PRIMEQUEST 2800B3
System Configuration Guide
July 2017
Contents
1.
Overview
2.
Base Unit
3.
System Board (SB)
4.
CPU
5.
Memory
6.
I/O Unit
7.
Disk Unit (DU)
8.
HDD/SSD in Disk Unit
9.
PSU for Base Unit, Power Cord for Base Unit
10.
PCI Card
11.
Rack Installation
12.
Maximum Quantity of PCIe Cards
13.
Available OS
Change Report
FUJITSU Server PRIMEQUEST
System Configuration Guide
PRIMEQUEST 2800B3
1 / 28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIMEQUEST 2800B3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fujitsu PRIMEQUEST 2800B3

Summary of Contents for Fujitsu PRIMEQUEST 2800B3

  • Page 1 System Configuration Guide PRIMEQUEST 2800B3 PRIMEQUEST 2800B3 System Configuration Guide July 2017 Contents Overview Base Unit System Board (SB) Memory I/O Unit Disk Unit (DU) HDD/SSD in Disk Unit PSU for Base Unit, Power Cord for Base Unit PCI Card...

  • Page 2: Overview

    System Configuration Guide PRIMEQUEST 2800B3 1. Overview Front side Disk Unit System Board Rear side Power Supply Unit or Fan I/O Unit (1GbE) or I/O Unit (10GbE) Management Board FUJITSU Server PRIMEQUEST 2 / 28...

  • Page 3: Base Unit

    System Configuration Guide PRIMEQUEST 2800B3 1. Overview Part Number Legend: Part Number: MC-****** is a Build-to-Order (BTO) option to be assembled with a Base Unit at Fujitsu factory. MCX****** is an option to be shipped separately from a Base Unit...

  • Page 4: System Configuration Guide

    Memory Memory Memory The following options are included in the Base Unit. - 1x Management Board (MMB) - 1x Rack Mount Kit PRIMEQUEST 2800B3 Base Unit I/O Unit #0 I/O Unit #2 MCH3AC111B PCI Slot PCI Slot - Rack mount type...

  • Page 5: System Board

    System Configuration Guide PRIMEQUEST 2800B3 3. System Board MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory System Board for 2800B3 MC-3HSB91B / MCX3HSB91B (LD) - Min.
  • Page 6 System Configuration Guide PRIMEQUEST 2800B3 4. CPU MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 CPU Module Xeon E7-8894v4 Memory Memory 2.4GHz / 60MB LLC / 24 cores...
  • Page 7 System Configuration Guide PRIMEQUEST 2800B3 5. Memory MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory Memory Expansion Board MC-3HMB31B / MCX3HMB31B (LD) - 1 x Memory Expansion Board can be mounted per CPU.

  • Page 8: Memory Mode

    System Configuration Guide PRIMEQUEST 2800B3 Memory Mode MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Option Memory Memory Memory Memory Memory Mode Setting (Normal)

  • Page 9: System Board (Sb

    System Configuration Guide PRIMEQUEST 2800B3 Memory Mounting Condition 1. Memory and Memory Expansion Board (1) Memory for PRIMEQUEST is composed of 2 x DIMMs. (2) 6 sets (12 x DIMMs) can be mounted per CPU on System Board and 6 sets (12 x DIMMs) can be mounted on Memory Expansion Board.
  • Page 10 System Configuration Guide PRIMEQUEST 2800B3 Memory Mounting (1) DIMM mounting order on System Board The Memory needs to be mounted from a small number in accordance with the chart below. 2 x CPUs per System Board CPU#0 CPU#1 0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3...

  • Page 11: Memory

    System Configuration Guide PRIMEQUEST 2800B3 Memory Mounting (2) DIMM mounting order on System Board The memory needs to be mounted from a small number in accordance with the chart below. 2 x CPUs per System Board CPU#0 CPU#1 0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3...

  • Page 12: I/O Unit

    System Configuration Guide PRIMEQUEST 2800B3 6. I/O Unit MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory Min. 1 x I/O Unit needs to be mounted for either 1GbE or 10GbE.
  • Page 13 System Configuration Guide PRIMEQUEST 2800B3 7. Disk Unit MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory Disk Unit MC-5HDU21B / MCX5HDU21B (LD) - Max.
  • Page 14 System Configuration Guide PRIMEQUEST 2800B3 8. Internal HDD in Disk Unit MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory SAS RAID Controller Card is neccesary to mount internal HDD.
  • Page 15 System Configuration Guide PRIMEQUEST 2800B3 8. Internal SSD in Disk Unit MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory SAS RAID Controller Card is neccesary to mount internal SSD.
  • Page 16 System Configuration Guide PRIMEQUEST 2800B3 9. PSU for Base Unit MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory Memory Memory Memory 200V High Efficiency PSU...

