Utax CD 5025 Technical Bulletin

Utax CD 5025 Technical Bulletin

Color laser mfp up to 20ppm
Hide thumbs

Advertisement

Quick Links

Download this manual
Technical Bulletin
TB 01 / Firmware Upgrade (V1.02)
T
:
OPIC
 Support for BAM.
This is corrected for shortening and stabilizing the recovery time from the power saving priority mode.
 Measure against the problem when setting the FAX initial screen into the one-touch screen.
When setting the FAX initial screen to the one-touch screen, the time may require to newly receive the address selection if
canceling the address by pressing "Reset Key" after selecting the one-touch registration address.
Therefore, this is corrected. - (The above can be released by the auto panel reset or pressing the cancel button.)
 Lateral spread from other models.
A certain barcode may not be normally printed out. - Therefore, this is corrected.
The two-dimensional barcode may not be printed out with a certain file. - Therefore, this is corrected.
This is corrected for preventing CF248 error with a certain data.
Type
MAIN
MMI
ENGINE
LANGUAGE BR
IO
DP
FAX BOOT/APL
ESPECIAL
When upgrading firmware or replacing board etc., please upgrade each firmware (MAIN, ENGINE and MMI) to the latest version at the
same time.
Classification:
Field Measure:
Serial Nos.:
UPGRADE PACK V1.02E
Program No.
2K3_2F00.001.403
2K3_7000.001.404
2K3_1000.004.002
2K3_81BR.001.004
2K3_1E00.001.010
3M8_9500.002.001
5JR_5500.B01.019
ES_SKIP.ON
Entire Stock Rework
In-Field modification at next visit
In-Field modification by case
X
No modification necessary
No particular problems are expected.
CD
5025P
– DC
6025P
CD 5025P – DC 6025P
CD
5030P
– DC
6030P
UTAX
UTAX
UTAX
VER.
Remarks
001.403
001.404
004.002
001.004
001.010
002.001
B01.019
BOOT(B01.019), APL(B01.019)
----------
Planned from the production in February 2011
CD
CD 5025P
CD
TA
DC
TA
DC 6025P
TA
DC
New upgrade
New upgrade
New upgrade
5025P
5030P
6025P
6030P
2K3-B053/M
Date: 28-02-2011
1/1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CD 5025 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Utax CD 5025

Summary of Contents for Utax CD 5025

  • Page 1 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 01 / Firmware Upgrade (V1.02) 2K3-B053/M Date: 28-02-2011 OPIC  Support for BAM. This is corrected for shortening and stabilizing the recovery time from the power saving priority mode.
  • Page 2 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 02 / Firmware Upgrade (V1.04E) - Fax System U 5JR-B104/M Date: 28-04-2011 OPIC The firmware is upgraded as follows. ONTENT OF CHANGES  Improving margin for communication between the controller board and FAX board There is little margin for detecting connection between the controller board and FAX board and in case the condition is worse depending on variation of the resistance value on the FAX board, system error *CF14A or CF378 may rarely appear.
  • Page 3 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 03 / Firmware Upgrade (V2.00) 2K3-B124/M Date: 18-05-2011 OPIC The firmware is upgraded as follows. ONTENT OF CHANGES  Measures against JAM5001 (Bridge conveying sensor 3 non arrival jam) The leading edge of paper may stop at the roller at the DF side of the bridge unit in the conditions below with continuous output fed from the standard cassette and ejected to DF-470, and JAM5001(Bridge conveying sensor 3 non arrival jam) may appear.
  • Page 4 Change of default display when pressing Favorite key. Before After Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please upgrade the firmware when the above phenomenon arises. Field Measure:   5025P - DC 6025P Serial No.:...
  • Page 5 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 04 / Blank copy output with DP scanning 2K3-B119/M Date: 30-05-2011 OPIC Note when fitting the upper left cover and rear cover. Service manual and service training materials state checking the optical lock lever is released when fitting the upper left cover.
  • Page 6 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 05 / Note when replacing the main board (C0180) 2K3-B137/M Date: 30-05-2011 OPIC The above models are not equipped with a HDD and some data is saved in the main board instead.
  • Page 7 Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please operate the above when replacing the main board. Field Measure:   Serial No.:...
