SERVICE MANUAL
2006
5
YA387
AV-27F577
AV-32F577
AV-32F577
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-30
COLOR TELEVISION
/R
/R
/Z

TABLE OF CONTENTS

COPYRIGHT © 2006 Victor Company of Japan, Limited
, AV-27F577
, AV-32F577
,
/S
,
/Y
BASIC CHASSIS
GJ6
No.YA387
2006/5

Advertisement

Chapters

Table of Contents
loading

  Related Manuals for JVC AV-27F577/R

  Summary of Contents for JVC AV-27F577/R

  • Page 1: Table Of Contents

    SERVICE MANUAL COLOR TELEVISION YA387 2006 AV-27F577 , AV-27F577 AV-32F577 , AV-32F577 AV-32F577 BASIC CHASSIS TABLE OF CONTENTS PRECAUTION............... . . 1-3 SPECIFIC SERVICE INSTRUCTIONS .
  • Page 2 SPECIFICATION Contents Items AV-27F577 AV-32F577 Dimensions (W × H × D) 75.8 cm × 59.3 cm × 50.0 cm 87.7 cm × 69.9 cm × 56.5 cm (29-7/8" × 23-3/8" × 19-3/4") (34-5/8" × 27-5/8" × 22-1/4") Mass 43.0 kg (94.6 Ibs) 64.0 kg (140.8 Ibs) TV RF System (Analog / Analog...
  • Page 3: Precaution

    SECTION 1 PRECAUTION SAFETY PRECAUTIONS (1) The design of this product contains special hardware, many (10) Isolation Check (Safety for Electrical Shock Hazard) circuits and components specially for safety purposes. For After re-assembling the product, always perform an isolation continued protection, no changes should be made to the original check on the exposed metal parts of the cabinet (antenna design unless authorized in writing by the manufacturer.
  • Page 4: Specific Service Instructions

    Expression of a favorite screen can be chosen by the VIDEO A.H.S. adds a more spacious surround sound. Music gives STATUS function. basic effect and movie for more effect. MAIN DIFFERENCE LIST Item AV-27F577/R AV-27F577/S AV-32F577/R AV-32F577/Y AV-32F577/Z PICTURE TUBE (ITC)
  • Page 5 TECHNICAL INFORMATION 2.4.1 MAIN MI-COM (CPU) PIN FUNCTION Pin name I/O Function Pin name Function M_MUTE O Fixed output muting [Muting : H] 29 YC_GND KEY1 Front key scan voltage (CH+ / VOL+ / VOL-) 30 V1_IN Not used KEY2 Front key scan voltage (CH- / MENU/POWER) 31 ABCL Current for automatic beam (brightness)/contrast limit...
  • Page 6: Disassembly

    SECTION 3 DISASSEMBLY DISASSEMBLY PROCEDURE CAUTION AT DISASSEMBLY: • Be sure to perform the SYSTEM SETTEING, at the end of the procedure. • Make sure that the power cord is disconnected from the outlet. • Pay special attention not to break or damage the parts. •...
  • Page 7 FRONT CABINET CRT SOCKET FRONT CONTROL PWB AV TERMINAL BOARD Claw MAIN PWB REAR LED&POWER SW PWB <AV-27F577> SPEKAER USB PWB CHASSIS AV TERMINAL BOARD <AV-32F577> L/F PWB ATSC TUNER SPACER AV SW PWB MODULE PWB SPEKAER SPEAKER HOLDER POWER CORD REAR COVER Fig.1 (No.YA387)1-7...
  • Page 8 3.1.11 REMOVING THE CRT NOTE: • Replacement of the CRT should be performed by 2 or more CRT CHANGE TABLE persons. • After removing the REAR COVER, CHASSIS etc., (1) Putting the CRT change table on soft cloth, the CRT APPROX.
  • Page 9: Service Menu

