 1/2)

    PH104 13.5V REG D117 RV102 84kHz ADJ RV201 13V ADJ IC207 PH107 D215 13.5V REG ON/OFF ON/OFF Q206 D226 D218 IC207 D216 PH106 Q205 IC205 D203 D109 SHUNT IC207 D212 D213 D217 D217 D208 Q202 APS-184 (1/2) (SWITCHING REG) PFM-50C1/50C1E...
  • Page 103: 2/2)

    T702 IC402 SHUNT D701 SWITCHING Q703 OUT1 T502 D602 D702 OUT2 SWITCHING Q704 IC601 PH950 VA REG D950 D604 IC601 RV950 76kHz ADJ RV601 VA ADJ PH951 ON/OFF D603 ON/OFF Q602 APS-184 (2/2) IC602 D601 SHUNT (SWITCHING REG) Q601 PFM-50C1/50C1E...
  • Page 105: Diagrams

    : NONFLAMMABLE METAL OXIDE : NONFLAMMABLE CEMENT : NONFLAMMABLE WIREWOUND : ADJUSTMENT RESISTOR COIL LF-8L : MICRO INDUCTOR CAPACITOR : TANTALUM : STYROL : POLYPROPYLENE : MYLAR : METALIZED POLYESTER : METALIZED POLYPROPYLENE : BIPOLAR : HIGH TEMPERATURE : HIGH RIPPLE PFM-50C1/50C1E...
  • Page 106: Frame Schematic Diagrams

    CN3002 CN3012 CN3005 CN3011 LED_R LED_R :ELCO CN3003 :DF13 :DF13 L-TYPE :FFC :EH WHT-L LED_G LED_G L-SP(+) L-SP(+) CN3007 :DF13 CN3009 :DF13 CN3008 P ON P ON L-SP(-) L-SP(-) :DF13 :OP_BOARD SIRCS SIRCS :ELCO R-SP(-) R-SP(-) R-SP(+) R-SP(+) B-SS11075-WW-FRAME PFM-50C1/50C1E...
  • Page 107: Schematic Diagrams And Printed Wiring Boards

