- Page 1 EQUINOX PRO INS TRUCTION MANUAL INS TRUCTION MANUAL 3 Legged Thing ® BUIL T TO ENABLE. CREA TED TO INSPIRE.
- Page 2 Look at the end of your box. See that little sticker with a serial number and a barcode? Peel it off and put it here for safe keeping. Or don’t. IMPORTANT DO NOT USE YOUR TRIPOD UNTIL YOU HAVE READ THESE INSTRUCTIONS.
- Page 3 ANATOMY OF A TRIPOD: We offer the three leg angles that we consider to be optimum for using a tripod. They are 23˚, 55˚ & 80˚. Each angle has its own merits. 80˚ 55˚ 23˚ Tri-Mount Plate Central Column Para-Lock (Column) Collar Locking Ring Leg Catch...
- Page 4 ANATOMY OF AN AIRHED QR3P (Release) Plate Pano-Clamp* Pano Lock* Plate Lock Camera Screw Pan Knob (behind head) Casing *Not all 3LT AirHeds have the Pano Clamp or Pano Lock. Ball Control Pan Base IMPORTANT The QR3P Release Plate included in all 3 Legged AirHeds and Release Plates Thing Tripod Kits does not have security bolts fitted, as bolts are incompatible with the Peak Design...
-
Page 5: Basic Functionality
Basic Functionality The Tri-Mount Plate comes with three hollow ends (a), for connecting your strap or carabiner, six 1/4” threaded holes (b) and one 3/8” threaded hole in the centre. The central bolt can be removed and has both 1/4” and 3/8” threads. In the base of the centre column is a D-Ring (c), which is used to connect either your strap, for carrying, or the bag (e), for ballast, using the carabiner (d). - Page 6 Basic Functionality To remove the centre column, unscrew the D-Ring (a), and the collar (b). You can then pull out the column (c), and completely remove the collar (b). Your Tri-Mount Plate (d) should be unscrewed from the other end of the column, and then carefully screwed directly to the canopy (e).
- Page 7 The Para-Locks (a) are designed to prevent accidental disassembly of the legs and column, and add additional strength to the mechanism and tripod. If the Para-Lock (a) seems locked, but the leg section is not firmly locked, then the Para-Lock is locked in the open position.
- Page 8 Additional Clamp Function Both Switch and Pano-clamps can be detached from the ball head and mounted directly to the tripod canopy. This is particularly useful as a quick release mechanism for the monopod leg. In the centre of the clamp is a hex screw (a). Undo this with the tools provided.
-
Page 9: Warranty Information
Your 3LT product comes with a 5 Year Global Warranty. On the box you will find a sticker with a unique barcode and serial number. Use this serial number to register your products at www.3leggedthing. com/register. Details of your warranty can be found at www.3leggedthing.com. - Page 12 3L T Social Media #3LeggedThing /3LeggedThing @3LeggedThing Unit 9 Kinsbourne Farm Bury End Stagsden Bedfordshire MK43 8TS United Kingdom of Fadeless Splendour...
