- Page 1 INSTRUCTIONS FOR USE INDUSTRIAL PC CONTROL 217 PC Read the instructions prior to performing any task!
- Page 2 Systec & Solutions GmbH Emmy-Noether-Straße 17 D–76131 Karlsruhe Telephone: 0721 6644 400 Fax: 0721 6644 444 email: talk@systec-solutions.com Internet: www.systec-solutions.com © 2013 CONTROL, 1, en_US, 11.11.2015 CONTROL 217 PC - Industrial PC...
-
Page 3: Table Of Contents
5.7 Hard disk LED (optional)..............32 Repairs......................33 Storage......................35 7.1 Unmounting the device..............35 7.2 Storing the device................36 Packaging and transport..............37 8.1 Packaging the device............... 37 8.2 Transporting the device..............37 Disposal......................39 Site information..................41 CONTROL 217 PC - Industrial PC... - Page 4 Table of contents CONTROL 217 PC - Industrial PC...
-
Page 5: General Information
1.1 Information on the user guide This translation of the original user guide is an integral part of the CONTROL 217 PC and provides you with information on the set-up, use, storage and disposal of the device. Before beginning any work, read the user guide and always keep it in an accessible place. - Page 6 General information Copyright notice CONTROL 217 PC - Industrial PC...
-
Page 7: Safety
Safety notices Safety 2.1 Designated use CONTROL 217 PC is an HMI PC system. CONTROL 217 PC is used to implement control and operating concepts and to display and manipu- late information in industrial and commercial environments. It is nonetheless possible for improper use to introduce hazards. For correct operation and safe use it is therefore important to comply with the information and instructions in this document. -
Page 8: Important Safety Notes
– Never plug in or unplug the power supply plug when live with voltage. – The supply cable must not be supplied with voltage until assembly has completely finished. CONTROL 217 PC - Industrial PC... - Page 9 Danger of material damage from improber use of the mounted keyboard! Handling the keyboard too strong like moving the entire system may cause material damage. – Only use immovable components to move the entire system. CONTROL 217 PC - Industrial PC...
- Page 10 Safety Important safety notes CONTROL 217 PC - Industrial PC...
-
Page 11: Product Description
Hard disk LED (optional) Flashes when accessing data on the internal HDD disk. Fig. 2: Rear view of PC The button on the back of the monitor is used to switch the PC ON and OFF. CONTROL 217 PC - Industrial PC... -
Page 12: Type Plate
3.2 Type plate The product designation and identification will be found on the type plate. This is always located on the rear of the device and contains the following information: Fig. 4: Position of type plate CONTROL 217 PC - Industrial PC... -
Page 13: Technical Data For The Device
N2930 1.86 GHz/Burst 2.16 GHz, quad core Intel Core i3-4010U 1.7 GHz ® ™ Intel ® Core ™ i5-4300U 1.9 GHz/Turbo 2.9 GHz Intel ® Core ™ i7-4650U 3.3 GHz 4 GB DDR3, max. 16 GB DDR3 (Celeron 8 GB) CONTROL 217 PC - Industrial PC... - Page 14 100 ‒ 240 V AC, 50 ‒ 60 Hz, 2,0 ‒ 0,9 A Protection of supply lead (Low voltage max. 16 A, the supply lead should be specified. Mean power consumption in oper- 35 - 50 W (depending on configuration) ating mode CONTROL 217 PC - Industrial PC...
-
Page 15: Dimensions
D 40 (optional for DC) Front panel W 504 / H 337 / D 5 Material of front panel Stainless steel 1.4301 Weight Net weight ca. 9 kg 3.4 Dimensions 383(AA215) Fig. 6: Dimensions of front of device CONTROL 217 PC - Industrial PC... - Page 16 Product description Dimensions min. 436 (cut-out) Fig. 7: Dimensions of back of device max60 Fig. 8: Dimensions in side view CONTROL 217 PC - Industrial PC...
-
Page 17: External Connections
3.5 External connections 3.5.1 Overview of external connections The following illustration shows the connectors that are located on the underside of the CONTROL 217 PC. Fig. 10: Overview of the interfaces on the underside 3.5.2 Description of the external connections Your device will not incorporate all of the following connectors (see Ä... - Page 18 = 15-pole HD-D "VGA" socket for connecting basic computer Fig. 14: VGA socket with pinout USB connection = 4-pole USB socket (type A) for connecting components: VoIP hardware components and/or touchscreen and/or keyboard Fig. 15: USB socket with pinout CONTROL 217 PC - Industrial PC...
- Page 19 (12‑24V DC) GF-7,62. The corresponding plug carries the designation Phoenix Con- tact PC 4/ 2-ST-7,62. Fig. 17: 2-pole Phoenix Contact socket for the power supply Pin Designation Significance Ground (GND) 0V Power supply + CONTROL 217 PC - Industrial PC...
