INSTRUCTIONS-PARTS LIST
This manual contains IMPORTANT
INSTRUCTIONS and WARNINGS.
READ AND RETAIN FOR REFERENCE.
Gas-Powered Supply Pump
GH 533 HYDRA-SPRAY SPRAYER
3000 psi (210 bar) MAXIMUM WORKING PRESSURE
U.S. Patent Pending
Model 231-533, Series B
Sprayer only. Has Severe-Duty* Displacement Pump
Model 230-974
Includes Sprayer 231-533, Hose, Swivel, Gun,
RAC IV, DripLess
Tip Guard and SwitchTip
*Severe-duty displacement pumps have an abrasion
and corrosion-resistant displacement rod and sleeve.
Refer to the Technical Data in manual 307-862.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Model 230-974 Parts
. . . . . . . . . . . . . . . . . . . . . . . . . .
Model 231-533 Parts
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NOTE: This is an example of the DANGER label on your sprayer.
This label is available in other languages, free of charge.
See page 20 to order.
Spray painting, flushing or cleaning equipment with flammable liq-
uids in confined areas can result in fire or explosion.
Use outdoors or in extremely well ventilated areas. Ground equip-
ment, hoses, containers and objects being sprayed.
Avoid all ignition sources such as static electricity from plastic drop
cloths, open flames such as pilot lights, hot objects such as ciga-
rettes, arcs from connecting or disconnecting power cords or turn-
ing light switches on and off.
Failure to follow this warning can result in death or serious injury.
READ AND UNDERSTAND ALL LABELS AND INSTRUCTION MANUALS BEFORE USE
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
2
3
4
4
6
8
10
11
12
15
16
Back Cover
Back Cover
Back Cover
FIRE AND
EXPLOSION HAZARD
COPYRIGHT 1983 GRACO INC.
Liquids can be injected into the body by high pressure airless spray
or leaks - especially hose leaks.
Keep body clear of the nozzle. Never stop leaks with any part of the
body. Drain all pressure before removing parts.Avoid accidental trig-
gering of gun by always setting safety latch when not spraying.
Never spray without a tip guard.
In case of accidental skin injection, seek immediate
"Surgical Treatment".
Failure to follow this warning can result in amputation or serious
injury.
307-615
Rev S
Supersedes R
SKIN INJECTION
HAZARD

Advertisement

Table of Contents
loading

Related Manuals for Graco GH 533

Summary of Contents for Graco GH 533

  • Page 1: Table Of Contents

    Failure to follow this warning can result in death or serious injury. Failure to follow this warning can result in amputation or serious injury. READ AND UNDERSTAND ALL LABELS AND INSTRUCTION MANUALS BEFORE USE GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 COPYRIGHT 1983 GRACO INC.

  • Page 2: Warnings

    WARNINGS HIGH PRESSURE SPRAY CAN CAUSE SERIOUS INJURY. FOR PROFESSIONAL USE ONLY. OBSERVE ALL WARNINGS. Read and understand all instruction manuals before operating equipment. FLUID INJECTION HAZARD General Safety NEVER wipe off build–up around the spray tip until pressure is fully relieved and the gun safety latch is engaged.
  • Page 3 DO NOT expose Graco hose to temperatures NEVER operate the engine in a closed building unless the engine exhaust is piped outside. The exhaust contains carbon above 180 F (82 C) or below –40 F (–40 C).

  • Page 4: Terms

    See Fig 2. Fill the Packing Nut/W et Cup 1/3 full with Graco Throat Seal Liquid (TSL), supplied. See 2.
  • Page 5 To prevent damage to the cooling system and c. If oil is needed, see the chart below for the hydraulic pump, use only Graco Hydraulic Oil, part recommended oil type and weight. no. 169–236 (5 gal./20 liter) or part no. 207–428 (1 d.

  • Page 6: Flushing Guidelines

    FLUSHING GUIDELINES When to Flush 4. Changing from oil–base to water–base paint. Flush with mineral spirits, followed by soapy water , 1. New sprayer. Your new sprayer was factory tested then a clean water flush. with lightweight oil which was left in to protect pump parts from corrosion.
  • Page 7 How to Flush (continued) 13. Making firm metal-to-metal contact, hold the gun firmly to the side of the grounded solvent pail. Trigger 10. Raise the foot brace and engage it in the hitch. the gun. At the same time, slowly turn the pressure 11.

