- Page 1 Portable electric folding bike OPERATION MANUAL...
- Page 2 DIAMOND TECH JUPITER BIKE 5600 AIRPORT BLVD. TAMPA, FL 33634 813-609-BIKE (2453) sales@jupiterbike.com www.Jupiterbike.com...
-
Page 3: Table Of Contents
Structural Diagram - 4 Specifications - 5 Operation Instructions - 6 Throttle & Brake Controls - 10 Charging Information - 11 Maintenance - 14 Precautions When Riding - 15 While Parked - 17 Proper Riding Attire - 17 Troubleshooting - 18 Warnings - 20 Acceptable riding practices and conditions - 23... -
Page 4: Structural Diagram
STRUCTURAL DIAGRAM PRODUCT DIMENSIONS COMPOSITION Folded: 16.3” x 20.5” Assembly Required: Unfolded: (Adjustable Seat) 49” x 6.29” x 35.5” Frame: Aluminum Product Weight: 21 lbs Wheels: Rubber Wheel Base: 39 Inches Break Type: Electric... -
Page 5: Specifications
SpeCIfICATIonS BATTERY & MOTOR Wattage: 240w Type: LG Lithium Battery Full Charge Time: 2 hours Max Charged Voltage: 48 V Auto Shutoff Full Charge: Motor Type: Brushless Hub Motor Charger Input: 100-240VAC CAPACITIES Maximum Distance: 15 Miles *Distance w/ expanded battery pack: 35 miles Max Weight: 200 lbs... -
Page 6: Operation Instructions
opeRATIon InSTRUCTIonS... - Page 9 • In order to ensure the safety of your riding, please read Operation Manual carefully and check whether all the parts are in good condition before riding. Please contact us if there are any problems. • Please read the manual carefully and abide by all Safety Measures •...
- Page 10 ACCeLeRAToR & BRAke ConTRoLS BRAke THRoTTLe Starting the Bike: Press the power switch. At this point the power light is on, indicating that the power has been switched on. Using the Accelerator: To engage the accelerator, press the throttle lever down. Note that the more you press down on the throttle, the faster the Jupiter Bike will move.
-
Page 11: Charging Information
CHARGInG InfoRMATIon For this type of lithium battery the Input Voltage range should be: 100~240 VAC. Methods of Use: 1. When charging, do so in a well ventilated area making sure to insert the charging plug into the charging socket beneath the main tube first, then connecting the adapter to the power source. -
Page 12: Battery Care
Battery Care: 5. Do not over-charge or fully drain the battery. 6. Do not cover the charger or battery with anything when charging- doing so would create a risk of overheating and fire. 7. Keep the battery away from direct sun exposure. If not using the bike for a long time, charge it at least once every 30 days. - Page 13 Charger Use: 12. Inspect supplied charger regularly for damage to cord, plug, enclosure or other parts. If damage is detected Do not use charger until it has been repaired by a suitable technician or replaced. 13. The charger contains high voltage circuit, please do not disassemble yourself.
-
Page 14: Maintenance
MAInTenAnCe To clean your Jupiter Bike, use a soft damp cloth to wipe clean. Never use corrosive or flammable chemical solvents to clean your Jupiter Bike. Do not use a pressure spray gun on your Jupiter Bike. When not in use, store the Jupiter Bike in a cool dry area. Never leave the Jupiter Bike outside for an extended period of time. -
Page 15: Precautions When Riding
pReCAUTIonS wHen RIDInG 1. Before riding, always check if the battery is sufficiently charged, tires are intact, and brakes are working properly. 2. Always wear a helmet and other appropriate protective gear when using the electric bike. 3. Riding in snow and rain or wet surfaces will severely impact braking performance. - Page 16 8. Obey Local Traffic Rules. 9. The Jupiter Bike is for riding on paved roads only. This is not an off- road vehicle. Serious injury or death could occur if used off-road or on unpaved surfaces. 10. Do not modify your Jupiter Bike without consulting Diamond Tech first.
-
Page 17: While Parked
Prolonged incline riding will damage battery life. 17. This manual may not cover every situation you may encounter using this product. For more information please contact us at JupiterBike.com with any questions. wHILe pARkeD 1. When finished riding and you have parked, you should turn the power switch off to prevent accidental starts or battery damage. -
Page 18: Troubleshooting
TRoUBLeSHooTInG 1. The power indicator light is not on: A. Check the AC Input B. Check the Input interface contact If both A and B are excluded, please contact us. 2. The charger indicator light is not on: A. Check the output interface contact B. -
Page 20: Warnings
wARnInGS To enjoy your Jupiter bike fully please read this section in its entirety and please take it seriously. RIDe AT yoUR own RISk AnD USe CoMMon SenSe. fAILURe To USe CoMMon SenSe AnD HeeD THe wARnInGS BeLow onLy SeRveS To InCReASe THe RISk of SeRIoUS InJURy AnD/oR DeATH. - Page 21 wARnInG: pARenTAL AnD ADULT ReSponSIBILITy & SUpeRvISIon IS neCeSSARy: Because products, like electric bicycles, can and do present potential hazards plainly associated with their use, it is well recognized THE NEED FOR ExERCISE OF PARENTAL RESPONSIBILITY IN SELECTING RIDING PRODUCTS APPROPRIATE TO THE AGE OF THE CHILD, OR PARENTAL SUPERVISION IN SITUATIONS IN WHICH CHILDREN OF VARIOUS AGES MAY HAVE ACCESS TO THE SAME RIDING PRODUCTS, IS IMPORTANT.
- Page 22 Do noT eXCeeD THe weIGHT LIMIT of 200 lbs. Rider weight does not necessarily mean a person’s size is appropriate to fit or maintain control of the bicycle. CHeCk AnD MAInTAIn THe BICyCLe BefoRe eACH USe Before each use, check to confirm that the bicycle frame is in good condition with no cracks or other breaks.
-
Page 23: Acceptable Riding Practices
ACCepTABLe RIDInG pRACTICeS & ConDITIonS Always check and obey any local laws or regulations which may affect the locations where the electric bicycle may be used. Keep safely away from cars and motor vehicle traffic at all times. Only use where allowed and with caution. Do not activate the accelerator unless you are on the bicycle wearing safety gear and in a safe, outdoor environment suitable for riding. -
Page 24: Warranty -24
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. ReTURnS & eXCHAnGeS: Please refer to our website JupiterBike.com for all product exchange information & procedures. Please keep the original packaging. DIAMOND TECH...
