2. ENGINE A SSEMBLING
I n o rder t o p erform t his j ob, y ou w ill n eed t he f ollowing t ools:
Compressed a ir
Allen W rench
Fixed W rench
Flat P liers
Socket S panner
Hooker
Straight R uler
Cross S crewdriver
Flat S crewdriver
Torque W rench
1
C ompressed a ir
Unpack t he e ngine a nd r emove a ny p ackaging
material o n i t.
2
6 mm A llen W rench
Lay t he e ngine o n i ts s ide a nd a ttach t he e ngine
mount t o t he e ngine b ase w ith f our 8 m m A llen
screws.
3 -­‐ 4 -­‐ 5 -­‐ 6 -­‐ 8 m m
5 -­‐ 7 -­‐ 8 -­‐ 1 0 – 1 4 -­‐ 1 7 m m
11 m m