    MEMORY IC REPLACEMENT • This model uses the memory IC. • This memory IC stores data for proper operation of the video and drive circuits. • When replacing, be sure to use an IC containing this (initial value) data. 3.2.1 MEMORY IC TABLE Simbol Number of pins Mounting PWB Main content of data...
  • Page 10 3.2.4 SETTINGS OF FACTORY SHIPMENT 3.2.4.1 BUTTON OPERATION 3.2.4.2 REMOTE CONTROL DIRECT OPERATION Setting item Setting position Setting item Setting position POWER INPUT CHANNEL CABLE-02 CHANNEL CABLE-02 VOLUME VOLUME MUTING DISPLAY SLEEP TIMER V. STATUS DYNAMIC THEAT. PRO C.C. STEREO ASPECT 4 : 3 A.H.S...
  • Page 11 REPLACEMENT OF CHIP COMPONENT 3.3.1 CAUTIONS (1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it. 3.3.2 SOLDERING IRON (1) Use a high insulation soldering iron with a thin pointed end of it.
  • Page 12: Adjustment

    SECTION 4 ADJUSTMENT ADJUSTMENT PREPARATION MEASURING INSTRUMENT AND FIXTURES (1) There are 2 ways of adjusting this TV : One is with the • DC voltmeter (or digital voltmeter) REMOTE CONTROL UNIT and the other is the • DC power supply conventional method using adjustment parts and •...
  • Page 13: Main Pwb

    ADJUSTMENT LOCATIONS FRONT FRONT LED & POWER SW PWB FRONT CONTROL PWB POWER LED CN600R POWER SW CN600B CN600B CN600G FRONT SPEAKER FRONT MAIN PWB DEG COIL L/F PWB MEMORY IC IC702 ATSC TUNER MODULE PWB F901 CN1005 IC201 DEF. YOKE CN001 CN002 AV SW PWB...
  • Page 14 SERVICE MODE 4.6.1 BASIC OPERATION OF SERVICE MODE Operate the SERVICE MODE with the REMOTE CONTROL UNIT. 4.6.1.1 HOW TO ENTER THE SERVICE MODE 4.6.1.4 SERVICE MODE SELECT KEY LOCATION (1) Set to "0 minutes" using the [SLEEP TIMER] key. (2) While "0 minutes"...
  • Page 15 4.6.2 SERVICE MODE MENU FLOW CHART SERVICE MENU Service Menu 1.Digital Service 2.TV-Micro Service 3.Conver Service [Not used] 3.Conver Service 4.Diagnostics 4.Diagnostics [Refer to SECTION 5] 1. Digital Service 2. TV-Micro Service TV-Micro Service Digital Service 1.Adjust 1.Adjust 2.White Balance 2.Memory Edit 3.Memory Edit 3.Edit Config...
  • Page 16 4.6.3 DESCRIPTION OF STATUS DISPLAY The status display on the upper part of the SERVICE MODE screen is common (to all models). 4.6.3.1 DIGITAL SERVICE MODE 1. Adjust (6) SETTING ITEM NO. Setting item numbers are displayed. The setting item numbers to be displayed are listed below.
  • Page 17 3. Edit Config 6. Clear Channel Map Setting value in the digital module is edited and confirmed on Channel map is cleared on this screen. [Do not adjust] this screen. [Do not adjust] CAUTION: CAUTION: This mode is not used in the ADJUSTMENT. Press the This mode is not used in the ADJUSTMENT.
  • Page 18 4.6.3.2 TV-MICRO SERVICE MODE 1. Adjust (6) SETTING ITEM NO. Setting item numbers are displayed. The setting item numbers to be displayed are listed below. SETTING ITEM No. SETTING VALUE (DATA) SETTING ITEM Item No. Setting item S001 - S045 Video system setting S001 BRIGHT...
  • Page 19 2. White Balance 3. Memory Edit White balance data is adjusted on this screen. Data in the EEPROM is edited on this screen. [Do not adjust] CAUTION: This mode is not used in the ADJUSTMENT. Press the SETTING VALUE (DATA) [BACK] key to return to the SERVICE MENU SCREEN.
  • Page 20 -128 - 127 A010 BBE TREB -128 - 127 A005 TREB OFS -128 - 127 4.7.2 [2. TV-Micro Service] 4.7.2.1 VIDEO SETTING Initial setting value AV-32F577/R AV-27F577/R AV-32F577/Y AV-27F577/S Variable AV-32F577/Z Setting item range STANDARD THEATER STANDARD THEATER 4 : 3...
  • Page 21 Initial setting value AV-27F577/R AV-27F577/S Variable Setting item range RF / EXTERNAL (S / COMPOSITE) EXTERNAL (COMPONENT) / ATSC STANDARD THEATER STANDARD THEATER HIGH HIGH HIGH HIGH S011 R CUT OFF 000 - 255 S012 G CUT OFF 000 - 255...
  • Page 22 Initial setting value Variable AV-32F577/R Setting item AV-27F577/R range AV-32F577/Y AV-27F577/S AV-32F577/Z S029 RGB MUTE 000 - 001 S030 BLUE B 000 - 001 S031 CMP ABCL 000 - 001 S032 OSD ABL 000 - 001 S033 OSD CONT 000 - 063...
  • Page 23 Initial setting value Variable Setting item AV-27F577/R AV-27F577/S AV-32F577/R AV-32F577/Y AV-32F577/Z range 4 : 3 16 : 9 4 : 3 16 : 9 4 : 3 16 : 9 4 : 3 16 : 9 4 : 3 16 : 9...
  • Page 24 (4) Disconnect the power plug. (5) Remove the resistor. RESISTOR (6) Again connect the power plug. : AV-27F577/S, AV-27F577/R, AV-27F577/R, AV-32F577/Z : AV-32F577/Z (7) Turn the power switch to on. (8) Make sure that the normal picture is displayed on the screen.
  • Page 25 4.8.3 DEFLECTION CIRCUIT [2.TV-Micro Service] Measuring Item Test point Adjustment part Description instrument V. SIZE / Signal [1.Adjust] (1) Receive the crosshatch signal. V. POSITION generator D05: V PHASE (2) Select the 2.TV-Micro Service from the SERVICE (4:3) D07: V SIZE MODE.
  • Page 26 Measuring Item Test point Adjustment part Description instrument H. POSITION / Signal [1.Adjust] • FORCUS adjustment should be finished. H. SIZE / generator D16: H SIZE+- • V. SIZE / V. POSITION adjustment should be finished. SIDE PIN D04: H POSI+- •...
  • Page 27 4.8.4 VIDEO CIRCUIT [2.TV-Micro Service] Measuring Item Test point Adjustment part Description instrument WHITE Signal [1.Adjust] (1) Receive the black and white signal ( color off ). BALANCE generator S01: BRIGHT (2) Set VIDEO STATUS to "STANDARD". (LOW LIGHT) S11: R CUTOFF (3) Select COLOR TEMPERATURE to "LOW".
  • Page 28 Measuring Item Test point Adjustment part Description instrument SUB BRIGHT Remote [1.Adjust] • WHITE BALANCE adjustment should be finished. control unit S01: BRIGHT (1) Receive any broadcast. (2) Set VIDEO STATUS to "STANDARD". (3) Select COLOR TEMPERATURE to "LOW". (4) Select the 2.TV-Micro Service from the SERVICE MODE.
  • Page 29 Measuring Item Test point Adjustment part Description instrument SUB TINT Remote [1.Adjust] [ Method of adjustment without measuring instrument ] control unit S04 : TINT • SUB CONTRAST adjustment should be finished. (1) Receive any broadcast. (2) Set VIDEO STATUS to "STANDARD". (3) Select COLOR TEMPERATURE to "LOW".
  • Page 30: Troubleshooting