  • Page 8 2K3-B149/M Date: 10-06-2011 OPIC Non relevant for UTAX / Triumph-Adler. ONTENT OF CHANGES  Eliminating encrypted FAX function for China. Related menu is hidden to disable settings for encryption from the operation panel. (It is also hidden or disabled on the Command Center and KMNV.)
  • Page 9 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 07 / Resetting partial operation control Beh-Hab/M Date: 16-06-2011 OPIC To be reset after partial operation is performed due to problems in the cassettes or other sections, and the related parts are serviced.
  • Page 10 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 08 / Paper stack when ejecting to the upper tray 2K3-B185/M Date: 08-07-2011 OPIC Depending on the condition of curled paper printed in duplex, it may push out the page ejected before it, and the page order may not be correct, in case a large volume of paper is ejected with the bridge unit attached.
  • Page 11 Q’ty Compatibility Old Part New Part Description Remarks Old New ------------ 2K394860 STOPPER PAPER C ASSY (service part only) Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please attach the stopper (No.1) in case the duplexed pages are ejected in Field Measure: the wrong order.
  • Page 12 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 09 / Change the shape of the USB host slot 2K3-B196/M Date: 08-07-2011 OPIC The USB host slot is located at the side of the operation panel and has a depth of the surface.
  • Page 13 Q’ty Compatibility Old Part New Part Description Remarks Old New ------------ 2K394870 COVER OPE LOW SET SET (*) 2K305021 2K305022 COVER OPERATION LOW * A set of No.2 and MOUNT USB. Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please note the old type cover is only compatible with the old type MOUNT USB.
  • Page 14 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 10 / Correcting Parts List – FIG. 8 >SENSOR ORIG.< PCI-B204/M Date: 18-07-2011 OPIC The parts number of the SENSOR ORIGINAL (No.1) is registered. FIG. 8 Scanner Section Q’ty...
  • Page 15 Change: Command Center Error No is changed to 3101.  UTAX/TA model names are indicated in the report prints. The UTAX/TA model names are indicated on the report prints when the destination is set to UTAX/TA.  Pause message change.
  • Page 16  Adding the operation panel display for the DF connection error. The attachment is fitted to the bridge and they are attached to the main machine when installing the DF, but the bridge may be attached without the attachment. Then, the C8990 of Document finisher communication error appears. Therefore, the explanation with the illustration is added to the operation panel display so that it is confirmed fitting the attachment is omitted.
  • Page 17 FIRMWARE / UPGRADE PACK V4.00 Type Program No. VER. Remarks MAIN 2K3_2F00.004.019 004.019 2K3_7000.004.019 004.019 ENGINE 2K3_1000.006.001 006.001 LANGUAGE BR 2K3_81BR.001.009 001.009 2K3_1E00.001.010 001.010 3M8_9500.004.001 004.001 FAX BOOT/APL 5JR_5500.B04.003 B04.003 ESPECIAL ES_SKIP.ON ---------- When upgrading firmware or replacing board etc., please upgrade each firmware (MAIN, ENGINE and MMI) to the latest version at the same time.
  • Page 18 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 12 / Change of the LVU main PWB 2K3-B031/M Date: 30-09-2011 OPIC PARTS LVU MAIN 200 SP (No.1) is changed as below for parts procurement ease.
  • Page 19 Procedures for detaching/refitting the cover when replacing the LVU main PWB Detailed figure Procedure Remove the controller box cover at the lower right side of the machine rear side. Remove the rear cover. Remove the left lower cover. Remove the front upper cover at the machine front side.
  • Page 20 Procedures for detaching/refitting the cover when replacing the LVU main PWB Detailed figure Procedure Remove the inner tray. (When refitting it, please fit the hook (X) at the machine inner side and the hook (Y) at the machine left side.) There is the LVU main PWB in the left figure that appears after removing the inner tray.
  • Page 21 Technical Bulletin UTAX 5025P UTAX CD 5025P 5030P 6025P DC 6025P 6030P TB 13 / Correcting Parts List - FIG. 15 >FASTENER MAT< PCI-B329/M Date: 19-10-2011 OPIC The parts numbers of the CUSHION ORIGINAL MAT and SPONGE ORIGINAL MAT are registered.
