ionTig 200 AC/DC
ionTig 200 AC/DC
INVERTER - AC/DC PULSED TIG WELDER
OPERATION MANUAL
IMPORTANT: Read this Owner's Manual Completely before attempting to use this
equipment. Save this manual and keep it handy for quick reference. Pay particular
attention to the safety instructions we have provided for your protection. Contact your
distributor if you do not fully understand this manual.
Copyright © Mundaka Welding & Gases, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ionTig 200 AC/DC and is the answer not in the manual?

Questions and answers

Related Manuals for Sua ionTig 200 AC/DC

Summary of Contents for Sua ionTig 200 AC/DC

  • Page 1 200 AC/DC ionTig 200 AC/DC INVERTER - AC/DC PULSED TIG WELDER OPERATION MANUAL IMPORTANT: Read this Owner’s Manual Completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your distributor if you do not fully understand this manual.

  • Page 2: Table Of Contents

    200 AC/DC CONTENT SAFETY ..............................3 1.1 Signal Explanation............................3 1.2 The Knowledge of Electric and Magnetic Fields ................... 6 Overview..............................7 2.1 Brief Introduction ............................7 2.3 Volt-Ampere Characteristic ........................10 Installation and Adjustment........................11 3.1 Parameters ..............................11 3.2 Duty cycle and Over-heat...........................

  • Page 3: Safety

    200 AC/DC 1. SAFETY 1.1 Signal Explanation  Welding may damage your body or others, so please take protection measure in operation.  Only ones who are trained professionally can install, debug, operate, maintain and repair the equipment.  Do not maintain and repair the machine when the machine is connected with power.
  • Page 4 200 AC/DC FUMES AND GASES CAN BE DANGEROUS  Welding may produce fumes and gases hazardous to health. Avoid breathing these fumes and gases. When welding, keep your head out of the fume. Use enough ventilation and/or exhaust at the arc to keep fumes and gases away from the breathing zone.
  • Page 5 200 AC/DC ELECTRIC SHOCK CAN KILL.  Never touch electrical parts.  Wear dry, hole-free gloves and clothes to insulate yourself.  Insulate yourself from work and ground using dry insulation. Make certain the insulation is large enough to cover your full area of physical contact with work and ground.

  • Page 6: The Knowledge Of Electric And Magnetic Fields

    200 AC/DC  Where compressed gases are to be used at the job site, special precautions should be used to prevent hazardous situation.  When not welding, make certain no part of the electrode circuit is touching the work or ground. Accidental contact can cause overheating and create a fire hazard.

  • Page 7: Overview

    Thus, it is characterized with portable, small size, light weight, low consumption and etc. The parameters of ionTig 200 AC/DC on the front panel all can be adjusted continuously and sleeplessly, such as start current, crater arc current, welding current, base current, duty ratio, upslope time, downslope time, pre-gas, post-gas, pulse frequency, AC frequency, balance, hot start, arc force and arc length etc.
  • Page 8 200 AC/DC  MCU control system, responds immediately to any changes.  High frequency and high voltage for arc igniting to ensure the success ratio of igniting arc, the reverse polarity ignition ensures good ignition behavior in TIG-AC welding.

  • Page 9: Working Principle

    200 AC/DC welding machine is suitable for all positions welding for various plates made of stainless steel, carbon steel, alloyed steel, titanium, aluminum, magnesium, cuprum, etc., which is also applied to pipe installment, mold mend, petrochemical, architecture decoration, car repair, bicycle, handicraft and common manufacture.

  • Page 10: Volt-Ampere Characteristic

    2.3 Volt-Ampere Characteristic ionTig 200 AC/DC welding machine has an excellent volt-ampere characteristic, whose graph is shown as the following figure. The relation between the conventional rated loading voltage U2 and the conventional welding current I2 is as follows: When I2≤600A，U2=10+0.04I2(V);...