  • Page 8: Operation

    OPERATION WARNING Brace one foot against the foot brace and gently pull the starter rope until you feel it engage, the Pressure Relief Procedure continue pulling all the way out and let it recoil To reduce the risk of serious bodily injury, including slowly into the starter.
  • Page 9 NOTE: In cold weather , run the engine for about 15 b. Always use the lowest pressure that is neces- minutes with the bypass valve open before sary to completely atomize the fluid. starting the displacement pump, to help avoid CAUTION hydraulic motor stalling.

  • Page 10: Maintenance

    (19 liters) of Graco Hydraulic through the intake filter. See Fig 11. Install the fill 4. Check the hydraulic oil level weekly. The oil must cap. be up to the top mark on the dipstick. Use only Graco HYDRAULIC Hydraulic Oil. NUTS OIL FILL CAP 5.

  • Page 11: Troubleshooting

    Check for loose connections on siphon assembly, tighten, then reprime pump. Fluid supply is low or empty. Refill supply container. *Check hydraulic fluid level often. Do not allow it to become too low. Use only Graco approved hydraulic fluid. See pages 5 and 20.
  • Page 12 7. Remove the two capscrews (150), lockwashers (66) 12. Reconnect the hoses. Reinstall the reservoir plug and washers (64) holding the pump (107) to the (51), and refill the reservoir with clean, Graco support (117). See Fig 12. approved hydraulic oil. 49,66...
  • Page 13 Replacing the Cooler and Blower c. Pull the pump support and blower off far enough for the blower to fall out of the bottom of the 1. Follow the Pressure Relief Procedure Warning on housing. page 11. Let the hydraulic system cool before begin- ning the service procedure.

  • Page 14: Displacement Pump Service

    DISPLACEMENT PUMP SERVICE Disconnect the Displacement Pump 1. Flush the pump if possible. Stop the pump on the down stroke. 2. Follow the Pressure Relief Procedure Warning on page 11. 3. Remove the suction tube and fluid hose from the displacement pump.

  • Page 15: Parts Drawing

    PARTS DRAWING Model 230–974, GH 533 Sprayer Includes items 301 to 309 as listed NO. PART NO. DESCRIPTION 231–533 GH533 SPRAYER 150–287* ADAPTER, 1/4 npt(m) x 3/8 npt(f) 214–705 HOSE, nylon, 3/8” dia., cpld 3/8 npt(mbe) 50 ft. (15 m) long 156–173...
  • Page 16 PARTS DRAWING...
  • Page 17 PARTS DRAWING LABEL LABEL LABEL LABEL LABEL LABEL 69,68...
  • Page 18 PARTS DRAWING Ref 77 Ref 111 Ref 22...
  • Page 19 PARTS LIST Model 231–533, Series B 177–585 PLATE, engine 216–141 SUPPORT, engine Includes items 1–145 100–468 CAPSCREW, hex hd, 3/8 x 1.5” 104–766 MOUNT, motor NO. PART NO. DESCRIPTION 100–023 WASHER, 3/8” 107–074 BREATHER, fill cap 178–754 SPACER, engine 106–114 STRAINER, inlet 100–133 LOCKWASHER, 3/8”...

  • Page 20: Technical Data

    This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco distributor for verification of the claim. If the claimed defect is verified, Graco will repair or replace free of charge any defective parts. The equipment will be returned to the origi- nal purchaser transportation prepaid.
  • Page 21 ....grounded, 50 ft (15 m) minimum, non-wire braid, spring guards on both ends GRACO INC. P.O. BOX 1441 TO PLACE AN ORDER , call 1–800–367–4023 Toll Free MINNEAPOLIS, MN 55440–1441 FOR TECHNICAL ASSIST ANCE , call COPYRIGHT 1989, GRACO INC.
  • Page 22 3Z7–615 Rev B Supplement to instruction manual 307–615. GH533 Hydra-Spray Sprayer WARNING INJECTION HAZARD This form is only a quick reference to the features and frequently ordered parts of INSTRUCTIONS this sprayer. To reduce the risk of seri- ous injury, including fluid injection, while operating or repairing this sprayer, follow the warnings and instructions in manual 307–615.
