Telular PHONECELL SX5e User Manual

Gsm fixed wireless terminal 900 mhz gsm 1800 mhz gsm 1800 mhz gsm
Hide thumbs Also See for PHONECELL SX5e:

Advertisement

Quick Links

Download this manual See also: Technical Manual
Enlarged version
P
HONECELL
F
W
IXED
900 MH
1800 MH
1800 MH
V
S
TANDARD
U
01/30/02
®
SX5e GSM
T
IRELESS
GSM
Z
GSM
Z
GSM
Z
C
OICE
OMMUNICATION
C
F
/D
OMPUTER
AX
ATA
F
(O
AX
TIONAL
'
M
SER
S
ANUAL
ERMINAL
)
Part Number 5602xxxx

Advertisement

loading
Need help?

Need help?

Do you have a question about the PHONECELL SX5e and is the answer not in the manual?

Questions and answers

Related Manuals for Telular PHONECELL SX5e

Summary of Contents for Telular PHONECELL SX5e

  • Page 1 ® SX5e GSM HONECELL IXED IRELESS ERMINAL 900 MH 1800 MH 1800 MH OICE OMMUNICATION OMPUTER TANDARD TIONAL ’ ANUAL 01/30/02 Part Number 5602xxxx...

  • Page 2: Important Notices

    PRODUCTS ("Product") These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW.
  • Page 3 TABLE OF CONTENTS Contents ........................2 Safe Operation Instructions ..................2 Important Notices ......................2 Installation........................Location and Setup ...................... Optional Wall-Mount Instructions ................. Connect Your to AC Power..............Phonecell ® Emergency Battery Backup ..................Plug in Your Telephone ....................Phonecell ® SX5 Operation .....................

