MAINTENANCE

• Change the dust bag: When the dust full indicator turns red, it is time to clear the dust
or replace the bag. (Fig 8)
• Open the front cover using the clip. (Fig 9)
• Take out the bag holder then remove the full dust bag. (Fig 10)
• Replace the outlet filter: Push the clip down and remove the outlet cover by hand to
replace the filter. (Fig 11 and 12)
• The motor protection filter should be removed and rinsed once a year. It can be reused
once it is dry. If the filter is damage, replace the filter. (Fig 13)
Fig 8
Fig 11

TECHNICAL DATA

Voltage 220–240V~50/60Hz
Output 1000 W
Total range 7.5 m
Sound level Max 81dB
Filtering Sponge filter
Dust capacity 2.5 litre
Suction power Max 170 W
Cord length
5 m
Weight 3.7 kg
Dimensions 360 x 260 x 210mm
Fig 9
Fig 12
Fig 10
Fig 13