    SECTION 5 TROUBLESHOOTING SELF CHECK FEATURE 5.1.1 OUTLINE This unit comes with the "Self check" feature, which checks the SERVICE MENU SCREEN operational state of the circuit and displays/saves it during Service Menu failure. Diagnosis is performed when power is turned on, and 1.Digital Service 2.TV-Micro Service information input to the main microcomputer is monitored at all...
  • Page 31 5.1.6 DETAILS Self check is performed for the following items: 5.1.6.1 PAGE 1 OF SCREEN Diagnosis Detection item Display Detection content Detection timing signal (line) X-ray protection X-RAY Not used. B1 over-current Not used. protection Low bias line short Not used. protection Timer (clock) The power frequency is changed as...
  • Page 32 Victor Company of Japan, Limited CRT Display Category 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan (No.YA387) Printed in Japan...
  • Page 33 SCHEMATIC DIAGRAMS COLOR TELEVISION AV-27F577 , AV-27F577 AV-32F577 , AV-32F577 AV-32F577 CD-ROM No.SML200605 BASIC CHASSIS COPYRIGHT © 2006 Victor Company of Japan, Limited. No.YA387 2006/5...
  • Page 34: Standard Circuit Diagram

    AV-27F577 AV-27F577 AV-32F577 AV-32F577 AV-32F577 STANDARD CIRCUIT DIAGRAM NOTE ON USING CIRCUIT DIAGRAMS 1.SAFETY Type No indication : Ceramic capacitor The components identified by the symbol and shading are : Metalized mylar capacitor critical for safety. For continued safety replace safety ciritical : Polypropylene capacitor components only with manufactures recommended parts.
  • Page 35: Circuit Diagrams

    LED & POWER SW PWB PATTERN ......................2-22 L/F PWB PATTERN ..........................2-23 USB PWB PATTERN ..........................2-23 VOLTAGE CHARTS .................. 2-25 WAVEFORMS .................... 2-26 USING P.W. BOARD PWB ASS'Y name AV-27F577/R AV-27F577/S AV-32F577/R AV-32F577/Y AV-32F577/Z MAIN P.W. BOARD SGJ-1308A-M2...
  • Page 36 BLOCK DIAGRAM AV SW PWB Y1/C1 INPUT -1 IC5001 AV SW L1/R1 VOUT Y2/V2 COUT Y1/C1 YOUT Y2/Pb2/Pr2 INPUT -2 L1/R1 CRT SOCKET PWB L2/R2 L2/R2 LOUT ROUT L3/R3 LTV/RTV L-ATSC R-ATSC Q3304 AUDIO OUT L/R R/G/B Q3306 AUDIO RGB OUT AUDIO_L AUDIO_R Q3103...
  • Page 37 SHEET 2 Y010 MAIN_POW Y007 Y015 TGND CN0E7 CN0E5 Y003 OPEN OPEN AGND MAIN PWB ASS'Y(1/2) SGJ-1308A-M2 [AV-27F577/R] CN0S3 CN00E SGJ-1302A-M2 [AV-27F577/S] CN00G SGJ-1313A-M2 [AV-32F577/R] CRT SOCKET PWB SGJ-1301A-M2 [AV-32F577/Y] FRONT CONTROL PWB CN300E CN600G SHEET 4 SGJ-1307A-M2 [AV-32F577/Z] SHEET 5 (No.YA387)2-5...
  • Page 38 R917 100k 1.5k 3.3k Q543 C918 PC921 HS005 IC921 C922 OPEN R973 R972 2.7k MAIN PWB ASS'Y(2/2) C971 SGJ-1308A-M2 [AV-27F577/R] Q971 SGJ-1302A-M2 [AV-27F577/S] R975 D972 SGJ-1313A-M2 [AV-32F577/R] Y501 R977 C972 R978 D973 SGJ-1301A-M2 [AV-32F577/Y] SGJ-1307A-M2 [AV-32F577/Z] C999 C998 GND1 (No.YA387)2-7...
