Page 1: Reference Manual
8600 Smart Routers 8665 Smart Router FP7.0 Reference Manual 76.8670-40128B 14.12.2015... -
Page 2: Revision History
This revision of the manual documents the following network element and the corresponding feature pack or higher. 8665 Smart Router FP7.0 If a different feature pack of 8600 products, please refer to the relevant product document program on the Tellabs and Coriant Portal by navigating to www.portal.tellabs.com > Product Documentation >... - Page 3 Circuit Emulation Service Command Line Interface Control card The control card in the 8600 system consists of a Control and DC Power Card CDC (used in 8630 Smart Router and 8660 Smart Router), Switching and Control Module SCM (used in 8611 Smart Router). In 8000 Intelligent Network Manager and CLI referred to as unit.
- Page 4 Label Edge Router Line card The line card in the 8600 system consists of an Ethernet Line Card (ELC1), Interface Module Concentrator (IFC) and up to two Interface Modules (IFMs) (used in 8630 Smart Router and 8660 Smart Router). In 8000 Intelligent Network Manager and CLI referred to as unit.
- Page 5 Station Clock Input Station Clock Output Synchronous Digital Hierarchy SDRAM Synchronous Dynamic Random Access Memory Synchronous Equipment Clock Small Form-Factor Pluggable. A transceiver type used in 8600 IFMs. Single Mode SNMP Simple Network Management Protocol SONET Synchronous Optical Network Synchronization Status Messages...
-
Page 6: Compliance Statement
10-Gigabit Small Form-Factor Pluggable. A transceiver type used in 8600 ELC1 line card. Compliance Statement Hereby, Coriant Oy declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC and Directive 2011/65/EU. FCC Notification Statement Federal Communications Commission (FCC) Rules require that you be notified of the following:... -
Page 7: Table Of Contents
Objectives..................................10 Audience..................................10 8600 Smart Routers Technical Documentation......................10 Document Conventions ..............................13 Documentation Feedback............................... 13 8600 Smart Routers Discontinued Products ..............14 Safety Notes ........................15 Intended Purpose ................................15 Class 1 Laser Product..............................15 Jewelry Removal ................................16 Installation and Maintenance ............................ - Page 8 Overview ................................45 Operation ................................45 Front Panel and Connectors..........................46 Input Fault Detection and LEDS ........................46 Cabling................................. 46 Pluggable Transceivers ....................47 Technical Specifications..................... 48 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
- Page 9 8665 Smart Router DC48 Power Input Module Technical Specifications ............53 8665 Smart Router Fan Module Technical Specifications .................. 53 Timing Block Technical Specifications ....................... 53 End of Life Treatment ....................... 55 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual...
-
Page 10: About This Manual
Tellabs and Coriant Portal by navigating to www.portal.tellabs.com > Product Documentation & Software > Data Networking > 8600 Smart Routers > Technical Documentation. Document Title Description 8600 Smart Routers Provides an overview of 8600 NEs PWE3 applications, ATM and TDM Configuration Guide... - Page 11 • 8600 Smart Routers FP7.0 Interface Configuration Guide (76.8670-50180) (for 8630 Smart Router and 8660 Smart Router) 8600 Smart Routers Provides an overview of 8600 NEs IP, forwarding and traffic IP Forwarding and Traffic management functionality, including: IP addressing; IP hosting Management Configuration Guide (ARP, DHCP);...
- Page 12 BFD; BGP; BGP MP; ECMP; IS-IS; OSPF and VRRP as well as Guide (76.8600-50121) instructions on how to configure them with CLI. 8600 Smart Routers Provide a summary of tested scalability limits of the 8600 Smart Scalability Reference Manual Routers. (76.8600-50160)
-
Page 13: Document Conventions
About This Manual Document Title Description 8600 Smart Routers Provides an overview of 8600 NEs measurement and connectivity Test and Measurement Configuration verification tools, including Ethernet loopback; IP ping and Guide (76.8600-50124) traceroute; MAC swap loopback; MPLS ping and traceroute;... -
Page 14: 8600 Smart Routers Discontinued Products
8600 Smart Routers Discontinued Products 8600 Smart Routers Discontinued Products 8600 Smart Routers Manufacture Discontinued (MD) notifications are available on the Tellabs and Coriant Portal, www.portal.tellabs.com > Product Documentation & Software > Data Networking > [8600 Smart Routers product name] > Product Notifications. -
Page 15: Safety Notes
ACHTUNG: Stecken Sie keine RJ-11 (Telefon) Stecker in die Ethernet oder E1/T1 Anschlüsse da dieses zu einer Beschädigung des Gerätes führen kann. CAUTION: Do not climb on or stand on the 8600 network element. Neither the network element nor its enclosure is designed to support the weight of a person. -
Page 16: Jewelry Removal
WARNING: This equipment is to be installed and maintained by qualified service personnel only. WARNUNG: Dieses Gerät darf nur von qualifiziertem Fach- oder Servicepersonal installiert oder gewartet werden. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. - Page 17 Modules, SCM, CDC, Line Cards, Power Modules, Power Input Modules and Fan Modules) of the 8600 network elements, always take care of proper handling, e.g. do not bend or twist the modules, do not touch the components on the modules, take care of good ESD working practices, do not use excessive force while inserting or removing the modules, do not drop the modules.
