EnviroRanger ERS 500
33455560
Rev
2.0
Programming Reference
PL-556
Nov. 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EnviroRanger ERS500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Milltronics EnviroRanger ERS500

  • Page 1 EnviroRanger ERS 500 Programming Reference PL-556 Nov. 1999 33455560...
  • Page 2 Milltronics, we endeavour to design equipment that is simple to use and reliable in its operation, with the aim of Ultrasonic level satisfying our customers' needs. Milltronics has been designing and manufacturing electronics based process measurement equipment since 1954. Our...
  • Page 3: Table Of Contents

    Table of Contents Introduction ..................7 About this Manual ............. 7 Using this Manual ............. 8 About the EnviroRanger ..............9 Display ................10 Hand Programmer ............11 Readings in Run Mode ........... 12 Programming the EnviroRanger ............15 Starting Program Mode ........... 16 Parameter Indexing............
  • Page 4 Display and Reading (P060 to P062) ......66 Failsafe (P070 to P072) ..........69 Relays (P100 to P119) ............ 72 Pump Setpoint Modifiers (P121 and P122) ..... 88 Independent Relay Failsafe (P129)......... 90 Advanced Pump Control Modifiers (P130 to P136)..91 Pump Energy Cost Reduction (P140 to P145)....
  • Page 5 Appendix A – Technical Reference..........197 Transmit Pulse .............. 197 Echo Processing ............197 Distance Calculation ............. 198 Sound Velocity .............. 199 Scanning ............... 199 Volume Calculation ............200 Flow Calculation............201 Maximum Process Speed ..........203 Appendix B – Troubleshooting ............205 Common Problems Chart..........
  • Page 6 Page 6 EnviroRanger Programming Reference PL-556...
  • Page 7: Introduction

    It can also time events to maximize efficiency or minimize cost. About this Manual This is the Programming Reference manual for the Milltronics EnviroRanger integrated level monitoring and control system. The manuals in the EnviroRanger library are:...
  • Page 8: Using This Manual

    Using this Manual Information Section Page Learn the concepts behind how About the EnviroRanger the EnviroRanger operates. Learn how to change parameter Programming values. To configure the EnviroRanger Application Examples for a particular application. To test the unit’s programming Testing the Configuration before putting it into full operation..
  • Page 9: About The Enviroranger

    About the EnviroRanger The EnviroRanger has two modes of operation: Program Mode Program mode allows the programmer to change parameter values and alter the way the unit operates. Note: • If the unit has been programmed and is in normal operation then putting it in program mode will de-energize all control relay outputs.
  • Page 10: Display

    Display Wall Mount Rack or Panel Mount Program Mode Run Mode index type index type index index parameter value primary reading units units auxiliary function hi and hi hi alarm level display scroll access tag filling display scroll access tag emptying display lo and lo lo alarm relay # programmed...
  • Page 11: Hand Programmer

    Hand Programmer Note: The hand programmer is ordered separately from Milltronics. Numeric Auxiliary Function Programming Mode Run Mode 8-digit Totalizer (toggle) Pump Running Time Head Flow based on Head Temperature Rate of Change Failsafe Time Left Time Date Decimal Point (TVT left)
  • Page 12: Readings In Run Mode

    Readings in Run Mode When the EnviroRanger is in run mode the values displayed can be changed by using keys on the hand programmer. All readings are shown in the Auxiliary field except for the totalizer and P920. Press this Key Function Toggle Readings between percent and units P920...
  • Page 13 Scrolling Display During “differential” or “average” Operation (P001 = 4 or 5), the display scrolls sequentially through Point Numbers 1, 2, and 3. Point Number 3 represents the difference between or average of Point Numbers 1 and 2. See Display (P730 to P739) on page 166 for more information. PL-556 EnviroRanger Programming Reference Page 13...
  • Page 14 Page 14 EnviroRanger Programming Reference PL-556...
  • Page 15: Programming The Enviroranger

    Programming the EnviroRanger To meet the needs of any given application the EnviroRanger must be correctly programmed. The EnviroRanger is programmed by changing parameter values. The available parameters are described in detail in the Parameter Reference on page 55 and sample applications are given in Application Examples on page 23.
  • Page 16: Starting Program Mode

    Starting Program Mode Entering program mode has the following effects: • all operating data is retained in memory • alarm relay status is held at last known values • control relays are de-energized (unless affected by parameter alteration or is pressed) •...
  • Page 17: Changing Parameters (Dolphin Plus)

    To access the index of a particular parameter: • Press once • Enter the parameter number • Press twice • Press the number of the required index, or • Press to scroll through the available values Note: When dealing with indexed parameters it is critical to ensure that you set the values accurately.
  • Page 18: Changing Parameters (Hand Programmer)

    Dolphin Plus is the primary method of changing EnviroRanger parameters. Most examples in this manual use the icons from the hand programmer but nearly all functions are also available through Dolphin Plus. The Dolphin Plus software is available separately from Milltronics. Changing Parameters (Hand Programmer) From Run mode, press and then to put the unit into Program mode.
  • Page 19: Special Parameters

    Special Parameters View Only Some Parameter Values are for display purposes only and cannot be altered. These are referred to as view only parameters. In the Parameter Reference section of this instruction manual, view only parameters are identified by a “(V)” beside the Parameter Number. Global Some parameter values must be common for all inputs and outputs on the EnviroRanger.
  • Page 20: Security

    Security All operator programming is retained in non-volatile memory, immune to power interruptions. When programming is complete, the programmer may be locked away to prevent inadvertent programming alteration. As well, the Lock (P000) parameter may be used. Displays The following displays are shown when the EnviroRanger cannot display a number.
  • Page 21: Planning Considerations

    Planning Considerations Review the Application When reviewing the application into which the EnviroRanger will be installed, note the: • Pump control system inputs and outputs • Dimensions of the wet well or reservoir (especially if pumped volume will be used) •...
  • Page 22: Test The Installation

    Test the Installation Test the inputs and outputs as shown in Testing the Configuration on page Document the Installation Use Dolphin Plus to record your parameter values for later reference. Page 22 EnviroRanger Programming Reference PL-556...
  • Page 23: Application Examples

    Application Examples Note: When the unit is first turned on it will give distance (P001=3) in meters from the transducer face to the material surface. If the wet well or reservoir is empty then this reading is the empty distance (P006) from the transducer face to the reservoir bottom.
  • Page 24 Setting a High High Alarm Relay Parameter Value Description Index P111 These settings trip the alarm when the P112 1.2m level rises above 1.2m and reset the alarm when the level falls below 1.15m. P113 1.15m Setting a Low Alarm Relay Parameter Value...
  • Page 25 Setting a Filling Rate Alarm Relay Parameter Value Description Index P111 These settings trip the alarm when the P112 reservoir is filling faster than 1m per minute and reset it at 0.9m per minute. P113 0.9m Setting an Emptying Rate Alarm Relay Parameter Value...
  • Page 26: Pump Control

    Pump Control See Parameters section for complete details on specific parameter values. Setting a Pump Down (Wet Well) Group Sets a group of three pumps to pump down a wet well. EnviroRanger with advanced pump control algorithms P006 outflow inflow P007 Set the Common Parameters Prerequisite: You must know the details of your application and substitute...
  • Page 27 Set the “On” Setpoints Relay Parameter Value Description Index Sets the three setpoints for the pump P112 1.0m relays. The first cycle will use these P112 1.1m setpoints. Subsequent cycles rotate the P112 1.2m setpoints among the pumps. Set the “Off” Setpoints Relay Parameter Value...
  • Page 28 Optional: Totalizing Pumped Volume Prerequisite: the volume of the wet well or reservoir must be known. Parameter Index Value Description P001 Operation = pumped volume P002 P003 P004 These parameters are “as above.” P005 P006 P007 P050 Tank volume is “flat-bottom” P051 17.6 Max volume is 17.6 m...
  • Page 29 Setting a Pump Up (Reservoir) Group Sets a group of three pumps to pump up a reservoir. EnviroRanger with advanced pump control algorithms P006 inflow P007 outflow Set the Common Parameters Prerequisite: You must know the details of your application and substitute the values for the sample values provided.
  • Page 30 Set the Relay “On” Setpoints Relay Parameter Value Description Index Sets the three setpoints for the pump P112 0.4m relays. The first cycle will use these P112 0.3m setpoints. Subsequent cycles rotate P112 0.2m the setpoints among the pumps. Set the Relay “Off” Setpoints Relay Parameter Value...
  • Page 31 Connecting a Pump Control Interlock EnviroRanger with advanced pump control algorithms using pump interlocks P006 outflow discrete input P007 inflow relay output Relay Parameter Value Description Index P111 Sets the pump relays (index 1, 2, and P111 3) to “alternate duty assist”. P111 P505 Sets discrete inputs 3, 4, and 5 as the...
  • Page 32: Open Channel Monitoring (Ocm)