  • Page 4: Led Status Indicators

    EXTERNAL CONNECTERS AC/Battery Switch Fax or PSTN Antenna (RJ-11) (TNC) Phone AC Power Input (RJ-11)) Serial Port (DB-9) LED STATUS INDICATORS RSSI 3 RSSI 2 RSSI 1 Service Indicator Hook Indicator Message Indicator Power/Battery Phonecell SX5e GSM Technical Manual ®...
  • Page 5 INSTALLATION Location and Setup The Phonecell ® SX5 comes with a standard spike antenna (TNC). For optimal signal strength, choose a location that is above ground and as close to windows (or exterior walls) as possible - See Figure 2. Cellular signal strength is displayed by the Received Signal Strength Indicator (RSSI) LED on the unit - See the How to Use the LED Status Indicators section of this guide.
  • Page 6 ® To Connect Your Phonecell SX5e to AC Power 1) Connect the barrel connector of the power supply to the AC power input receptacle of the Phonecell SX5 - See Figure 5. ® 2) Plug the power supply into the AC socket. 3) Press and hold the power button until the power LED is green - See Figure 5 and Figure 8.
  • Page 7 PHONECELL SX5E OPERATION To Use the LED Status Indicators ® 1) Power-on the unit (see the Connect Your Phonecell to AC Power section of this manual). 2) The LED indicators on the front of the SX5e will turn ON. The following tables describe the modes and operation of the indicators.
  • Page 8 To Install the SIM Card ® The GSM module within the Phonecell SX5 requires a Subscriber Identification Module (SIM) for normal operation. The service provider supplies a SIM card, which carries the account infor- ® mation needed to operate the Phonecell SX5.
  • Page 9 5) Hang up the telephone handset (place on-hook). For Example: To enable automatic PIN entry for PIN "1234," dial: # * 65 * 1 * 1234 # Phonecell SX5e GSM Technical Manual ®...
  • Page 10 To Change the PIN Value Entered by the Automatic PIN Entry Feature Automatic PIN entry must be disabled when youl program the new PIN and Auto PIN Entry. 1) Using a tone-dial (DTMF) POTS telephone connected to the Phone port, lift up the handset(take off-hook).
  • Page 11 To Unblock a SIM PIN Use the following key sequence to unblock a SIM card: 1) Press: * * 05 * <PIN_unblocking key> * <new_PIN * <new PIN> # 2) Press: * * 052 * <PIN2_unblocking key> * <new_PIN2 * <new PIN2> # NOTE: This procedure will change the PIN encoded on the SIM.
  • Page 12 How to Use Call-Dependent Supplementary Services Call-dependent supplementary services are those services handled within an active call. These features are network-dependent. Check with your cellular provider to determine available fea- tures. Use the following commands to activate the call-dependent supplementary services: NOTE: <send>...
  • Page 13 Variable Dial Time (Auto SEND Delay) Option ® When you place a call, your Phonecell SX5 automatically sends the phone number over the cellular network after you dial the last digit – just like a landline phone. However, to make sure you have enough time to dial the last digit, a 3-second Auto SEND Delay is programmed into the unit at the factory.
  • Page 14 Using Standard Supplementary Services ® Your Phonecell SX5 is compatible with a variety of special services, including: Call Forwarding Call Barring Call Waiting Three-Way Calling Caller ID Voice Mail and more... Depending upon your cellular provider, these services may be available on a subscription basis.
  • Page 15 Call Forwarding on No Reply: Allows a called subscriber to have the network send all incoming calls, or just those associated with a specific basic service group, addressed to the called subscriber's directory number and which meet "no reply" for a specific amount of time to another directory number. Register:* * 61 * Ph No * Teleservice * Delay # <Send>...
  • Page 16 Barring of Outgoing International Calls: Outgoing call setup possibilities exist only to subscribers of the PLMN(s) and the fixed network(s) of the country where the mobile subscriber is presently located. Activate:* 331 * Password * TeleService # <Send> Deactivate:# 331 * Password * TeleService # <Send> Barring of Outgoing International Calls Except Those Directed to the Home PLMN Country: Outgoing call setup possibilities exist only to subscribers of the PLMN(s) and the fixed...
  • Page 17 PHONECELLSX5 USER-PROGRAMMING COMMANDS ® The Phonecell SX5 can be programmed on location with an ordinary telephone, which is some- times referred to as a POTS (Plain Old Telephone Set) phone. NOTE: the User Programming mode is not accessible while you’re in a call. In the following sections, an <entered value>...
  • Page 18 To Enable/Disable Zero Dial Delay for Frequently Called Numbers Press: # * 21 * <zero-delay dial> # The < > brackets represent the 1-digit Zero Dial Delay option: enter: 0 to disable Zero Dial Delay option enter: 1 to enable Zero Dial Delay option You must enter either 0 or 1, otherwise the FWT will not update or store this value;...
  • Page 19 PHONECELL SX5E TECHNICIAN-PROGRAMMING COMMANDS ® The following commands are to used by trained field technicians to set up the Phonecell for operation in the network. Since these commands can directly affect the proper operation of the unit, there is an additional level of security to prevent casual access.