  • Page 22 Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Field Measure:   5020P / DC 6025P Serial Nos.: CD 5025P / DC 6025P Service information only 5030P / DC 6030P CDC 5520 / DCC 6520 CDC 5525 / DCC 6525 ...
  • Page 23 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 14 / Cassette withdrawing failure with stiffness 2K3-B432/M Date: 02-01-2012 OPIC If the following conditions occur together, the boss of the paper width cursor support point at the backside of the cassette contacts the machine base edge protection material as variation across the ages and it may be so stiff to withdraw the cassette.
  • Page 24 OW TO INSTALL THE GUIDE A: GUIDE B: screw Cassette backside - Clean where to affix GUIDE at the cassette backside with alcohol. - Peel off the release paper for double coated adhesive paper as marked A for GUIDE and affix GUIDE aligning to the boss and screw hole and fix it with the screw.
  • Page 25 Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please install the parts No.1 in the cassette when the above phenomenon arises. Field Measure:   5025P / DC 6025P Serial Nos.: CD 5025P / DC 6025P Planned from November 2011 production 5030P / DC...

  • Page 26: Corrective Measures

    Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 15 / Corrective measures for the J9000 jam (DP) 2K3-B446/M Date: 03-01-2012 OPIC The DP feed roller does not descend and the J9000 (no original feed jam) may appear.
  • Page 27 Mechanism of occurrence Normal operation High stack originals intensely set Degree of adherence between the rib seal and stopper is intense. Top cover rib Top cover rib Original intensely set Stopper Original Stopper 1) Set the original. 1) Set the high stack original intensely. 2) Drive starts and the DP feed roller descends.
  • Page 28 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 16 / Full-page solid image or C3200 (MAIN BOARD…) 2K3-B292/M Date: 08-02-2012 OPIC The full-page solid image is output or the C3200 error (Exposure lamp error) appears when copying.
  • Page 29 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 17 / Abnormal noise from the drum unit 2K3-C073/M Date: 03-04-2012 OPIC An abnormal noise of squeaks may be heard from the shaft of ROLLER,MC CLN and its bushing.
  • Page 30 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 18 / Firmware Upgrade (V5.00) 2K3-C082/M Date: 16-04-2012 OPIC firmware is upgraded as follows. ONTENT OF CHANGES  Auto rotated manual copy setting is supported in the system menu.
  • Page 31  Corrective measures for the scanning failure with large volume originals. Scanning may fail with large volume original if initiated from the PC. - Therefore, this is corrected.  Corrective measures for the image failure when outputting from a certain CAD software. White streaks image may be output when printing from certain CAD software.

  • Page 32: System Menu

     Corrective measures for the F245 error at on-hook sending in the FAX display. The F245 error may appear at on-hook sending in the FAX display with the branch exchange turned off and with the network administrator authentication. - Therefore, this is corrected. ...
  • Page 33 FFSET ONE PAGE DOCUMENT IS SUPPORTED … SYSTEM MENU  Common Settings  Offset One Page Documents (not indicated when no finisher is installed)  Off  On default Offset one page document is now switchable while it is not currently supported . *Offset is not applied to multiple sets from 1 page original.
  • Page 34 COVER ISU FRONT (color machine) *1: only for CD 5025, CD 5025P, CD 5030 / DC 6025, DC 6025P, DC 6030 (b/w machines) *2: only for CDC 5520, CDC 5525 / DCC 6520, DCC 6525 (color machines) Note: Please use the new type parts for the new development models.
  • Page 35 Entire Stock Rework Classification: In-Field modification at next visit In-Field modification by case No modification necessary Please replace with the new type parts when the cover (No.1 to 3) is abraded. Field Measure:   5025P - DC 6025P Serial No.: After using up the old stock.
  • Page 36 All the affected models resistance. (No.1) (PC+ABS  PC) change The shape of the actuator (No.2) is changed after the CD 5025 / DC 6025 above change 1). CD 5025P / DC 6025P Actuator (The new type lift plate is heat-resistant, but less rigid that...
  • Page 37 Lift plate Actuator Failure to occur [Empty] is detected thought the paper is still remaining. The lift plate bends with its less rigidity to fail to detect paper full Phenomenon detail Actuator Sensor 2 Sensor 1 Remaining paper level detail Empty Normal High-Full...