  • Page 11: Installation And Adjustment

    200 AC/DC 3. Installation and Adjustment 3.1 Parameters Models ionTig 200 AC/DC Parameters Input power 1~220±10%，50Hz Rated input current（A） 35.4（TIG） 39.5（MMA） Rated input power（KW） 5.2（TIG） 6.4（MMA） Power factor 0.68 Max no-load voltage(V) Adjustment range of start 5～ LIFT current（A）...

  • Page 12: Duty Cycle And Over-Heat

    200 AC/DC Insulation class Dimensions of Machine 470×240×380 （L×W×H） （mm） Weight(Kg) Note: The above parameters are subject to change with the improvement of machines. 3.2 Duty cycle and Over-heat The letter “X” stands for duty cycle, which is defined as the proportion of the time that a machine can work continuously within a certain time (10 minutes).

  • Page 13: Power Supply Input Connection

    3.4 Power supply input connection ionTig 200 AC/DC welding machines’ power supply connects to 220V. When the power supply voltage is over the safe work voltage, there are over voltage and under voltage protection inside the welder, the alarm light will on, at the same time, the current output will be cut off.

  • Page 14: Operation

    200 AC/DC  When WSME welding machines are operated in HF ignition method, the ignition spark can cause interferences in equipment near the welding machine. Be sure to take specially safety precautions or shielding measures. 4. Operation 4.1 Layout for the panel...

  • Page 15: Control Panel

    200 AC/DC (7) Shield gas input joint: To connect one head of the gas hose while the other head of which is connected to argon gas cylinder. (8) Fan: It is used for cooling the components and parts inside the welder.
  • Page 16 200 AC/DC (12)Welding current display Overview The key feature of the control panel is the logical way in which the controls are arranged. All the main parameters needed for day-to-day working can easily be -selected with the keys -altered with the adjusting dial -shown on the display during welding.
  • Page 17 200 AC/DC Tdown Available parameters where 2T and 4T mode have been selected: Gas pre-flow time Unit Setting range 0.1—1 Factory setting Starting current (only with 4T) Unit Setting range 5—100%of main current Iw (DC)；10—100%of main current Iw (AC-HF) 30—100%of main current Iw (AC-LIFT)
  • Page 18 200 AC/DC Base current Unit WSME-160 5—160 (DC)；10—160 (AC-HF)；10—160 (AC-LIFT) WSME-200 5—200 (DC)；10—200 (AC-HF)；10—200 (AC-LIFT) Important! Only selectable when “pulse key” has been pressed. Suggestion! Ib and Iw cannot differ greatly. Ratio of pulse duration to base current duration...
  • Page 19 200 AC/DC Unit Setting range 50—250 (Iw<50A) 50—200 (50A≤Iw<100A) 50—150 (100A≤Iw<150A) 50—100 (150A≤Iw<200A) Balance (only with TIG-AC) Balance adjustment is mainly used to set the adjustment of eliminating metal-oxide (such as Aluminum, Magnesium and its alloy) while AC output.

  • Page 20: Remote Control

    200 AC/DC After the start of welding, the left-hand display shows the present actual value of the welding current. The control panel indicates which position has been reached in the welding process by brightening the light. NOTE: Only “Parameter selection keys” and “Adjusting dial” can be used in the welding process.

  • Page 21: Remote Box Control

    200 AC/DC the fourteen-lead aero-socket is short circuit; the third, fourth and fifth of the fourteen-lead aero-socket is pedal adjustable resistance. Adjustment knob welding current Adjustment knob of max welding current Connected to the 14-lead aero socket on the front panel 4.3.2 Remote box control...

  • Page 22: Gun Switch Control Current

    200 AC/DC 4.3.3 Gun switch control current Adjust current button, when Gun switch it’s pushed up, the current increase, when it’s pushed down, the current decrease. 4.4 Argon Arc Welding Operation 4.4.1 TIG welding （4T operation） The start current and crater current can be pre-set. This function can compensate the possible crater that appears at the beginning and end of the welding.
  • Page 23 200 AC/DC Introduction ：  0： Press and hold the gun switch, Electromagnetic gas valve is turned on. The shielding gas stars to flow;  0～t1： Pre-gas time (0.1~1S);  t1～t2： Arc is ignited at t1 and then output the setting value of start current;...