  • Page 17: Pci Card

    System Configuration Guide PRIMEQUEST 2800B3 9. Power Cords for Base Unit for APAC and Americas MMB #0 PSU/ PSU/ PSU/ FAN #0 FAN #1 FAN #2 PSU/ PSU/ PSU/ FAN #3 FAN #4 FAN #5 SB #0 SB #2 Memory...
  • Page 18 System Configuration Guide PRIMEQUEST 2800B3 9. Power Cords for Base Unit for EMEA & India Base Unit Power Cords you need one cable for each PSU S26361-F3151-E301 T26139-Y3850-E10 Power Cord 16A No powercord as No mix of different power cords is possible.
  • Page 19 System Configuration Guide PRIMEQUEST 2800B3 10. PCI Card Base Unit I/O Unit PCI slot Single Channel 8Gbps Fibre Channel Card MC-0JFC31 / MCX0JFC31 (LD) LAN port - LPe1250, Low Profile Single Channel 8Gbps Fibre Channel Card MC-0JFC91 / MCX0JFC91 ( LD)
  • Page 20 System Configuration Guide PRIMEQUEST 2800B3 10. PCI Card Per Base Unit: Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) . Dual Channel 1000BASE-T Card MC-0JGEA1 / MCX0JGEA1 (LD) -Per I/O Unit (1GbE) : Max. 4 x PCI cards can be mounted.
  • Page 21 System Configuration Guide PRIMEQUEST 2800B3 10. PCI Card Dual Channel FCoE card (10Gbps) LP MC-0JCE61 / MCX0JCE61 (LD) - CNA Ctrl 10Gb 2 Channels OCe10102 with Low Profile bracket Per Base Unit: Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) .
  • Page 22 System Configuration Guide PRIMEQUEST 2800B3 10. PCI Card Single channel 56Gbps Infiniband HCA card MC-0JHC31 / MCX0JHC31 (LD) - For PCI slots with Full Height / Low Profile brackets Dual channel 56Gbps Infiniband HCA card Per Base Unit: Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) .

  • Page 23: Rack Installation

    System Configuration Guide PRIMEQUEST 2800B3 10. PCI Card Per Base Unit: PCIe SSD Card (800GB) Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) . MC-0JSD61 / MCX0JSD61 (LD) - DWPD: 10 times -Per I/O Unit (1GbE) : Max.
  • Page 24 Rack Mount Kit: Rack for APAC & Americas - can be used to mount PRIMEQUEST to Rack Units which are delivered from Fujitsu factories (Japan and Germany). - is bundled with PRIMEQUEST Base Unit. Rack Units Model 2724 Base Rack...
  • Page 25 System Configuration Guide PRIMEQUEST 2800B3 11. Rack Installation for EMEA and India Rack Installation Rack mounting kit (RMK) is included in the PQ2000 Base Unit and PCI BOX. suitable for : - PRIMERGY 19" PRIMECENTER Rack, FJ rack, and 3rd party racks...

  • Page 26: Maximum Quantity Of Pcie Cards

    System Configuration Guide PRIMEQUEST 2800B3 12. Maximum Quantity of PCIe Cards Maximum Quantity of PCI Cards that can be mounted per Base Unit Order Number Quantity Product Name Shipped with Base Units Loose Delivery PQ2800B3 Bracket Bracket Bracket Bracket SAS RAID controller card...

  • Page 27: Available Os

    VMware ESXi 6.5, VMware ESXi 6.0(Update1b and Update2) Full Height Full Height Base Unit PRIMEQUEST 2800E3 Base Unit MCH3AC111 PRIMEQUEST 2400E3 Base Unit MCH2AC111 PRIMEQUEST 2800B3 Base Unit MCH3AC111B System Board System Board for 2800E3 MC-3HSB91 MCX3HSB91 System Board for 2400E3 MC-2HSB91...

  • Page 28: Change Report

    System Configuration Guide PRIMEQUEST 2800B3 Change Report Date Order number Changes Feb. 8th, 2017 1st Release Mar. 29th, 2017 2nd Release FUJITSU Server PRIMEQUEST 28 / 28...