  • Page 38 ROCEDURE TO REPLACE THE LIFT PLATE Take out the cassette from the machine. Lift plate Machine front side Remove the side A of the lift plate as indicated in the above procedure 1 Bend and lift up the lift plate while pushing the hook of the cassette frame.
  • Page 39 ROCEDURE TO REPLACE THE ACTUATOR Unlatch the hook (D) of the actuator from the latch and unlatch the cross shape emboss (E) while pulling it toward the machine front side (to the direction of the arrow). Machine rear side (Viewed from the machine rear side) Machine rear side Machine front side Fit the hook (D) of the new type actuator...
  • Page 40 *1: Set up for the service parts this time *2: PF-471  Qty 2 pcs, Other models  Qty 1 pc. *3: CD 5025, CD 5025P, CD 5030 / DC 6025, DC 6025P, DC 6030  Qty1 pc. PF 470  Qty 1 pc.
  • Page 41  Change of the initial setting in the U285 [Setting service status page] for TA/UTAX only. The initial setting of the maintenance mode U285 is changed from “OFF” to “ON” that was set up for TA/UTAX only. The print coverage is indicated on the service status page by setting ON in U285.
  • Page 42  DP firmware  Support for the new models. The upgraded firmware for supporting the 306i and 256i is used for this models as horizontal spread. FIRMWARE / UPGRADE PACK V 6.00 Type Program No. Remarks  MAIN 2K3_2F00.006.004 2K3_7000.005.016 ...
  • Page 43 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 22 / Correcting Parts List - Document Proc. >PULLEY..< Beh-Dur/M Date: 06-09-2012 OPIC The parts numbers are set to the following parts (No.1 to 4). Q’ty...
  • Page 44 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 23 / Measure for the developing unit detection failure 2K3-C234/M Date: 10-09-2012 OPIC The detection PWB for the developing unit may be attached while being tilted counterclockwise depending on structural variation because there is backlash between the detection PWB and its holder at the main machine.
  • Page 45 IELD MEASURE 1. Open the right cover 1 and the front cover. 2. Release the lock lever and then remove the waste toner box. 3. Release the toner container lever (blue) and then remove the toner container. 4. Release the 2 lock levers (yellow) and open the developing cover. 5.
  • Page 46 ETAILED CONTENT OF CHANGES Temporary measures - Attached the detection PWB in the holder while aligning it rightwards. - Checked if the main machine detects the detection PWB for the developing unit at factory. Backside of the left figure Holder (Not supply parts individually) The detection PWB is movable horizontally...
  • Page 47 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 24 / Firmware Upgrade (V6.01) 2MW-C339/M Date: 16-01-2013 OPIC firmware is upgraded as follows. ONTENT OF CHANGES  Corrective measures for the wrong detection at the cassette.
  • Page 48 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please upgrade the firmware when the above phenomenon arises.   Serial No.: 5025P - DC 6025P Planned from December, 2012 production. CD 5025P - DC 6025P 5030P - DC...
  • Page 49 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 25 / PF 470 - Correcting Parts List >BELT FEED PF< Beh/M Date: 28-01-2013 OPIC The parts number is set up for the part. BELT FEED PF -No.11...
  • Page 50 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 26 / Abnormal noise from DP (gear step-out noise) 2MV-D139/M Date: 19-07-2013 OPIC When the power is turned on or paper is fed to the DP, the engagement of gears (A,B) may drift and abnormal noise due to the gears step-out depending on the variation of the parts.
  • Page 51 OW TO REPLACE THE SPRING Remove the rear cover (unlatch 2 hooks). Rear cover Open the DP top cover and remove the inner cover (unlatch 5 hooks). Inner cover Replace the spring. No.11 Spring Old Part New Part Q’ty Compatibility Description Remarks 3M807160...
  • Page 52 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 27 / Corrective measure for the DP hang-down COM-D156/M Date: 13-08-2013 OPIC The DP may hang down from its high position if the force to hold the hinge when the DP is opened is deteriorated after the prolonged use.
  • Page 53 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Replace with the new spring (No.1) when the above phenomenon arises.   Serial Nos.: 5025P 6025P CD 5025P / DC 6025P No production 5030P 6030P...
