Chapter 1
1-1 Preface ...........................................................................................
1-2 Key Feature ...................................................................................
Installation ..................................................................................
2-1 Unpacking ........................................................................................ 3
2-2 Mainboard Layout ............................................................................ 4
2-3 Installation Steps ............................................................................. 6
2-3-1 Jumper Settings ................................................................... 6
2-3-2 System Memory (DRAM) ..................................................... 8
2-4 Central processing Unit (CPU) ........................................................ 8
2-5 Expansion Cards ............................................................................. 9
2-6 External Connectors ........................................................................ 10
AWARD BIOS SETUP .................................................................
3-1 STANDARD CMOS SETUP ............................................................... 17
3-2 BIOS FEATURES SETUP .................................................................. 17
3-3 CHIPSET FEATURES SETUP ........................................................... 21
3-4 POWER MANAGEMENT SETUP ...................................................... 22
3-4-1 The Description of the Power Management......................... 22
3-4-2 Description of the Green Functions ..................................... 23
3-5 PNP/PCI CONFIGURATION SETUP ................................................. 24
3-6 LOAD BIOS DEFAULTS .................................................................... 25
3-7 LOAD SETUP DEFAULTS ................................................................. 25
3-8 INTEGRATED PERIPHERALS SETUP ............................................. 26
3-9 SUPERVISOR/USER PASSWORD ................................................... 28
3-10 IDE HDD AUTO DETECTION .......................................................... 28
3-11 SAVE & EXIT SETUP ....................................................................... 30
3-12 EXIT WITHOUT SAVING ................................................................. 30
3-13 I/O & MEMORY MAP ....................................................................... 30
3-14 TIME & DMA CHANNELS MAP ....................................................... 32
3-15 INTERRUPT MAP ............................................................................ 32
3-16 RTC & CMOS RAM MAP ................................................................. 32
3-17 BIOS REFERENCE-POST CODES ................................................. 33
TABLE OF CONTENT
i
1
1
3
16
Advertisement
Table of Contents
Related Manuals for JETWAY J-791A
Summary of Contents for JETWAY J-791A
-
Page 1: Table Of Contents
TABLE OF CONTENT Chapter 1 1-1 Preface ................... 1-2 Key Feature ................... Chapter 2 Installation .................. 2-1 Unpacking ..................3 2-2 Mainboard Layout ................4 2-3 Installation Steps ................6 2-3-1 Jumper Settings ..............6 2-3-2 System Memory (DRAM) ............. 8 2-4 Central processing Unit (CPU) ............ -
Page 2: Preface
1-1 Preface mainboard. This mainboard supports Pentium ® II Welcome to use the J-791A/J-791A/L processor PC/AT compatible system with AGP slot,ISA bus and PCI local bus. Also this board including some special designs, like ACPI/APM power management & powerful performance , We think you will enjoying your personal computer because of your right choice. - Page 3 Fans: Support two Extra fan connectors to evacuate the heat from CPU, and the heat • within the computer case. PC HEALTH MONITOR: (Only in J-791A/L) • To frack PC system temperature system Vottage,and Fan speed. When system temperature is over warning temperature by HEALTH Monitor Utility will have alarm to warn...
-
Page 4: Chapter 2 Installation
Chapter 2 Hardware Installation 2-1 Unpacking This mainboard package should contain the following: J-791A/J-791A/L mainboard • USER’S MANUAL for mainboard • Cable set for IDE x1, Floppy x1 • CD for Drivers PACK • The mainboard contains sensitive electronic components which can be easily damaged by electron-static, so the mainboard should be left in its original packing until it is installed. -
Page 5: Mainboard Layout
2-2 Mainboard Layout KB/MS FAN1 CPUFAN ATX PO WE R CO NN. USB1 CO M1 VT82C691 LPT1 CO M2 IDE 2 IDE 1 SLO T1 AG P SLO T AG P1 PC I 1 JIR1 PCI 2 VT82C 596 SB -LINK 1 PC I 3 PC I 4 BATT. -
Page 6: Expansion Slots
Jumpers 1) U4 p. 7 DIP Switch for CPU Ratio Selection JBAT1 p. 7 CMOS RAM (Normal/Clear CMOS Data) (Yellow color selector) 3) U2 p. 7 DIP Switch for CPU BUS Frequency Selection Connectors 1) CN1 p. 10 ATX Power connector (20-pin Block) 2) KB/MS p. -
Page 7: Installation Steps
2-3 Installation Steps Before using your computer, you must follow the steps as follows: 1. Set Jumpers on the Motherboard 2. Install the CPU 3. Install DRAM Modules 4. Install Expansion card 5. Connect Cables, Wires, and Power Supply 6. Setup the BIOS Software 2-3-1 Jumper Settings 1. - Page 8 333MHz 350MHz 400MHz 450MHz 233MHz 300MHz 266MHz 233MHz 400MHz 266MHz 300MHz 333MHz 350MHz 450MHz 2. SDRAM Clock Selector: U2 #4 This selector can choose SDRAM clock Synchronous or Asynchronous to CPU Bus frequency. When choose Asynchronous can let users have more choice of NON-PC100 SDRAM at over 66 MHz Bus frequency .
