Service
Manual
Inverter Pair
Ceiling Mounted Cassette Type
FFQ-Q Series
[Applied Models]
Inverter Pair : Heat Pump
SiUS091628EA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FFQ09Q2VJUFFQ12Q2VJUFFQ15Q2VJUFFQ18Q2VJURX09QMVJURX12QMVJURX15QMVJURX18QMVJU and is the answer not in the manual?

Questions and answers

Related Manuals for Daikin FFQ09Q2VJUFFQ12Q2VJUFFQ15Q2VJUFFQ18Q2VJURX09QMVJURX12QMVJURX15QMVJURX18QMVJU

Summary of Contents for Daikin FFQ09Q2VJUFFQ12Q2VJUFFQ15Q2VJUFFQ18Q2VJURX09QMVJURX12QMVJURX15QMVJURX18QMVJU

  • Page 1 SiUS091628EA Service Manual Inverter Pair Ceiling Mounted Cassette Type FFQ-Q Series [Applied Models] Inverter Pair : Heat Pump...
  • Page 2 SiUS091628EA Inverter Pair Ceiling Mounted Cassette Type FFQ-Q Series Heat Pump Indoor Unit FFQ09Q2VJU FFQ12Q2VJU FFQ15Q2VJU FFQ18Q2VJU Outdoor Unit RX09QMVJU RX12QMVJU RX15QMVJU RX18QMVJU Table of Contents...

  • Page 3: Table Of Contents

    SiUS091628EA 1. Safety Cautions................... v 1.1 Warnings and Cautions Regarding Safety of Workers......... v 1.2 Warnings and Cautions Regarding Safety of Users........vii 2. Icons Used ....................x Part 1 List of Functions ..............1 1. Functions..................... 2 Part 2 Specifications ............... 3 1.
  • Page 4 SiUS091628EA 2.5 Input Current Control.................. 36 2.6 Freeze-up Protection Control ..............37 2.7 Heating Peak-cut Control ................37 2.8 Outdoor Fan Control................... 38 2.9 Liquid Compression Protection Function............ 38 2.10 Defrost Control ................... 39 2.11 Electronic Expansion Valve Control ............40 2.12 Malfunctions ....................
  • Page 5 SiUS091628EA 4.22 System Shutdown due to Compressor Internal Temperature Abnormality ....................90 4.23 Compressor System Sensor Abnormality ..........91 4.24 Position Sensor Abnormality ..............92 4.25 Thermistor or Related Abnormality (Outdoor Unit)........94 4.26 Electrical Box Temperature Rise..............96 4.27 Radiation Fin Temperature Rise ..............97 4.28 Output Overcurrent Detection ..............

  • Page 6: Safety Cautions

    Safety Cautions SiUS091628EA 1. Safety Cautions Be sure to read the following safety cautions before conducting repair work. After the repair work is complete, be sure to conduct a test operation to ensure that the equipment operates normally, and explain the cautions for operating the product to the customer. Caution Items The caution items are classified into Warning and...
  • Page 7 SiUS091628EA Safety Cautions Warning Do not turn the air conditioner on or off by plugging in or unplugging the power cable. Plugging in or unplugging the power cable to operate the equipment may cause an electrical shock or fire. Be sure to wear a safety helmet, gloves, and a safety belt when working in a high place (more than 2 m (6.5 ft)).

  • Page 8: Warnings And Cautions Regarding Safety Of Users

    Safety Cautions SiUS091628EA Caution Be sure to check that the refrigerating cycle section has cooled down enough before conducting repair work. Working on the unit when the refrigerating cycle section is hot may cause burns. Conduct welding work in a well-ventilated place. Using a welder in an enclosed room may cause oxygen deficiency.
  • Page 9 SiUS091628EA Safety Cautions Warning When wiring between the indoor and outdoor units, make sure that the terminal cover does not lift off or dismount because of the cable. If the cover is not mounted properly, the terminal connection section may cause an electrical shock, excessive heat generation or fire.
  • Page 10 Safety Cautions SiUS091628EA Caution Installation of a leakage breaker is necessary in some cases depending on the conditions of the installation site, to prevent electrical shocks. Do not install the equipment in a place where there is a possibility of combustible gas leaks.

  • Page 11: Icons Used

    SiUS091628EA Icons Used 2. Icons Used The following icons are used to attract the attention of the reader to specific information. Icon Type of Description Information Warning A Warning is used when there is danger of personal injury. Warning Caution A Caution is used when there is danger that the reader, through incorrect manipulation, may damage equipment, lose data, get Caution...

  • Page 12: Part 1 List Of Functions

    SiUS091628EA Part 1 List of Functions 1. Functions..................... 2 List of Functions...

  • Page 13: Functions

    SiUS091628EA Functions 1. Functions Category Functions Category Functions Basic Inverter (with inverter power control) Health & Auto cleaning filter — — Functions Cleanliness Operation limit for cooling Air-purifying filter — — Refer to P. 133 Operation limit for heating Titanium apatite deodorizing filter —...

  • Page 14: Part 2 Specifications

    SiUS091628EA Part 2 Specifications 1. Specifications ....................4 Specifications...

  • Page 15: Specifications

    SiUS091628EA Specifications 1. Specifications 60 Hz, 208 - 230V Indoor Unit FFQ09Q2VJU FFQ12Q2VJU Model RX09QMVJU RX12QMVJU Outdoor Unit Cooling Heating Cooling Heating Capacity Btu/h 9,100 (4,600 ~ 11,000) 10,000 (4,600 ~ 14,000) 10,800 (4,600 ~ 13,300) 13,500 (4,600 ~ 16,800) Rated (Min.
  • Page 16 Specifications SiUS091628EA 60 Hz, 208 - 230V Indoor Unit FFQ15Q2VJU FFQ18Q2VJU Model RX15QMVJU RX18QMVJU Outdoor Unit Cooling Heating Cooling Heating Capacity Btu/h 14,400 (5,100 ~ 16,200) 16,200 (5,200 ~ 16,300) 17,400 (5,100 ~ 18,800) 21,600 (5,400 ~ 21,800) Rated (Min. ~ Max.) Running Current (Rated) 5.83 - 5.27 6.23 - 5.63...

  • Page 17: Part 3 Printed Circuit Board Connector Wiring Diagram

    SiUS091628EA Part 3 Printed Circuit Board Connector Wiring Diagram 1. Indoor Unit....................7 1.1 FFQ09/12/15/18Q2VJU................7 2. Wired Remote Controller................8 2.1 BRC1E73 ..................... 8 3. Wireless Remote Controller Kit ..............9 3.1 BRC082A41W, BRC082A42W(S)..............9 4. Outdoor Unit....................10 4.1 RX09/12QMVJU..................10 4.2 RX15/18QMVJU..................

