- Page 1 PAL to XGA PC Tuner Box (CM-345T) Operation Manual...
- Page 2 Introduction This unit is capable of converting from numerous inputs, including composite video, S-Video, YCbCr, to XGA output. It also accommodates bypass, TV aerial input, as well as stereo and PC audio input. Features The unit is a high quality video scaler with a TV tuner. •...
- Page 3 Operation Controls and Functions Top Panel 1. Power- This is the power button used to switch the unit on or off. 2. Input- This is the input selection button. Press the button repeatedly and it will toggle through five input sources available for your selection. The sequence of selection is- TV (RF)- Composite Video- S-Video- YCbCr- PC Bypass.
-
Page 4: Installation
Rear Panel 1. Power- DC 12V 800mA Center positive - This is the power supply input port. 2. RF-In- Terrestrial VHF/UHF Antenna input or CATV coaxial cable input. 3. C-Video Input- This is the Composite Video input port. 4. S-Video input- This is the S-Video input port. 5. - Page 5 OSD Operation: 1. After you have powered on the unit, press the menu button in order to bring up the main menu page. Use channel up and down arrows in order to move up or down the highlight bar to your desired parameter. When a parameter is selected, its colour will be inverted.
- Page 6 The only way to recall the channel is to press its channel number directly, or to add it back to the channel list. Add channel- To add a channel into your up-down memory list. Once a channel has been added to the list, it can be called up by pressing channel up/down button.
- Page 7 1. Input- Press the button repeatedly to select desired input source from TV, Composite Video, S-Video, YCbCr or PC. 2. TV/CATV- Press the button to select either aerial channel or cable channel. 3. Display- Press the button to turn on or off OSD display of input source on the screen.
-
Page 8: Connection And Installation
Connection and Installation The AC adaptor power unit should not be plugged into a wall outlet until all connections are complete. Connect your Audio Amp to the Audio Out port (Number 9 on rear ● panel). Using the appropriate connector cable connect your PC to the PC ●... -
Page 9: Output Format
Specifications Input Connectors Composite Video: RCA S-Video: 4 pin, mini Din YCbCr: 3 x RCA PC loop through: 15-pin D-Sub Antenna: F connector Output Connectors 15-pin D-Sub, Female type Output Format 640 x 480 800 x 600 1024 x 768 @ 60 Hz refresh rate...