-
Page 9: System Memory (Dram)
2-3-2 System Memory (DRAM) This motherboard support tree168-pin DIMM Module, using +3V unbuffer synchronous DRAM in either EDO or SDRAM with Max. memory size of 768MB. Total Memory DIMM1 DIMM2 DIMM3 Combination 16MB none none 16MB 16MB 16MB none 32MB 16MB 16MB 16MB... -
Page 10: Expansion Cards
PART A 2-5 Expansion Cards You must read the documentation come with expansion card for any hardware or software settings that may be required to setup your specific card. Installation Procedure: 1. Read the documentation from your expansion card. 2. Set any necessary jumpers on your expansion card. 3. -
Page 11: External Connectors
To simplify this process the motherboard has complied with the Plug and Play (PNP) specification which was developed to allow automatic system configuration whenever a PNP- compliant card is added to the system. For PNP cards, IRQs are assigned automatically from those available. - Page 12 The PS/2 Keyboard is a 6-pin miniature DIN connector. It is for a standard PS/2 style keyboard. May also be known as a 101 enhanced keyboard. The PS/2 Mouse connector is a similar 6-pin, miniature DIN connector. PS/2 Mouse PS/2 Keyboard 3.
- Page 13 This connector supports the provided floppy drive ribbon cable. After connecting the single plug end to motherboard, connect the two plugs at other end to the floppy drives. Pin 1 Floppy Drive Connector 6. Primary IDE Connector (40-pin block): IDE1 This connector supports the provided IDE hard disk ribbon cable.
- Page 14 SMI_SW SMI_SW 9. IDE activity LED: HDLED (J9 1&3) This connector connects to the hard disk activity indicator light on the case. HDLED IDE (Hard Drive) LED 10. Turbo LED switch: TBLED The motherboard‘s turbo function is always on. The turbo LED will remain constantly lit while the system power is on.
- Page 15 This connector supports the optional wireless transmitting and receiving infrared module. This module mounts to small opening on system cases that support this feature you must also configure the setting through BIOS setup. Use the four pins as shown on the Back View and connect a ribbon cable from the module to the motherboard according to the pin definitions.
-
Page 16: Chapter 3
FAN1 +12V R.P.M. SENCE Fan Connector 18. Power-On button connector: PWR_BTN(J5 2&4) PWR-BTN Push Button Power-On button connector 19. SB LINK connector: SB_LINK1 PCI REQN PCI GNTN SB_link connector 20. Wake On Lan connector: WON1 WON1 Wake On Lan Chapter 3... -
Page 17: Award Bios Setup
AWARD BIOS SETUP Award's ROM BIOS provides a built-in Setup program which allows user modify the basic system configuration and hardware parameters. The modified data will be stored in a battery- backed CMOS RAM so data will be retained even when the power is turned off. In general, the information saved in the CMOS RAM stay unchanged unless here is configuration change in the system, such as hard drive replacement or new equipment is installed. -
Page 18: Standard Cmos Setup
Choose "STANDARD CMOS SETUP" in the CMOS SETUP UTILITY Menu (Figure 3-1). The STANDARD CMOS SETUP allows user to configure system setting such as current date and time, type of hard disk drive installed in the system, floppy drive type, and the type of display monitor. - Page 19 ! ! ! ! ! ! ! ! ! ! ! ! S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * ! ! ! ! S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * C J P T ! G F B U V S F T ! T F U V Q ! ! ! !
- Page 20 CPU Internal Cache / External Cache: These two categories speed up memory access. • However, it depends on CPU/chipset design. The default value is Enable. If your CPU without Internal Cache then this item "CPU Internal Cache" will not be show. Enabled: Enable cachehis category speeds up Power On Self Test.
- Page 21 Typematic Rate Setting: This determines the typematic rate. • Enabled: Enable typematic rate and typematic delay programming. Disabled: Disable typematic rate and typematic delay programming. The system BIOS will use default value of this 2 items and the default is controlled by keyboard. Typematic Rate (Chars/Sec): •...
