- Page 1 EICKVIEW HD USB CAMERA USER MANUAL Art. No. 306181 TELEPHONE +49 7461 96 580 0 www.eickemeyer.com...
- Page 3 With the latest USB 3.0 HD Technology, * Design and specifications are subject to change without notice. * Manual & Software Update will be continuous. - Contents - 1. Safety Caution & Specification 2. Introduction of Software Installation and Process and UN-Installation 3.
- Page 4 1. Safety Caution & Specification Safety Caution *. In order to obtain optimum performance and ensure patient safety, please read this instruction manual thoroughly. * Do not use CAMERA if you notice any signs of damage or malfunction and contact PROVIX or its official distributor in your country immediately. * Do not use in the presence of flammable anesthetics.
- Page 5 2. Introduction of Software Installation Process Introduction of Software Installation Process Warning: For this USB 3.0 HD Camera, it is imperative to use the computer / laptop meeting the below specification. Even though the computer has USB 3.0 INPUT Port, if the specification doesn’t meet the below details, the USB 3.0 HD Camera will not work properly.
- Page 6 Introduction of Software Installation Process 1. Please insert the CD provided by PROVIX 2. Double Click CD-Driver, or open the files in CD. 3. Double Click “Setup” file 4. Click “Next” Button 5. After designate the folder, click “Next” button 6.
- Page 7 Introduction of Software Installation Process 7. Click “I Agree” Button 8. Click “Install” Button 9. Click “Next” Button 10. Click “Finish” Button (The video code installation is done) 11. Click “Next” Button (Visual C++ Installation) 12. Agreed & Install...
- Page 8 Introduction of Software Installation Process 14. Choose the proper language. Then click “OK” The installation is started 15. Click “Next” Button and restart the computer 16. After restarting, Please plug in USB Cable 17. Please wait until the device is ready. 18.
- Page 9 VIEWER SOFTWARE FUNCTIONS 1. Please choose IT200HCU and click Select Device 2.3.: The file(s) will be saved automatically, as JPEG or AVI You can review the files in the folder, C:/PROVIX/ 4. You can change the resolution of the window. 1366 * 768 ->...
- Page 10 Introduction of Software UN-Installation Process If you install all process successfully, 3 programs will be installed as below, When you have any trouble so you need to re-install the software. Please remove the file from the control panel’s program uninstallation option. NEED TO BE UNINSTALLED FOR THE REINSTLLATION “PROVIX –...
-
Page 11: Button & Function Description
3. Button & Function Description Button Description & Function White Balance Button: Activating White Balance Capture Button: Activating Capture... - Page 12 GERMANY EICKEMEYER KG Eltastraße 8 78532 Tuttlingen T +49 7461 96 580 0 F +49 7461 96 580 90 E info@eickemeyer.de www.eickemeyer.de SWITZERLAND DENMARK ITALY EICKEMEYER AG EICKEMEYER ApS EICKEMEYER S.R.L. Sandgrube 29 Lysbjergvej 6, Hammelev Via G. Verdi, 8...
