Installation Instruction, Electrical
Applicable for Z530c and Z530i
Contents
1
General............................................................................................................................. 2
2
Go/No Go Testing............................................................................................................ 2
2.1
2.2
2.3
3
Calibration....................................................................................................................... 5
3.1
3.2
3.3
4
Power Supply and Jumper Cables (optional)............................................................... 8
5
Lead-Free Electrical Repair........................................................................................... 8
6
Revision History.............................................................................................................. 9
1/000 21-2/FEA 209 544/103 A
©
Sony Ericsson Mobile Communications AB
Test Set-Up Diagram......................................................................................... 2
Hardware ........................................................................................................... 3
Software............................................................................................................. 4
Calibration Set-Up Diagram.............................................................................. 5
Hardware ........................................................................................................... 5
Software............................................................................................................. 7
Installation Instruction, Electrical
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sony Ericsson Z530c
Summary of Contents for Sony Ericsson Z530c
-
Page 1: Table Of Contents
Installation Instruction, Electrical Installation Instruction, Electrical Applicable for Z530c and Z530i Contents General..........................2 Go/No Go Testing......................2 Test Set-Up Diagram..................2 Hardware ......................3 Software......................4 Calibration........................5 Calibration Set-Up Diagram................5 Hardware ......................5 Software......................7 Power Supply and Jumper Cables (optional)............... 8 Lead-Free Electrical Repair................... -
Page 2: General
The Electrical Installation Instructions describes the procedures for installing all of the hardware and software needed to perform testing, calibration, and repair activities at an Electrical level for the Sony Ericsson products specified. 2 Go/No Go Testing There are two options available for making an RF connection to the handset during the Go No/Go test. -
Page 3: Hardware
2.2.2 Test Instrument The test instrument (POS-76) used must be a Sony Ericsson approved instrument with all required software and hardware options installed. Refer to the Z530 Equipment List, Electrical for the list of approved test instruments. -
Page 4: Software
2.3.1 Willtek 420x Go/No-Go Test Script An approved Sony Ericsson Test Script must be installed in the Test Instrument. The Willtek 420x script can be downloaded from CSPN. The Test Script is located on CSPN under Repair Instructions / Standard. You can also “Search the Archives” on CSPN using reference number 10274-33673 for more details about the script. -
Page 5: Calibration
Installation Instruction, Electrical 3 Calibration Calibration Set-Up Diagram Hardware 3.2.1 Computer Ensure the computer (POS-96) is installed and configured correctly according to the instructions supplied by the manufacturer. 1/000 21-2/FEA 209 544/103 A 5(9) © Sony Ericsson Mobile Communications AB... -
Page 6: Battery Charger
A battery charger must be connected to the Sony Ericsson Programming Interface Cable during calibration. 1. Connect the plug of the battery charger (POS-27) into the plug of the Sony Ericsson Programming Interface Cable (POS-10). 2. Ensure the battery charger (POS-27) is connected to the line voltage. -
Page 7: Software
Software 3.3.1 SERP Calibration Routines SERP stands for “Sony Ericsson Repair Platform”. It is an application used for testing, calibrating and repairing Sony Ericsson mobile phones. 4. Download the latest revision of the SERP application from CSPN (Repair Instructions/Standard/SERP Install Package) or through the use of the SERP Online Update Tool (OUT). -
Page 8: Power Supply And Jumper Cables (Optional)
Note that any item that contacts the solder must be labelled and used for lead-free work only. Soldering Tips Wicking Tape Tip Cleaner (steel wool) Solder Tip Tinner Soldering Iron 1/000 21-2/FEA 209 544/103 A 8(9) © Sony Ericsson Mobile Communications AB... -
Page 9: Revision History
In the figure below, the large hot air device functions as the divider. 6 Revision History Rev. Date Changes / Comments 2006-03-23 Initial Release 1/000 21-2/FEA 209 544/103 A 9(9) © Sony Ericsson Mobile Communications AB...
