- Page 1 IPCB42501 / IPCB42551 Installation manual IPCB42501 IPCB42551 Version 03/2017 English translation of the original German user manual. Retain for future reference.
- Page 2 This user manual has been produced with the greatest of care. Should you discover any missing information or inaccuracies, please let us know about them. ABUS Security-Center GmbH & Co. KG does not accept any liability for technical and typographical errors, and reserves the right to make changes to the product and user manuals at any time and without prior warning.
- Page 3 Important safety information All guarantee claims are invalid in the event of damage caused by non-compliance with this user manual. We cannot be held liable for resulting damage. We cannot be held liable for material or personal damage caused by improper operation or non-compliance with the safety information.
-
Page 4: Table Of Contents
Contents INTENDED USE ........................16 EXPLANATION OF SYMBOLS ................... 16 CONNECTIONS AND FUNCTIONS ..................17 3.1 P ........................17 OWER SUPPLY 3.2 C ) ................17 ALL FACTORY DEFAULT SETTINGS ESET 3.3 S ....................17 WITCHING INPUT OUTPUT 3.4 A ........................ -
Page 5: Intended Use
You can download a PDF version of the user manuals in your language at www.abus.com via the product search. -
Page 6: Connections And Functions
3. Connections and functions 3.1 Power supply ATTENTION! Before you begin the installation, make sure that the supply voltage and the nominal voltage of the camera match. 12 VDC, round plug, 5,5 x 2,1 mm 3.2 Call factory default settings (Reset) 1. -
Page 7: Audio Output
3.4 Audio output (only IPCB42551) Description Connection information Audio output „A“ Impedance: 600 Ω Frequency range: 20 Hz – 20 kHz „GND“ Output power: 20 mW @ 16 Ω 3.5 WPS function (only IPCB42551) 1. Activate the WPS function on the router. 2. -
Page 8: Notes To The Usage Of Internal Ir Leds
3.7 Notes to the usage of internal IR LEDs The IR range is strongly dependent on the environmental conditions. If the area in the camera's field of view reflects poorly or if there are no objects within the max. illumination range, the brightness of the video image at night may be too low. This will result in poor usability of the video image. -
Page 9: Maintenance And Cleaning
