- Page 1 P3PC-1142-03EN Color Image Scanner fi-5110EOX2 Please read this guide before connecting the scanner to your PC.
-
Page 2: Table Of Contents
2. Connecting ScanSnap ............................6 2.1. Installing the Supplied Software ................................6 2.1.1. Installing Adobe Acrobat 6.0 ................................6 2.1.2. Installing ScanSnap Manager, ScanSnap Organizer, CardMinder and PDF Thumbnail View ............7 2.2. Connecting the Scanner ..................................7 2.2.1. Connecting the AC cable .................................. 7 2.2.2. -
Page 3: Introduction
● Smaller than a sheet of A4 or letter paper in size, ScanSnap fi-5110EOX2 consists of: ScanSnap scanner can be left on your desk all the 1) fi-5110EOX2: Color image scanner. time. 2) Carrier Sheet: A document is inserted into the sheet Business cards easily filed! which is then used for scanning. -
Page 4: Canadian Doc Regulations
(PDF manual included in ScanSnap Setup CD-ROM): provides detailed information about the installation of This digital apparatus does not exceed the Class B the ScanSnap software and hardware, operation of the limit for radio noise emissions from digital scanner hardware and ScanSnap Manager. -
Page 5: Symbols Used In This Manual
The user must not perform repairs on this scanner. Contact the store where you purchased the scanner or an authorized FUJITSU Image Scanner service provider to make repairs to this product. ScanSnap fi-5110EOX2 Getting Started | 3... -
Page 6: Safety Precautions
Safety Precautions FOLLOW THESE INSTRUCTIONS AND BE SURE TO CAUTION HEED ALL WARNINGS AND CAUTIONS The following describes important cautions. DESCRIBED BELOW. Install the scanner on a desk so that none of its WARNING parts protrude outside of the desktop. Also, make sure that the scanner is installed on a flat, level surface Do not touch the power plug with wet hands. -
Page 7: Preparation
Stacker For using this part, pull it out Buttons as shown in the figure. → Documents are ejected from the ADF onto this tray. * You can also use the scanner without the Stacker. ScanSnap fi-5110EOX2 Getting Started | 5... -
Page 8: Connecting Scansnap
2. Connecting ScanSnap This chapter describes how to connect ScanSnap to your 2.1.1. Installing Adobe Acrobat 7.0 Please prepare the Adobe Acrobat 7.0 CD-ROM. 2.1. Installing the Supplied Software Adobe Acrobat 7.0 is not supported by Windows 98 and Windows Me. -
Page 9: Installing Scansnap Manager, Scansnap Organizer, Cardminder And Pdf Thumbnail View
(When reinstalling the programs, the following 2 windows will not appear.) ScanSnap Organizer, CardMinder and PDF Thumbnail View Please prepare the ScanSnap Setup CD-ROM. Insert the “ScanSnap Setup CD-ROM” into the CD-ROM drive. The “ScanSnap Setup” window appears. This window is not displayed automatically HINT when the "Auto play"... -
Page 10: Connecting The Usb Cable
[POWER] button on the scanner. The installation of ScanSnap is complete! Your computer will automatically detect the scanner. The "ScanSnap Manager" icon in the task tray is For Windows 98 displayed as There is a request to insert a disk. When such a message... -
Page 11: How To Use Scansnap
There are six tabs used to configure the scan options: 3.1. Scanning Documents [Application] Select the application for viewing/editing the scanned With “ScanSnap” you can turn paper office documents on images. your desk into digital files and save them just by pressing a [Save] single button. -
Page 12: Scanning With The Carrier Sheet
“Duplex” mode. scanning, it is not possible To scan the document in the Simplex” mode, to scan several sheets change this setting using the ScanSnap Manager continuously. Please load the sheets one by one and scan. ●... -
Page 13: About Pdf Thumbnail View
ScanSnap Organizer is an application that manages the thumbnail display of image files such as PDF and JPEG files. Files scanned in ScanSnap can be viewed without opening Scanned image them. You can also create folders, and arrange files for these folders for different purposes. -
Page 14: Troubleshooting
4. Troubleshooting This chapter describes common problems during the usage of ScanSnap and how to remedy them. 4.1. Troubleshooting Checklist Before you ask for repair service, please check the following items. If you cannot solve the problem even after checking the following items, contact the store where you purchased the scanner, or contact an authorized FUJITSU scanner service provider. - Page 15 Is the B&W document scanned in the color Select “B&W” at [Color mode:] on the white image is the same as for a color mode? [Scanning] tab in the “Scan and Save document. Settings” window. ScanSnap fi-5110EOX2 Getting Started | 13...
- Page 16 *1) For Windows XP, From "Device Manager", right click on computer name an perform “Scan for hardware changes". *2) Confirm that PC and ScanSnap are powered on and connected properly. - From Device Manager, check if ScanSnap is recognized as unknown device. If so, delete it from [Control Panel] - [System]. - Close ScanSnap Manager - Go to [Control Panel] - select [Add or remove Programs] and uninstall ScanSnap Manager and ScanSnap Organizer.
-
Page 17: Clearing Paper Jams
- Reinstall ScanSnap Manager and restart. *3) To confirm whether the scanner is connected with USB1.1 or USB2.0, right-click ScanSnap icon on the task and select [Help] - [About ScanSnap Manager], then click [Detail] button on [Version Information] window. [USB type] is displayed in [Scanner information]. -
Page 18: Daily Care
5. Daily Care This chapter describes how to clean the ScanSnap scanner. 5.3. Cleaning Inside of the scanner WARNING Clean inside of the scanner with a cloth moistened with Fire/Electric Shock cleaner F1. In an alternating succession of scanning documents, the... - Page 19 When you closed the ADF, make sure that it is completely closed. Otherwise, paper jams or other feeding troubles may occur. ScanSnap fi-5110EOX2 Getting Started | 17...
-
Page 20: Cleaning The Carrier Sheet
5.4. Cleaning the Carrier Sheet While using the Carrier Sheet continuously, dirt and dust may stick onto the surface or the interior. When you use the Carrier Sheet continuously, please clean it regularly, as that may be the cause of scanning error. <Cleaning method>... -
Page 21: Consumables/Carrier Sheet
1. Right click the "ScanSnap Manager" icon on the task tray. 2. Click [Check consumable supplies] at the menu. Attach the new Pad ASSY. -
Page 22: Replacing The Pick Roller
Turn on the scanner. Rotate the Pick roller bushing (Left) in the direction of the arrow. ScanSnap Manager icon changes from Right click the "ScanSnap Manager" icon on the task tray, and select [Check consumable supplies] from the menu. In the “Check consumable status” window, click the [Reset] button of Pad ASSY Count. - Page 23 11. Close the ADF. Bushing ADF cover Shaft You should hear the ADF cover click when it Pick roller returns to its original position. 12. Turn on the scanner. ScanSnap Manager icon changes from ScanSnap fi-5110EOX2 Getting Started | 21...
-
Page 24: Purchasing The Carrier Sheet
13. Right click the "ScanSnap Manager" icon on the task tray, and select [Check consumable supplies] from the menu. 14. In the “Check consumable status” window, click the [Reset] button of the Pick Roller Count. 6.4. Purchasing the Carrier Sheet If the “Carrier Sheet”...