  • Page 54 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 28 / Correcting Parts List - ARM SIZE DETECTION PCI-D182/M Date: 11-09-2013 OPIC The ARM SIZE DETECTION (No.1) at backside of the cassette is supplied as service parts.
  • Page 55 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please order the parts according to the necessity.   Serial Nos.: 5025P 6025P CD 5025P / DC 6025P 5030P 6030P 5520P 6520P 5525P 6525P...
  • Page 56 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 29 / Firmware Upgrade (V6.02N) 2MW-D230/M Date: 12-11-2013 OPIC The firmware is upgraded as follows. ONTENT OF CHANGES  Corrective measures for the DP stepping-out at low temperature environment.
  • Page 57 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please upgrade the firmware when the above phenomenon arises.   Serial Nos.: 5025P / DC 6025P CD 5025P / DC 6025P No production.
  • Page 58 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB 30 / Note when detaching the GUIDE PF at the DP COM-D259/M Date: 08-01-2014 When detaching the GUIDE PF from the DP, first twist the DP rear side of the GUIDE PF to vertically stand the fulcrum part of the GUIDE PF.
  • Page 59 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure:   Serial Nos.: 5025P / DC 6025P CD 5025P / DC 6025P 5030P / DC 6030P CDC 5520 / DCC 6520P CDC 5525 / DCC 6525P 256ic...
  • Page 60 TB 31 / Corrective measures for J9000, J9200 and J9410 2MW-E004/M Date: 20-02-2014 Only  CD 5025, CD 5030 / DC 6025, DC 6030 ONTENT OF CHANGES The paper jam J9000/J9200/J9410 (Note1) may occur due to the following causes. Thus, the following are changed.
  • Page 61 Mechanism of the phenomenon A occurrence- Normal condition Wrong condition The original stopper is not The original stopper is (When conveying the original stack) riding on the rib of the DP top riding on the rib of the DP cover. top cover.
  • Page 62 Mechanism of the phenomenon C occurrence- DP top cover Original detection actuator View from top Normal condition Wrong condition DP original sensor Original detection actuator If the original detection actuator is located toward the machine front side (in the arrow X direction) depending on the parts variation, that actuator may ride on the DP original sensor, and it may cause misdetection.
  • Page 63 2MY_81BR.001.013 BROWSER 2M8_F000.001.002 2K0_1E00.001.020 2LC_1A00.002.001 2K0_1C00.002.002  NEW 3M8_9500.007.001  ESPECIAL ES_SKIP.ON CD 5025, CD 5025P, CD 5030 / DC 6025, DC 6025P, DC 6030 FIRMWARE UPGRADE PACK V 6.03N Type File Remarks MAIN 2K3_2F00.006.004 2K3_7000.005.016 ENGINE 2K3_1000.010.002  LANGUAGE 2K3_81BR.001.012...
  • Page 64 Old Part New Part Q’ty Compatibility Affected model Description Remarks For the 3M894021 3M894022 FEED ROLLER (DP) Phenomenon A 3M894051 3M894052 PARTS COVER PF ASSY SP For the Phenomenon C ----------- C2895130 SHIM 8.2-0.5T Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure:...
  • Page 65 TB 32 / DP - Parts Change Info: FEED ROLLER + GUIDE… PCI-C068/M Date: 20-02-2014 Only  CD 5025, CD 5030 / DC 6025, DC 6030 OPIC The following are changed to improve the margin for the DP pick-up holder elevation motion.
  • Page 66 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure:   Serial Nos.: 5025P / DC 6025P CD 5025P / DC 6025P 5030P / DC 6030P CDC 5520 / DCC 6520P CDC 5525 / DCC 6525P Parts Information only...
  • Page 67 Q’ty Remarks 256i, 306i, 2K393140 MC-475 CD 5025, CD 5025P, CD 5030 DC 6025, DC 6025P, DC 6030 CD 1435, CD 1445, CD 1455, CD 1465, CD 1480 2LF93020 MC-6705 DC 2435, DC 2445, DC 2445, DC 2465, DC 2480...
