DIAGRAMS

4-3. CIRCUIT BOARDS LOCATION

KDL-32R420A/421A/423A/424A
KDL-40R470A/471A/473A/474A
A Board
GL3 Board
GL4 Board
A Board
Switch Unit
Switch Unit
H Board
H Board
KDL-46R470A/473A
GL5 Board
A Board
Switch Unit
H Board
31
KDL-32R420A/421A/423A/424A, 40R470A/471A/473A/474A, 46R470A/473A(AEP/UK)