  • Page 39 AV SW PWB CIRCUIT DIAGRAM SHEET 3 AV SW PWB ASS'Y C5001 SGJ-5301A-M2 R5001 D5002 D5003 R5037 R5038 R5039 R5040 R5041 C5017 R5042 C5018 R5043 R5044 C5002 6.8k 6.8k .1/16 6.8k .1/16 6.8k R5002 D5001 R5045 C5020 6.8k 4.7/50 R5003 D5004 J5001 C5003...
  • Page 40 CN30SC HS3010 HS3011 HS3012 OPEN OPEN OPEN C3363 .001 C3332 C3331 C3333 CN30E2 180p CRT SOCKET PWB ASS'Y 180p 180p SGJ-3304A-M2 [AV-27F577/R] R3331 R3332 TP-E1 TP-E1 SGJ-3302A-M2 [AV-27F577/S] R3333 2.2k R3334 2.2k C3302 2.2k C3301 1.8k 390p C3303 560p 560p...
  • Page 41 FRONT CONTROL PWB CIRCUIT DIAGRAM SHEET 5 Y6401 OPEN C6401 J6401 LC6401 CN600R R6401 Y6402 OPEN AV SW PWB CN500R Y6403 SHEET 3 OPEN C6402 R6402 J6402 220k K6401 Y6407 LC6402 OPEN Y6404 OPEN Y6405 R6403 OPEN C6403 J6403 220k LC6403 Y6406 OPEN...
  • Page 42 LED & POWER SW PWB CIRCUIT DIAGRAM SHEET 6 USB PWB CIRCUIT DIAGRAM SHEET 7 USB PWB ASS'Y CN800L IC7701 SGJ-8302A-M2 D8002 J8001 D8001 R8001 R8002 S7701 R7701 D7701 1.5k C7701 R7702 IC8001 TPS2041BD-X D8003 C8003 C8002 C8001 C8005 CN700B D8004 Q7701 R7704...
  • Page 43 L/F PWB CIRCUIT DIAGRAM SHEET 8 CN90E3 L/F PWB ASS'Y SGJ-9302A-M2 [AV-27F577/R, AV-27F577/S] SGJ-9301A-M2 [AV-32F577/R, AV-32F577/Y, AV-32F577/Z] Y991 MAIN PWB(2/2) CN00F R999 SHEET 2 CN900F C997 T951 R998 2.7M Y908 Y904 OPEN OPEN Y907 Y903 OPEN OPEN MAIN PWB(2/2) CN00W...
  • Page 44 PATTERN DIAGRAMS CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S) MAIN PWB PATTERN AND ROHM'S MFR'S TYPE CP(S). W243 C111 C110 Y007 Y007 W242 D531 R554 W243 W242 CN0S1 CN00A D521 C111 C110 CN0S3 Y015...
  • Page 45 AV SW PWB PATTERN FRONT CONTROL PWB PATTERN LED & POWER SW PWB PATTERN CL5001 D5018 R5002 D5019 D5017 R5002 R5078 R5078 IC5002 R5075 R5071 R5075 C5014 R5077 R5077 R5074 R6704 R5074 C5009 C5016 R5073 IC5001 W5409 R5073 R5044 R5076 W5220 D5012 R5013...
  • Page 46 L/F PWB PATTERN R999 Y991 Y908 Y904 Y903 Y907 FRONT LF902 LF901 Y901 Y905 Y902 Y906 FC902 F901 USB PWB PATTERN FRONT J8001 IC8501 D8003 C8501 D8004 C8004 C8003 W8003 CN800L C8001 C8005 IC8001 C8002 (No.YA387)2-23 2-24(No.YA387)
  • Page 47 VOLTAGE CHARTS WAVEFORMS <MAIN PWB> <AV SW PWB> <CRT SOCKET PWB> [P.2-13-P.2-14] [P.2-19-P.2-20] [P.2-15-P.2-16] [P.2-17-P.2-18] MAIN PWB(1/2) MODE MODE MODE MODE MODE MODE MODE DC (V) DC (V) DC (V) DC (V) DC (V) DC (V) DC (V) PIN NO. PIN NO.
  • Page 48 Victor Company of Japan, Limited CRT Display Category 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama-city, kanagawa-prefecture, 221-8528, Japan (No.YA387) Printed in Japan...
  • Page 49: Parts List