  • Page 68 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure:   Serial Nos.: 1435P 2435P 1445P 2445P 1455P 2455P 1465P 2465P 1480P 2480P 5025P 6025P CD 5025P / DC 6025P 5030P 6030P 1930P 2930P...
  • Page 69 Thickness of electroless nickel plating Thickness of electroless nickel plating 256i, 306i, 4 to 6μm 10 to 15μm CD 5025, CD 5025P, CD 5030 DC 6025, DC 6025P, DC 6030 Bigger size of Chamfer Material of shaft: SMG-CS Material of shaft: SUM24L No.2...
  • Page 70 Old Part New Part Q’ty Compatibility Affected model Description Remarks 2K393140 2K393141 MC-475 2LF93020 2LF93021 MC-6705 2K993060 2K993061 MC-8705 At Set Up Classification: Next Visit / Service Call Next Periodic Maintenance Information only No modification necessary Replace with new charge roller when the above phenomenon arises. Field Measure: ...
  • Page 71 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB-35B 2MV-E170/M Date: 14-10-2014 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: DP: blurred characters at about 35mm from the paper rear end...
  • Page 72 ROCEDURES Release the hooks at the machine front side by using a tool such as a flat-blade Hook screwdriver. Scanner guide Remove the scanner guide. Note: Make sure not to lose two springs between the scanner guide and the frame. Make sure not to lose the springs Remove two pulleys at the DP exit side.
  • Page 73 Reattach the scanner guide in order of the machine rear side and the machine front (Machine front side) side while paying attention to the spring. Note: At this time, reattach the scanner guide so that the guide (No.1) is below the black resin guide.
  • Page 74 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB-36B COM-E160/M Date: 15-12-2014 …A  highest priority / …B  second priority / …C  other / S… Service Information Priority: DP original size detection error (change of contact point lubricant) And ...
  • Page 75 ISASSEMBLY ROCEDURES DP 770, DP 770B Affected Model: CD 1435, CD 1445, CD 1455 / DC 2435, DC 2445, DC 2455 CDC 1930, CDC 1935, CDC 1945, CDC 1950 / DCC 2930, DCC 2935, DCC 2945, DCC 2950 3060i, 3560i, 3555i, 4555i, 5555i 2500ci, 3005ci, 3505ci, 4505ci, 5505ci Lift up the original tray and remove the screw to remove the strap.
  • Page 76 Insert a tool like flat-blade screwdriver and Tool release two hooks of the original table. After that, remove the original table. Hook *Take care so that the original width guide does not come off from the edge. If coming off, reattach taking care of the phase with the right and left side guides.
  • Page 77 Standard DP of CD 1465, CD 1480 / DC 2465, DC 2480 CDC 1965, CDC 1970 / DCC 2965, DCC 2970 6555i, 8055i 6505ci, 7505ci DP 771, DP 772 Affected Model: CD 1435, CD 1445, CD 1455 / DC 2435, DC 2445, DC 2455 CDC 1930, CDC 1935, CDC 1945, CDC 1950 / DCC 2930, DCC 2935, DCC 2945, DCC 2950 3060i, 3560i, 3555i, 4555i, 5555i 2500ci, 3005ci, 3505ci, 4505ci, 5505ci...
  • Page 78 Standard DP of CD 5025, CD 5030 / DC 6025, DC 6030 CDC 5520, CDC 5525 / DCC 6520, DCC 6525 256i, 306i 206ci, 256ci, 2550ci DP 773 Affected Model: 3060i, 3560i 2500ci Open the document processor. Release three hooks on the DP rear cover.
  • Page 79 Open the DP upper cover. DP upper cover Machine rear side Remove three clamps and pull out the wire from the holder. Clamp Wire Holder (Machine rear side) Wire is pulled out Wire 6/12...
  • Page 80 Machine front side Front cover Release the hook of the original table from the front cover. Hook Original table Machine rear side Pull the original table toward the machine front side and remove the wire holder of the original table. Wire holder *Removing the wire holder, work afterward will be easy.
  • Page 81 Remove three screws on the lower cover of the original table. Lower cover of original table Screw Open the upper cover of the original table. Upper cover of the original table Clean the detector plate fitted at the backside of the original table and the Backside of the upper cover of the original table board with alcohol and wipe them with a...