  • Page 18: Indoor Unit

    Indoor Unit SiUS091628EA 1. Indoor Unit FFQ09/12/15/18Q2VJU Control PCB (A1P) 1) X15A Connector for float switch 2) X16A Connector for room temperature thermistor (suction air thermistor) 3) X17A, X18A Connector for indoor heat exchanger thermistor 4) X20A Connector for DC fan motor 5) X24A Connector for transmitter board (when the wireless remote controller (option) is used)

  • Page 19: Wired Remote Controller

    SiUS091628EA Wired Remote Controller 2. Wired Remote Controller BRC1E73 Wired Remote Controller PCB 1) P1, P2 Terminal for indoor unit 2) R4T Room temperature thermistor 2P298037-7 Printed Circuit Board Connector Wiring Diagram...

  • Page 20: Wireless Remote Controller Kit

    Wireless Remote Controller Kit SiUS091628EA 3. Wireless Remote Controller Kit BRC082A41W, BRC082A42W(S) Transmitter Board (A2P) 1) X1A Connector for receiver (A3P) 2) X2A Connector for control PCB (A1P) 3) SS1 MAIN/SUB setting switch ∗ Refer to page 123 for details. 4) SS2 Address setting switch ∗...

  • Page 21: Outdoor Unit

    SiUS091628EA Outdoor Unit 4. Outdoor Unit RX09/12QMVJU Main PCB (PCB1) 1) S20 Connector for electronic expansion valve coil 2) S30 Connector for compressor 3) S40 Connector for overload protector 4) S71 Connector for DC fan motor 5) S80 Connector for four way valve coil 6) S90 Connector for thermistors (outdoor temperature, outdoor heat exchanger, discharge pipe)

  • Page 22: Rx15/18Qmvju

    Outdoor Unit SiUS091628EA RX15/18QMVJU Main PCB 1) S20 Connector for electronic expansion valve coil 2) S40 Connector for overload protector 3) S70 Connector for DC fan motor 4) S80 Connector for four way valve coil 5) S90 Connector for thermistors (outdoor temperature, outdoor heat exchanger, discharge pipe) 6) HL1, HN1, S Connector for terminal block...

  • Page 23: Part 4 Functions And Control

    SiUS091628EA Part 4 Functions and Control 1. Main Functions..................13 1.1 Temperature Control .................. 13 1.2 Frequency Principle..................13 1.3 Airflow Direction Control................15 1.4 Fan Speed Control for Indoor Unit ............. 15 1.5 Program Dry Operation ................16 1.6 Clock and Calendar Setting (With Wired Remote Controller BRC1E73) ..........

  • Page 24: Main Functions

    Main Functions SiUS091628EA 1. Main Functions Temperature Control Definitions of The definitions of temperatures are classified as following. Temperatures Room temperature: temperature of lower part of the room Set temperature: temperature set by remote controller Room thermistor temperature: temperature detected by room temperature thermistor Target temperature: temperature determined by microcomputer Target temperature Room thermistor temperature...
  • Page 25 SiUS091628EA Main Functions The following drawing shows a schematic view of the inverter principle: Refrigerant circulation rate (high) high speed Amount of heat Amount of heat exchanged air (large) exchanged air (large) high f low f Amount of heat Amount of heat exchanged air (small) exchanged air (small) low speed...

  • Page 26: Airflow Direction Control

    Main Functions SiUS091628EA Airflow Direction Control Outline There are two types of airflow direction settings. Automatic swing setting The flaps automatically oscillate up and down. Indoor unit (Automatic swing) (Automatic swing) (R24069) Airflow direction fixed setting You can select from one of the fixed directions. The display of the remote controller and the actual angle of the flap do not match.

  • Page 27: Program Dry Operation

    SiUS091628EA Main Functions Program Dry Operation Outline Program dry operation removes humidity while preventing the room temperature from lowering. Since the microcomputer controls both the temperature and airflow rate, the temperature adjustment and FAN setting buttons are inoperable. Details The microcomputer automatically sets the temperature and airflow rate. The difference between the room thermistor temperature at start-up and the target temperature is divided into two zones.

  • Page 28: Clock And Calendar Setting (With Wired Remote Controller Brc1E73)

    Main Functions SiUS091628EA Clock and Calendar Setting (With Wired Remote Controller BRC1E73) Press Menu/OK button to display the main menu screen. Press buttons to select Clock & Calendar on the main menu screen. Press Menu/OK button to display the clock & calendar screen. Press buttons to select Date &...
  • Page 29 SiUS091628EA Main Functions Select Hour with buttons. Change the hour with buttons. Holding down the button causes the number to change continuously. Select Minute with buttons. Change the minute with buttons. Holding down the button causes the number to change continuously. Press Menu/OK button.

  • Page 30: Schedule Timer Operation (With Wired Remote Controller Brc1E73)

    Main Functions SiUS091628EA Schedule TIMER Operation (With Wired Remote Controller BRC1E73) Outline Day settings are selected from 4 patterns: 7Days Weekday/Sat/Sun Weekday/Weekend Everyday Up to 5 actions can be set for each day. Details Set the startup time and operation stop time. Startup time, cooling and heating temperature setpoints can be configured.
  • Page 31 SiUS091628EA Main Functions Daily Patterns The schedule screen will appear. Press buttons to select Daily Patterns on the schedule screen. The daily patterns screen will appear when Menu/OK button is pressed. Press buttons to select 7 Days Weekday/Sat/Sun Weekday/Weekend Everyday the daily patterns screen.
  • Page 32 Main Functions SiUS091628EA Press buttons to move the highlighted item and press buttons to configure ON/OFF/-- settings. --, ON, or OFF changes in sequence when buttons are pressed. ON: The temperature setpoints can be configured. OFF: The setback temperature setpoints can be configured.
  • Page 33 SiUS091628EA Main Functions Enabling or disabling the schedule Display the schedule screen. Press buttons to select Enable / Disable on the schedule screen. Press Menu/OK button to display the enable/disable screen. Press buttons to select Enable Disable on the enable/disable screen.

