- Page 1 Discover Video Mantis Encoder User Guide Version 1.2 Discover Video LLC 10/7/2016 www.discovervideo.com...
-
Page 2: Table Of Contents
Mantis Encoder Contents General Description ................3 Installation ..................4 Find IP Address .................5 Configuration ..................5 Setting ....................5 Record ....................8 Status ....................9 Network Setup ................10 Firmware Update ................10 Account Setup ................11 Restore Default ................11 Front Panel ..................12 Operation &... -
Page 3: General Description
Chapter 1: Introduction General Description The Discover Video Mantis is a live video encoder that provides live streaming and recording from a variety of video input types. It is an economical appliance that is ideal for IPTV, executive broadcasts, morning announcements, enterprise and web streaming. -
Page 4: Installation
Mantis Encoder Chapter 2: Configuration Installation Connect desired Audio/Video input, 10/100 Ethernet, and Power. Power is supplied by an external AC power supply and connects to the Mantis via a locking DC connector. Video Input may be: HDMI – Via HDMI connector (female) ... -
Page 5: Find Ip Address
Mantis Encoder Find IP Address Apply power and turn the front panel switch to the on position. Allow a few minutes for the unit to boot up. The Mantis is configured for DHCP and will obtain an IP address automatically. To find the IP address used, insert a USB Flash Drive into the USB connector and wait a few moments. - Page 6 Mantis Encoder Server Off – Streaming is disabled RTSP – Streaming is available from Mantis via RTSP RTMP – Stream is available directly from Mantis as RTMP HLS – Stream is available directly from Mantis as HLS RTMP Publish –...
- Page 7 Mantis Encoder Video Select the desired video input Audio Digital, RCA, Line-in (mini-jack) Video Tuning / Volume Tuning – not available for digital inputs Scale Down – Normally set to “No” where the output resolution ...
-
Page 8: Record
Mantis Encoder Record Mantis can record to a USB device (including a high capacity drive). To use recording, insert a USB drive and check that it is accepted and available on the Record screen. Enter a record name prefix. The... -
Page 9: Status
Mantis Encoder Status Status shows the current status of the Manis. Page 9 Mantis Encoder... -
Page 10: Network Setup
Firmware Update Select Firmware Update to update the Mantis with files provided by Discover Video. With the streaming server set to OFF, upload firmware ending in “A”, followed by “B”. Once the message “Warning, Please reboot” appears, cycle power to reboot. -
Page 11: Account Setup
Mantis Encoder Other Setup Select Other Setup to change the system password. Enter the original Account (username) and password then select “Submit”, then enter new Account (username) and password. Enter a device name for the Mantis, which will show up in the Mantis Finder program to ease device identification. -
Page 12: Front Panel
Mantis Encoder Front Panel Power – turns power on/off USB – Optional storage for recording Stream -- Press once for 3 sec to start streaming. Again to stop. Record – Press once for 3 sec to start recording. Again to stop. -
Page 13: Operation & Notes
When Mantis is set to RTMP, the viewing URL is: rtmp://[IP]/live/Mantis (case sensitive). This can be viewed in the Discover Video player, 3 party players, and can be pulled in to DEVOS via Advanced/Pull function. When Mantis is set to RTSP, the viewing URL is: ... -
Page 14: Mantis Shelf
Mantis Encoder Mantis Shelf The Mantis Shelf can mount up to six Mantis encoders and provides power supply and power distribution to the encoders. Install the encoders by securing them with the included screws (two on top, two on the bottom). -
Page 15: Scaling
Mantis Encoder Scaling The following scaling settings are supported. Output -> 1920x1080 1440x1080 1440x900 1280x720 960x540 720x576 720x480 320x240 Input 1080p60 1080i60 1080p50 1080i50 720p60 720p50 576p60 480p60 NTSC Page 15 Mantis Encoder... -
Page 16: Warranty
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE (OR JURISDICTION TO JURISDICTION). DISCOVER VIDEO LLC RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN HARDWARE IS LIMITED TO REPAIR AND REPLACEMENT AS SET FORTH IN THIS WARRANTY STATEMENT.