    Open Channel Monitoring (OCM) See Parameters section for complete details on specific parameter values. There are three ways of defining an OCM installation depending on your Primary Measuring Device (PMD). See the listed examples for required parameters. • Dimensional is provided for some common weir and flume types. For these PMDs the dimensions (P602) are entered directly.
  • Page 33 Set the Common Parameters These “Quick Start” parameters are required for all installations. Dimension examples on next page. Parameter Index Value Description P001 Operation = OCM P002 Material = liquid P003 Maximum Process Speed = medium P004 Transducer = XPS-10 P005 Units = meters P006...
  • Page 34 Setting Zero Head Many PMDs trap a pool of liquid when there is no flow. There are two methods of accounting for this trapped liquid: Use P605 Zero Head to raise the start of Span (P007) above the Empty distance (P006). See P605 (G) Zero Head on page 143. P006 P007 P605...
  • Page 35: Bs-3680 / Iso 1438/1 Thin Plate V Notch Weir

    Setting Totalized Volume To display the totalized volume on the LCD use the following parameters: Parameter Index Value Description Show the eight digit totalizer in the P737 primary display Direct Support BS-3680 / ISO 1438/1 Thin plate V notch weir notch angle transducer P006...
  • Page 36: Bs-3680 / Iso 4359 Rectangular Flume

    BS-3680 / ISO 4359 Rectangular Flume 3 to 4 x h = P007) flow transducer P006 flow (P608) P605 (p) Parameter Index Value P600 6 – ISO 4359 Rectangular Flume P602 Approach width (B) Throat width (b) Hump Height (p) Throat length (L) (view only) Velocity coefficient (Cv)
  • Page 37: Palmer Bowlus Flume

    Palmer Bowlus Flume Flow D/2, point of Plan view transducer measurement P006 P007 P603 Side view Front view P605 Parameter Index Value P600 2 – Palmer Bowlus Flume P602 Flume width (D) P603 Maximum Head (preset = P007) P604 Maximum Flow P605 Zero Head P606...
  • Page 38: H Flume

    H Flume transducer point of measurement plan view P006 P007 front view side view Parameter Index Value P600 3 – H Flume P602 Flume height (D) P603 Maximum Head (preset = P007) P604 Maximum Flow P606 Time Units • Sized by maximum depth of flume, D •...
  • Page 39: Standard Weirs

    PMDs with Exponential Flow to Head Function For Primary Measuring Devices (PMDs) that measure flow by an exponential equation use these parameters. Ensure that you use the correct exponent for your PMD, the values below are samples only. Standard Weirs transducer weir profile Applicable Weir Profiles...
  • Page 40: Parshall Flume

    Non-Applicable Weir Profiles contracted compound Poebing approximate rectangular exponential Flows through these weirs can be measured using the universal flow calculation P600 = 4 or 5. See Universal Calculation Support on page 42. Parshall Flume C = converging dimension Plan View transducer P006 Front View...
  • Page 41 Leopold Lagco Flume throat plan view transducer converging diverging point of measurement P006 P007 P603 Head side view front view P605 Parameter Index Value P600 1 – Leopold Lagco Flume P601 1.55 P603 Maximum Head (preset P007) P604 Maximum Flow P605 Zero Head P606...
  • Page 42: Cut Throat Flume

    Cut Throat Flume Plan View • Similar to Parshall flume except that the floor is flat bottomed and throat has no virtual length. • Refer to manufacturer’s specifications for flow equation and point of head measurement. Parameter Index Value P600 1 –...
  • Page 43: Example Flumes

    Characterization is achieved by entering the head (P610) and corresponding flow (P611), either from empirical measurement or from the manufacturer's specification. The more breakpoints that are defined, the more accurate will be the flow measurement. Breakpoints should be concentrated in areas exhibiting the higher degrees of non linear flow.
  • Page 44: Gate Control

    Gate Control See Parameters section for complete details on specific parameter values. This technique can also be applied to some types of valves. Setting a Gate (Penstock) Control transducer gate overflow relays flow direction Set the Common Parameters Prerequisite: You must know the details of your application and substitute the values for the sample values provided.
  • Page 45 Set Relay 1 (Open Gate) Relay 1 is wired to the “open” connections on the gate control. When relay 1 is energized the gate moves up. Parameter Index Value Description P111 Sets relay 1 to energize (open gate) when the level is below 45% of the span P112 (0.63m).
  • Page 46: Rake (Screen) Control

    Rake (Screen) Control Screens or rakes are mounted on the inflow channel of the wastewater treatment plant to prevent debris from clogging the equipment. When material builds up on the screen a level differential is created with the water level higher in front of the screen than behind it. When this differential reaches the programmed setpoint the EnviroRanger activates a relay to run mechanical rakes to clean the screen and ensure a steady flow into the treatment process.
  • Page 47 Parameter Index Value Description P001 Operation = Differential P002 Material = liquid P003 Maximum Process Speed = medium P004 Transducer = XPS-10 P005 Units = meters P006 Empty = 1.8m Empty = 2.2m P007 Span = 1.4m Span = 1.4m Set Relay 1 (Operate Rake) Parameter Index...
  • Page 48 Page 48 EnviroRanger Programming Reference PL-556...
  • Page 49: Testing The Configuration

    Testing the Configuration Once you’ve programmed the EnviroRanger you must test the device to ensure that it performs to your specifications. This test can be run in simulation mode or by varying the level in the wet well. The latter is preferred as it more accurately represents running conditions.
  • Page 50 Simulating a Level Cycle To start a (P920, P921, P922, or P923) simulation (from level = 0)... Press to simulate level rise and fall at 1% of Span / second. Use the keys to adjust the simulated rate of rise or fall. Rise at 4% of Span per second (maximum) Rise at 1 % of Span per second (preset at start of simulation) Stopped...
  • Page 51: I/O Checkout

    I/O Checkout Once the EnviroRanger is installed a test is usually performed to verify the wiring. Relays Use P119 (IR) Relay Logic Test (page 87) to force a state change and verify that the results are as expected (pump starts, alarm sounds, etc.). Discrete Inputs Use P270 to force the input value and verify that the results are as expected (pump removed from rotation, overflow event, etc.).
  • Page 52: Application Test

    Application Test If the application is being tested by varying the material level (preferred) then ensure that none of the control devices are connected (or at least there is no power available to them). If the application is being tested in simulation mode (and P000 is not -1) then control relays are not energized and they can remain connected.
  • Page 53 For normal operation, return to the Run mode. The EnviroRanger will perform reliably, requiring little or no maintenance. Connect (or enable) process control/alarm equipment to the EnviroRanger only after satisfactory performance is verified for all possible operating conditions. PL-556 EnviroRanger Programming Reference Page 53...
  • Page 54 Page 54 EnviroRanger Programming Reference PL-556...
  • Page 55: Parameter Reference

    Parameter Reference How to Read the Reference Each item in the programming reference has five sections: Title The number, type and name of the parameter. Possible types are: Type Name Description Global This parameter applies to the entire unit View only This parameter can not be set, only viewed Transducer Indexed by transducer (if P001=4 or 5)
  • Page 56 P000 (G) Lock Use this parameter to secure the EnviroRanger from changes. WARNING Use this lock as backup security only. It uses a fixed value which can be discovered by unauthorized personnel. Access this parameter directly (type the number 000) and enter any value (other than 1954) to secure the programming lock.
  • Page 57: Quick Start (P001 To P009)

    Quick Start (P001 to P009) P001 (G) Operation Sets the type of measurement required for the application. If 0 – “out-of-service” is entered alarm relay(s) energize (set “off”), and pump relay(s) de-energize (set “off”). If “DPD” or “DPA” is entered, either 2 transducers of the same type are required, or one transducer and one mA input.
  • Page 58 Transducer Scanning (P726 to P728) on page 164 • Rate (P700 to P708) on page 159 P004 (G) Transducer Specifies the Milltronics transducer connected. Enter the type of transducer(s) connected to the EnviroRanger. If multiple transducers are used they must be of the same type. Values...
  • Page 59 P005 (G) Units Specifies the units used for dimensional values. Changing this value automatically changes the units displayed for all parameters. Existing values are converted and do not have to be re-entered. Values Meters Centimeters Millimeters Feet Inches Related • P060 (IT) Decimal Position on page 66 P006 (IT) Empty The distance in “units”...
  • Page 60 Always prevent the monitored surface from approaching within 0.33 m (1 ft) of the transducer face as this is the minimum blanking for most Milltronics transducers (some require more blanking – see your transducer manual). Many other parameters are set as a percentage of span (even if they are entered in units).
  • Page 61 Year 2000 Compliance 00-69 Assumed to be the years 2000 to 2069 70-99 Assumed to be the years 1970 to 1999 Values 70:01:01 to 69:12:31 P009 (G) Time Time is the current time in 24-hour format: HH.MM.SS. The time is entered using the numeric keypad and the decimal “.”...
  • Page 62: Volume (P050 To P055)

    Volume (P050 to P055) To enable the EnviroRanger to show readings based on vessel or wet well volume (rather than level) use these parameters. If one of the “universal” tank shapes is used then follow this procedure: • Plot a volume to height chart •...
  • Page 63 Values 0 = volume calculation not required (preset) 1 = flat level bottom 4 = half sphere bottom 8 = sphere 2 = cone / pyramid bottom 5 = flat sloped bottom 9 = universal linear 6 = flat ends 3 = parabola bottom 10 = universal curved 7 = parabola ends...
  • Page 64 Values 0.0 to 9999 Preset: 100.0 Related • P006 (IT) Empty on page 59 • P007 (IT) Span on page 60 • P060 (IT) Decimal Position on page 66 P052 (G) Tank Dimension ‘A’ This is dimension ‘A’ as used in P050 (G) Tank Shape on page 62. Enter the height of the tank bottom if P050 = 2,3,4, or 5, or the length of one end section of the tank if P050 = 7, in Units (P005).
  • Page 65 P055 (IB) Volume Breakpoints (Universal Volume Calculation) Each segment defined by the level breakpoints (P055) requires a volume to allow the EnviroRanger to make the level-to-volume calculations. These values should be provided by the tank manufacturer. Some typical volume calculations are: Sphere V = (4/3)πr Cone...
  • Page 66: Display And Reading (P060 To P062)

    Display and Reading (P060 to P062) Alter the following parameters to: • Change the number of decimal places displayed • Convert the Reading to alternate units • Reference measurements to other than Empty (P006) or Span (P007) P060 (IT) Decimal Position Defines the maximum number of decimal places used on the LCD.
  • Page 67 This method does not calculate volume and must not be used in place of the volume parameters if any volume dependent features (such as pump efficiency) are used. To calculate true volumes see Volume (P050 to P055) on page 62. Avoid entering a value that, when multiplied by the maximum current Reading, could exceed five digits before the Decimal Position or the device will not display the value correctly.
  • Page 68 Related • P920 (IL) Reading Measurement on page 193 Page 68 EnviroRanger Programming Reference PL-556...
  • Page 69: Failsafe (P070 To P072)

    Failsafe (P070 to P072) The failsafe parameters are used to ensure that if no valid level reading is available then the devices controlled by the EnviroRanger default to an appropriate state. By default, if an error condition is detected then the display and relay status are held at their last "known"...
  • Page 70 Values 0.000 to 9999 Preset: 10.00 minutes Related • P003 (IT) Maximum Process Speed on page 58 • P129 (IR) Relay Failsafe on page 90 P071 (IT) Failsafe Material Level The material level reported when a Failsafe State is initiated. There are four possible settings for this parameter: HOLd Keep the last known material level...
  • Page 71 Related • P001 (G) Operation on page 57 • P006 (IT) Empty on page 59 • P007 (IT) Span on page 60 • P111 (IR) Relay Control Function on page 74 • P112 (IR) Relay “on” Setpoint on page 84 •...
  • Page 72: Relays (P100 To P119)

    Relays (P100 to P119) The EnviroRanger comes with five relays, sometimes called digital outputs, typically used to control devices and alarms. While the number of devices directly controlled is limited by the relays all control functions are accessible through software. Refer to the EnviroRanger Communications Reference for information on accessing information through software.
  • Page 73 Parameters Affected by Pre-set Applications Value # Parameters affected 0 All relays set “off” Pump down with the following level settings: Wet Well 1 Relay # Parameter P111 1 (H) 1 (L) P112 – P113 – Pump down with the following level and rate settings: Relay # Parameter Wet Well 2...
  • Page 74 P110 (IR) Level Source The level source on which the indexed relay matches setpoints. This value is reset if Relay Set Up (P100) is altered. Points 2 and 3 are available only if Operation is set for difference or average (P001 = 4 or 5). Values Point # 1 = transducer 1 Point # 2 = transducer 2...
  • Page 75 Values Control Type Relay Control General Relay set off, no action Level based on level setpoints “on” and “off” when level enters the range between “on” In Bounds and “off” setpoints when level exits the range between “on” and Out of Bounds “off”...
  • Page 76 P111 (IR) Alarms (values 0-12) EnviroRanger alarm relays are normally closed but can be adjusted using P118 (IR) Relay Output Logic on page 86. Power Failure When power is cut to the EnviroRanger its relays fail in the following states: Rack or Panel Mount Wall Mount Relay...
  • Page 77 To select a Level Alarm Designation (L,LL,H,HH or blank)... Press to display the Auxiliary Function symbol, Press as required to scroll to the alarm designation, Press to enter the value. In Bounds (2) Use the “on” setpoint (P112) to define the top of the setpoint dead band bounded area.
  • Page 78 Temperature (5) Use the “on” and “off” setpoints to define the temperatures to trip and reset the alarm relay. All temperatures are specified in °C. Loss of Echo (6) Use the loss of echo (LOE) alarm to trip a relay when the device fails to read echos.
  • Page 79 P111 (IR) Flow Totals (values 40-41) EnviroRanger pump relays are normally open but can be adjusted using P118 (IR) Relay Output Logic on page 86. LCD Status Indicators Normal Totalizer pulse (momentary) Relay contact open Relay contact closed P118 as preset P118 as preset The relay is activated by units of totalized flow from Pumped Volume or OCM:...
  • Page 80 The source of units varies depending on the operation: Operation Units Source Parameter P604 (G) Maximum Flow on page 143 OCM (P001=6) P608 (G) Flowrate Units on page 145 Pumped Volume (P001=7) P051 (G) Max Volume on page 63 Related •...
  • Page 81 Pump Up (reservoir) set the “on” setpoint (P112) below the “off” setpoint (P113) in units (P005) or percent of span (P007). LCD Status Indicators Pump off Pump on Relay contact open Relay contact closed P118 as preset P118 as preset Values Duty Assist...
  • Page 82 FIFO (56) The “on” and “off” setpoints are shared for the pump group and pumps are started using the alternate algorithm but are shut off using the “first in, first out” rule. “Off” setpoints are generally staggered. Note: Do not use “FIFO” pump sequencing with volume totalization because for totalization to work all of the pump “off”...
  • Page 83 Overflow (61) Use the "Overflow Control" Relay Function to activate a device based upon high levels associated with Overflow conditions. e.g. Open gate (valve) to divert overflow into a holding vessel and optionally turn off pumps. See Overflow / Underflow (P160 to P169) on page 99 for details.
  • Page 84 P112 (IR) Relay “on” Setpoint The process point at which the relay changes from its “normal” state. For most applications this is the point at which the relay is tripped. For “in- bounds” and “out-of-bounds” alarms it is the high point in the specified range.
  • Page 85 P114 (IR) Relay “duration” Setpoint The length of time in minutes the relay is to be energized. This value must be less than the “interval” setpoint or the relay will never reset. P114 (min.) P115 (hours) Values 0.000 to 9999 Preset: ---- Related •...
  • Page 86 P116 (IR) Dead Band The distance above and below the bound alarm setpoints which actually energizes and de-energizes the alarm relays. actual “on” or For “in-bounds” and “out-of-bounds” “off” setpoint Relay Functions (P111 = 2 and 3 P116 respectively) a dead band prevents setpoint as set in relay chatter due to material level P112 or P113...
  • Page 87 To use relay 5 as a general alarm indicator, set P118 to value “3 – negative logic” and wire the alarm for normally open operation. When an alarm event occurs (described below) or when power is cut to the EnviroRanger the circuit closes and the alarm sounds.
  • Page 88: Pump Setpoint Modifiers (P121 And P122)

    Pump Setpoint Modifiers (P121 and P122) These parameters provide alternate ways of starting the pumps in the pump group. See Appendix C – Pump Control on page 215 for descriptions of the pump control algorithms. P121 (G) Pump by Rate Sets the pump relays to accept control by rate of level change once the first “on”...
  • Page 89 P122 (IR) Pump Service Ratio Selects pump usage based on the run time ratio rather than last used. This parameter only relates to relays with P111=54 or 55. To make this parameter useful, assign it to all of the pump relays. The number assigned to each pump relay represents the ratio that is applied when determining the next pump to start or stop.
  • Page 90: Independent Relay Failsafe (P129)

    Independent Relay Failsafe (P129) P129 (IR) Relay Failsafe Sets the failsafe operation per relay to allow for more flexible programming. Use this feature for relay failsafe operation independent from the Failsafe Material Level (P070). Relay Failsafe is only available for the following relay functions (P111). Relay Function (P111) Preset (P129) 1 –...
  • Page 91: Advanced Pump Control Modifiers (P130 To P136)

    Advanced Pump Control Modifiers (P130 to P136) These parameters affect only relays set to pump operation (P111 = 50 to 56). P130 (G) Pump Run-On Interval Sets the number of hours between pump run-on occurrences. One technique of clearing sediment in a “pump-down” wet well is to occasionally run the pump, after the normal “off”...
  • Page 92 P132 (G) Pump Start Delay Staggers pump start times to reduce power surges. Use this feature to reduce the power surge that would occur if all pumps started simultaneously. Enter the time to elapse (in seconds) after a pump has started before the next pump is permitted to start (if called for).
  • Page 93 P134 (IR) Pump Exercising Reduces pump corrosion or sediment build up by running the pump if it is idle for a long time. If a pump remains idle for the time (in hours) specified by P115 (IR) Relay “interval” Setpoint value entered then the pump runs for the time specified by P114 (IR) Relay “duration”...
  • Page 94 P137 (IR) Pump Group Assigns pumps to groups to allow for multiple pump rotations on one transducer. Use this feature to group pumps (relay points 1 - 5) into group 1 or 2. The feature is applied to pump rotation and occurs independently within each group.
  • Page 95: Pump Energy Cost Reduction (P140 To P145)

    Pump Energy Cost Reduction (P140 to P145) These parameters affect only relays set to pump operation (P111 = 50 to 56). Using these parameters you can configure an EnviroRanger to maximize its operation during periods of low energy cost and minimize its operation during periods of high-energy cost.
  • Page 96 All end times must have the same index value as the corresponding start time. Values HH.MM Preset: 00:00 P143 (G) Peak Lead Time The time (in minutes) before the Peak Start Time that the EnviroRanger will begin pumping. Enter the estimated pump running time (in minutes) required to pump the level from the highest Relay Setpoint “on”...
  • Page 97 P145 (IR) Peak “off” Setpoint Enter the value (similar to Relay Setpoint “off”, P113) to be used for the high- energy cost period. This feature allows the pump(s) to be stopped before the normal Relay Setpoint “off”, to reduce pump-running time during the high energy cost period.
  • Page 98 P146 (IR) Time of Day Setpoint Use this feature to set the time at which a relay set for time day alarm (P111=9) will trip. Enter the time in HH.MM (24 hour) format. Values 00:00 to 23:59 Page 98 EnviroRanger Programming Reference PL-556...
  • Page 99: Overflow / Underflow (P160 To P169)

    Overflow / Underflow (P160 to P169) The overflow / underflow parameters allow the EnviroRanger to react to flow conditions caused by storms or other unusual events. When the EnviroRanger enters a flow event the following actions are taken: • Logging starts. See Overflow (CSO) Records (P313 to P316) on page 119 for details.
  • Page 100 Note: You must specify the correct overflow or underflow settings for your “on” and “off” setpoints. If these values don’t match (for example, Overflow set as 1:1 and “on” setpoint below “off” setpoint) then no action is taken. Use 0:0 to disable overflow logging. If either value is set to “0” then no overflow or underflow action is enabled.
  • Page 101 Values 0.000 to 9999 Preset: 0.000 P163 (G) Overflow / Underflow Time Delay Defines the time, in seconds, used to calm (debounce) the flow condition inputs. The time delay is used only when the level source (P160) is a discrete input. Otherwise, the “off”...
  • Page 102 P165 (IR) Overflow / Underflow Relay Action Determines how relays operate during a flow condition. When a flow condition is detected each relay can be forced on, forced off, or left in its normal state. Use this feature when you want a control device to activate on an overflow or underflow condition.
  • Page 103: Flush Systems (P170 To P173)

    Flush Systems (P170 to P173) Use this feature to control an electrically operated flush valve on a pump. When a flush valve is run it usually diverts some pump output back into the wet well to stir up sediment. Note: The settings of these parameters affect the operation of all relays with P111 set to “64 –...
  • Page 104 P172 (G) Flush Interval The number of pump cycles which occur before flush control is enabled. To start a new flush cycle every ten times the pumps are run use the value “10” in this parameter. Values 0 to 9999 Preset: 0 P173 (G) Flush Duration The length of time for each flush cycle that the flush control is active.
  • Page 105: Pump Efficiency (P180 To P186)

    Pump Efficiency (P180 to P186) The efficiency of the pumps is calculated on volume change in the wet well or reservoir. Any application using pump efficiency must have accurate values in the Volume (P050 to P055) parameters starting at page 62. Pump faults can also be indicated by input from pump interlocks.
  • Page 106 P182 (V)(IR) Pump Measured Capacity Displays the value of the actual Pump Capacity as calculated over the Pump Capacity time (P181). This parameter can be used to estimate the Pump Rated Capacity (P183) by running a pump cycle, then viewing this parameter. The units used depend on whether the volume parameters are configured.
  • Page 107 P185 (IR) Pump Low Efficiency Action The action taken when a pump’s low efficiency counter (P184) expires. When the action removes a pump from the duty schedule P512 Pump Low Efficiency Fault is set. See the description on page 135 for details. Values No action Alarm (any relays set for P111=8), set P512=1...
  • Page 108: Ma Input (P250 To P254)

    mA Input (P250 to P254) The mA input can be used as a level measurement or passed on to a SCADA system. To use the mA input as a level set the transducer to "Auxiliary" (P004 = 250). To pass the mA input on to a SCADA system, read the value from the appropriate communication registers.
  • Page 109 P252 (G) 20 mA Input Level The process level that corresponds to the 20 mA value. When using an external mA signal to determine level the input range must be scaled to give accurate results. The preset value is 100% of Span (or equivalent units). Values -999 to 9999 Preset: 100% of Span...
  • Page 110: Ma Input Trim (P260 To P262)

    mA Input Trim (P260 to P262) The EnviroRanger’s mA inputs are calibrated at the factory. Use these parameters only if you know that your EnviroRanger requires recalibration. Note: Ignore any values given in P261 or P262. P260 (V) mA Raw Input Shows the raw mA input supplied by the external device.
  • Page 111: Discrete Input Functions (P270 To P275)

    Discrete Input Functions (P270 to P275) Discrete inputs can be used for the following: • P160 (G) Overflow / Underflow Level Source as described on page 99 • Pump Interlock Allocation (P500 to P509) as described on page 128 • Passing other information to a remote system through communications Use the following parameters to configure the discrete input itself.
  • Page 112 P271 (IDI) Frequency Input 0Hz Offset The value associated with 0Hz frequency input. When the discrete input receives a signal of less than 1Hz this parameter determines what the scaled value is. This parameter is valid only for discrete inputs set to the “Frequency Input (5)”...
  • Page 113 P272 (IDI) Discrete Input Multiplier The upper value for Frequency Input or the increment value for a Pulse Counter. This parameter works with both the “Pulse Counter (4)” and the “Frequency Input (5)” functions. Pulse Counter (P270 = 4) Sets the value to iterate for every pulse received. This allows the input value to be scaled as it is totalized.
  • Page 114 Values 0.000 to 9999 Preset: 0 (frequency input) ---- (other) P275 (V)(IDI) Scaled Discrete Input Value The current value of the discrete input after any scaling is applied. These readings are updated continuously, even in program mode. The value indicated here is used by pump interlocks or overflow detection to signal an event.
  • Page 115: Data Logging (P300 To P321)

    Data Logging (P300 to P321) • To view Data Logging time stamps press and then • To view date stamps press and then If the unit is powered up without a temperature sensor connected the value – 50C is displayed. This information can help trace problems with both built in and external temperature sensors.
  • Page 116 P302 (V) Temperature, Sensor Max View the highest temperature encountered, as measured by the TS-3 Temperature Sensor (if applicable). Press and then to reset the log after experiencing a short circuit on the temperature sensor wiring. Values - 50 to 150°C Preset: - 50°C P303 (V) Temperature, Sensor Min View the lowest temperature encountered, as measured by the TS-3...
  • Page 117: Record Readings (P304 And P305)

    Record Readings (P304 and P305) Use these features to identify the occurrence of the record high and low level readings. Press and then to reset these values once the installation is working correctly. P304 (V)(IT) Reading Max View the highest Reading calculated (in normal Reading units or %). Values -999 to 9999 P305 (V)(IT) Reading Min...
  • Page 118: Pump Records (P310 To P312)

    Pump Records (P310 to P312) Use these features to identify pump usage. These features are enabled if the associated Relay Function (P111) is set for any "pump control" feature. The value displayed pertains to the pump connected to the associated EnviroRanger terminals. Enter a value to set the current record to that value.
  • Page 119: Overflow (Cso) Records (P313 To P316)

    Overflow (CSO) Records (P313 to P316) These records cannot be reset. The index contains 20 entries with 1 being the most recent and 20 being the least recent. When more than 20 records are stored new ones will “wrap” and write over the oldest ones. Flow events are logged immediately, so if the system is in overflow state when the overflow records are viewed then the first record shows the current event.
  • Page 120: Flow Records (P320 And P321)

    Flow Records (P320 and P321) These features are enabled if Operation is set for "OCM" (P001 = 6). Use these features to identify the occurrence of the record high and low flow rates as displayed in OCM Max Flow (P604) units, or as a percent of OCM Max Flow.
  • Page 121: Lcd Totalizer (P322 And P323)

    LCD Totalizer (P322 and P323) Use these features to view, reset, or preset the 8 digit display totalizer. These features may be enabled if Operation is set for "OCM" or "Pumped Volume" (P001 = 6 or 7). The 8 digit totalizer is divided into 2 groups of 4 digits.The 4 least significant totalizer digits are stored in P322 and the 4 most significant digits are stored in P323.
  • Page 122: Profile Records (P330 To P337)

    Profile Records (P330 to P337) WARNING: The following parameters are for authorized Milltronics service personnel or Instrumentation Technicians familiar with Milltronics echo processing techniques. Use these features to record and save a total of up to 10 Echo profiles, initiated manually (P330), or automatically (P331 et al). See Scope displays (P810) for echo profile viewing hardware / software requirements.
  • Page 123 To manually record a profile Press to fire the transducer and record the echo profile into the internal scope buffer for display. For differential or average operation (P001 = 4 or 5), access scope Displays (P810) parameter to select the transducer number. To save a manual record Press to copy the echo profile record in the scope buffer and save it in...
  • Page 124 P333 (G) Auto Record Interval Enter the time (in minutes) to elapse after an Auto Profile Record is saved before another Auto Profile Record can be saved (subject to all other restrictions). Values 0.0 to 9999 Preset: 120 Page 124 EnviroRanger Programming Reference PL-556...
  • Page 125: Auto Record "On" And "Off" Setpoints (P334 To P337)

    Auto Record “on” and “off” Setpoints (P334 to P337) Use Auto Record “on” Setpoint (P334) and Auto Record “off” Setpoint (P335) to define the boundaries within which the level must be, for the resultant Echo Profile to be considered for an Auto Profile Record. If "----"...
  • Page 126 P337 (G) Auto Record LOE Time Use this feature to restrict Auto Profile Records from being saved unless an extended loss of echo (LOE) condition occurs. If the LOE condition exceeds the period entered (in seconds) the Echo Profile is saved, subject to this and other restrictions. When set for "0"...
  • Page 127: Installation Records (P340 To P342)

    Installation Records (P340 to P342) Use these features to view data relating to this specific EnviroRanger installation. P340 (V) Date of Manufacture View the date of manufacture of this EnviroRanger. Values YY:MM:DD format P341 (V) Run Time View the accumulated number of days this EnviroRanger has been operating, since the Date of Manufacture (P340).
  • Page 128: Pump Interlock Allocation (P500 To P509)

    Pump Interlock Allocation (P500 to P509) Discrete inputs allow you to feed pump information to the EnviroRanger so that it can modify pump algorithms. See Appendix C – Pump Control on page 215 or Appendix D – Discrete inputs on page 223 for more information. All of these parameters are indexed by pump relay.
  • Page 129 For Example If a three-position “Run/Off/Auto” switch is connected to discrete input 3 with the following contacts: Switch Position Discrete Input #3 Circuit Open Open Auto Closed Then, for an EnviroRanger with three pumps, the following parameters would be set Parameter Index Value...
  • Page 130 Note: This parameter allows for remote control of the pump but does not automatically set it up. Remote control must be initiated from the remote system through the Pump Control and Status register. See the EnviroRanger Communications Reference (PL-558) for details. Values 0 to 8 Preset: 0...
  • Page 131 P503 (IR) Pump Run Status Allocation Determines whether the indexed pump is running. When EnviroRanger activates a pump relay it assumes that the pump is running. To verify this assumption a circuit can be set up to confirm the run status from the motor starter to a discrete input.
  • Page 132 P505 (IR) Pump Fault “A” Allocation Detects whether there is a fault on the indexed pump. When a pump is capable of reporting faults in operation it can be connected to a discrete input and this information can be used by EnviroRanger to modify its pump control algorithms.
  • Page 133 Values 0 to 8 Preset: 0 Related • P275 (V)(IDI) Scaled Discrete Input Value on page 114 • P514 (V)(IR) Pump Fault “B” Status on page 136 P509 (IR) Pump Reset Allocation Resets the pump fault status parameters using a momentary contact. When a contact is made on the referenced discrete input all pump faults are reset for the indexed pump and that pump is put back into the duty schedule.
  • Page 134: Pump Fault Status (P510 To P515)

    Pump Fault Status (P510 to P515) Use these parameters to determine which condition failed the indexed pump. All relays are available for indexing but only those set to pump control in the Relay Control Function (P111 = 50 to 56) will be affected by these parameters.
  • Page 135 Values normal operation pump failed Related • P503 (IR) Pump Run Status Allocation on page 131 • P505 (IR) Pump Fault “A” Allocation on page 131 • P506 (IR) Pump Fault “B” on page 132 • P509 (IR) Pump Reset on page 133 •...
  • Page 136 P513 (V)(IR) Pump Fault “A” Status Reports status of P505 (IR) Pump Fault “A” Allocation. Values normal operation fault detected Related • P275 (V)(IDI) Scaled Discrete Input Value on page 114 • P505 (IR) Pump Fault “A” Allocation on page 132 P514 (V)(IR) Pump Fault “B”...
  • Page 137 P519 (V) Power Failure Status Reports the status of P502 (G) Power Failure Allocation. Values power available power failure Related • P275 (V)(IDI) Scaled Discrete Input Value on page 114 • P502 (G) Power Failure Allocation on page 130 • P111 (IR) Alarms (values 0-12) on page 76 PL-556 EnviroRanger Programming Reference...
  • Page 138: Pump Control Source (P520 To P524)

    Pump Control Source (P520 to P524) Use these parameters to determine from where the EnviroRanger pump relays are controlled: Auto Manual Local P521 P522 Remote P523 P524 P520 (V)(IR) Pump Available Indicates whether the pump is available to the EnviroRanger pump control routines.
  • Page 139 P523 (V)(IR) Pump in Remote Auto Indicates that control of the indexed pump is from the EnviroRanger pump control algorithms and that remote control is enabled. See the EnviroRanger Communications Reference for details on the pump controls available through communications. Values pump not in remote / auto pump in remote / auto...
  • Page 140: Ocm (P600 To P621)

    OCM (P600 to P621) If the EnviroRanger is used to monitor open channel flow, alter the following parameters as required and run a calibration as described in P621. Note: See Open Channel Monitoring (OCM) on page 32 for application examples involving common weirs and flumes. The EnviroRanger calculates "head"...
  • Page 141 P601 (G) Flow Exponent The Exponent for the flow calculation formula. Use this parameter if the Primary Measuring Device (P600) is set to 1 (exponential). It creates an exponential curve with end points set by Max Head (P603) and Zero Head (P604) and with the curve based on the specified exponent.
  • Page 142 P602 (ID) PMD Dimensions The dimensions of the Primary Measuring Device (PMD). Use this parameter if the Primary Measuring Device is directly supported (P600=2,3,6,7). The dimensions required for each PMD vary. See the examples on page 32 for full descriptions of the required values (listed below for reference).
  • Page 143 P604 (G) Maximum Flow The maximum flowrate associated with Maximum Head (P603). Use this parameter when the Primary Measuring Device (PMD) requires a maximum head and flow reference point. These PMDs are: • P600 = 1, Exponential • P600 = 2, Palmer Bowlus Flume •...
  • Page 144 Values -999 to 9999 Preset = 0.000 Related • P006 (IT) Empty on page 59 • P801 (G) Range Extension on page 176 transducer Material level at zero flow Empty (P006) PMD base Zero Head (P605) P606 (G) Time Units Determine the time units used when displaying current flow and logging flow values.
  • Page 145 Values no digits after the decimal point 1 digit after the decimal point 2 digits after the decimal point 3 digits after the decimal point Related • P060 (IT) Decimal Position on page 66 P608 (G) Flowrate Units The volume units used to display total flow. This parameter is enabled only if the primary measuring device (PMD) supports absolute calculations (P600=6,7).
  • Page 146 Head vs. Flowrate (P610 and P611) Max Flow Zero Flow Head Breakpoints P611 (IB) Breakpoint Flowrates The flowrate corresponding to each Head Breakpoint entered. These are the flowrates for the related breakpoints. See Universal Calculation Support on page 42 for a description of how to specify universal flows.
  • Page 147 P621 (G) Auto Zero Head Calibrates Zero Head (P605) based on actual head measurements. Use this parameter when the reported head is consistently high or low by a fixed amount. Before using this feature, verify the following parameters are correct: •...
  • Page 148: Pumped Volume Totalizer (P622 To P623)

    Pumped Volume Totalizer (P622 to P623) If the 8 digit totalizer display, or a remote totalizer contact closure is desired, alter the following parameters as required. P622 (G) Inflow / Discharge Adjust The method used to calculate the volume pumped, for "pumped total" Operation (P001 = 7).
  • Page 149 entirely dependent on the accuracy of the rate calculation, so the user must ensure that appropriate settings are entered for Pump Capacity Time (P181) and Pump Start Delay (P132). PL-556 EnviroRanger Programming Reference Page 149...
  • Page 150: Totalizer (P630 To P645)

    Totalizer (P630 to P645) P630 (G) LCD Totalized Multiplier Use this feature if the LCD Total increments by too large (or too small) an amount. Enter the factor (powers of 10 only) by which actual volume is divided, prior to display on the LCD. Use a value such that the eight-digit totalizer doesn’t roll over between readings.
  • Page 151 P640 (G) Remote Totalized Multiplier Use this feature if the remote totalizer (device connected to the relay set for "totalizer operation" Relay Function, P111 = 40), updates too slowly or rapidly. This parameter is relevant only if Operation is set to OCM or Pumped Volume (P001 = 6 or 7).
  • Page 152 Values 0.001 to 9999 Preset = 1.000 Related • P001 (G) Operation on page 57 • P111 (IR) Relay Control Function on page 74 • OCM (P600 to P621) on page 140 P642 (G) Flow Sampler Exponent Use this feature in conjunction with Flow Sampler Mantissa (P641) to establish the number of flow units required to increment the Flow Sampler (device connected to the EnviroRanger relay set for the "flow sampler operation"...
  • Page 153 Values 0.1 to 1024 Preset = 0.2 (sec) Related • P111 (IR) Relay Control Function on page 74 PL-556 EnviroRanger Programming Reference Page 153...
  • Page 154: Range Calibration (P650 To P654)

    Range Calibration (P650 to P654) There are two types of calibration possible: Offset Adjusts the measurements by a fixed amount. Sound Velocity Adjusts the speed of sound and changes the measurement calculations. Do Offset calibration at any steady level unless a Sound Velocity calibration is also done.
  • Page 155 For best results do this calibration with the level at a known value near empty. With the level steady at some low value... Allow sufficient time for the vapour concentration to stabilize Press to display the calculated reading Repeat step 2 at least 5 times to verify repeatability Measure the actual reading (e.g.
  • Page 156 P654 (G) Velocity at 20°C This value is used to automatically calculate Sound Velocity (P653). After performing a Sound Velocity Calibration, check this value to verify the acoustic beam atmosphere is "air" (344.1 m/s or 1129 ft/s). Alternatively, if the acoustic beam atmosphere sound velocity at 20°C (68 °F) is known, and the sound velocity vs.
  • Page 157: Temperature Compensation (P660 To P664)

    Temperature Compensation (P660 to P664) P660 (IT) Temp Source Source of the temperature reading used to adjust the speed of sound. The EnviroRanger measures the TS-3 temperature sensor assigned to the transducer. If a TS-3 sensor is not connected, the temperature measurement from the ultrasonic/temperature transducer is used.
  • Page 158 direct sunlight (or near some other radiant heat source). Allocate the temperature measurement of the other transducer to both transducer Point Numbers. Enter the Transducer Number whose temperature measurement will be used for the distance calculation of the Point Number displayed. When both transducers are allocated to a Point Number, the temperature measurements from each transducer are averaged.
  • Page 159: Rate (P700 To P708)

    Rate (P700 to P708) The Rate parameters determine how the EnviroRanger reports changes in material level. P700 (G) Max Fill Rate Adjusts the EnviroRanger response to increases in the actual material level (or advance to a higher Failsafe Material Level, P071). Enter a value slightly greater than the maximum vessel filling rate.
  • Page 160 P702 (G) Filling Indicator The fill rate required to activate the LCD Filling indicator ( ). This value (in Units (P005) or % of Span (P007) per minute) is automatically set to 1/10 of the Max Fill Rate (P700). Values -999 to 9999 P703 (G) Emptying Indicator The empty rate required to activate the LCD Emptying indicator ( ).
  • Page 161 Related • P003 (IT) Maximum Process Speed on page 58 • P705 (G) Rate Update Time on page 161 • P706 (G) Rate Update Distance on page 161 P705 (G) Rate Update Time The time period (in seconds) over which the material level rate of change is averaged before Rate Value update.
  • Page 162: Measurement Verification (P710 To P713)

    Measurement Verification (P710 to P713) P710 (G) Fuzz Filter Use this feature to stabilize the reported level, due to level fluctuations (such as a rippling or splashing liquid surface), within the Echo Lock Window (P713). This value (in % of Span, P007) is automatically altered when Maximum Process Speed (P003) is altered.
  • Page 163 P712 (G) Echo Lock Sampling The sampling criterion sets the number of consecutive echoes appearing above or below the echo currently locked onto, that must occur before the measurements are validated as the new reading (for Echo Lock P711 values: 1 or 2). P711 value P712 preset value 1, max verification...
  • Page 164: Transducer Scanning (P726 To P728)

    Transducer Scanning (P726 to P728) P726 (G) Level System Sync Enables the System Sync on the terminal block. Use this parameter if another level measurement system is mounted near the EnviroRanger and they are wired together on the Sync terminal. See the Installation Guide for further information.
  • Page 165 P729 (V)(IT) Scan Time View the elapsed time (in seconds) since the point displayed was last scanned. This value may be viewed as an Auxiliary Reading in the RUN mode, and is particularly useful when "differential" or "average" Operation (P001 = 4 or 5) is selected.
  • Page 166: Display (P730 To P739)

    Display (P730 to P739) P730 (G) Auxiliary Reading Use this feature to display operator selected Auxiliary Readings temporarily or indefinitely (as desired). Select "OFF" to display Auxiliary Readings temporarily. Select "HOLd" to display Auxiliary Readings until another Auxiliary Reading is selected or programming mode is entered. See Hand Programmer on page 11 for run mode auxiliary readings.
  • Page 167 P732 (G) Display Delay Adjusts the Point Number display scroll speed. Use this feature (if desired) when "differential" or "average" Operation (P001 = 4 or 5) is selected, to adjust the delay (in seconds) before the display advances to the next Point Number. (Display scrolling is independent from transducer scanning.) Values 0.5 to 10 (preset to 1.5 seconds)
  • Page 168 P736 (G) Date Format The order of days and months in date readings in run mode. This parameter determines the order of days and months of dates shown in run mode. It does not affect the way dates are set in program mode. Values DD:MM MM:DD...
  • Page 169: Smartlinx Reserved (750 To 769)

    SmartLinx Reserved (750 to 769) These parameters are reserved for optional SmartLinx communications cards and vary by card. Refer to the SmartLinx documentation to determine if any of them are used. PL-556 EnviroRanger Programming Reference Page 169...
  • Page 170: Communications (P770 To P782)

    Modbus standard in both ASCII and RTU formats. The Milltronics protocol is compatible with the Dolphin Plus configuration program. See the Milltronics web site for information on this PC product (http://www.milltronics.com/). The Modbus protocol is an open standard developed by AEG Schneider Automation Inc.
  • Page 171 Do not use the value “0” for Modbus communications as this is the broadcast address and is inappropriate for a slave device. Values 0 to 9999 Preset: 1 P772 (IP) Baud Rate The communication rate with the master device. This parameter specifies the rate of communication in Kbaud. Any value may be entered but only the values shown below are supported.
  • Page 172 P774 (IP) Data Bits The number of data bits per character. Protocol P774 Value Modbus RTU Modbus ASCII 7 or 8 Dolphin Plus 7 or 8 Values 5 to 8 Preset: 8 P775 (IP) Stop Bits The number of bits between the data bits. Values 1 or 2 Preset: 1...
  • Page 173 P778 (IP) Modem Available Sets the EnviroRanger to use an external modem on the RS-232 port. Any connected modem must be set up to auto-answer incoming calls. The EnviroRanger does not automatically configure the modem. Autobaud (enabled by P778=1) When the EnviroRanger is powered up or the P779 Modem Inactivity Timeout expires three carriage returns are sent to the modem to allow it to set its serial connection to P772 Baud Rate.
  • Page 174 Ensure that P779 is set longer than the standard polling time of the connected master device. 0 disables the inactivity timer. Values 0-9999 Preset: 0 P782 (G) Parameter Index Location Determines where index information is stored for the parameter access area. EnviroRanger parameters can be indexed by a primary and secondary index value.
  • Page 175: Smartlinx Hardware Testing

    SmartLinx Hardware Testing These parameters are used to test and debug an installed SmartLinx card. If there is no SmartLinx card installed in the EnviroRanger ignore these parameters. P790 (G) Hardware Error Displays the results of ongoing hardware tests within the communications circuitry.
  • Page 176: Echo Processing (P800 To P807)

    Echo Processing (P800 to P807) P800 (G) Near Blanking The space close to the transducer face which cannot be measured Use this feature if the surface monitored is incorrectly reported as near the transducer face and the true level is further away. Extend Near Blanking to overcome measurement difficulties which cannot be corrected by transducer relocation, mounting, or aiming.
  • Page 177 monitored distance. This is often the case with OCM when using weirs and some flumes. Values 0.000 to 9999 20% of Span (P007) Related • P006 (IT) Empty on page 59 • P007 (IT) Span on page 60 • P004 (G) Transducer on page 58 P802 (G) Submergence Transducer Used when the transducer has a submergence shield attached and the transducer is expected to be submerged on occasion.
  • Page 178 Values short short and long Related • P006 (IT) Empty on page 59 • P805 (V)(IT) Echo Confidence on page 178 • P804 (G) Confidence Threshold on page 178 • P852 (G) Short Shot Range on page 189 P804 (G) Confidence Threshold Determines which echoes are evaluated by software.
  • Page 179 Display Description "x:--" short shot confidence value, (long shot not used). "--:y" long shot confidence value, (short shot not used). "x:y" short and long shot confidence values (both used). "E" transducer cable is open or short circuited. "--:--" no shots were processed for Sonic Intelligence evaluation.
  • Page 180: Advanced Echo Processing (P810 To P825)

    Advanced Echo Processing (P810 to P825) Note: The following parameters are for authorized Milltronics Service personnel or Instrumentation Technicians familiar with Milltronics echo processing techniques. Anatomy of an Echo Profile The relevant parts of an echo profile are listed here. These are visible in either Dolphin Plus or an oscilloscope.
  • Page 181 Any combination of the following Scope Displays are available. Display Symbol Echo Profile TVT Curve Echo Marker Echo Lock Window There are two methods of selecting the Scope Displays: Scrolling Press to display the Auxiliary Function symbol. Press to access the desired Reading display symbols. Press with the desired display symbols displayed.
  • Page 182: Profile Pointer (P817 To P825)

    Profile Pointer (P817 to P825) When a Profile Pointer Parameter is accessed, the Echo Lock Window scope display changes to a Profile Pointer display. The Profile Pointer may be moved to a number of points on the Echo Profile, to gain specific information dependent upon the Profile Pointer Parameter used.
  • Page 183 P820 (G) Algorithm Chooses the algorithm used to generate the measured value from the echo profile. Use this feature to select the algorithm(s) which the Sonic Intelligence echo selection is based on. Use P805 (V)(IT) Echo Confidence (page 178) to determine which algorithm gives the highest confidence under all level conditions.
  • Page 184 P822 (G) Narrow Echo Filter Filters out echoes of a specific width. Use this feature if transducer acoustic beam interference (e.g. ladder rungs) is processed. Enter the width of false echoes (in ms), to be removed from the long shot Echo Profile.
  • Page 185: Advanced Tvt Adjustment (P830 To P835)

    Advanced TVT Adjustment (P830 to P835) Note: The following parameters are for authorized Milltronics Service personnel or Instrumentation Technicians familiar with Milltronics echo processing techniques. P830 (G) TVT Type Selects the TVT Curve used. This feature is automatically altered when Material (P002) is altered. Do not use "TVT Slopes"...
  • Page 186 If Dolphin Plus is not available then an oscilloscope can be used. When using an oscilloscope, the Echo Lock Window display becomes the TVT Curve Pointer. See P810 (IT) Scope Displays on page 180 for more information. The TVT curve is divided into 40 breakpoints, accessible by enabling the point number as the breakpoint index field.
  • Page 187 Enter the time (in ms) for the TVT Curve to decrease from the TVT Start Min (P833) point to the TVT Curve baseline. Values 0 to 9999 (preset = 30) P835 (G) TVT Slope Min Enter the minimum slope (in dB/s) for the middle of the TVT Curve. This feature (preset to 200) is used in conjunction with TVT Start Duration (when a long flat TVT Type is selected) to ensure the TVT Curve remains above false echoes which appear in the middle of the Echo Profile.
  • Page 188: Advanced Shot Adjustment (P840 To P852)

    Advanced Shot Adjustment (P840 to P852) Note: These parameters are for Milltronics service personnel only. P840 (G) Short Shot Number Enter the number of short shots to be fired (and results averaged) per transmit pulse. Values 0 to 100 Preset: 1...
  • Page 189 P844 (G) Short Shot Width Adjust the width (in ms) of the short shot transmit pulse. This feature is automatically altered when Transducer (P004) is altered. Values 0.000 to 5.000 P845 (G) Long Shot Width Adjust the width (in ms) of the long shot transmit pulse. This feature is automatically altered when Transducer (P004) is altered.
  • Page 190: Test (P900 To P913)

    Test (P900 to P913) Note: Test Parameters are intended for use by Milltronics Service personnel. P900 (V) Software Revision # View the EPROM Rev. #. Values 00.00 to 99.99 P901 (V) Memory Press to activate the EnviroRanger memory test. Values...
  • Page 191 P904 (G) Keypad Press each keypad key in the following sequence: As each key is pressed, the associated keypad number is displayed. On successful test completion, "PASS" is displayed. "FAIL" is displayed if a key is pressed out of sequence or the programmer keypad malfunctions. P905 (IT) Transmit Pulse Press to supply repeated transmit pulses, at the frequency entered, to...
  • Page 192 P909 (G) Front RS-232 Port Press to test the RS-232 port on the front of the unit. On successful test completion, "PASS" is displayed. Otherwise, "FAIL" is displayed. An external device must be connected to the RS-232 port for this test to pass.
  • Page 193: Measurement (P920 To P927)

    Measurement (P920 to P927) Use these parameters to verify EnviroRanger programming. All of these parameters are available in run mode. See Readings in Run Mode on page 12 for more information. The range and values shown for each of these parameters depends on the Operation (P001) chosen.
  • Page 194 P922 (IT) Space Measurement Corresponds to the distance, in units or percent, between the monitored surface and Span (P007). Values 0.000 to 9999 P923 (IT) Distance Measurement Corresponds to the distance, in units, between the monitored surface and the transducer face. Values 0.000 to 9999 P924 (G) Volume Measurement...
  • Page 195 P927 (IT) Distance Measurement Corresponds to the distance, in units (P005) or percent of empty (P006), between the monitored surface and the transducer face. Use P923 unless the distance information is required in percent of span. Values 0.000 to 9999 PL-556 EnviroRanger Programming Reference Page 195...
  • Page 196: Master Reset (P999)

    Master Reset (P999) P999 (G) Master Reset This feature resets all parameters to original values. Use this feature prior to initial programming if arbitrary Parameter Values were used during a "bench test", or after upgrading the EnviroRanger software. Following a Master Reset, complete reprogramming is required. To perform a Master Reset…...
  • Page 197: Appendix A - Technical Reference

    Appendix A – Technical Reference Transmit Pulse The EnviroRanger transmit pulse consists of one or more electrical “shot” pulses, which are supplied to the Transducer connected to the EnviroRanger terminals. The transducer fires an acoustic “shot” for each electrical pulse supplied. After each shot is fired, sufficient time is provided for echo (shot reflection) reception, before the next (if applicable) shot is fired.
  • Page 198: Distance Calculation

    Scope Display (P810) Span (P007) + Range Extension (P801) Echo Lock TVT Curve Window Echo Profile Near Blanking Echo Marker (P800) msec x 100 Dolphin Plus Display echo marker echo profile TVT curve Distance Calculation To calculate the transducer to material level (object) distance, the transmission medium (atmosphere) sound velocity (P653) is multiplied by the acoustic transmission to reception time period.
  • Page 199: Sound Velocity

    Unless altered, the sound velocity used for the distance calculation is 344.1 m / s (1129 ft / s). Variable air temperature is automatically compensated when a Milltronics ultrasonic / temperature transducer is used. If the transducer is exposed to direct sunlight, use a sunshield or better yet, a separate TS-3 temperature sensor.
  • Page 200: Volume Calculation

    When echo processing is complete, (if more than 1 vessel is monitored) the scanning relay changes state to supply the transmit pulse to the other transducer after the Scan Delay (P727). Scan Delay is automatically set by Maximum Process Speed (P003). When high speed scanning is required (sometimes the case for equipment position monitoring), the Scan Delay may be reduced.
  • Page 201: Flow Calculation