  • Page 24: Tig Welding (2T Operation)

    200 AC/DC 4.4.2 TIG welding (2T operation) This function without the adjustment of start current and crater current is suitable for the Re-tack welding、transient welding、thin plate welding and so on. I（A） Welding current Is Loosen the welding gun switch...
  • Page 25 200 AC/DC then arc is turned off.  t4～t5: Post-gas time, after the arc is turned off. You can adjust it (0.1~10s) through turnning the knob on the front panel.  t5: electromagnetic gas valve turned off, the shield gas stops to flow, and welding is finished.

  • Page 26: Welding Parameters

    200 AC/DC adjust the gas flow which is shown on the gas hose pressure meter or the gas bottle pressure meter. ● The spark ignition works better if you keep the 3mm distance from the workpiece to the tungsten electrode during the ignition.

  • Page 27: Tig Parameters Matching

    200 AC/DC 4.5.3 TIG Parameters Matching The corresponding relationship between gas nozzle diameter and electrode diameter Gas nozzle diameter/mm Electrode diameter/mm 1.6 or 2.4 11.1 Notice: the above parameters originate from《Welding Dictionary》P142, Volume 1 of Edition 2. Gas nozzle and the shield gas flow rate...
  • Page 28 200 AC/DC 20～200 TIG of stainless steel (single run welding) Workpiece tungsten Argon gas welding Welding welding wire thickness Joint form electrode flow rate/ current speed/ diameter/mm diameter/mm L·min (DCEP) cm·min Butt joint 20～50 Butt joint 50～80 Butt joint 65～105...
  • Page 29 200 AC/DC 110～ 8～10 14～16 12～14 5～6 120～ 8～10 14～16 12～14 5～6 Notice: the above parameters originate from《Welding Dictionary》P167, Volume 1 of Edition 2. Parameters of AC TIG (MMA) for Aluminum and its alloy Argon Welding Tungsten flow Sheet...

  • Page 30: Operation Environment

    200 AC/DC 300～ 4～5 5～6 150～200 18～22 16～20 340～ 5～6 5～6 180～200 20～24 16～20 340～ 5～6 200～220 20～24 16～20 360～ 5～6 200～240 25～30 16～20 360～ 5～6 200～260 25～30 20～22 300～ 16～20 5～6 200～260 25～30 16～20 X-groove butt 360～ 22～25 5～6...

  • Page 31: Operation Notices

    200 AC/DC 4.7 Operation Notices ● Read §1 carefully before attempting to use this equipment. ● Connect the ground wire with the machine directly, and refer to §3.5. ● In case closing the power switch, no-load voltage may be exported. Do not touch the output electrode with any part of your body.
  • Page 32 200 AC/DC If the switch is not flexible or it can't be put correctly in place, please replace immediately; Please get in touch with maintenance service department if there are no accessories. After turn-on power, watch/listen to that whether the arc welding machine has shaking, whistle calling or peculiar smell.

  • Page 33: Troubleshooting

    200 AC/DC Measure the insulating impedance among the main circuit, PCB and case, if it below Yearly 1MΩ, insulation is thought to be damaged and need to change, and need to change or examination strengthen insulation. 5.2 Troubleshooting ...
  • Page 34 200 AC/DC Troubles Reasons Solution The fan motor damaged Change fan No power supply input Check whether there is power supply Turn on the power source, the power fuse inside machine lamp is not on, and fan doesn’t work...
  • Page 35 200 AC/DC Troubles Reasons Solution Electromagnetic valve is damaged Change it The adjustment knob of pre-gas Repair or change it time on the front panel is damaged The welding current potentiometer The welding current cannot be adjusted on the front panel connection is not...

  • Page 36: Electrical Principle Drawing

    200 AC/DC 5.3 Electrical principle drawing: Copyright © Mundaka Welding & Gases, Inc.