    CN9502 SUFFIX: -11 D9505 R9505 MTZJ-T-77-10B C9508 0.01 PROTECT R9519 R9520 3.3k D9501 MTZJ-T-77-10B C9501 PROTECT DMP_CLK AUDIO IN R9502 DMP_RX DMP_TX J9501 OP_CS R9503 C9502 D9502 STBY5V MTZJ-T-77-10B PROTECT C9509 13.5V (INPUT BUFFER) B-SS11075-WW-QA -B SIDE- SUFFIX: -11 PFM-50C1/50C1E...
  • Page 108 75 Z A OUT OUTPUT3 DRIVER B OUT – A IN– + INPUT1 + – A IN+ B IN– SELECT A 75 Z B IN+ _ INPUT1 OUTPUT2 SELECT B DRIVER 75 Z OUTPUT1 _ INPUT2 DRIVER + INPUT2 PFM-50C1/50C1E...
  • Page 109 OUT(V) STBY 5V-2 R3004 IN2(H) 1/10W :CHIP (P2) SIRCS2 SIRCS Q3001 IN2(V) STBY 5V-2 DTC144EE STBY R3014 INV. 5V-2 1/10W :CHIP STBY5V D3001 MA157-TX 8 7 6 5 PROTECT IC3002 BR24C21F EEPROM (1/3) R/G/B (VIDEO SW) (P3) RGB3 B-SS11075-WW-Q-P1 PFM-50C1/50C1E...
  • Page 110 R3135 B:CHIP 100k 100k (P3) AUDIO_R 1/10W 1/10W +12V :CHIP :CHIP R3103 3.3k 1/10W :CHIP C3154 C3164 B:CHIP B:CHIP R3104 C3142 5.6k 1/10W AUDIO :CHIP F:CHIP C3140 -12V C3109 1000p CH:CHIP C3147 C3152 1000 B:CHIP (2/3) (AUDIO PROCESS) B-SS11075-WW-Q-P2 PFM-50C1/50C1E...
  • Page 111 TEM P1 TO B BOARD TEM P2 CN1005 TEM P3 CN3012 STBY 5V TO S BOARD TEM P1 CN1501 STBY 5V TO S BOARD TEM P2 CN1501 STBY 5V TO S BOARD TEM P3 CN1501 (3/3) (RS-232C INTERFACE) B-SS11075-WW-Q-P3 PFM-50C1/50C1E...
  • Page 112 C3184 C3181 IC3001 IC3002 C3182 R3160 R3159 D3054 D3035 D3036 D3037 D3038 D3056 Q3024 Q3025 D3055 R3158 R3157 C3205 D3053 D3052 D3062 Q3030 R3195 R3197 R3193 Q3029 D3061 J3007 J3003 J3004 J3006 J3005 J3002 J3001 -A SIDE- SUFFIX: -14 PFM-50C1/50C1E...
  • Page 113 J L 3 0 0 1 J L 3 0 0 2 J L 3 0 0 4 J L 3 0 0 5 J L 3 0 1 8 J L 3 0 3 7 -B SIDE- SUFFIX: -14 PFM-50C1/50C1E...
  • Page 114 * B-1 TP614 * B-3 TP615 TP801 * B-2 TP802 TP803 TP804 * B-2 TP805 * B-2 * B-2 * B-2 * C-2 * C-2 * C-2 * C-2 * B-2 * C-2 * C-2 * C-2 7-10 7-10 PFM-50C1/50C1E...
  • Page 115 R 7 0 8 5 R 7 2 7 6 R 7 0 8 4 R 7 2 7 7 C 2 1 4 C 2 0 5 L 2 0 2 C 2 7 2 -B SIDE- SUFFIX: -11 7-11 7-11 PFM-50C1/50C1E...
  • Page 116 TU_RES RESET JL20 JL31 DIG3.3V 0.47 JL32 B:CHIP TO SWITCHING JL21 JL33 A13V REGULATOR 5V-2 CN9005 DIG5V DIG5V JL22 BA05FP 5V-3 5V REG AN6V AN6V JL24 A13V 6.3V :AL-CP :AL-CP B:CHIP :AL-CP (1/8) (COLOR DECODER,AUTO WIDE) B-SS111075-WW-B-P1 7-12 7-12 PFM-50C1/50C1E...
  • Page 117 B:CHIP :CHIP :RN-CP IC204 B:CHIP TC7S04F RB206 RB205 RB204 SCL_LS 1kx4 1kx4 1kx4 IC207 (P1,5) SDA_LS LM1881MX SYNC SEP Input : Y/C (2/8) R215 C259 R280 :CHIP (COMB FILTER) 1/10W 2.5 Vp-p (3.58 MHz) B:CHIP :CHIP B-SS111075-WW-B-P2 7-13 7-13 PFM-50C1/50C1E...
  • Page 118 V AMP 1/16W :RN-CP :RN-CP C451 C456 IC404 C448 M52347FP 0.01 C459 SYNC SEP B:CHIP B:CHIP 100p B:CHIP CH:CHIP C454 C455 D403 DAN202K B:CHIP :AL-CP R434 R415 C446 (3/8) 1/16W 1/10W :RN-CP :CHIP B:CHIP (A/D CONVERTER) B-SS111075-WW-B-P3 7-14 7-14 PFM-50C1/50C1E...