  • Page 34: Setback Function (With Wired Remote Controller Brc1E73)

    Main Functions SiUS091628EA Setback Function (With Wired Remote Controller BRC1E73) The Setback function can be used to maintain the space temperature in an assigned range for an unoccupied period. The setback icon flashes on the LCD of wired remote controller when the unit is turned on by the setback control.
  • Page 35 SiUS091628EA Main Functions 1.9.2 If the Float Switch is OFF with the Thermostat ON in Cooling Operation ∗2 ∗1 ∗4 ∗3 Float switch 5 sec. 5 sec. Thermostat (running) Error display Drain pump 5 min. 5 sec. 5 min. 5 sec. 5 min. 5 sec. (R24610) When the float switch stays OFF for 5 sec., the thermostat turns OFF.

  • Page 36: Hot Start Control (In Heating Operation Only)

    Main Functions SiUS091628EA 1.9.4 If the Float Switch Turns OFF and ON Continuously, or the Float Switch Turns OFF While AF Displayed ∗1 ∗2 ∗3 Float Switch 5 sec. 5 sec. 5 sec. 5 sec. 5 sec. Thermostat (running) Error Display Drain Pump 5 min.

  • Page 37: Presence And Floor Sensors (Option)

    SiUS091628EA Main Functions 1.11 Presence and Floor Sensors (Option) Outline With the human presence signal and the floor temperature signal from the optional sensor kit, the system provides the energy saving control, or the comfortable temperature control and airflow direction control preventing the direct draft to the human. To use sensor related functions, a wired remote controller (BRC1E73) and optional sensor kit (BRYQ60A2W(S)) are necessary to be installed.
  • Page 38 Main Functions SiUS091628EA 2. Auto-setback by sensor (with presence sensor) After pre-determined time has elapsed without detection of human presence, the unit automatically shifts the target temperature gradually for energy saving. The target temperature displayed on the remote controller remains same as the initial set value during the above change of target temperature.
  • Page 39 SiUS091628EA Main Functions 3. Auto-off by sensor (with presence sensor) After pre-determined time has elapsed without detection of human presence, the unit automatically stops operation. The auto-off time can be set between 1- 24 hours by the hour. Once the unit stops operation by auto-off function, the system would not restart even if the human is detected again.

  • Page 40: Other Functions

    Main Functions SiUS091628EA 1.12 Other Functions 1.12.1 Signal Receiving Sign When the indoor unit receives a signal from the remote controller, the unit emits a signal receiving sound. 1.12.2 Auto-restart Function If a power failure (even a momentary one) occurs during the operation, the system restarts automatically in the same conditions as before when the power supply is restored to the conditions prior to the power failure.

  • Page 41: Control Specification

    SiUS091628EA Control Specification 2. Control Specification Mode Hierarchy Outline The air conditioner control has normal operation mode, forced operation mode, and power transistor test mode for installation and servicing. Details Heat Pump Model Air conditioner control mode Forced operation mode Forced cooling operation (for pump down operation) Power transistor test mode Normal operation mode...

  • Page 42: Frequency Control

    Control Specification SiUS091628EA Frequency Control Outline The compressor frequency is determined according to the difference between the room thermistor temperature and the target temperature. When the shift of the frequency is less than zero (∆F<0) by PI control, the target frequency is used as the command frequency. Dropping function Input current control, etc.
  • Page 43 SiUS091628EA Control Specification When starting the compressor, the frequency is initialized according to the ∆ D value of the indoor Initial Frequency unit. ∆ D signal: Indoor frequency command The difference between the room thermistor temperature and the target temperature is taken as the ∆...

  • Page 44: Controls At Mode Changing/Start-Up

    Control Specification SiUS091628EA Controls at Mode Changing/Start-up 2.3.1 Preheating Control Outline The inverter operation in open phase starts with the conditions of the outdoor temperature, the discharge pipe temperature, the radiation fin temperature and the preheating command from the indoor unit. Outdoor temperature ≥...

  • Page 45: Compressor Protection Function

    SiUS091628EA Control Specification 2.3.3 Four Way Valve Operation Compensation Outline At the beginning of operation as the four way valve is switched, the pressure difference to activate the four way valve is acquired when the output frequency is higher than a certain fixed frequency, for a certain fixed time.

  • Page 46: Discharge Pipe Temperature Control

    Control Specification SiUS091628EA Discharge Pipe Temperature Control Outline The discharge pipe temperature is used as the internal temperature of the compressor. If the discharge pipe temperature rises above a certain level, the upper limit of frequency is set to keep the discharge pipe temperature from rising further.

  • Page 47: Input Current Control

    SiUS091628EA Control Specification Input Current Control Outline The microcomputer calculates the input current while the compressor is running, and sets the frequency upper limit based on the input current. In case of heat pump models, this control is the upper limit control of frequency and takes priority over the lower limit control of four way valve operation compensation.

  • Page 48: Freeze-Up Protection Control

    Control Specification SiUS091628EA Freeze-up Protection Control During cooling operation, the signal sent from the indoor unit determines the frequency upper limit and prevents freezing of the indoor heat exchanger. (The signal from the indoor unit is divided into zones.) The operating frequency limitation is judged with the indoor heat exchanger temperature. Indoor heat exchanger temperature (R2T) 13˚C (55.4˚F)

  • Page 49: Outdoor Fan Control

    SiUS091628EA Control Specification Outdoor Fan Control 1. Fan ON control to cool down the electrical box The outdoor fan is turned ON when the electrical box temperature is high while the compressor is OFF. 2. Fan OFF control during defrosting The outdoor fan is turned OFF during defrosting.

  • Page 50: Defrost Control

    Control Specification SiUS091628EA 2.10 Defrost Control Outline Defrosting is carried out by the cooling cycle (reverse cycle). The defrosting time or outdoor heat exchanger temperature must be more than a certain value to finish defrosting. Details Conditions for Starting Defrost The starting conditions are determined with the outdoor temperature and the outdoor heat exchanger temperature.

  • Page 51: Electronic Expansion Valve Control

    SiUS091628EA Control Specification 2.11 Electronic Expansion Valve Control Outline The following items are included in the electronic expansion valve control. Electronic expansion valve is fully closed 1. Electronic expansion valve is fully closed when turning on the power. 2. Pressure equalizing control Open Control 1.

  • Page 52: Pressure Equalizing Control

    Control Specification SiUS091628EA 2.11.1 Initialization as Power Supply On The electronic expansion valve is initialized (fully closed) when the power is turned on. Then, the valve opening is set and the pressure is equalized. 2.11.2 Pressure Equalizing Control When the compressor is stopped, the pressure equalizing control is activated. The electronic expansion valve opens and the pressure is equalized.
  • Page 53 SiUS091628EA Control Specification 2. When the operation mode is heating When the following condition is fulfilled, the discharge pipe thermistor disconnection is ascertained. Discharge pipe temperature +6°C (+10.8°F) < indoor heat exchanger temperature 09/12 class 15/18 class A (seconds) When the thermistor is disconnected When the disconnection is ascertained, the compressor continues operation for 9 minutes and then stops.

