Summary of Contents for Vaillant ecoLEVEL
- Page 1 Installation and maintenance instructions For the competent person Installation and maintenance instructions ecoLEVEL Condensed water pump GB, IE...
-
Page 2: Table Of Contents
Handing over to the operator ........16 Maintenance ..............17 Cleaning the non-return valve ........17 Cleaning the pump ............18 Spare parts ..............18 Guarantee and Customer Service......19 10.1 Vaillant guarantee ............19 10.2 Vaillant Service ..............19 ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 3: Notes On The Documentation
The ecoLEVEL condensed water pump is intended for use > Permissible voltages (Directive EN 60 335-1 and only in conjunction with Vaillant system components in... -
Page 4: General Safety Information
> Avoid any contact of the condensed water with the eyes. > Make sure that the ecoLEVEL condensed water pump is General safety information only operated out of the reach of children. - Page 5 – Electrical connection – VDE 0100 Erection of power installations with rated voltages below 1000 V, – VDE 0105, part 100 Operation of electrical systems DIN 18382 Electrical cable and wiring systems in buildings ecoLEVEL installation and maintenance instructions 0020029316_01...
-
Page 6: Installation
> If the walls are not in a suitable condition, a suitable installation surface must be prepared before starting the installation. The ecoLEVEL condensed water pump must not be used as a storage surface for objects. ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 7: Dimensions And Installation Clearances
> Install the wall bracket in a suitable position underneath the condensate drain point of the boiler. The wall bracket must be installed horizontally. Use a spirit level. ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 8: Hydraulic Connection
> To open the cover of the pump (2), turn the non-return valve (1) a quarter turn to the left. Both the cover and the non-return valve are then unlocked. > Remove the cover (2) and the non-return valve (1) by pulling upwards. ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 9: Install The Inlet Hose
> Note that the hoses must be pushed no more than 3 notches into the inlet openings (3) and (4). Replacing the cover > Place the cover onto the ecoLEVEL condensed water pump from above. Connecting and positioning the drain hose Connecting the drain hose >... -
Page 10: Connecting The Drain Hose To The Existing Discharge Pipe
> Shorten the end of the drain hose (1). For this, ensure that the cut on the hose is at a right angle and is free from burrs (¬ fig. 4.3). ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 11: Connecting The Condensed Water Pump To The Boiler
(3) together (¬ fig. 4.6). Connecting the condensed water pump to the boiler The ecoLEVEL condensed water pump can be connected to the siphon of all Vaillant condensing boilers using the inlet hose provided. > If the boiler's condensed water drain hose is long enough, it can be connected directly to the pump (¬... -
Page 12: Electrical Connection
3 Connection cable for the safety cut-out switch with Pro-E plug installation (¬ section 3) and the hydraulic connection and X-40 plug (¬ section 4) for the ecoLEVEL condensed water pump must be completed. The 230 V connection cable (1) with the free cable end pro- vides the power supply to the pump. -
Page 13: Connecting The Condensed Water Pump To The Safety Cut-Out Switch
Variants I. and II. > Open the electronics box on the boiler. > On the boiler PCB, remove the plug from the blue socket which is labelled as either "Anl-Therm" (I.) or "Burner off" (B.Off) (II.) (1). ecoLEVEL installation and maintenance instructions 0020029316_01... - Page 14 (¬ fig. 5.1), item 3) and insulate the cable ends. > Connect the boiler mains voltage line accordingly (¬ fig. 5.5). > Connect the 230 V mains voltage for the ecoLEVEL con- densed water pump in accordance with (¬ section 5.3). Boiler...
-
Page 15: Operation And Troubleshooting
LED display of operating status or faults The water level has exceeded the maximum On the front of the ecoLEVEL condensed water pump cas- permitted value. The ing, there are two LEDs (¬ fig. 6.1), items 1 and 2) which... -
Page 16: Handing Over To The Operator
Handing over to the operator Cause Troubleshooting The operator must be instructed in the handling and func- tions of the ecoLEVEL condensed water pump. Pump not pumping: Remove kink > Provide the operator with all relevant instructions and Kink in the drain hose unit documentation for safe-keeping. -
Page 17: Maintenance
> Position the burls (¬ fig. 8.2), item 3) of the sealing insert (¬ fig. 8.2), item 2) at the designated position. > Carefully push the sealing insert into the non-return valve. 8.1 Removing the non-return valve ecoLEVEL installation and maintenance instructions 0020029316_01... -
Page 18: Cleaning The Pump
The original components of the unit were also certified as part of the CE declaration of conformity. If you do not use certified Vaillant genuine spare parts, this voids the CE con- formity of the unit. We therefore strongly recommend that you fit Vaillant genuine spare parts. -
Page 19: Recycling And Disposal
Gas Safety (Installation and Use) Regulations 1998, and end of its useful life. > In this case, make sure that the Vaillant unit and any the manufacturer’s instructions. In the UK competent per- sons approved at the time by the Health and Safety Execu-... -
Page 20: Technical Data
Radio-shielded, non-interacting with the mains supply Safety cut-out switch 5 mA - 4 A; 230 V Level of protection in accordance with EN 60529 IP 44 Approved for individual units up to 45 12.1 Technical data ecoLEVEL installation and maintenance instructions 0020029316_01... - Page 24 Supplier Manufacturer...