-
Page 20: Conformity
The product listed above fulfills the requirements of the Directive 2006/95/EC on the basis of the following standard: – EN 60950-1:2006 CERTIFICATE Compliance with protection requirements was established with the housing closed on all sides. Systec & Solutions GmbH Emmy-Noether-Straße 17 D–76131 Karlsruhe CONTROL 217 PC - Industrial PC... - Page 21 Product description Conformity Germany Phone +49 721 6634 400 Fax +49 721 6634 444 talk@systec-solutions.com www.systec-solutions.com Karlsruhe, December 1, 2014 Karl G. Linder CONTROL 217 PC - Industrial PC...
- Page 22 Product description Conformity CONTROL 217 PC - Industrial PC...
-
Page 23: Starting Up
Make sure the ambient temperature does not exceed the specified maximum value (see Ä Chapter 3.3 “Technical data for the device” on page 13). When installing the equipment also observe Ä Chapter 3.4 “Dimen- sions” on page 15. CONTROL 217 PC - Industrial PC... -
Page 24: Mounting The Device
Working on heavy equipment may lead to serious injuries. – Always have two people when working with heavy equipment. Push the device into the installation cutout from the front and hold it firmly in place. CONTROL 217 PC - Industrial PC... - Page 25 Optionally counterbores may be attached to the threads. Please insert the attached O-rings. Fig. 21: Counterbore CONTROL 217 PC - Industrial PC...
- Page 26 Starting up Mounting the device CONTROL 217 PC - Industrial PC...
-
Page 27: Operation
5.1 Switching the device on Fig. 22: ON/OFF button for switching on and off Press the ON/OFF button between the dummy plugs on the front of the CONTROL 217 PC. ð The system goes into operation. 5.2 Switching the device off NOTICE! Loss of data due to failure to save it. -
Page 28: Cleaning The Device
Clean the display without applying any excessive pres- sure. Regularly clean the surface of the device using a soft, moist, lint- free cloth. For more significant soiling: Use isopropanol as cleaning agent. Note the information in the following chemical resistance data: CONTROL 217 PC - Industrial PC... - Page 29 Glycol Toluol Bichromate Glycerine Triacetin Ferrocyanide salts Heating oil III-trichloroethane Drilling emulsion Isopropanol Trichloroethylene Brake fluid Potash soap Trichloroacetic acid <10% Butyl cellosolve Potassium hydroxide Tricresyl phosphate <30% Sodachlorine <20% Kerosene Thinner (white spirit) CONTROL 217 PC - Industrial PC...
- Page 30 Top Job Ajax Jet Dry Grape juice Domestos Coffee Downey Lenor Vortex Fantastic Milk Wisk Formula 409 PersiI Windex Slight discoloration was detectable for the following materials: Mustard Tomato ketchup Tomato juice Lemon juice CONTROL 217 PC - Industrial PC...
-
Page 31: Using The Optional Usb Connection
The WLAN USB stick may be connected only directly to a USB interface with no interposed USB hub. Install the WLAN driver from the supplied USB stick. ð The WLAN is set up. CONTROL 217 PC - Industrial PC... -
Page 32: Hard Disk Led (Optional)
Operation Hard disk LED (optional) 5.7 Hard disk LED (optional) The hard disk LED flashes when the internal HDD hard disk is accessed. This is, however, possible only for HDD disks. CONTROL 217 PC - Industrial PC... -
Page 33: Repairs
If you encounter a product fault while using the device: – immediately switch it off (see Ä Chapter 5.2 “Switching the device off” on page 27). The device is defective. Send an e‑mail to support@systec-hardware.com or Fill out a support form at http://www.systec-solutions.com/de/hardware-support.html. CONTROL 217 PC - Industrial PC... - Page 34 Repairs CONTROL 217 PC - Industrial PC...
-
Page 35: Storage
Ä Chapter 5.4 “Cleaning the device” on page 28). Release the nuts from the M6 bolts on the back of the front panel. Remove the device from the wall cutout. ð The device is unmounted. CONTROL 217 PC - Industrial PC... -
Page 36: Storing The Device
Always shield the equipment from solar radiation. Avoid mechanical vibration and shocks. Avoid cold weather and extreme temperature fluctuations. Pay attention to the information in the “Technical data” section. Ä Chapter 3.3 “Technical data for the device” on page 13 CONTROL 217 PC - Industrial PC... -
Page 37: Packaging And Transport
Avoid extreme temperature fluctuations. Pay attention to the information in the “Technical data” section. When the consignment is delivered, immediately check it for possible transport damage and deal appropriately with any detected transport damage or non-obvious defects. CONTROL 217 PC - Industrial PC... - Page 38 Packaging and transport Transporting the device CONTROL 217 PC - Industrial PC...
-
Page 39: Disposal
Systec-Services GmbH for proper dis- posal. Do not dispose of the equipment via your local municipal col- lection centers. Under the WEEE Directive these may be used only for privately used equipment. CONTROL 217 PC - Industrial PC... - Page 40 Disposal CONTROL 217 PC - Industrial PC...
-
Page 41: Site Information
VAT ID no. as per §27a Value Added Tax Act: DE 815434969 ©Systec & Solutions GmbH / All rights reserved Technical modifications reserved All trademarks and registered trademarks mentioned are the property of their respective owners CONTROL 217 PC - Industrial PC...