-
Page 18: Lightning Activity
WARNING: Do not work on the system or connect or disconnect cables during periods of lightning activity. WARNUNG: Arbeiten Sie während eines Gewitters mit Blitzschlag nicht an dem Gerät oder schließen Sie auch keine Kabel an bzw. trennen Sie keine ab. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. -
Page 19: 8665 Smart Router Overview
Smart Router subrack allows the subrack and backplane serial numbers to be read by the software from an EEPROM device, thereby making them visible on 8000 Intelligent Network Manager and CLI. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 20: Backplane
NE internal control is not lost even if the forwarding plane network processors have problems. The other buses are power, synchronization (clock), fan module control and unit presence busses. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual... -
Page 21: Unit Slots
• High speed data links with the switch unit • Line interfaces • Local power supply • CPU for control plane processing • Network processor for packet processing • Timing interfaces and stable OCXO clock 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... - Page 22 Note that the CU on the line units is a completely separate running protected process. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual...
-
Page 23: Cooling
8665 Smart Router has three hot swappable fan modules. When there is only one SU1, packet header terminations and additions, packet size and other factors affect the throughput. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... - Page 24 8665 Smart Router Fan Modules and Their Operating Voltages 8665 Smart Router fan module Operating voltage is the 48 Vdc battery voltage, fed to fan modules via the power input modules and the backplane. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
-
Page 25: 8665 Smart Router Powering
The fan modules and air filter can be replaced on the fly without disturbing the data traffic through the NE. Refer to the 8600 Smart Routers Hardware Installation Guide for detailed instructions. Fan Module One fan module has three brushless fans, three fan drive circuits and a common control logic including a watchdog. -
Page 26: 8665 Smart Router Power Consumption
To properly dimension systems and resources to support the network elements in a sufficient but economically feasible way, the users of the 8600 products may consider for what purpose they need the power consumption values and decide which value they want to use for which purpose. -
Page 27: Synchronization
• Station Clock Input signal (E1/DS1) • Station Clock Input clock (E1 G.703 2048 kHz) For details of the synchronization functionality please refer to 8600 Smart Routers Synchronization Configuration Guide. The selected reference signal must be originated from an equipment having, at least, the SEC quality clock, that is, the reference signal quality must be as defined in [ETS 300 462-3] and [EN 300... -
Page 28: Line Unit Redundancy
1 8665 Smart Router Overview 1.5.2 Line Unit Redundancy Ethernet Link Protection (ELP) or [IEEE 802.1AX] Ethernet Link Aggregation (LAG) are applied for protecting Ethernet physical interfaces. For more information see 8600 Smart Routers Ethernet Configuration Guide. 1.5.3 Switch Unit Redundancy 8665 Smart Router provides two slots for the switch units. -
Page 29: Line Unit (Lu1)
Interfaces. As all the other 8600 cards, LU1 is hot-swappable. The maximum configuration of six LU1 can be achieved either with one or two 8665 Smart Router DC48 power input modules in the 8665 Smart Router subrack. -
Page 30: Operation
The application software is stored in FLASH memory. Thus, it is possible to update the software on the field when new software feature packs become available. Similarly, the card and interface parameters are stored in FLASH, so those are restored after reset. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual... -
Page 31: Npu Subsystem
[G.703] 2048 kHz synchronization interface or an interface with Synchronization Status Messages. The 8600 Smart Routers Network Element Clock complies with SEC [G.813] and Stratum 3 generator [GR-1244-CORE]. The functional modelling is specified in [ETS 300 417-6-1] and [G.781]. - Page 32 Station Clock Interface Signals of RJ-48c, Female 8 Pins Pin # Description Input A-wire (ring) Input B-wire (tip) Not connected Output A-wire (ring) 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
-
Page 33: Backplane Data Links
During boot-up, LU1 performs self tests to verify that the system operational status is nominal. During normal operation, the CPU monitors the following: • LU1 operating voltages • Temperature inside LU1 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 34: Interfaces
For M2/4...13 ports the maximum link span with 10GBASE-ZR SFP+ optics is ~65km depending on the link conditions, all other 10GBASE-R ports support the full link span. Fig. 6 LU1 Virtual Modules and Ports 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual... -
Page 35: Front Panel
Fig. 7 LU1 Front Panel 2.5.1 CFP2, SFP+ and SFP Transceivers For more information on CFP2, SFP+ and SFP transceivers approved by Coriant and the Receive (Rx) and Transmit (Tx) directions in them, see 8600 Smart Routers Hardware Installation Guide. 76.8670-40128B 8600 Smart Routers ©... -
Page 36: Usb Port
Long cables should be terminated properly to reduce interference. RJ-45 Female CLI Connector Pin Map Signal Name Do not connect Not connected Do not connect Not connected Not connected 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. -