  • Page 20 To Enter Line-Reversal Outgoing Option Press: # * 22 * <line_reversal_outgoing> # The line-reversal outgoing value is set to 0 to disable line reversal, 1 to enable line reversal. If the value is neither 0 nor 1, it is considered invalid. The factory default is 0. To Enter Line-Reversal Incoming Option Press: # * 23 * <line_reversal_incoming>...
  • Page 21 To Enter Disconnect Pulse Option Press: # * 79 * <disconnect pulse> # The disconnect pulse value is programmed in 1 millisecond increments from 10 to 65,535. A value of 0 disables the disconnect pulse. If the value is not 0 or between 10 and 65,535, inclu- sive, it will be considered invalid and the FWT will not update or store this value;...
  • Page 22 DIGITAL DATA SERVICE The SX5e features a DB-9 digital computer fax/data port for connection to a personal computer (PC) - not supplied. When connected to a PC, the SX5e’s PC interface is capable of sending and receiving digital fax and data transmissions, sending and receiving e-mail communications, and browsing the Internet.
  • Page 23 Browsing the Internet 1) Set up standard 19,200 bps modem. 2) Use dial-up networking setting. 3) Press:* * 9 3 to set “Data Service” mode. Phonecell SX5e GSM Technical Manual ®...
  • Page 24 Phonecell SX5e GSM Technical Manual ®...
  • Page 25 ANALOG FAX Analog (i.e. normal fax from fax machine) fax calls (CCITT Group 3, Bearer Service TS 62) can be made from phone and fax jacks, depending on the option set. To Send Fax Calls 1) Set up your fax machine just as you would for a wired telephone.
  • Page 26 Dual/Single Jack Operation The Phonecell ® SX5 may be operated in either dual-jack or single-jack mode. The factory default is dual-jack mode. Dual-Jack Operation In dual-jack operation, for outgoing calls, the first jack to seize the line (go off-hook) will discon- nect the other jack.
  • Page 27 If the telephone sys- tem or wiring is not working properly, replace or repair the equipment as required. Otherwise, contact your cellular provider or your authorized Telular distributor. Unable to Receive Incoming Calls If more than one telephone or telephone device is connected to your Phonecell ®...
  • Page 28 WARNING! Only Authorized Service Personnel should remove the cover of your ® Phonecell SX5. For further assistance, contact your Authorized Telular Representative. Please have your unit’s model and serial number ready. ® Your Phonecell SX5 functions as both a radio transmitter and receiver. When it is ON, the FWT receives and sends out radio frequency (RF) energy.
  • Page 29 • Increase the separation between the equipment and the terminal. • Connect the equipment into an outlet on a circuit different from that to which the terminal is connected. • Consult your Authorized Telular Distributor or an experienced radio/TV technician for help. Phonecell SX5e GSM Technical Manual ®...
  • Page 30 (15) months from date of shipment from Telular. Telular, at its option, shall at no charge either repair, replace or refund the purchase price of the Product during the warranty period, provided it is returned by Buyer in accordance with the terms of this warranty to the Telular designated repair center.
  • Page 31 Telular software. Telular software may be copied into, used in and redistributed with only the Product associated with such Telular software. No other use, including without limi - tation, disassembly of such Telular software or exercise of exclusive rights in such Telular soft- ware is permitted and Telular reserves all rights not expressly granted in this Limited Commercial Warranty.
  • Page 32 APPENDIX A: HOW TO SETUP PC SERIAL PORTS FOR PHONECELL DIGITAL FAX/DATA Requirements · GSM account with your network service provider including a Data/Fax facility. · PC/Laptop/ Notebook with Com Port. · Windows 95/98 NOTE: When all of the above have been satisfied, you may proceed. Modem Setup 1) Power on your PC/laptop and start Windows 95/98.
  • Page 33 4) The install new modem window may appear asking for the type of modem to install. Click on "Other" followed by clicking the NEXT button. If this window does not appear, go to Step 5. 5) The install new modem window will appear. Then, click on the "Don't detect my modem option"...
  • Page 34 6) The install new modem will update again to select the manufacturer and modem model. Click on "Standard Modem Types" from the manufactures list followed by "Standard 19200 bps Modem" from the model list. Then click on the NEXT button. 7) The install new modem will update to select the com port.
  • Page 35 8) The Install New Modem window will update again. Click on Finish to proceed. 9) The Modems Properties window should appear. Click on the Properties button. Phonecell SX5e GSM Technical Manual ®...
  • Page 36 10) The Standard 19200 bps Modem Properties window will open in the General tab. Set as shown with the com port you have selected. 11) Then click on the Connection tab. Set as shown below. Phonecell SX5e GSM Technical Manual ®...
  • Page 37 12) Click on the Advanced button. Set as shown. 13) Click on OK and Close to back out of each window. Your modem is now set up. Phonecell SX5e GSM Technical Manual ®...
