• TROUBLESHOOTING

Symptom
Press Reset Button on BCM
Check main fuse in Distribution Panel.
Display Commander (DC) will
not turn ON or the touch screen
will not function
Check 12V+ on wire to DC (RED wire).
Check Ground wire to DC.
Try cycling power at Distribution Panel.
Check if the Red power LED is off.
No power to the Body Control
Check the fuse in the Distribution Panel.
Module (BCM)
Check 12V+ on wire at pin 35. Check Ground wire at pin 33.
Ensure Pin 7 is NOT grounded
Cycle power to the BCM and DC
Ensure the wires to the BCM and DC are connected and there is 12V
DC screen flashing on and off
after installation
Ensure the wires to the BCM and DC are not damaged or pinched
Ensure the Battery is charged
Electric Motors do not move Check 12V+ at Pin 34. Ensure the relay activates*.
Travel Lock on Ensure 12V+ is removed from Pin 15.
Replace the 1505 relay with one from an unused circuit by gently pulling it off
*Relay not activating
the board, or install an new one.
If an issue is unable to be resolved using the above methods, contact ASA Electronics Technical
Support at 1-877-845-8750 or email them at info@asaelectronics.com
