- Page 1 Installation and Maintenance Instructions Medium & Heavy Duty Swing Gate Operators Models: SW470 SW490 Doc 01-G0665 Rev A...
-
Page 2: Table Of Contents
Pre-Installation Check List _________________________________________________ 9 Wiring Specifications _____________________________________________________ 9 System Features_________________________________________________________ 10 Installation ___________________________________________________ 12 Post Mount for SW470 Operator Only _______________________________________ 12 Pad Mount Installation ___________________________________________________ 13 Control Arm Assembly ___________________________________________________ 14 Gate Bracket Installation__________________________________________________ 16 Limit Switch Adjustments_________________________________________________ 17... -
Page 3: Contents
Contents SW470 Exploded View___________________________________________________ 26 SW490 Parts List and Drawing ___________________________________ 27 SW490 Parts List________________________________________________________ 27 SW490 Exploded View___________________________________________________ 29 Warranty Policy _______________________________________________ 30 IMPORTANT! Please leave this manual at the job site, preferably with the end user or facility manager. -
Page 4: General Information
Inspect the operator for any possible shipping damage and any shortage of parts. Please note that if accessories were ordered with this unit, some may be packed separately. PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. SW470 Powerhead 02-103 3-button control station 02-103 3-button control station 08-2001 Pipe holders 07-1202... -
Page 5: Specifications
MODEL CLASS 1 CLASS 2 CLASS 3 CLASS 4 SW470 SW490 Table 2 Specifications Model Max. Wt. (Lbs.) Max. Gate Width SW470-50 ½... -
Page 6: Safety Information
Safety Information Safety Information Vehicular gate systems provide convenience and security. Gate systems are comprised of many component parts. The gate operator is only one component. Each gate system is specifically designed for an individual application. Gate operating system designers, installers and users must take into account the possible hazards associated with each individual application. - Page 7 Safety Information STEP 2: DURING INSTALLATION Disconnect power at service panel before making any electrical connection. Avoid pinch points; be aware of all moving parts. Adjust clutch or load sensing device to minimum force setting. Do not overtighten clutch or adjust force setting above minimum. Install controls where user cannot touch gate while operating controls.
-
Page 8: Safety Precautions For Swing Gates And Ornamental "Grill Type" Gates
Safety Information Safety Precautions for Swing Gates and Ornamental “Grill Type” Gates ENTRAPMENT ZONES Pedestrians must stay clear of the gate path, particularly the area where the gate can trap them, as shown in Figure 1. 01-G0610F3 Figure 1 Gate edges and/or photo-electric beams must be incorporated into the swing gate system to assist in the protection of people who may come near the gate operating system. -
Page 9: Preparing The Installation
Preparing the Installation Preparing the Installation Pre-Installation Check List Check the gate. It must operate smoothly and freely. If necessary, lubricate the hinges, adjust or repair the gate prior to operator installation. The gate must be level. Double check the size and weight of the gate to make sure that it is proper for this application. -
Page 10: System Features
Preparing the Installation Single Phase 3 Phase 115 VAC 230 VAC 230 VAC 460 VAC 575 VAC Maximum wire length in feet for 1/3 HP motor 3,100 4,750 14,225 35,550 1,950 3,000 8,975 22,425 1,225 1,900 5,650 14,075 1,175 3,525 8,825 Maximum wire length in feet for ½... - Page 11 Preparing the Installation THREE BUTTON CONTROL (SEQUENCE OF OPERATION) Open, stop, close. Stop will override all other functions. If closing, open will cause the operator to stop and reverse to full open. If opening, close will cause operator to stop and reverse to full close position. ONE BUTTON CONTROL (SEQUENCE OF OPERATION) The one button control can be programmed to either function as described above or to function as a close button only.
-
Page 12: Installation
If it does not, damage to the operator may result and the life expectancy will be greatly reduced. SW470 gate operators have provisions for both post and pad mounting. However, because of the high torque involved in most swing gate installations, pad mounting is the recommended method. -
Page 13: Pad Mount Installation
Lay out the concrete pad as detailed. Concrete depth should be below frost line or as required by local codes. Operator cabinets may be installed either parallel to the fence, the SW470 only perpendicular to the fence. CAUTION Be sure that the measurements for the operator mounting are from the centerline of the fence and centerline of gate hinge. -
Page 14: Control Arm Assembly
Installation Control Arm Assembly Set the control arm stops on the operator in the positions appropriate for the model and installation. Then install the control arm and hub assembly to the operator output shaft. Make sure key is inserted properly in keyway. Lock with set screw. - Page 15 Installation 01-G0665F4 Figure 9 Model SW 490: Attach control arm extension to arm hub with ¼ -20 hand screws and nuts provided as shown in Figure 10. Place hub onto shaft with key and lock on with set screw. Be sure rubber seal is on end of hub to keep water out of bearing.