    PARTS LIST CAUTION The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the  safety. The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied. P.W.
  • Page 50 USING P.W. BOARD & REMOTE CONTROL UNIT ....................3-3 EXPLODED VIEW PARTS LIST -1 ..........................3-4 EXPLODED VIEW -1 ..............................3-5 PRINTED WIRING BOARD PARTS LIST [AV-27F577/R] ..................3-6 MAIN P.W. BOARD ASS'Y (SGJ-1308A-M2) ....................3-6 CRT SOCKET P.W. BOARD ASS'Y (SGJ-3304A-M2) ..................3-8 AV SW P.W.
  • Page 51: Using P.w. Board & Remote Control Unit

    USING P.W. BOARD & REMOTE CONTROL UNIT P.W.B ASS'Y No. P.W.B ASS'Y name AV-27F577/R AV-27F577/S AV-32F577/R AV-32F577/Y AV-32F577/Z MAIN P.W.B SGJ-1308A-M2 SGJ-1302A-M2 SGJ-1313A-M2 SGJ-1301A-M2 SGJ-1307A-M2 CRT SOCKET P.W.B SGJ-3304A-M2 SGJ-3302A-M2 SGJ-3305A-M2 SGJ-3301A-M2 SGJ-3303A-M2 ← ← ← ← AV SW P.W.B SGJ-5301A-M2 ←...
  • Page 52: Exploded View Parts List -1

    DEG COIL AV-27F577R,AV-27F577S  L01 QQW0116-001 DEG COIL AV-32F577R,AV-32F577Y  L01 QQW0176-001 DEG COIL AV-32F577Z  T502 QQH0175-001 FB TRANSFER CM48006-010-C JVC MARK LC30191-003A-A REMOCON WINDOW LC20628-001D-A DOOR CM48229-00A-C DOOR LATCH LC31238-004A-A OPERATION SHEET LC31237-001B-A POWER KNOB CM36481-002A-A SPRING LC10878-018A-A...
  • Page 53: Exploded View -1

    EXPLODED VIEW -1 < FRONT SIDE VIEW > T502 REAR <AV-27F577> <AV-32F577> RATING LABEL (No.YA387)3-5...
  • Page 54: Main P.w. Board Ass'y (Sgj-1308A-M2)

    PRINTED WIRING BOARD PARTS LIST [AV-27F577 MAIN P.W. BOARD ASS'Y (SGJ-1308A-M2) Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local D945 MTZJ9.1B-T2 Z DIODE D952 1SS133-T2 SI DIODE IC101 CXA2094Q-X D953 1SS133-T2 SI DIODE IC201 TM8812CSDNG6H60 IC(MCU) D954...
  • Page 55 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C623 NCB31HK-102X C CAPACITOR 1000pF 50V K R006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J C624 NCB31CK-334X C CAPACITOR 0.33uF 16V K R007 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 56: Crt Socket P.w. Board Ass'y (Sgj-3304A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R653 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L851 QQR1401-001 CHOKE COIL R654 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L853 QQL26AK-330Z CHOKE COIL 33uH K R661 NRSA63J-822X...
  • Page 57: Av Sw P.w. Board Ass'y (Sgj-5301A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R3126 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J C5003 QETN1HM-106Z E CAPACITOR 10uF 50V M R3127 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J C5004 QETN1HM-225Z E CAPACITOR 2.2uF 50V M R3128 NRSA63J-122X...
  • Page 58: Front Control P.w. Board Ass'y (Sgj-6301A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R5053 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7702 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R5054 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7703 NRSA63J-101X MG RESISTOR 100Ω...
  • Page 59: Printed Wiring Board Parts List [Av-27F577/S]

    PRINTED WIRING BOARD PARTS LIST [AV-27F577 Ref No. Part No. Part Name Description Local MAIN P.W. BOARD ASS'Y (SGJ-1302A-M2) Ref No. Part No. Part Name Description Local D945 MTZJ9.1B-T2 Z DIODE D952 1SS133-T2 SI DIODE D953 1SS133-T2 SI DIODE IC101 CXA2094Q-X D954 1N4003SG-T2...
  • Page 60 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C623 NCB31HK-102X C CAPACITOR 1000pF 50V K R006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J C624 NCB31CK-334X C CAPACITOR 0.33uF 16V K R007 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 61: Crt Socket P.w. Board Ass'y (Sgj-3302A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R653 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L851 QQR1401-001 CHOKE COIL R654 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L853 QQL26AK-330Z CHOKE COIL 33uH K R661 NRSA63J-822X...
  • Page 62: Av Sw P.w. Board Ass'y (Sgj-5301A-M2)

    Ref No. Part No. Part Name Description Local R3126 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R3127 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R3128 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R3129 NRSA63J-100X MG RESISTOR 10Ω 1/16W J R3130 NRSA63J-820X MG RESISTOR 82Ω...
  • Page 63: Printed Wiring Board Parts List [Av-32F577/R]

