Technical Specifications; Product Highlights - Philips MatchLine 23PF9945 Specifications

flat TV with Crystal Clear III
23" LCD progressive scan

Technical specifications

Picture/Display
• Aspect ratio: Widescreen
• Brightness: 450 cd/m²
• Contrast ratio (typical): 400:1
• Diagonal screen size: 23 inch / 58 cm
• Visible diagonal screen size: 58 cm
• Display screen type: LCD WXGA Active Matrix
TFT
• Picture enhancement: 2D Combfilter, 3/2 - 2/2
motion pull down, Active Control + Light
sensor, Color Transient Improvement, Color
Temperature Adjustment, Contrast Plus, Crystal
Clear III, Jagged Line Suppression, Luminance
Transient Improver, Progressive Scan, Sharpness
Adjustment
• Screen enhancement: Anti-Reflection coated
screen
• Viewing angle (H / V): 170 / 170 degree
• Panel resolution: 1280 x 768p
• Response time (typical): 25 ms
Supported Display Resolution
• Computer formats
Resolution Refresh rate
1024 x 768 60Hz
1280 x 768 60Hz
640 x 480 60, 72, 75, 85Hz
800 x 600 56, 60, 72, 75,85Hz
• Video Formats
Resolution Refresh rate
720 x 576i 1Fh
720 x 576p 2Fh
Sound
• Sound Enhancement: Ultra Bass
• Sound System: Mono, Nicam Stereo, Virtual
Dolby Surround
• Total Sound Power (RMS): 20 W
Convenience
• Ease of Installation: Auto Programme Naming,
Automatic Channel Install(ACI), Automatic
Tuning System (ATS), Autostore, Fine Tuning,
Plug & Play, Program Name, Sorting
• Ease of Use: Auto Volume Leveller (AVL), FM
Radio, Graphical User Interface, Program List,
Smart Picture Control, Smart Sound Control
• Remote control type: RCAE039
• Teletext: 100 page Smart Text
Date of issue 2006-07-07
Version: 1.0
12 NC: 8670 000 18218
EAN: 87 10895 78036 0
For preview purpose only
• Teletext enhancements:
Program information Line
• Picture in Picture:
text
• Remote Control:
• Screen Format Adjustments:
and Heading Shift, Superwide, Widescreen,
Zoom 14:9, Zoom 16:9
• Clock: Sleep Timer, Wake up Clock
• VESA Mount:
• Child Protection:
Tuner/Reception/Transmission
• Tuner bands:
FM
• TV system:
SECAM, SECAM B/G, SECAM D/K, SECAM L/L'
• Video Playback:
• Aerial Input:
• Tuner Display:
• Number of Preset Channels:
Connectivity
• Number of Scarts:
• Ext 1 Scart:
• Ext 2 Scart:
video in
• Other connections:
constant level out, FM Antenna, PC-in VGA +
Audio L/R in
• Front / Side connections:
Headphone out, S-Video in
Power
• Power consumption:
W W
• Standby power consumption:
• Ambient temperature:
• Power supply:
Dimensions
• Product weight:
• Dimensions (with base) (W x H x D):
704 x 373 x 80 mm
Accessories
• Included Accessories:
guide, Registration card, Remote Control, RF
cable, User Manual
• AC/DC Adaptor/Charger:
•
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
4 favourite pages,
Picture in graphics, Twin page
DVD, TV, VCR
Full screen, Subtitle
100 x 100 mm
Child Lock
Hyperband, S-Channel, UHF, VHF,
PAL, PAL I, PAL B/G, PAL D/K,
NTSC, PAL, SECAM
75 ohm coaxial (IEC75)
PLL
100
2
Audio L/R, CVBS in/out, RGB
Audio L/R, CVBS in/out, Y/C, S-
Antenna IEC75, Audio
Audio in, CVBS in,
96 W Normal Operation
< 3 W
+5 -/+ 40 C
AC 90-240
11.2 kg
Power cord, Quick start
Multi-voltage
23PF9945/12

Product highlights

LCD WXGA display, 1280 x 768p
This WXGA display with state-of-the-art LCD screen
technology gives you HD resolution of 1280 x 768p
pixels. It produces brilliant flicker-free progressive scan
pictures with optimum brightness and superb colors.
This vibrant and sharp image will provide you with an
enhanced viewing experience.
Crystal Clear III
Crystal Clear III combines a whole range of
enhancements to provide a better picture. They include
a 2D Comb filter, Dynamic contrast, Blue stretch and
Green enhancement so that you always get the most
natural looking colors.
Progressive Scan
Progressive Scan doubles the vertical resolution of the
image resulting in a noticeably sharper picture. Instead
of sending a field comprising the odd lines to the screen
first, followed by the field with the even lines, both fields
are written at one time. A full image is created
instantaneously, using the maximum resolution. At such
a speed, your eye perceives a sharper picture with no
line structure.
Active Control + Light Sensor
Active Control is a unique and intelligent way of
optimizing picture quality by measuring and analyzing
the incoming signal to automatically adjust picture
quality settings. Active Control with Light Sensor uses a
sensor to adjust the picture brightness depending on the
room light conditions.
Virtual Dolby Surround
Virtual Dolby Surround is a processing technology for
enhancing surround sound effects. It which create the
sensation of Dolby Pro Logic without the necessity of
additional rear speakers. You become totally immersed
in your television experience.
FM-radio
A small FM radio is integrated into the headphone so
you always have a music source with you.
100 page Smart Text
The teletext is a common system transmitted by most
broadcasters. The 100 page smart text feature gives
you fast access to information when changing pages.
Twin page teletext
Twin page teletext allows you to simultaneously view
two teletext pages side by side
VGA input
The TV set has a VGA input which is compatible with
the display output signal from your PC. This means you
can use the set both as a TV and PC Monitor at your
convenience.
Picture in Graphics
Picture-in-Graphics is a small window in the main
picture, allowing to watch data/graphics in your main
TV screen. It provides the ability to simultaneously
watch data/graphics and the TV.