  • Page 119 MD42 MD42 C806 C832 MA10 MA10 A10/AP A10/AP B:CHIP B:CHIP +3.3V (P5,6) SRX_4W C811 C809 C813 C815 C817 C819 C821 C823 C836 C848 B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP B:CHIP (4/8) (SCAN CONVERTER) B-SS111075-WW-B-P4 7-15 7-15 PFM-50C1/50C1E...
  • Page 120 :1608 JL88 F_MODE B:CHIP FLASH MODE POWER (P1) R1006 R1002 (P6) CS_PLD 4 3 2 1 JL89 :CHIP :CHIP (P4) CS_SC R1032 R1033 (P6) VMUTE IC1016 100K 100K STBY TC7W14FU C1036 B:CHIP (5/8) CN1006 (MAIN CPU) B-SS111075-WW-B-P5 7-16 7-16 PFM-50C1/50C1E...
  • Page 121 :1608 CLKIN-3 (P7) CLKIN-2 C7247 R7287 +3.3V R7279 6.3V :1608 :AL-CP :1608 C7211 C7215 C7212 C7214 C7213 C7210 R7288 :1608 B:1608 B:1608 B:1608 B:1608 B:1608 B:1608 (6/8) (P7) R/G/B (P8) R7296 (P7) (DISPLAY PORT/PANEL INTERFACE) :CHIP B-SS111075-WW-B-P6 7-17 7-17 PFM-50C1/50C1E...
  • Page 122 :1608 JL7206 B0(LSB) C7084 B:1608 VCC/CLKSEL CLK- JL7207 CLK+ CN7023 C7087 B:1608 R/G/B B7(MSB) (P6) PDWNL PDWNL CLKIN C7085 B:1608 R7083 R7081 R7084 R7082 :1608 :1608 :CHIP :1608 (P6) CLKIN-2 CONTL (P6) (7/8) (OSD CONT,LVDS TRANSMITTER) B-SS111075-WW-B-P7 7-18 7-18 PFM-50C1/50C1E...
  • Page 123 3.2 Vp-p (H) RGB_STC (P4) IPHS TP613 PIHS Input : Y/C IPVS TP614 R629 1/10W :CHIP (P4) 3.2 Vp-p (V) PIVS IPCLK TP615 R630 1/10W :CHIP PICLK (8/8) R611 1/10W :CHIP 5.0 Vp-p (15.15 MHz) (SYSTEM IC,I/P TRANS) B-SS111075-WW-B-P8 7-19 7-19 PFM-50C1/50C1E...
  • Page 124 V C/D CHROMA SEPA INTEC SEPA CHROMA AFC-FIL CVBS/YC SYNC-GND TRAP NOISE H. STATE V. STATE CLAMP GREEN COMP/H COMP/H V IN V DET V TIME GATE SELECT H C/D H VCO C1-IN (RGB1-IN) FC BUS CONTROL 7-20 7-20 PFM-50C1/50C1E...
  • Page 125 DVcc mode B (1/8), (2/8) TC4W53FU (IC3, IC208, IC209) B (5/8) SN74CBTD3306 (IC1019) CLOUT CLKBUF PAL N/M 10E 1 8 VCC PAL/NTSC CLOCK 1A 2 IBIPAS 1B 3 Comb/BPF 7 2OE GND 4 6 2B 5 2A 7-21 7-21 PFM-50C1/50C1E...
  • Page 126 OUTPUT I DRIVE LOGIC CONTROL & MUX LINE & B (5/8) TC74VHCT14AFT (IC1012) FIELD SFLD CONTROL B (5/8) TC7W14FU (IC1016) LINE & FID DECODES 17 3 2 18 VSS (A) RREF B (1/8), (5/8) TC7W241FU-TE12R (IC1, IC1009) 7-22 7-22 PFM-50C1/50C1E...
  • Page 127 4.7k S8551 1/10W POWER :CHIP S8654 ENTER R8655 2.7k 1/10W :CHIP S8655 IC8551 GPLUM-26SXK VOL- R8555 REMOCON RECEIVER R8656 :CHIP 1.8k 1/10W :CHIP S8656 C8551 D8552 D8555 VOL+ UDZSTE175.6B UDZSTE175.6B B:CHIP PROTECT PROTECT (POWER SW/LED) B-SS11075-WW-H1 B-SS11075-WW-H2 7-23 7-23 PFM-50C1/50C1E...
  • Page 128 L_SP(-) :CHIP SP902 R9004 :CHIP FERRITE (SPEAKER L) L_SP(+) C1501 R1501 C1503 TO Q BOARD 6.3V :RN-CP 0.01 AL-CP B:CHIP CN3008 R1503 C1502 6.8k R1502 0.01 :RN-CP 2.2k B:CHIP :RN-CP IC1502(2/2) µPC358G2-T2 (SPEAKER) (TEMP SENSOR) B-SS11065-WW-SP B-SS11075-WW-S 7-24 7-24 PFM-50C1/50C1E...
  • Page 129 * I-8 Q113 RV950 D307 * H-8 Q116 * H-8 D308 Q153 * H-8 D310 Q154 D401 Q202 * C-3 D402 * H-4 Q203 * A-3 D403 * H-4 Q204 * D-3 D404 * H-4 Q205 * B-3 7-25 7-25 PFM-50C1/50C1E...
  • Page 130: Aps-184