    PRINTED WIRING BOARD PARTS LIST [AV-32F577 Ref No. Part No. Part Name Description Local MAIN P.W. BOARD ASS'Y (SGJ-1313A-M2) Ref No. Part No. Part Name Description Local D945 MTZJ9.1B-T2 Z DIODE D952 1SS133-T2 SI DIODE D953 1SS133-T2 SI DIODE IC101 CXA2094Q-X D954 1N4003SG-T2...
  • Page 64 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C625 NCB31HK-822X C CAPACITOR 8200pF 50V K R008 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J C627 NCB31CK-105X C CAPACITOR 1uF 16V K R101 NRSA63J-221X MG RESISTOR 220Ω...
  • Page 65: Crt Socket P.w. Board Ass'y (Sgj-3305A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R653 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L851 QQR1401-001 CHOKE COIL R654 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L853 QQL26AK-330Z CHOKE COIL 33uH K R661 NRSA63J-822X...
  • Page 66: Av Sw P.w. Board Ass'y (Sgj-5301A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R3126 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R999 QRE121J-121Y C RESISTOR 120Ω 1/2W J R3127 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R3128 NRSA63J-122X MG RESISTOR 1.2kΩ...
  • Page 67: Printed Wiring Board Parts List [Av-32F577/Y]

    PRINTED WIRING BOARD PARTS LIST [AV-32F577 Ref No. Part No. Part Name Description Local MAIN P.W. BOARD ASS'Y (SGJ-1301A-M2) Ref No. Part No. Part Name Description Local D945 MTZJ9.1B-T2 Z DIODE D952 1SS133-T2 SI DIODE D953 1SS133-T2 SI DIODE IC101 CXA2094Q-X D954 1N4003SG-T2...
  • Page 68 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C625 NCB31HK-822X C CAPACITOR 8200pF 50V K R008 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J C627 NCB31CK-105X C CAPACITOR 1uF 16V K R101 NRSA63J-221X MG RESISTOR 220Ω...
  • Page 69: Crt Socket P.w. Board Ass'y (Sgj-3301A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R654 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L853 QQL26AK-330Z CHOKE COIL 33uH K R661 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J L854 QQL26AK-470Z CHOKE COIL 47uH K R662 NRSA63J-472X...
  • Page 70: Av Sw P.w. Board Ass'y (Sgj-5301A-M2)

    Ref No. Part No. Part Name Description Local R3127 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R3128 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R3129 NRSA63J-100X MG RESISTOR 10Ω 1/16W J R3130 NRSA63J-820X MG RESISTOR 82Ω 1/16W J R3131 NRSA63J-331X MG RESISTOR 330Ω...
  • Page 71: Printed Wiring Board Parts List [Av-32F577/Z]

    PRINTED WIRING BOARD PARTS LIST [AV-32F577 Ref No. Part No. Part Name Description Local MAIN P.W. BOARD ASS'Y (SGJ-1307A-M2) Ref No. Part No. Part Name Description Local D945 MTZJ9.1B-T2 Z DIODE D952 1SS133-T2 SI DIODE D953 1SS133-T2 SI DIODE IC101 CXA2094Q-X D954 1N4003SG-T2...
  • Page 72 Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local C625 NCB31HK-822X C CAPACITOR 8200pF 50V K R008 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J C627 NCB31CK-105X C CAPACITOR 1uF 16V K R101 NRSA63J-221X MG RESISTOR 220Ω...
  • Page 73: Crt Socket P.w. Board Ass'y (Sgj-3303A-M2)

    Ref No. Part No. Part Name Description Local Ref No. Part No. Part Name Description Local R654 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J L853 QQL26AK-330Z CHOKE COIL 33uH K R661 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J L854 QQL26AK-470Z CHOKE COIL 47uH K R662 NRSA63J-472X...
  • Page 74: Av Sw P.w. Board Ass'y (Sgj-5301A-M2)

    Ref No. Part No. Part Name Description Local R3127 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R3128 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R3129 NRSA63J-100X MG RESISTOR 10Ω 1/16W J R3130 NRSA63J-820X MG RESISTOR 82Ω 1/16W J R3131 NRSA63J-331X MG RESISTOR 330Ω...
  • Page 75: Remote Control Unit Parts List (Rm-C1290G-1C)

    REMOTE CONTROL UNIT PARTS LIST (RM-C1290G-1C)  Ref.No. Part No. Part Name Description Local 10030-0006800 BATTERY COVER PACKING PACKING PARTS LIST  Ref.No. Part No. Part Name Description Local LC10181-025C-A PACKING CASE AV-27F577R,AV-27F577S LC10181-026C-A PACKING CASE AV-32F577R,AV-32F577Y,AV-32F577Z LC10884-002B-A CUSHION ASSY 4pcs in 1set AV-27F577R,AV-27F577S LC11049-002B-A...