-
Page 22: Chipset Features Setup
3-3 CHIPSET FEATURES SETUP Choose the "CHIPSET FEATURES SETUP" in the CMOS SETUP UTILITY menu to display following menu. S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * ! ! ! ! -
Page 23: Power Management Setup
USB Keyboard Support : Select Enabled if your system contains a Universal Serial Bus • (USB) controller and you have a USB keyboard . The choice : Enabled,Disabled. 3-4 POWER MANAGEMENT SETUP Choose the "POWER MANAGEMENT SETUP" in the CMOS SETUP UTILITY to display the following screen. -
Page 24: Description Of The Green Functions
Timeout parameters: • HDD Standby HDD Standby timer can be set from 1 to 15 minute(s). System Doze The "System Doze" mode timer starts to count when there is no "PM events" occurred. The valid timeout setting is from 1 minute up to 1 hour. System Standby The "Standby"... -
Page 25: Pnp/Pci Configuration Setup
3-5 PNP/PCI CONFIGURATION SETUP This “PNP and PCI configuration Setup” option configures the PCI bus slots. All PCI bus slots on the system use INTA#, thus all installed PCI cards must be set to this value. S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * ! ! ! ! -
Page 26: Load Bios Defaults
3-6 LOAD BIOS DEFAULTS The "LOAD BIOS DEFAULTS" function loads the system default data directly from ROM and initialize associated hardware properly. This function will be necessary only when the system CMOS data is corrupted. S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * ! ! ! ! S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 M G K 2 C *... -
Page 27: Integrated Peripherals Setup
3-8 INTEGRATED PERIPHERALS SETUP S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * ! ! ! ! J O U F H S B U F E ! Q F... - Page 28 IDE Secondary Slave PIO: The default value is • Auto: BIOS will automatically detect the Onboard Secondary Slave PCI IDE HDD Accessing mode. Mode0~4: Manually set the IDE Accessing mode. Onboard Primary PCI IDE: The default value is Enabled. • Enabled: Enable Onboard 1 st channel IDE port.
-
Page 29: Supervisor/User Password
Onboard Parallel port Mode: This field allows the user to select the parallel port mode. • The default value is ECP + EPP. Normal: Standard mode. IBM PC/AT Compatible bidirectional parallel port. EPP: Enhanced Parallel Port mode. ECP: Extended Capabilities Port mode. EPP+ECP: ECP Mode &... - Page 30 S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * S P N ! Q D J 0 J T B ! C J P T ! ) 3 B 7 : K K 2 C * ! ! ! ! T U B O E B S E ! D N P T ! T F U V Q ! ! ! !
-
Page 31: Save & Exit Setup
LARGE mode Extended HDD access mode supported by Award Software. Some IDE HDDs contain more than 1024 cylinder without LBA support (in some cases, user do not want LBA). The Award BIOS provides another alternative to support these kinds of LARGE mode: CYLS. - Page 32 E0000-EEFFF Available for UMB EF000-EFFFF Video service routine for Monochrome & CGA adapter F0000-F7FFF BIOS CMOS setup utility F8000-FCFFF BIOS runtime service routine (2) FD000-FDFFF Plug and Play ESCD data area FE000-FFFFF BIOS runtime service routine (1) I/O MAP 000-01F DMA controller (Master) 020-021 INTERRUPT CONTROLLER (Master)
-
Page 33: Time & Dma Channels Map
3-14 TIME & DMA CHANNELS MAP TIME MAP: TIMER Channel 0 System timer interrupt TIMER Channel 1 DRAM REFRESH request TIMER Channel 2 SPEAKER tone generator DMA CHANNELS: DMA Channel 0 Available DMA Channel 1 Onboard ECP (Option) DMA Channel 2 FLOPPY DISK (SMC CHIP) DMA Channel 3 Onboard ECP (Default) DMA Channel 4 Cascade for DMA controller 1 DMA Channel 5 Available... -
Page 34: Bios Reference-Post Codes
Status register C Status register D Diagnostic status byte Shutdown byte FLOPPY DISK drive type byte Reserve HARD DISK type byte Reserve Equipment type Base memory low byte Base memory high byte Extension memory low byte Extension memory high byte 19-2d 2E-2F Reserved for extension memory low byte... - Page 35 Blank video, Initialize Keyboard controller initialization. keyboard Reserved Test CMOS Interface and Verifies CMOS is working correctly, detects bad Battery Status battery. Chipset Default Program chipset registers with power on BIOS Initialization defaults. Memory presence test OEM Specific-Test to size on-board memory. Early Shadow OEM Specific-Early Shadow enable for fast boot.
- Page 36 Test Stuck 8259's Turn off interrupts then verify no interrupt mask register is on. Interrupt Bits Test 8259 Interrupt Force an interrupt and verify the interrupt occurred. Functionality Test Stuck NMI Bits Verity NMI can be cleared. (Parity I/O Check) Display CPU clock.
- Page 37 Detect & Initialize Initialize any serial and parallel ports (also game Serial/Parallel Ports port). Reserved Detect & Initialize Initialize math coprocessor. Math Coprocessor Reserved Reserved 48-4D Reserved Manufacturing POST Loop Reboot if Manufacturing POST Loop pin is set. or Display Messages Otherwise display any messages (i.e., any non-fatal errors that were detected during POST) and enter Setup.
