3.1 CD ENCODER 10 MAIN UNIT

1. USB SOCKET
2. SD/MMC SOCKET
3. RECORD FROM MIC key
4. RECORD FROM LINE-IN key
5. RECORD FROM CD key
6. CONFIRM key
7. RECORD TO SD/MMC key
8. RECORD TO USB key
9. MIC/LINE IN REC LEVEL- key
10. MIC/LINE IN REC LEVEL+ key
11. VOLUME- key
12. VOLUME+ key
13. FOLDER- key
14. FOLDER+ key
15. INFO key
16. PLAY LIST key
17. PREVIOUS
18. NEXT key
19. REPEAT key
20. SD-USB-CD key
21. STOP Key
22. PLAY/PAUSE
23. RECORD
24. OPEN/CLOSE BUTTON
25. LEFT MIC
26. REMOTE SENSOR : To receive
signals from the remote control.
27. RIGHT MIC
28. LINE IN JACK
• Audio Input Jack 3.5mm.
29. PHONES JACK
• Connection for phones
30. POWER button
• Press to turn the power ON/OFF
31. LINE OUT LEFT
32. LINE OUT RIGHT
key
Key
key
3.2 REMOTE CONTROL
1. STANDBY/ON key
2. RECORD TO SD/MMC key
3. RECORD TO USB key
4. RECORD FROM MIC key
5. RECORD FROM LINE-IN key
6. RECORD FROM CD key
7. FOLDER + key
8. REC LEVEL+ key
9. VOLUME + key
10. FOLDER - key
11. REC LEVEL- key
12. VOLUME - key
13. SD-USB-CD key
14. REPEAT key
15. PLAY LIST key
16. REW key
17. PLAY/PAUSE
18. FF key
19. INFO/CONFIRM key
20. STOP key
21. RECORD
E-6
key
key
