PERFECT FOR MINERAL POOLS
SMC
INSTRUCTION MANUAL
TM
Model:
SMC20TA-
2500 PPM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMC20TA-2500 PPM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks SMC20TA-2500 PPM

Summary of Contents for SMC Networks SMC20TA-2500 PPM

  • Page 1 PERFECT FOR MINERAL POOLS Model: SMC20TA- 2500 PPM INSTRUCTION MANUAL...
  • Page 2 DISCLAIMER • While every effort has been made to ensure that the information contained in this guide is accurate and complete, no liability can be accepted for any errors or omissions. • Australian Innovative Systems Pty Ltd reserves the right to change the specifications of the hardware and software described herein at any time without prior notice.
  • Page 3 1. Min/Off 6. Water Flow Press to reduce the chlorine output. If light flashes and chlorine generator When no lights are lit, the chlorine beeps then no water is flowing through the electrode housing. generator is off. See Troubleshooting Guide, pages 14–15. 2.
  • Page 4 CHLORINE GENERATOR INSTALLATION ELECTRODE HOUSING The electrode housing may be installed either horizontally or vertically in the return water line to the pool. The water flow through the housing may be in either direction. Plumbing may be either 40mm or 50mm pipe. Horizontal - the plumbing connection on the side of the electrode housing must face downwards.
  • Page 5 INSTALLATION WITH POOL HEATER The power supply should be installed in a weatherproof, well ventilated area and mounted vertically within 1.5 metres of the electrode. Although the unit has an IP24 rating it can still be susceptible to wind driven rain. Min/ On Max/ On High Salt...
  • Page 7 RAISING THE SALINITY (TDS) OF A NEW POOL Calculate the water volume of your pool as follows: average length x average width x average depth in metres. Multiply this answer by 2.5. The answer is the amount of minerals in kilograms you need to add to increase the salinity of your pool from fresh water to 2500 ppm (the recommended TDS level for this chlorine generator).
  • Page 8 INTRODUCTION TO THE TIME CLOCK The time clock is accessed by pulling down the bottom flap of the front cover. There are four buttons: “Clock”, “Timer”, “Man” and “Auto”. “Clock” and “Timer”: Used to enter and exit the timer settings. Once the timing program is set they are not used again unless you wish to alter the program times.
  • Page 9 For your convenience the time clock has two factory programs ON periods. This program is recommended for the average pool. These are 8.00am to 12.00midday and 4.00pm to 8.00pm. (Fig. 2) Fig. 2 To have the time clock operate correctly, you will first need to input the correct time of day into the clock.
  • Page 10 ENTERING CORRECT TIME 1. Turn on the power to the chlorine generator. If the unit starts running, press the “Man” button to turn it off. 2. Press the “Clock” button and the word CLOCK will appear on the screen. (Remember this is a 24 hour clock). 3.

  • Page 11: Programming The Timer

    PROGRAMMING THE TIMER All segments between the start and stop times need to be turned ON (darkened) as shown in the picture below. 1. Press the “Timer” button, the word TIMER will appear on the screen. There will be one dark segment flashing. 2.

  • Page 12: Timer Operation

    TIMER OPERATION AUTOMATIC OPERATION: Press the “Auto” button to put the chlorine generator into automatic timed operation. The word AUTO, the time of day and your set times will appear on the screen. The chlorine generator and the filter pump will turn on and off at the times you entered during programming.

  • Page 13: Manual Operation

    MANUAL OPERATION: Press the “Man” button to either turn the generator off (e.g. for maintenance) if it is running, or turn it on if the generator is not running. To return to auto timer function the “Auto” button must be selected. Fig.

  • Page 14: Maintenance

    MAINTENANCE ELECTRODE INSPECTION: SMC series generators have a reverse polarity feature which reduces electrode cleaning to the minimum. Regular inspection of the electrode is recommended. ELECTRODE REMOVAL: Ensure the power to the chlorine generator is switched off. Step 1 Unplug the electrode lead from the electrode. Step 2 Unscrew (anticlockwise) the large threaded locking nut.

  • Page 15: Electrode Cleaning

    ELECTRODE CLEANING: Mix up a solution of 1 part hydrochloric acid to 8 parts water. Submerse the electrode in this solution. CAUTION: • When working with acid the use of eye protection and rubber gloves is strongly recommended. • When mixing, add acid to water, but NEVER water to acid.

  • Page 16: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM REASON SOLUTION 1. There is no mains power 1. Unplug the chlorine There are no lights on the chlorine generator and the generator from the power 2. The time clock is on Auto pump is not running and test power outlet and in an OFF period with another known...
  • Page 17 TROUBLESHOOTING GUIDE PROBLEM REASON SOLUTION The high salinity light is on Water salinity is to high or Have salinity level tested or flashing chlorine generator is faulty by pool professional and decrease to 2500 ppm if necessary 1. Water salinity is too low 1.

  • Page 18: Technical Specifications

    TECHNICAL SPECIFICATIONS Chlorine output 22 gms/hr (grams of chlorine gas equivalent per hour) Input voltage 190 – 250 volts. 50 – 60 Hz Input current 1.0 amps (excluding pump) Output voltage 15 – 26 volts DC Output current 6 amps Unit cooling Fan forced air flow Reverse time...

  • Page 19: Warranty

    WARRANTY Your MineralChlor chlorine generator is covered by a thirty six (36) month in-factory repair warranty, on all parts and labour, from the date of purchase. This warranty applies to the original purchaser and is not transferable. All chlorine generators are fully tested prior to being packed. If within 36 months of purchase a problem occurs due to faulty workmanship or components, AIS will (at their discretion) repair or replace the chlorine generator.
  • Page 20 AIS Contacts Head Office +61 7 3396 5222 or 1300 965 222 (Australia wide) Email: info@aiswater.com.au Facsimile +61 7 3393 3441 WARRANTY HOTLINE 1800 676 076 (Australia wide) Australian Innovative Systems 51 Millennium Place, Tingalpa, Queensland 4173 Australia www.aiswater.com.au...