-
Page 16: Gate Bracket Installation
Install the gate bracket at the appropriate point on the gate (or angle, if used). As an alternative on the Model SW470 only, (2) 3/8 – 16 bolts and a nut plate are provided. Adjust arm length and then rotate the eccentric stop 180 degrees so that the small thickness is against the arm. -
Page 17: Limit Switch Adjustments
Installation Limit Switch Adjustments Limit switches are pre-adjusted at the factory and should require only slight adjustments to suit individual installations. Refer to Figure 14 to identify limit switches. CAUTION Never make adjustments before making sure that power is off and that operator direction is selected by dip switch #1, pin #2 for left or right hand operation. -
Page 18: Electrical Power Connections
Installation Electrical Power Connections CAUTION Make sure power is disconnected at the main power source and at the operator’s electrical disconnect switch before proceeding. Secure all electrical power connections inside the power wiring compartment. Use the electrical wiring diagram supplied with this unit. All single phase operators will have –... -
Page 19: Programming
Programming Programming 01-G0665F11 Figure 16 Switch #1: Operator Programming POLE #1 – SINGLE/CLOSE BUTTON ON = Close button only OFF = Open/Close Button POLE #2 – RIGHT HAND/LEFT HAND ON = Left Hand (gate will open to the left) OFF = Right Hand (gate will open to the right) 01-0665F12 (inside of fence looking out) Figure 17... -
Page 20: Switch #2: Timer To Close
Programming TOTAL TIME TOTAL TIME WARNING WARNING POLE #1 POLE #2 POLE #3 POLE #4 DEVICE DEVICE DISABLED ENABLED DISABLED DISABLED 1 SEC. 4 SEC. 13 SEC. 16 SEC. 26 SEC. 2 SEC. 40 SEC. 43 SEC. 52 SEC. 55 SEC. 65 SEC. -
Page 21: Controls And Accessory Install
Controls and Accessory Install. Controls and Accessory Install. See wiring diagram for more information. See Wiring Specifications on p. 9 for wiring distances and wire gauge information. All inputs are normally open and momentary, except the stop (NC), and emergency close and emergency open (constant pressure). -
Page 22: Manual Operation And System Check-Out
Check-Out Manual Gate Operation MANUAL OPERATION Model SW470: Remove the (2) black hand-knobs which secure the control arm assembly to the operator. The gate will swing freely when the arm assembly is removed. Model SW490: Move the arm assembly away from the closed stop. The gate may then be moved by applying force to the end of it, causing the clutch in the operator to slip. -
Page 23: Required Maintenance - Normal Usage
Required Maintenance – Normal Usage Required Maintenance – Normal Usage Check at least once every Month Intervals Internal speed sensor Check for proper operation External safety systems Check for proper operation Gate caution signs Make sure they are present Clutch system (see Check &... -
Page 24: Troubleshooting
Troubleshooting Troubleshooting A properly installed SW470 or SW490 operator will operate for many years with a minimum or service maintenance. It is important to note, however, that a binding or defective gate can severely reduce the life of the operator. The gate operation should be checked frequently as recommended by the manufacturer. -
Page 25: Sw470 Parts List And Drawing
SW470 Parts List and Drawing SW470 Parts List and Drawing SW470 Parts List Part # Qty. Description Part # Qty. Description 17-6017 PULLEY, MOTOR For 115 Volt Operators 17-G0475 PULLEY, GEAR RUDUCER 18-5206 (N) COMPRESSION SPRING 20-2100 23-2016 ALUM. STANDOFF 6-32, 3/8”... -
Page 26: Sw470 Exploded View
SW470 Parts List and Drawing SW470 Exploded View 01-G0665F13 Figure 20 Doc 01-G0665 Rev A... -
Page 27: Sw490 Parts List And Drawing
SW490 Parts List and Drawing SW490 Parts List and Drawing SW490 Parts List STANDARD PARTS Part No. Qty. Description Part No. Qty. Description 02-401S (N) STOP BUTTON 10-9024 MASER LINK, #50 03-8024 REVERSING CONTACTOR 24VAC 23-2016 LIMIT SWITCH, AUX. OPEN/CLOSE 03-ABDIN-4 DIN RAIL 28-G0518... - Page 28 SW490 Parts List and Drawing VARIABLE PARTS Variable No. Description Used On SW490-100-11, SW490- 20-XXXX-XX 20-1100-1T MOTOR, 1HP 100-81, SW490-100-21 SW490-33-11, SW490-50- 11, SW490-33-81/ MOTOR, 1/3 & 1/2HP, 20-1050-1T SW490-50-81 115/208/230V-PH SW490-33-21 SW490-50-21/ SW490-75-11 MOTOR, 3/4HP, 20-1075-1T SW490-75-81 115/208/230V -1PH SW490-75-21 SW490-10083 MOTOR, 1HP &,...
-
Page 29: Sw490 Exploded View
SW490 Parts List and Drawing SW490 Exploded View Figure 21 Doc 01-G0665 Rev A... -
Page 30: Warranty Policy
Warranty Policy Warranty Policy Seller warrants that the goods are free from defect in materials and/or workmanship for a period of one year from the date of shipment from the F.O.B. point. Goods returned to Seller for warranty repair within the warranty period, which upon receipt by Seller are confirmed to be defective and covered by this limited warranty, will be repaired or replaced (at Seller’s sole option) at no cost and returned pre-paid. - Page 31 Sentex. This documentation contains information proprietary to Sentex and such information may not be distributed without the prior written consent of Sentex. The software and firmware included in the Sentex product as they relate to this documentation...