Page 37: External Alarm Interface
The port must be connected to the same type of port with proper cable, otherwise network element functionality may be affected or physical damage may occur. Long cables should be terminated properly to reduce interference. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 38: Lu1 Leds
ON when NE power is ON and undervoltage not detected. BLINKING Power supply failure. OFF otherwise. 2.6.2 LU1 Ethernet LEDs There are two LEDs to indicate the LU1 Ethernet port status. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. -
Page 39: Cabling
Cabling depends on the SFP, SFP+ or CFP2 type on the optical interfaces, see chapter Pluggable Transceivers in 8600 Smart Routers Hardware Installation Guide. Laser Safety See more on laser safety in chapter Pluggable Transceivers in 8600 Smart Routers Hardware Installation Guide. Laser safety... -
Page 40: Switch Unit (Su1)
SU1. Each LU1 has a direct connection via the backplane to both switch units in 8665 Smart Router. Coriant recommends to use always two SU1s in 8665 Smart Router. Main Features • CPU subsystem •... -
Page 41: Cpu Subsystem
FLASH, so those are restored after reset. Various system control functions are embedded in SUP PLD. I2C bus and switches are used for accessing devices such as EEPROMs, A/D converters and temperature sensors. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 42: Fpga Subsystem
During boot-up, SU1 performs self tests to verify that the system operational status is nominal. During normal operation, the CPU monitors the following: • SU1 operating voltages. • Temperature inside SU1. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. -
Page 43: Front Panel
Front Panel Fig. 12 SU1 Front Panel 3.4.1 SU1 Status LEDs There are four LEDs to indicate the SU1 status and one for the power OK status. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... - Page 44 BLINKING when manually set to forced blinking. OFF otherwise. Power GREEN ON when NE power is ON and undervoltage not detected. BLINKING Power supply failure. OFF otherwise. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
-
Page 45: Power Input Module
PIMs. One PIM is able to supply the whole current required by the 8665 Smart Router subrack in case of failure in other PIM. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 46: Front Panel And Connectors
8665 Smart Router subrack with PIMs installed; that is, at least 16 mm (approximately 5 AWG) or 25 mm (approximately 3 AWG). For more details on power and grounding cabling, please refer to 8600 Smart Routers Hardware Installation Guide. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual... -
Page 47: Pluggable Transceivers
5 Pluggable Transceivers 5 Pluggable Transceivers For detailed information on the transceivers approved by Coriant supported in 8600 Smart Routers, refer to 8600 Smart Routers Hardware Installation Guide. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... -
Page 48: Technical Specifications
The operational temperature range of the whole network element is determined on the narrowest operating temperature of the interface modules and or SFP/SFP+/XFPs used. Rain is not allowed. Condensation is not allowed. 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant. - Page 49 Note that the temperature of the SFP/SFP+/XFP case will be approximately 15 degrees higher than ambient temperature. For more information on the allowed SFP/SFP+/XFP case temperature range see chapter Pluggable Transceivers in 8600 Smart Routers Hardware Installation Guide.
- Page 50 Runs routing and label distribution protocols via the control functionality (CU). Unit optionally protected (redundant) - synchronization management and routing protocols. Switch unit. Coriant recommends that two SU1s are always used. LU1: 2 GBytes Packet buffer size Performance HW-based architecture guarantees forwarding at wire speed both for IP and MPLS traffic under any condition.
- Page 51 MPLS OAM [Y.1711]. Packet Loop Tester (PLT). [IEEE802.1ag]/ITU-T [Y.1731] Ethernet OAM connectivity check, loobpack, and link trace. ITU-T [Y.1731] Ethernet OAM delay, delay variation, and loss measurements. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual...
-
Page 52: Lu1 Technical Specifications
440 K Interfaces — One 100GBASE-R CFP2 interface — Twenty four 1000BASE-X/10GBASE—R SFP/SFP+ interfaces. See chapter Pluggable Transceivers in 8600 Smart Routers Hardware Installation Guide. Synchronization Synchronous Ethernet support at both ingress and egress: — Optical egress signal synchronized to ETSI SEC or ANSI Stratum 3 (NE clock) —... -
Page 53: 8665 Smart Router Dc48 Power Input Module Technical Specifications
Bandwidth is between 1 … 10 Hz when the clock system operates in SEC mode and < 0.1 Hz when it operates in Stratum 3 mode, phase gain < 0.1 dB 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual... - Page 54 100 kHz to 3100 kHz ≥ 18 dB Output return loss According to [ETS 300 166] Connector type SMB (50-ohm unbalanced male) RJ-48c (balanced female) RJ-45 (time of day) 8600 Smart Routers 76.8670-40128B 8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
-
Page 55: End Of Life Treatment
Correct handling of the disposed equipment contributes to reuse, recycling and other form of recovery to protect the environment. The equipment is marked with the figure shown below, to indicate that the equipment must be collected separately. 76.8670-40128B 8600 Smart Routers © 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual...