    APS-184 APS-184 APS-184 -A SIDE- SUFFIX: -11 7-26 7-26 PFM-50C1/50C1E...
  • Page 131 APS-184 APS-184 APS-184 -B SIDE- SUFFIX: -11 7-27 7-27 PFM-50C1/50C1E...
  • Page 132: Aps-184 (1/4)

    C314 C318 R345 C315 C316 C328 R302 D301 C301 R309 C302 R319 C303 MUN2211 RV301 330pF 0.47 HZU7.5B 1000p 4.7k 0.01 0.01 2.2k 1000p 0.047 1500p 0.47 BUFF D302 D303 C308 APS-184 HRU0103A HRU0103A 470p (1/4)(SWITCHING REGULATOR) 7-28 7-28 PFM-50C1/50C1E...
  • Page 133: Aps-184 (2/4)

    (3/4) C161 R163 C162 C163 C165 C166 C167 C168 C169 1000p 1000p RV150 0.22 330p 4700p 0.022 0.01 (3/4) (1/4) 60kHz APS-184 (2/4)(SWITCHING REGULATOR) 7-29 7-29 PFM-50C1/50C1E HZU30BD 4 1 D 4 70 0 R C 1 M SB709 10kR...
  • Page 134: Aps-184 (3/4)

    D208 C217 IC205 4.7k RV102 C201 R215 1000p 1000p 1000p 0.01 0.022 330p 0.022 R224 C210 MMDL914T 0.01 HA17431UA 0.01 2.2k 0.01 (1/4) (2/4) 84kHz (2/4) (2/4) (4/4) Q202 Q205 Q206 2SK2158 APS-184 MSD601 2SK2158 (3/4)(SWITCHING REGULATOR) 7-30 7-30 PFM-50C1/50C1E...
  • Page 135: Aps-184 (4/4)

    C955 R956 C956 C957 1.8k 0.022 330p 4700p 0.01 IC602 1000p 1000p 1000p 0.01 0.22 RV950 2SK2158 C601 C614 HA17431UA 0.022 C602 R602 RV601 2.2k SHUNT REG. 0.01 R603 C603 0.01 8.2k (1/4) (1/4) APS-184 (4/4)(SWITCHING REGULATOR) 7-31 7-31 PFM-50C1/50C1E...
  • Page 137 2 V AC range are suitable. (See Fig. A) To Exposed Metal Parts on Set 0.15 µ F 1.5 k Z voltmeter (0.75V) Earth Ground Fig A. Using an AC voltmeter to check AC leakage. PFM-50C1/50C1E...
  • Page 138 English 02FS16-1 Sony Corporation Printed in Japan B&P Company 9-870-335-01 ©2002.6...

This manual is also suitable for:

Pfm-50c1e

Comments to this Manuals

Symbols: 0
Latest comments:
