APPENDIX-1
1. KDL-32R420A/421A/423A/424A
Speaker and GND combine dressing-4
NG
OK
NG
Note:
Speaker & Ground wire combined harness need keep
away with S-board, speaker harness keep close to
Speaker Baffle inside of ground harness.
39
KDL-32R420A/421A/423A/424A, 40R470A/471A/473A/474A, 46R470A/473A(AEP/UK)