  • Page 54: Malfunctions

    Control Specification SiUS091628EA 2.12 Malfunctions 2.12.1 Sensor Malfunction Detection Sensor malfunction can be detected in the following thermistor: 1. Outdoor heat exchanger thermistor 2. Discharge pipe thermistor 3. Radiation fin thermistor 4. Outdoor temperature thermistor 2.12.2 Detection of Overcurrent and Overload Outline An excessive output current is detected and the OL temperature is observed to protect the compressor.

  • Page 55: Part 5 Remote Controller

    SiUS091628EA Part 5 Remote Controller 1. Wired Remote Controller (BRC1E73) ............45 2. Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) ..51 Remote Controller...

  • Page 56: Wired Remote Controller (Brc1E73)

    Wired Remote Controller (BRC1E73) SiUS091628EA 1. Wired Remote Controller (BRC1E73) 1. Operation mode selector button 11. LCD (with backlight) 4. Up button 5. Down button 6. Right button 7. Left button 9. Operation lamp 8. On/Off button 3. Menu/OK button 10.

  • Page 57: Operation Lamp

    SiUS091628EA Wired Remote Controller (BRC1E73) 1. Operation mode selector button 7. Left button • Press this button to select the operation • Used to highlight the next items on the mode of your preference. left-hand side. • * Available modes vary with the indoor unit Each screen is scrolled in the left-hand model.
  • Page 58 Wired Remote Controller (BRC1E73) SiUS091628EA Liquid Crystal Display • Three types of display mode (Standard, Detailed and Simple) are available. • Standard display is set by default. • Detailed and Simple displays can be selected in the main menu. Standard display 10.Changeover controlled 11.Setback by the master indoor unit...
  • Page 59 SiUS091628EA Wired Remote Controller (BRC1E73) Simple display 1.Operation mode 14.Selectable Display Item 3.Setpoint 11.Setback 2.Fan speed 4.Stand by for Defrost/ <Simple display example> Hot start Note for all display modes • Depending on the field settings, while the indoor unit is stopped, OFF may be displayed instead of the operation mode and/or the setpoint may not be displayed.

  • Page 60: Operation Mode

    Wired Remote Controller (BRC1E73) SiUS091628EA “Error: Push Menu button” 1. Operation mode “Warning: Push Menu button” Used to display the current operation • • Displayed if an error or warning is detected. mode: Cool, Heat, Vent, Fan, Dry or Auto. In Auto mode, the actual operation mode •...

  • Page 61: Airflow Direction

    SiUS091628EA Wired Remote Controller (BRC1E73) 11. Setback “ ” • The setback icon flashes when the unit is turned on by the setback control. 12. Airflow Direction “ ” Displayed when the airflow direction and • swing are set. If the connected indoor unit model does not •...

  • Page 62: Wireless Remote Controller Kit (Brc082A41W, Brc082A42W(S))

    Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) SiUS091628EA 2. Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) (R23936) (R23937) Remote Controller...
  • Page 63 SiUS091628EA Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) 11 TIMER MODE START/STOP BUTTON DISPLAY (SIGNAL TRANSMISSION) 12 TIMER RESERVE/CANCEL BUTTON This lights up when a signal is being 13 AIRFLOW DIRECTION ADJUST BUTTON transmitted. OPERATION MODE SELECTOR BUTTON DISPLAY Press this button to select OPERATION MODE. (OPERATION MODE) 15 FILTER SIGN RESET BUTTON This display shows the current OPERATION...

  • Page 64: Part 6 Service Diagnosis

    SiUS091628EA Part 6 Service Diagnosis 1. General Problem Symptoms and Check Items .........55 2. Troubleshooting with LED .................56 2.1 Indoor Unit....................56 2.2 Outdoor Unit ....................56 3. Service Diagnosis ..................57 3.1 Wired Remote Controller (BRC1E73) ............57 3.2 Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) ..59 4.
  • Page 65 SiUS091628EA 5. Check ...................... 100 5.1 Thermistor Resistance Check ..............100 5.2 Indoor Fan Motor Connector Output Check ..........101 5.3 Power Supply Waveforms Check............. 101 5.4 Electronic Expansion Valve Check............102 5.5 Four Way Valve Performance Check ............103 5.6 Inverter Unit Refrigerant System Check...........

  • Page 66: General Problem Symptoms And Check Items

    General Problem Symptoms and Check Items SiUS091628EA 1. General Problem Symptoms and Check Items Symptom Check Item Details Reference Page The unit does not operate. Check the power supply. Check if the rated voltage is supplied. — Check the type of the indoor unit. Check if the indoor unit type is compatible with the —...

  • Page 67: Troubleshooting With Led

    SiUS091628EA Troubleshooting with LED 2. Troubleshooting with LED Indoor Unit Operation Lamp The operation lamp blinks when any of the following errors is detected. 1. When a protection device of the indoor or outdoor unit is activated, or when the thermistor malfunctions.

  • Page 68: Service Diagnosis

    Service Diagnosis SiUS091628EA 3. Service Diagnosis Wired Remote Controller (BRC1E73) Relations On power-up, the message “Checking the connection. Please standby.” will be displayed on the remote controller screen temporarily and then the basic screen will be displayed. To access a mode Between Modes from the basic screen, refer to the figure below.
  • Page 69 The error code will flash and the service Error Code: A1 Contact Info contact and model name or code may 0123-456-7890 be displayed. Indoor Model ---/000 Notify your Daikin dealer of the Error Outdoor Model ---/000 code and model name or code. Service Diagnosis...

  • Page 70: Wireless Remote Controller Kit (Brc082A41W, Brc082A42W(S))

    Service Diagnosis SiUS091628EA Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) Relations The following modes can be selected by using INSPECTION/TEST OPERATION button on the remote controller. Between Modes Service data can be obtained. Indoor unit settings can be made. Press INSPECTION/TEST Error code history Filter cleaning sign time OPERATION button for...
  • Page 71 SiUS091628EA Service Diagnosis Step Action Press UP or DOWN button and change the UNIT No. until the indoor unit starts to beep. UP button DOWN button (R15408) If you hear... Then... 3 short beeps Follow all steps below. 1 short beep Follow steps 3 and 4.
  • Page 72 Service Diagnosis SiUS091628EA Step Action Press UP or DOWN button to change the error code upper digit until the indoor unit beeps. DOWN UP button DOWN button (R15411) If you hear... Then... 2 short beeps The upper digit matches. 1 short beep No digits match.
  • Page 73 SiUS091628EA Service Diagnosis Step Action Press UP or DOWN button and change the error code lower digit until the indoor unit generates long beep. DOWN UP button DOWN button (R15413) If you hear... Then... 2 short beeps No digits match. 1 long beep Both upper and lower digits match.

  • Page 74: Troubleshooting

    Troubleshooting SiUS091628EA 4. Troubleshooting Error Codes and Description Reference Error Codes Description Page System Normal — Low-voltage detection or over-voltage detection Signal transmission error (between indoor unit and outdoor unit) Mismatching of indoor unit and outdoor unit Indoor Indoor unit PCB abnormality Unit Drain level control system abnormality Indoor fan motor (DC motor) or related abnormality...

  • Page 75: Indoor Unit Pcb Abnormality

    SiUS091628EA Troubleshooting Indoor Unit PCB Abnormality Error Code Method of Error The system checks the data from EEPROM. Detection Error Decision The data from the EEPROM is not received correctly. Conditions EEPROM (Electrically Erasable Programmable Read Only Memory): A memory chip that holds its content without power.

  • Page 76: Drain Level Control System Abnormality

    Troubleshooting SiUS091628EA Drain Level Control System Abnormality Error Code Method of Error The float switch detects error. Detection Error Decision The water level reaches its upper limit and the float switch turns OFF. Conditions Supposed Defective drain pump Causes Improper drain piping work Clogged drain piping Defective float switch Defective indoor unit PCB...

  • Page 77: Indoor Fan Motor (Dc Motor) Or Related Abnormality

    SiUS091628EA Troubleshooting Indoor Fan Motor (DC Motor) or Related Abnormality Error Code Method of Error The rotation speed detected by the Hall IC during fan motor operation determines abnormal fan motor operation. Detection Error Decision The fan motor is not revved up. Conditions Supposed Layer short inside the fan motor winding...
  • Page 78 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check the power supply voltage. Check No.02 Refer to P.101 Is the voltage fluctuation within Correct the power ±10% from the rated supply.

  • Page 79: Humidifier Or Related Abnormality

    SiUS091628EA Troubleshooting Humidifier or Related Abnormality Error Code Method of Error Water leakage from humidifier(s) is detected based on the float switch ON/OFF changeover while the system is not operating. Detection Error Decision The float switch changes from ON to OFF while the system is OFF. Conditions Supposed Defective float switch...

  • Page 80: Thermistor Or Related Abnormality

    Troubleshooting SiUS091628EA Thermistor or Related Abnormality C4 , C5 , C9 Error Code Method of Error The temperatures detected by the thermistors determine thermistor errors. Detection Error Decision The thermistor is disconnected or shorted while the unit is running. Conditions Supposed Disconnection of connector Defective thermistor(s)

  • Page 81: Presence Sensor Or Floor Sensor Abnormality

    SiUS091628EA Troubleshooting Presence Sensor or Floor Sensor Abnormality Error Code Method of Error The system detects abnormality by the output signal from the sensor(s). Detection Error Decision The sensor is disconnected or shorted while the unit is running. Conditions Supposed Disconnection of connector Breaking of wires Causes...

  • Page 82: Remote Controller Thermistor Abnormality

    Troubleshooting SiUS091628EA Remote Controller Thermistor Abnormality Error Code Method of Error Even if remote controller thermistor is faulty, system is possible to operate by system thermistor. Malfunction detection is carried out by the temperature detected by the remote controller Detection thermistor.

  • Page 83: Signal Transmission Error (Between Indoor Unit And Remote Controller)

    SiUS091628EA Troubleshooting Signal Transmission Error (Between Indoor Unit and Remote Controller) Error Code Method of Error In case of controlling 1 indoor unit with 2 remote controllers, check the system using microcomputer if signal transmission between indoor unit and remote controller (main and sub) is normal. Detection Error Decision Normal transmission does not continue for specified period.

  • Page 84: Signal Transmission Error (Between Main Remote Controller And Sub Remote Controller)

    Troubleshooting SiUS091628EA 4.10 Signal Transmission Error (Between MAIN Remote Controller and SUB Remote Controller) Error Code Method of Error In case of controlling 1 indoor unit with 2 remote controllers, check the system using microcomputer if signal transmission between MAIN remote controller and SUB remote controller is normal. Detection Error Decision Normal transmission does not continue for specified period.

  • Page 85: Low-Voltage Detection Or Over-Voltage Detection

    SiUS091628EA Troubleshooting 4.11 Low-voltage Detection or Over-voltage Detection Error Code Method of Error Low-voltage detection: An abnormal voltage drop is detected by the DC voltage detection circuit. Detection Over-voltage detection: An abnormal voltage rise is detected by the over-voltage detection circuit. Error Decision Low-voltage detection: The voltage detected by the DC voltage detection circuit is below 180 ~ 196 V (depending on...
  • Page 86 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check the power supply voltage. Is the voltage fluctuation Correct the power supply. within ±10% from the rated value? Check the connection of the compressor harness.

  • Page 87: Signal Transmission Error (Between Indoor Unit And Outdoor Unit)

    SiUS091628EA Troubleshooting 4.12 Signal Transmission Error (Between Indoor Unit and Outdoor Unit) Error Code Method of Error The signal transmission data from the outdoor unit is checked whether it is normal. Detection Error Decision The data sent from the outdoor unit cannot be received normally, or the content of the data is abnormal.
  • Page 88 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.11 Check the power supply voltage. Refer to P.101 Is the voltage fluctuation Correct the power supply. within ±10% from the rated value? Check the connection wires...

  • Page 89: Mismatching Of Indoor Unit And Outdoor Unit

    SiUS091628EA Troubleshooting 4.13 Mismatching of Indoor Unit and Outdoor Unit Error Code Error Decision Improper combination of indoor and outdoor units Conditions Supposed Defective indoor unit PCB Indoor-outdoor unit transmission wiring error Causes Defective optional unit(s) wirings Improper power supply wiring of indoor unit Improper wiring of connecting wires between indoor/outdoor units Troubleshooting Be sure to turn off the power switch before connecting or disconnecting...

  • Page 90: Outdoor Unit Pcb Abnormality

    Troubleshooting SiUS091628EA 4.14 Outdoor Unit PCB Abnormality Error Code Method of Error The system checks if the microprocessor is working in order. The system checks if the zero-cross signal comes in properly. Detection Error Decision The microprocessor program runs out of control. The zero-cross signal is not detected.

  • Page 91: Ol Activation (Compressor Overload)

    SiUS091628EA Troubleshooting 4.15 OL Activation (Compressor Overload) Error Code Method of Error A compressor overload is detected through compressor OL. Detection Error Decision If the error repeats, the system is shut down. Reset condition: Continuous run for about 60 minutes without any other error Conditions Supposed Disconnection of discharge pipe thermistor...
  • Page 92 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.01 Refer to P.100 Discharge pipe thermistor Insert the thermistor in disconnected? position. Check No.12 Refer to P.102 Check No.

  • Page 93: Compressor Lock

    SiUS091628EA Troubleshooting 4.16 Compressor Lock Error Code Method of Error A compressor lock is detected by the current waveform generated when applying high-frequency voltage to the motor. Detection Error Decision If the error repeats, the system is shut down. Conditions Reset condition: Continuous run for about 11 minutes without any other error Supposed Closed stop valve...

  • Page 94: Dc Fan Lock (Outdoor Fan Motor)

    Troubleshooting SiUS091628EA 4.17 DC Fan Lock (Outdoor Fan Motor) Error Code Method of Error An error is determined with the high-voltage fan motor rotation speed detected by the Hall IC. Detection Error Decision The fan does not start in 15 ~ 30 seconds even when the fan motor is running. If the error repeats, the system is shut down.

  • Page 95: Input Overcurrent Detection

    SiUS091628EA Troubleshooting 4.18 Input Overcurrent Detection Error Code Method of Error An input overcurrent is detected by checking the input current value with the compressor running. Detection Error Decision The current exceeds about 12.0 ~ 12.5 A (depending on the model) for 2.5 seconds with the compressor running.

  • Page 96: Four Way Valve Abnormality

    Troubleshooting SiUS091628EA 4.19 Four Way Valve Abnormality Error Code Method of Error The room temperature thermistor and the indoor heat exchanger thermistor are checked if they function within their normal ranges in each operation mode. Detection Error Decision The following condition continues over 10 minutes after operating for 5 minutes. Conditions Cooling/Dry A –...
  • Page 97 SiUS091628EA Troubleshooting Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.01 Four way valve coil Refer to P.100 Correct the four way valve disconnected (loose)? coil. Check No.13 Refer to P.103 Harness disconnected? Reconnect the harness.

  • Page 98: Discharge Pipe Temperature Control

    Troubleshooting SiUS091628EA 4.20 Discharge Pipe Temperature Control Error Code Method of Error An error is determined with the temperature detected by the discharge pipe thermistor. Detection Error Decision If the temperature detected by the discharge pipe thermistor rises above A, the compressor stops.

  • Page 99: High Pressure Control In Cooling

    SiUS091628EA Troubleshooting 4.21 High Pressure Control in Cooling Error Code Method of Error High-pressure control (operation halt, frequency drop, etc.) is activated in cooling operation if the temperature sensed by the outdoor heat exchanger thermistor exceeds the limit. Detection Error Decision The temperature sensed by the outdoor heat exchanger thermistor rise above 57.5 ~ 61°C Conditions (135.5 ~ 141.8°F) (depending on the model).
  • Page 100 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.01 Check the installation space. Refer to P.100 Check No. 17 Check No.12 Change the installation Check the installation Refer to P.102 location or direction.

  • Page 101: System Shutdown Due To Compressor Internal Temperature Abnormality

    SiUS091628EA Troubleshooting 4.22 System Shutdown due to Compressor Internal Temperature Abnormality Error Code Method of Error Operation is halted when the temperature detected by the discharge pipe thermistor exceeds the Detection determined limit. Error Decision Temperature exceeds the detection threshold of 127.5°C during forced cooling operation. Conditions Supposed Abnormal operation due to air intrusion...

  • Page 102: Compressor System Sensor Abnormality

    Troubleshooting SiUS091628EA 4.23 Compressor System Sensor Abnormality Error Code Method of Error The system checks the DC current before the compressor starts. Detection Error Decision The voltage converted from the DC current before compressor start-up is out of the range 0.5 ~ 4.5 V.

  • Page 103: Position Sensor Abnormality

    SiUS091628EA Troubleshooting 4.24 Position Sensor Abnormality Error Code Method of Error A compressor start-up failure is detected by checking the compressor running condition through the position detection circuit. Detection Error Decision If the error repeats, the system is shut down. Conditions Reset condition: Continuous run for about 11 minutes without any other error Supposed...
  • Page 104 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.15 Turn off the power. Refer to P.104 Check the power supply voltage. Check No.18 Refer to P.107 Is the power supply voltage fluctuation within...

  • Page 105: Thermistor Or Related Abnormality (Outdoor Unit)

    SiUS091628EA Troubleshooting 4.25 Thermistor or Related Abnormality (Outdoor Unit) H9 , J3 , J6 , P4 Error Code Method of Error This fault is identified based on the thermistor input voltage to the microcomputer. A thermistor fault is identified based on the temperature sensed by each thermistor. Detection Error Decision The voltage between the both ends of the thermistor is either 4.96 V or more, or 0.04 V or less...
  • Page 106 Troubleshooting SiUS091628EA In case of H9 , J3 , J6 Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. Check No.01 Turn on the power again. Refer to P.100 Error displayed Reconnect the connectors again on remote...

  • Page 107: Electrical Box Temperature Rise

    SiUS091628EA Troubleshooting 4.26 Electrical Box Temperature Rise Error Code Method of Error An electrical box temperature rise is detected by checking the radiation fin thermistor with the compressor off. Detection Error Decision With the compressor off, the radiation fin temperature is above A. Conditions The error is cleared when the radiation fin temperature drops below B.

  • Page 108: Radiation Fin Temperature Rise

    Troubleshooting SiUS091628EA 4.27 Radiation Fin Temperature Rise Error Code Method of Error A radiation fin temperature rise is detected by checking the radiation fin thermistor with the compressor on. Detection Error Decision If the radiation fin temperature with the compressor on is above A. The error is cleared when the radiation fin temperature drops below B.

  • Page 109: Output Overcurrent Detection

    SiUS091628EA Troubleshooting 4.28 Output Overcurrent Detection Error Code Method of Error An output overcurrent is detected by checking the current that flows in the inverter DC section. Detection Error Decision A position signal error occurs while the compressor is running. A rotation speed error occurs while the compressor is running.
  • Page 110 Troubleshooting SiUS091628EA Troubleshooting Be sure to turn off the power switch before connecting or disconnecting Caution connectors, or parts may be damaged. ∗ An output overcurrent may result from wrong internal wiring. If the system is interrupted by an output Check No.15 overcurrent after the wires have been disconnected and reconnected for part replacement, check the wiring again.

