Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
24
23
22
21
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
20
19
18
17
16
SNOW BLASTER
IMPORTANT:
20
19
18
17
16
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
15
14
13
12
11
15
14
13
12
11
10
9
8
7
6
Model # 5662
bit.ly/wenvideo
10
9
8
7
6
(M-F 8AM-5PM CST)
5
4
3
2
1
R
Q
P
N
M
L
K
J
H
G
F
E
D
C
B
UNLESS OTHERWISE SPECIFIED:
FINISH:
DEBURR AND
BREAK SHARP
DO NOT SCALE DRAWING
REVISION
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
EDGES
TOLERANCES:
LINEAR:
ANGULAR:
NAME
SIGNATURE
DATE
TITLE:
DRAWN
CHK'D
A
APPV'D
MFG
MATERIAL:
DWG NO.
Q.A
A0
3D for snow thrower
WEIGHT:
SCALE:1:5
SHEET 1 OF 1
5
4
3
2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5662 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 5662

Summary of Contents for Wen 5662

  • Page 1 APPV'D MATERIAL: DWG NO. 3D for snow thrower Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, WEIGHT: SCALE:1:5 SHEET 1 OF 1 ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Electrical Information Know Your Snow Thrower Assembly and Adjustments Operation Exploded View and Parts List Maintenance Warranty TECHNICAL DATA Model Number: 5662 120 V, 60 Hz, 13.5A Motor: 18 inches Clearing Width: 7.8 inches Clearing Height: Max Throwing Distance: 20 feet...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your tool works. SAVE THESE SAFE- TY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 4 Special care should be paid to any rubber parts, since these parts may increase the en- gine load and decrease its mechanical power if damaged. ONLY USE RECOMMENDED ACCESSORIES: any accessory that does not specify compatibility with the WEN 5662 Snow Thrower creates a risk of injury.

  • Page 5: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 6: Know Your Snow Thrower

    KNOW YOUR SNOW THROWER UNPACKING Carefully remove your WEN Snow Blaster and all other items from the box. Aside from the Snow Blaster itself, your purchase also comes with the following pieces of hardware: - One chute - Four knobs...

  • Page 7: Assembly And Adjustments

    ASSEMBLY AND ADJUSTMENTS WARNING: Always be sure that the tool is switched off and unplugged before adjusting, adding accessories, or checking a function on the tool. CHUTE ASSEMBLY (Fig. A) 1. Line the chute up with the screw holes mounted around the edge of the hole in top of the snow thrower’s body.

  • Page 8: Operation

    ASSEMBLY AND ADJUSTMENTS CHUTE CRANK ASSEMBLY 1. Locate the upper chute crank in the parts bag. Loosen the thumb screw (Fig. D - 1) located on the lower chute crank (Fig. D - 2) that comes pre- attached to the body of the snow thrower. 2.
  • Page 9 OPERATION PLOWING THE SNOW WARNING: Keep the area of operation free of foreign objects that can become thrown by the auger blades. Per- form a thorough inspection of the area before plowing since some objects may be hidden from view by surround- ing snow.

  • Page 10: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST Part Number Description Qty. No. Part Number Description Qty. 5662B-001 Switch Subassembly 5662B-057 Upper Housing 5662B-002 Switch Cover (Right) 5662B-058 Right Housing Cover 5662B-003 Button 5662B-059 Lock Nut 5662B-004 Switch Spring 5662B-060 Counter Sunk Screw 5662B-005 Switch Bracket 5662B-061...
  • Page 11 EXPLODED VIEW AND PARTS LIST...

  • Page 12: Maintenance

    MAINTENANCE WARNING: Make sure to turn off the switch and disconnect the extension cord before performing any mainte- nance tasks on your snow thrower. 1. KNOW YOUR LIMITATIONS. Do not overload your snow thrower’s capacity by attempting to clear snow at too fast of a rate.

  • Page 13: Warranty

    LIMITED TWO YEARS WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
  • Page 14 Thanks for remembering...
