SEC 2. ADJUSTMENT

HOW TO ENTERING SERVICE MODE

1) Turn on the main power switch to place this set in standby mode.
2) Press the buttons on the remote commander as follows, and entering service mode.
3) Service mode display.
Status Information
Self diagnosis history
Panel Selection
NO_SIGNAL_MUTE
TUNING SYSTEM
LVDS Spectrum (%o)
Low of HPD
UART Selection
SERIAL NUMBER EDID
MODEL NAME EDID
- When replace Main Board or panel, please confirm "Panel Selection" and "MODEL NAME EDID" in service mode.
If they are different, please select a suitable thing.
- Change of SERIAL NUMBER EDID and MODEL NAME EDID are possible only once when they are white character.
Note: About the software data update, please refer to "APPENDIX-4".
KDL-32R420A/421A/423A/424A, 40R470A/471A/473A/474A, 46R470A/473A(AEP/UK)
5
Info
Channel
Volume
Service Mode
<[ 19_S320DB3-1_EU ]>
<[
<[
AUTO
<[
<[
<[
Usb Fact
6000001
KDL-32R420A
[</>]Set[Home]Exit
TV POWER
>>
>>
Panel Selection
Off
]>
19_S320DB3-1_EU
]>
30
]>
5
]>
]>
18_S400DH1-1_EU
48_S460DH1-1_EU
MODEL NAME EDID
KDL-32R420A
KDL-32R421A
KDL-32R423A
KDL-32R424A
KDL-40R470A
KDL-40R471A
KDL-40R473A
KDL-40R474A
KDL-46R470A
KDL-46R473A
19