  • Page 111: Check

    SiUS091628EA Check 5. Check Thermistor Resistance Check Check No.01 Disconnect the connectors of the thermistors from the PCB, and measure the resistance of each thermistor using a multimeter. Thermistor temperature Resistance (kΩ) °C °F –20 –4 197.8 –15 148.2 –10 112.1 –5 85.60...

  • Page 112: Indoor Fan Motor Connector Output Check

    Check SiUS091628EA Indoor Fan Motor Connector Output Check Check No.02 1. Check the connection of connector. 2. Check motor power supply voltage output (pins 5 ~ 8). 3. Check motor control voltage (pins 5 ~ 4). 4. Check rotation command voltage output (pins 5 ~ 3). X20A Motor power supply voltage (290 ~ 330 VDC) Unused...

  • Page 113: Electronic Expansion Valve Check

    SiUS091628EA Check Electronic Expansion Valve Check Check No.12 Conduct the following to check the electronic expansion valve (EV). 1. Check if the EV connector is correctly connected to the PCB. 2. Turn the power off and on again, and check if the EV generates a latching sound. 3.

  • Page 114: Four Way Valve Performance Check

    Check SiUS091628EA Four Way Valve Performance Check Check No.13 Turn the power off and then on again. ∗ Four way valve coil Start heating operation. Cooling / Dry / Defrost: Not energized Heating: energized voltage at 208 - 230 Replace the outdoor unit VAC with compressor PCB (main PCB).

  • Page 115: Inverter Analyzer Check

    SiUS091628EA Check Inverter Analyzer Check Check No.15 Characteristics Inverter analyzer: RSUK0917C If an abnormal stop occurs due to compressor startup failure or overcurrent output when using an inverter unit, it is difficult to judge whether the stop is caused by the compressor failure or some other failure (main PCB, power module, etc.).
  • Page 116 Check SiUS091628EA Step 3 Activate power transistor test operation from the outdoor unit. Start method of power transistor test operation Note: Power transistor test operation can be activated only once after turning on the power supply. If reactivation of the power supply transistor operation is needed, turn the power supply off and then on again.

  • Page 117: Rotation Pulse Check On The Outdoor Unit Pcb

    SiUS091628EA Check Caution 1. When the output frequency is low, the LEDs blink slowly. As the output frequency increases, the LEDs blink quicker. (The LEDs look like they are lit.) 2. On completion of the inverter analyzer diagnosis, be sure to re-crimp the FASTON terminals. Otherwise, the terminals may be burned due to loosening.

  • Page 118: Installation Condition Check

    Check SiUS091628EA Installation Condition Check Check No.17 Installation condition check Check the allowable dimensions of the air Change the installation suction and location or direction. discharge area. Is the discharged air Change the installation short-circuited? location or direction. Is the outdoor heat Clean the outdoor heat exchanger very dirty? exchanger.

  • Page 119: Outdoor Fan System Check

    SiUS091628EA Check 5.11 Outdoor Fan System Check Check No.19 DC motor Check the outdoor fan system. Fan motor Is the lead wire connector outdoor fan running? Go to Check No. 16. disconnected? Reconnect the connector. Outdoor fan system is functioning. (R21195) 5.12 Main Circuit Short Check Check No.20...
  • Page 120 Check SiUS091628EA 15/18 class Multimeter (R20701) Service Diagnosis...

  • Page 121: Power Module Check

    SiUS091628EA Check 5.13 Power Module Check Check No.22 Check to make sure that the voltage between (+) and (–) of the power module is approximately 0 V before checking. Disconnect the compressor harness connector from the outdoor unit PCB. To disengage the connector, press the protrusion on the connector.
  • Page 122 Check SiUS091628EA 15/18 class DC_P1: + (R20704) DC_N1: – Service Diagnosis...

  • Page 123: Part 7 Trial Operation And Field Settings

    SiUS091628EA Part 7 Trial Operation and Field Settings 1. Pump Down Operation................113 2. Forced Cooling Operation ...............114 3. Trial Operation ..................115 4. Field Settings ..................118 4.1 How to Change the Field Settings............118 4.2 Overview of the Field Settings..............121 4.3 MAIN/SUB Setting when Using 2 Wired Remote Controllers....

  • Page 124: Pump Down Operation

    Pump Down Operation SiUS091628EA 1. Pump Down Operation Outline In order to protect the environment, be sure to conduct pump down operation when relocating or disposing of the unit. Details 1. Remove the valve caps from the liquid stop valve and the gas stop valve. 2.

  • Page 125: Forced Cooling Operation

    SiUS091628EA Forced Cooling Operation 2. Forced Cooling Operation Outline The forced cooling operation is allowed when both the following conditions are met. 1. The outdoor unit is not abnormal and not in the 3-minute standby mode. 2. The outdoor unit is not operating. Protection functions have priority over all other functions during forced cooling operation.

  • Page 126: Trial Operation

    Trial Operation SiUS091628EA 3. Trial Operation Outline Make sure to install the decoration panel before carrying out trial operation if the wireless remote controller is used. Trial operation should be carried out in either cooling or heating operation. 1. Measure the supply voltage and make sure that it is within the specified range. 2.
  • Page 127 SiUS091628EA Trial Operation With Wired Remote Controller (BRC1E73) 1. Set to COOL or HEAT operation using the Basic screen remote controller. Cool Set to 2. Press and hold Cancel button for 4 seconds Press and hold Cancel or longer. Service settings menu is button for 4 seconds or displayed.
  • Page 128 Trial Operation SiUS091628EA With Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) 1. Press button and select the COOL or HEAT operation. 2. Press button twice. “TEST” is displayed. 3. Press button within 10 seconds, and the test operation starts. Monitor the operation of the indoor unit for a minimum of 10 minutes. During test operation, the indoor unit will continue to cool/heat regardless of the temperature setpoint and room temperature.

