- Page 1 AMD LASERS, LLC 608 Rolling Hills Dr. Johnson City, TN 37604 USA T: +1 (866) 999-2635 F: +1 (678) 868-4108 www.amdlasers.com OPERATING INSTRUCTIONS MANUAL 7.1 PICASSO & PICASSO LITE OIM 7.1 ENGLISH ©2009-2013 AMD LASERS, LLC. All rights reserved. AMDOIM7ENG0413...
- Page 2 Protection Against Vertically Falling Only Applicable for USA Drops of Water (e.g. Condensation) MT Promedt Consulting GmbH Altenhofstr, 80 D-66386 St. Ingbert, Germany Tel: +49 6894-58 10 20 Fax: +49 6894-58 10 21 www.mt-procons.com ©2009-2013 AMD LASERS, LLC. All rights reserved.
-
Page 3: Table Of Contents
The Picasso line of soft tissue dental lasers is designed for a wide variety of oral soft tissue and teeth whitening procedures. Picasso & Picasso Lite lasers utilize solid state diodes as a laser energy source. The energy is delivered to the operating area by means of a delivery system consisting of a flexible fiber connecting the laser source and the handpiece. - Page 4 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. enable the footswitch. One beep will sound to indicate that the system is ready for use. The STANDBY/READY button on the Picasso will turn green.
-
Page 5: Contents Of Picasso & Picasso Lite
Protective Case Unit Keys Used to Turn Machine Off/On Wireless Foot Control Wireless Foot Control Standard Picasso & Picasso Lite Connects the Unit & Net Power Supply AC Adapter Input: 100–240 V 50/60 Hz, Output: 9 V–3A AC/DC adapter is specified as a part of ME EQUIPMENT. -
Page 6: Indication For Use
6. Connect remote interlock. 7. Connect power cord to power connector on unit and plug into wall outlet. Use of Picasso & Picasso Lite is generally indicated for incision, excision, vaporization, ablation and coagulation of oral soft tissues including the following: 8. - Page 7 To select the brightness for aiming beam, first press the SETTINGS button. Then press the button to change the brightness settings. There are five levels for Picasso: Off / Weakest / Weak / Strong / Strongest. VOLUME settings To select the volume, press the SETTINGS button. Then press the button to change the volume settings.
-
Page 8: Warnings
Replace with a new alkaline AA size battery as indicated in the battery compartment. Replace battery cover and AMD Picasso and Picasso Lite Diode Laser Systems are for Dental Use Only according to the Indications for Use in this OIM Version verify operation by depressing the foot-control button, returning the unit to standby, and viewing the green activity light. - Page 9 Slide the whitening adapter (1) onto the Quadra Tips (2) until it is fully seated. *Customer supplied disposable tip (18 gauge or larger) Note: The AMD LASERS logo should face up on the adapter, and the notch on the adapter should align with the Quadra Tips peg. To connect handpiece to fiber optic assembly: The Quadra Tips are used 1–2 mm from the teeth once the bleach is placed on the teeth.
- Page 10 Ensure that the fiber is secure by pulling lightly on the fiber optic cable at the proximal end. • 300 µm and 400 µm tips may be used according to the Picasso or Picasso Lite duty cycle up to 5 W. The 200 µm tips may not 8.
-
Page 11: Product Specifications
SPEED MODE setting by first selecting desired parameter for power and then by pushing and holding down the Speed button for Picasso or 30 ms for Picasso Lite. In pulse mode, the wattage is reduced meaning that a setting on 1.0 W in pulse mode may for approximately 5 seconds. -
Page 12: Instructions For Accessories
5.0–7.0 W Intermittent Operation 5 min on, 4 min off or in standby mode. to the end of the Quadra Tips with care taken to ensure the AMD LASERS logo is facing up. The Quadra Tips do not make contact with the patient during the whitening procedure. -
Page 13: Maintenance
_____//______//___________ __________________________________ (36 months after purchase date) CALIBRATION PROCEDURE Picasso & Picasso Lite comes factory calibrated and certified for use. For accurate treatment results, the unit(s) should be calibrated Calibration 4 _____//______//___________ __________________________________ every 12 months following the date of manufacture. Due to the potential for electrical shock, personal injury, or death; calibration (48 months after purchase date) should only be performed by authorized personnel. - Page 14 IEC 60601-2-22:2007 VISIBLE AND INVISIBLE LASER RADIATION AMD LASER Logo AVOID EYE OR SKIN EXPOSURE TO IEC Explanatory Label (Picasso Lite) DIRECT OR SCATTERED RADIATION CLASS 4 LASER PRODUCT Working Beam: 810 nm, Max 2.5 W Pulse Duration: 30 ms Aiming Beam: 630–670 nm, Max 5 mW...
- Page 15 UNDER THE LIMITED WARRANTY, BUT WILL REQUIRE THE RETURN OF THE DEFECTIVE PART. A CREDIT CARD WILL BE NEEDED TO SECURE THE VALUE OF THE DEFECTIVE UNIT AND WILL BE CHARGED IF DEFECTIVE PART IS NOT RETURNED TO AMD LASERS IN A TIMELY MANNER OR IF,...
-
Page 16: Limited Liability
NOT LIMITED TO, DAMAGES FOR LOSS OF REVENUE, LOSS OF BUSINESS OR BUSINESS OPPORTUNITY, OR OTHER SIMILAR FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE PERFORMANCE, USE, OR INTERRUPTED USE OF THE “PICASSO” SYSTEM(S) OR ANY AMD Wire transfer only (Banking information available upon request) LASERS MATERIALS.
