Summary of Contents for CHD Elektroservis SH2/9-M
Page 1
Model 8-437 ver. 1.0 OWNER’S MANUAL © 2011 CHD Elektroservis...
Page 2: Table Of Contents
Automatic activation of interface ........23 Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 3: Device Description
(from host syste to MIDI-IN input of the interface). MIDI-THRU/OUT output of the interface stays unconnected. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 4: Connection For Memory Content Transfer
Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 5: Instrument Operation
BANK BUFFER during reset (HW, CC, SysEx) User accessible permanent memory Internal temporary memory Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 6: System Parameters
ENV circuits. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 7: Preset Parameters
MIDI notes. Step is one semitone. Valid range of shift is from 0 to +79 semitones – value of the parameter can be from 0 to 79 thus. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 8: Sh2/9-M Midi Interface For Roland Sh-2 / Sh
Pic. 5 – Influence of “VCO Pitch - Key Shift“ parameter Range of acceptable MIDI notes Range of standard keyboards Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 9: Vco Pitch - Aftertouch Bend
Polarity ”Center 1 - 0°“ Frequency of VCO is swept symmetrically around basic frequency. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 10
Frequency of VCO is swept only down from basic frequency (i.e. VCO frequency is only decreased by modulation). Pic. 7 – Modulation signal polarity Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 11: Vco Mod - Rate
0,866 1,154 0,245 4,080 0,069 14,420 2,943 0,340 0,833 1,201 0,236 4,244 0,067 15,000 Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 12: Vco Mod - Wheel Amount
Channel Aftertouch in dependence on VCO PITCH - Aftertouch Bend parameter (see pic. 9). Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 13: Parametr "Vco Mod - Retrig
Parameter sets affecting level of instrument’s VCF by position of key on the master keyboard (i.e. in dependence on tone height). Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 14: Vcf Cutoff - Velocity Amount
The parameter value in edit buffer can be set during operation with help of MIDI controller (Control Changes) Nr. 54 – see chapter 5.1.2.2. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 15: Vca Level - Volume Mode
Indication LED lights in red in quiescent status and it lights in green if GATE signal is active. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 16: Midi Implementation
VCA LEVEL - Volume Control is set to value 1 or 3. The interface accepts whole range of controller values from 0 to 127. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 17: Own Controllers For Preset Parameters Setting
(see pic. 4) – it is valid till the next change of the controller or till reset of the device. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 18
(see pic. 4) – it is valid till the next change of the controller or till reset of the device. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 19
(see pic. 4) – it is valid till the next change of the controller or till reset of the device. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 20: Own Controllers For Interface's Functions Control
MIDI host system. The software generator can create easily any kind of message necessary for control of the interface. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 21: Limitation During The Interface Usage And Recommended Setting
- mechanical damage caused by consumer during transportation or usage of equipment, - unprofessional interference with the equipment or by equipment modification without manufacturer’s approval. Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 22: Midi Implementation Chart
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO X : No Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
Page 23: Error Status Indication
Manufacturer : CHD Elektroservis Nad kundratkou 27, 19000 Praha 9 Czech Republic info@chd-el.cz www.chd-el.cz Copyright © 2011 CHD Elektroservis. All rights reserved. No part of this publication may be reproduced in any form without the written permission of CHD Elektroservis.
