- Page 1 Multisystem TV Tuner ID# 231 Operation Manual...
- Page 2 Introduction This unit is a multisystem tuner that receives terrestrial and cable TV broadcasting systems of all PAL and SECAM countries. Features Receive terrestrial and cable TV broadcasting systems of all PAL and • SECAM countries. Full channels on TV/ CATV systems. •...
- Page 3 Rear Panel 1. Remote Out- Remote control infrared receive sensor. 2. Audio Out- This is the Audio Output port. Connect the port to your audio device using a RCA Jack. 3. Video Out 1- This is the Composite Video Output port 1. Connect the port to your device using a RCA Jack.
- Page 4 Connection and Installation The adaptor power unit should not be plugged into a wall outlet until all connections are complete. - Connect the Video Output port (Number 3/4 on rear panel) and the Audio Output port (Number 2 on the rear panel) to your TV. - Connect your antenna or cable TV to the RF Input port (Number 1 on the front panel).