    Universal, Curved (P050 = 10) This calculation creates a cubic spline approximation of the level/volume curve, providing best results if the curve is non-linear, and there are no sharp angles. Select at least enough breakpoints from the curve to satisfy the following: •...
  • Page 202 Enter a Head Breakpoint at each point where the head/flow curve bends sharply (2 minimum). For combination curves (mostly linear but include 1 or more arcs), enter numerous breakpoints along the arc, for best flow calculation accuracy. See also: Checking OCM Flow Characterization on page 50. Universal, Curved (P600 = 5) This calculation creates a cubic spline approximation of the head/flow curve, providing best results if the curve is non-linear, and there are no sharp...
  • Page 203: Maximum Process Speed

    Maximum Process Speed The EnviroRanger’s ability to respond to material level changes is designed to exceed even the most demanding installation requirements. The Maximum Process Speed setting automatically presets various parameters affecting the EnviroRanger response to material level changes as follows: Parameter Values Dependent on Maximum Process Speed (P003)
  • Page 204 Page 204 EnviroRanger Programming Reference PL-556...
  • Page 205: Appendix B - Troubleshooting

    Appendix B – Troubleshooting Note: Many of the parameters and techniques described here require extensive knowledge of ultrasonic technologies and Milltronics echo processing software. Use this information with caution. If the EnviroRanger setup becomes too confusing use P999 to reset the parameters and start again.
  • Page 206: Noise Problems

    Symptom Cause Action Value too large to Select larger Units Displays "EEEE". display in 4 or 5 (P005), or lower Convert characters. Reading (P061). Alter Maximum Process Speed (P003) or Reading fluctuates while Incorrect measurement damping (P704) material level is still, (or stabilization.
  • Page 207 Reducing Electrical Noise higher unchanged Common Wiring Problems lower Reducing Acoustical Noise higher Reducing Electrical Noise unchanged unchanged Contact Milltronics lower Reducing Acoustical Noise higher Common Wiring Problems lower unchanged Common Wiring Problems lower Reducing Acoustical Noise PL-556 EnviroRanger Programming Reference...
  • Page 208 On Milltronics transducers the white wire is negative and the black wire is positive. If the extension wire is colored differently, make sure that it is wired consistently.
  • Page 209: Measurement Difficulties

    Reducing Electrical Noise • Ensure that the transducer cable does not run parallel to other cables carrying high voltage or current. • Move the transducer cable away from noise generators such as variable speed drives. • Put the transducer cable in grounded metal conduit. •...
  • Page 210 Echo Confidence (P805) and Echo Strength (P806) for all material levels within the measurement range. The most efficient method of checking echos is with Milltronics’ Dolphin Plus software. To display echos…...
  • Page 211: Fixed Reading

    (narrower beam) transducer, enter the new transducer model (P004), and (if necessary) optimize aiming and frequency again. Always contact your Milltronics service personnel before selecting a transducer to solve this type of problem. Use Dolphin Plus to Debug Echo...
  • Page 212 Standpipe Mountings If the transducer is mounted on or in a standpipe, grind smooth any burrs or welds on the inside or open end, (the end that opens into the vessel). If the problem persists, install a larger diameter or shorter length standpipe, bevel the inside of the bottom end, or cut the open end of the standpipe at a 45 angle.
  • Page 213: Wrong Reading

    If the material monitored is a liquid, check for splashing in the vessel. Enter a lower Maximum Process Speed (P003) value to stabilize the Reading, or install a stilling well. (Contact Milltronics or your local distributor). Adjust the Echo Algorithm Use Dolphin Plus to view live sonic profiles and make adjustments to the P820 (G) Algorithm parameter found on page 183.
  • Page 214: Transducer Ringing

    Should a stable measurement still not be attainable, contact Milltronics or your local distributor. Transducer Ringing If the transducer is mounted too tightly, or if it is mounted so that its side touches something, its resonance characteristics change and this can cause problems.
  • Page 215: Appendix C - Pump Control

    Appendix C – Pump Control The EnviroRanger has the pump control strategies to solve nearly any water / wastewater application. This section details these strategies for engineers requiring in-depth knowledge of the system and how it operates. Pump Control Options The various methods of pump control are made up of a combination of two control vectors: Pump Duty...
  • Page 216: Discrete Inputs

    Discrete Inputs Some pumps can tell the EnviroRanger through contacts that they are running (confirmation) or experiencing a fault. Pumps can be removed from the rotation if they are not pumping efficiently or they are reporting a failure. Failures are reported using the discrete interlocks provided on the EnviroRanger.
  • Page 217 Fixed Starts pumps based on individual setpoints and always starts the same pumps in the same sequence. Alternate Starts pumps based on the duty schedule and always leads with a new pump. Service Ratio Starts pumps based on user-defined ratio of running time. Fixed Duty Assist (P111 = 50) Ties the indexed pump relay directly to the indexed setpoint.
  • Page 218 Relay Table The following table shows relay status when each setpoint is reached. Relays index on 3 on 2 on 1 off 0 Alternate Duty Assist (P111 = 52) Alternates the lead pump each time the material level cycles and runs all pumps together.
  • Page 219 Alternate Duty Backup (P111 = 53) Alternates the lead pump each time the material level cycles and runs only one pump at a time. Relay Operation (for P118 = 2) The setpoints associated with the relays are grouped so that they can be rotated.
  • Page 220 Relay Operation (for P118 = 2) The setpoints associated with the relays are grouped so they can be redistributed based on pump run time ratios. The next pump to start or stop is the one with the required time to actual time ratio. Over time the number of hours demanded of each pump will conform to the ratios specified.
  • Page 221: Other Pump Controls

    Other Pump Controls There are a number of other controls available to modify pump behaviour. Pump Run-on (page 91) Extends the run period for a pump based on the number of pump starts. This allows for the wet well to be pumped lower than usual and reduces sludge build-up on the well bottom.
  • Page 222 Page 222 EnviroRanger Programming Reference PL-556...
  • Page 223: Appendix D - Discrete Inputs

    Appendix D – Discrete inputs The discrete inputs on the EnviroRanger allow the unit to be more flexible by interlocking control functions with external conditions in the wet well. To configure a discrete input on the EnviroRanger, follow these steps. Wire the Discrete Input The discrete input contacts are either normally-open or normally-closed when the system state is normal.
  • Page 224: Program The Interlock Logic

    Program the Interlock Logic The interlock can take one of three forms, detailed below. Overflow or Underflow Event Used to detect an unusual flow event such as a storm overflowing a wet well. Determine the Source Set P160 (G) Overflow / Underflow Level Source as described on page 99. Determine the Action Set P165 (IR) Overflow / Underflow Relay Action as described on page 102.
  • Page 225 Pump Status Used to confirm that a pump is operating correctly and to remove it from the duty schedule if it is not. The interlock events that can remove a pump from the duty schedule are Failure to Start Use P503 (IR) Pump Run Status Allocation and P504 (IR) Pump Run Status Time Delay as detailed on page 131.
  • Page 226: Test The Interlock

    Test the Interlock Once wired and programmed test the interlocks to verify operation. Use P270 (IDI) Discrete Input Function (page 111) to force the input “on” or “off” and verify that the unit responds as expected. Testing the interlocks is part of a complete system test as described in Testing the Configuration on page 49.
  • Page 227: Index

    Index 0 index ..........16 application examples ......23 0/4 mA input level ......108 application testing....... 52 20 mA input level ......109 applications about the enviroranger ......9 alarms..........23 about this manual ......... 7 OCM ..........32 advanced echo processing....
  • Page 228 bus error count ......... 175 data logging parameters....115 calibration ......... 154 date..........12, 60 changing parameters date format ........168 dolphin plus ........17 date of manufacture......127 hand programmer......18 dead band........... 86 characterization dead zone......See blanking flow ..........
  • Page 229 wall mount ........10 failsafe time left........12 display and reading parameters ..66 FIFO display delay........167 parameter (P111) ......82 display parameters ......166 filling indicator........160 displays..........20 filling rate alarm ........25 distance ..........12 finding information ........ 8 distance calculation ......
  • Page 230 scaling .......... 112 LCD total low ........121 function LCD totalized multiplier..... 150 general ........... 82 LCD totalizer........150 other devices ........82 LCD totalizer parameters....121 pumps..........80 Leopold Lagco ........141 fuzz filter ........... 162 Leopold Lagco flume ......41 gate.............
  • Page 231 maximum frequency ......113 off setpoint ........27, 30 maximum head ......... 142 offset calibration ....... 154 maximum process speed offset correction ........ 155 parameter ........58 offset reading........67 technical reference ....... 203 on setpoints ........27, 30 measurement........193 open channel monitoring measurement difficulties....