  • Page 82 DP 480 Affected Model: 1855, 2256 Open the DP upper cover. DP upper cover Machine front side Release the hook of the original table from the front cover. Hook Front cover Machine rear side Pull the original table toward the machine front side and remove the wire holder of the original table.
  • Page 83 Clean the detector plate fitted at the backside of the original table and the board with alcohol and wipe them with a dry cloth. Detector plate (Take care not to deform the detector plate when cleaning it.) Apply the gel type lubricant to the board. (Refer to page 1 for details of where to apply Hook it, etc.)
  • Page 84 (Refer to page two and after for the Disassembly Procedures.)    No production Serial Nos.: CD 1465 2465ci  No production CD 1480 2480ci  No production CD 5025 6025ci  No production CD 5030 6030ci  No production CDC 1965 2965ci  No production CDC 1970 2970ci ...
  • Page 85 EAFLET FOR APPLYING THE LUBRICANT 12/12...
  • Page 86 Technical Bulletin UTAX 5025P UTAX CD 5025P UTAX 5030P 6025P DC 6025P 6030P TB-37B 2MW-E218/M Date: 09-01-2015 …A  highest priority / …B  second priority / …C  other / S… Service Information Priority: Corrective measures for the Document Processor frame damage...
  • Page 87 EPLACEMENT ROCEDURES DP disassembly procedures Remove the DP front cover. (5 hooks) Hooks DP front cover Open the DP and remove the original mat. Original mat 3-1) Open the DP. 3-2) Release 3 hooks on the DP rear cover. Hook Hook Hook DP rear cover...
  • Page 88 Remove the DP rear cover. Hooks DP rear cover Remove the DP from the main unit. 6-1) Open the DP upper cover 6-2) Remove the ring stopper. Ring stopper 6-3) Remove the stopper. DP upper cover 6-4) Remove the DP top cover. Stopper 3/11...
  • Page 89 7-1) Remove 5 clamps. 7-2) Disconnect the wire connector connected to the PWB. Stopper (Machine rear side) Clamp 8-1) Remove the wire connector. Z: Connected to the PI sensor wire (*) Z’: Connected to the wire of the frame assembly (*) Z’...
  • Page 90 9-1) Remove the screw securing the wire Screw Screw Wire holder holder. 9-2) Remove the screw and connector. Remove the DP signal wire. Frame Signal wire Connector Take out the original tray while passing the original tray wire through the hole on the rear frame.
  • Page 91 (Machine front side) LED PWB 12-1) Disconnect the wire connector from the Upper conveying unit LED PWB. 12-2) Remove the wire from the hooks as marked with red circles in the figure to Connector the right. 12-3) Remove the access band. 12-4) Remove 2 screws securing the upper conveying unit.
  • Page 92 14-1) Remove the PI sensor, 2 clamps and the access band. Screws 14-2) Remove 4 screws and then remove the lower conveying unit. PI sensor Clamps Access band Screws Lower conveying unit Remove 6 screws indicated by red circles (one secured with the ground plate).
  • Page 93 Remove 4 screws indicated by red circles and then remove the right side hinge. Right side hinge 17-1) Remove the screw and then remove the Ground plate DP switch. DP switch 17-2) Remove 5 screws indicated by red circles (one secured together with the left side hinge) and then remove the left side hinge.
  • Page 94 Remove the DP lower cover. DP lower cover (Reverse side of the above) Latches DP lower cover Hooks DP reassembly procedures Affix SHEET LEFT GUIDE F and SHEET SHEET LEFT GUIDE F LEFT GUIDE R bundled to PARTS BASE 183,5mm ASSY SP after cleaning it with alcohol.
  • Page 95 Note when reassembling (Machine rear side) (Machine front side) Align wire within (When conducting the procedure 13) Upper conveying unit this range Reattach the upper conveying unit to the frame Check wire assembly in the following procedure. To avoid wire pinching at the work later, temporarily place the upper conveying unit on the frame assembly to check the wire alignment inside the unit.
  • Page 96 In-Field modification at next visit In-Field modification by case Information only No modification necessary Field Measure: Replace with the set parts (No1) when the above phenomenon arises.   Serial Nos.: CD 5025 6025ci CD 5030 6030ci CDC 5520 6520ci CDC 5525 6525ci...