  • Page 129: Field Settings

    SiUS091628EA Field Settings 4. Field Settings How to Change the Field Settings Outline If optional accessories are mounted on the indoor unit, the indoor unit setting may have to be changed. Refer to the instruction manual for each optional accessory. Note: When using 2 remote controllers for 1 indoor unit, change the field settings from MAIN remote controller.
  • Page 130 Field Settings SiUS091628EA 3. Highlight the mode, and select desired “Mode No.” by using ▲ ▼ (Up/Down) button. 4. In the case of setting per indoor unit during group control (When Mode No. such as 20 22 23 25 are selected), highlight the unit No.and select “Indoor unit No.” to be set by using ▲...
  • Page 131 SiUS091628EA Field Settings Wireless Remote Controller Kit (BRC082A41W, BRC082A42W(S)) UP button Mode No. Field setting mode DOWN button First code No. RESERVE button MODE button Second code No. INSPECTION/TEST button (R24061) To set the field settings, you have to change: Mode No.

  • Page 132: Overview Of The Field Settings

    Field Settings SiUS091628EA Overview of the Field Settings First Second Code No. Mode Code Description of setting Approx. Approx. Filter cleaning Longlife 2,500 1,250 — — — — sign interval filter hrs. hrs. (20) Remote controller thermistor Enabled Disabled — —...

  • Page 133: Main/Sub Setting When Using 2 Wired Remote Controllers

    SiUS091628EA Field Settings MAIN/SUB Setting when Using 2 Wired Remote Controllers Outline The MAIN/SUB setting is necessary when 1 indoor unit is controlled by 2 remote controllers. When you use 2 remote controllers, set one to MAIN and the other to SUB. Details 1.

  • Page 134: Address And Main/Sub Setting For Wireless Remote Controller

    Field Settings SiUS091628EA Address and MAIN/SUB Setting for Wireless Remote Controller Outline If setting multiple wireless remote controllers to operate in one room, perform address setting for the receiver and the wireless remote controller. If using both a wired remote controller and a wireless remote controller with 1 indoor unit, change the MAIN/SUB switch of the transmitter board.
  • Page 135 SiUS091628EA Field Settings Wireless Remote Factory set is 1. Change the wireless remote controller address setting by the following steps, if Controller necessary. 1. Hold down button and /TEST button at the same time for at least 4 seconds to enter the Address field setting mode.

  • Page 136: Facility Setting (Cooling At Low Outdoor Temperature)

    Field Settings SiUS091628EA After Setting Affix corresponding unit number labels onto both air outlet of the decoration panel and onto back of the wireless remote controller. (R24066) Note: Set the unit No. of the receiver and the wireless remote controller to be the equal. If the settings differ, the signal from the remote controller cannot be transmitted.

  • Page 137: Silicone Grease On Power Transistor/Diode Bridge

    SiUS091628EA Silicone Grease on Power Transistor/Diode Bridge 5. Silicone Grease on Power Transistor/Diode Bridge Outline Apply the specified silicone grease to the heat radiation part of a power transistor/diode bridge when you replace an outdoor unit PCB. The silicone grease encourages the heat radiation of a power transistor/diode bridge.

  • Page 138: Part 8 Appendix

    SiUS091628EA Part 8 Appendix 1. Piping Diagrams..................128 1.1 Indoor Unit....................128 1.2 Outdoor Unit ..................... 129 2. Wiring Diagrams..................130 2.1 Indoor Unit....................130 2.2 Outdoor Unit ..................... 131 3. Operation Limit..................133 Appendix...

  • Page 139: Piping Diagrams

    SiUS091628EA Piping Diagrams 1. Piping Diagrams Indoor Unit FFQ09/12/15/18Q2VJU REFRIGERANT FLOW COOLING HEATING HEAT EXCHANGER LIQUID PIPE CONNECTION PORT φA GAS PIPE CONNECTION PORT φB MODEL FFQ09Q2VJU 1/4 (6.4) 3/8 (9.5) FFQ12Q2VJU FFQ15Q2VJU 1/2 (12.7) FFQ18Q2VJU 4D106033 Appendix...

  • Page 140: Outdoor Unit

    Piping Diagrams SiUS091628EA Outdoor Unit RX09/12QMVJU OUTDOOR UNIT OUTDOOR TEMPERATURE HEAT EXCHANGER THERMISTOR 9/32 CuT 9/32 CuT HEAT EXCHANGER THERMISTOR 3/16 CuT 1/4 CuT 1/4 CuT 3/16 CuT MUFFLER WITH MOTOR FILTER OPERATED PROPELLER FAN VALVE MUFFLER WITH 3/8 CuT FILTER FOUR WAY VALVE...

  • Page 141: Wiring Diagrams

    SiUS091628EA Wiring Diagrams 2. Wiring Diagrams Indoor Unit FFQ09/12/15/18Q2VJU INDOOR UNIT PILOT LAMP (ON-RED) PILOT LAMP PRINTED CIRCUIT BOARD WIRING DIAGRAM WIRELESS REMOTE CONTROLLER (TIMER-GREEN) C105 CAPACITOR (M1F) (RECEIVER/DISPLAY UNIT) DIP SWITCH ON PCB PILOT LAMP (OPTIONAL ACCESSORY) (FILTER SIGN-RED) FUSE (F, 5A, 250V) FLASHING LAMP PILOT LAMP...

  • Page 142: Outdoor Unit

    Wiring Diagrams SiUS091628EA Outdoor Unit RX09/12QMVJU WIRING DIAGRAM IPM1 MRM10 L2 2 C400 INDOOR C405 V150 3.15A 3.15A POWER SUPPLY MRCW FIELD WIRING. OUTDOOR PCB1 NOTE 1. REFER TO THE NAMEPLATE FOR THE POWER t˚ t˚ t˚ IN CASE OF REQUIREMENTS.
  • Page 143 SiUS091628EA Wiring Diagrams RX15/18QMVJU WIRING DIAGRAM FIELD WIRING INDOOR MRM20 IPM1 TO INDOOR UNIT MRM10 L2 2 3.15A 3.15A W V U POWER SUPPLY MRCW X11A OUTDOOR NOTE 1. REFER TO THE NAMEPLATE FOR THE POWER REQUIREMENTS. t˚ t˚ t˚ : CAPACITOR : DIODE BRIDGE IN CASE OF...

  • Page 144: Operation Limit

    Operation Limit SiUS091628EA 3. Operation Limit RX09/12/15/18QMVJU Heating Cooling 64.4 114.8 *NOTE 2 57.2 68 73.4 82.4 Indoor temp. (˚FWB) Indoor temp. (˚FDB) Notes: 1. The graphs are based on the following conditions. • Equivalent piping length 25ft • Level difference 2.
  • Page 145 Revision History Month / Year Version Revised contents 12 / 2016 SiUS091628E First edition 03 / 2017 SiUS091628EA Model addition: FFQ18Q2VJU, RX18QMVJU...
  • Page 146 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorized parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.

Table of Contents

Save PDF
