Genesis GEN3t User Manual

Portable data recorder
Hide thumbs
1
2
3
4
Table Of Contents
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669
670
671
672
673
674
675
676
677
678
679
680
681
682
683
684
685
686
687
688
689
690
691
692
693
694
695
696
697
698
699
700
701
702
703
704
705
706
707
708
709
710
711
712
713
714
715
716
717
718
719
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
736
737
738
739
740
741
742
743
744
745
746
747
748
749
750
751
752
753
754
755
756
757
758
759
760
761
762
763
764
765
766
767
768
769
770
771
772
773
774
775
776
777
778
779
780
781
782
783
784
785
786
787
788
789
790
791
792
793
794
795
796
797
798
799
800
801
802
803
804
805
806
807
808
809
810
811
812
813
814
815
816
817
818
819
820
821
822
823
824
825
826
827
828
829
830
831
832
833
834
835
836
837
838
839
840
841
842
843
844
845
846
847
848
849
850
851
852
853
854
855
856
857
858
859
860
861
862
863
864
865
866
867
868
869
870
871
872
873
874
875
876
877
878
879
880
881
882
883
884
885
886
887
888
889
890
891
892
893
894
895
896
897
898
899
900
901
902
903
904
905
906
907
908
909
910
911
912
913
914
915
916
917
918
919
920
921
922
923
924
925
926
927
928
929
930
931
932
933
934
935
936
937
938
939
940
941
942
943
944
945
946
947
948
949
950
951
952
953
954
955
956
957
958
959
960
961
962
963
964
965
966
967
968
969
970
971
972
973
974
975
976
977
978
979
980
981
982
983
984
985
986
987
988
989
990
Table of Contents

Advertisement

Quick Links

User Manual
English
Portable Data Recorder
GEN3t

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GEN3t and is the answer not in the manual?

Questions and answers

Summary of Contents for Genesis GEN3t

  • Page 1 User Manual English Portable Data Recorder GEN3t...
  • Page 2 GEN3t Document version 3.1 - December 2016 References made to the Perception software are for version 6.72 or higher www.hbm.com/terms For HBM's Terms and Conditions visit HBM GmbH Im Tiefen See 45 64293 Darmstadt Germany Tel: +49 6151 80 30 Fax: +49 6151 8039100 Email: info@hbm.com...
  • Page 3 GEN3t LICENSE AGREEMENT and WARRANTY For information about LICENSE AGREEMENT AND WARRANTY refer to www.hbm.com/terms. Trademarks and patents ® StatStream is a registered trademark of HBM in the European Union and a trademark in other countries. ® StatStream is patented in the US, Patent No. 7,868,886; patent pending in other countries.
  • Page 4 I3995-3.1 en HBM: public...

  • Page 5: Table Of Contents

    GEN3t Table of Contents Page About this manual Symbols used in this manual Manual conventions Safety Messages Introduction FCC and general Grounding Instrument symbols Protection and isolation 2.5.1 Measurement categories 2.5.1.1 Categories in accordance with IEC 61010-2-030:2010 2.5.2 Basic insulation versus reinforced 2.5.2.1...
  • Page 6 6.3.4 Thermal protection Acquisition 6.4.1 StatStream® Signal conditioning Data storage Interface/Controller section Setting up the GEN3t GEN3t connections Connecting the GEN series to a network 7.2.1 Default network settings 7.2.2 Connecting the GEN series directly to a PC 7.2.3 Connecting the GEN series to a company network 7.2.4...
  • Page 7 To turn the feet in: Probe calibration DC power output Digital Event/Timer/Counter 7.9.1 Isolated event adapter 7.9.2 Torque/RPM adapter Getting Started GEN3t control Connecting GEN3t to Perception Acquisition and Storage Introduction Recording Storage 9.3.1 More on sweeps 9.3.2 Pre-trigger sweeps 9.3.3...
  • Page 8 GEN3t 10.4.4 Interval timer 10.4.4.1 Interval timer - Less 10.4.4.2 Interval timer - More 10.4.4.3 Interval timer - Between 10.4.4.4 Interval timer - NotBetween 10.4.5 Event counter 10.5 Recorder and system trigger 10.6 Channel alarm Interface/Controller 11.1 Introduction 11.2 Communication and control 11.2.1...
  • Page 9 EtherCAT® generic principles 11.10.2 EtherCAT® Slave Stack 11.10.3 Physical Layer 11.10.4 Data Link Layer 11.10.5 Application Layer 11.10.6 Setting up EtherCAT® channels in Genesis 11.10.6.1 Real-time formula database 11.10.7 Selecting the appropriate EtherCAT® configuration 11.10.7.1 Static mode 11.10.7.2 Dynamic mode 11.10.8 CoE Object layout 11.10.9...
  • Page 10 GEN3t 12.2.3 GN610, Isolated 1kV 2MS/s input card 12.2.4 GN611, Isolated 1 kV 200kS/s input card 12.2.5 Using the GN610/GN611 and GN610B/GN611B 12.2.6 Understanding the GN610/GN611 and GN610B/GN611B category rating 12.2.7 Understanding the GN610/GN611 and GN610B/GN611B input 12.2.8 Using the High Precision Differential Probe 12.2.9...
  • Page 11 GEN3t 12.4.7 Bridge connector reference card 12.4.8 Configuring and using the bridge amplifier 12.4.8.1 Bridge completion 12.4.8.2 Bridge completion - full (4/4) bridge 12.4.8.3 Bridge completion - Half (1/2 or 2/4) bridge 12.4.8.4 Bridge completion - Quarter (1/4) bridge 12.4.8.5 Excitation 12.4.8.6...
  • Page 12 GEN3t 12.10.8 Configure the Timer/Counters in Perception 12.10.8.1 To activate Channel 8 or Channel 9 in Perception 12.10.9 GN4070 Connectors and pinning Option Cards 13.1 Option Carrier Card (OCC) 13.1.1 Option cards supported 13.2 5B Integration card GEN series Synchronization Methods 14.1...
  • Page 13 15.3.3 Probes and differential measurements 15.4 Current shunt measurements Specifications B3772-3.1 en (GEN3t Portable Data Recorder) B2629–2.1 en (GEN series GN401) B2633–2.1 en (GEN series GN410) B2639–2.1 en (GEN series GN411) B2627-2.1 en (GEN series GN412) B4160-1.1 en (GEN series GN413) B2631-2.0 en (GEN series GN440)
  • Page 14 GEN3t B.2.1 Breakout cables B.2.2 Breakout panels B.2.3 DIN rail breakouts Bridge articles B.3.1 Bridge completion pack B.3.2 16 pin LEMO connector pack Burden resistor B.4.1 High precision burden resistor Card adapters B.5.1 Artificial star adapter B.5.2 Artifical star adapter wiring diagram B.5.3...
  • Page 15 GEN3t B.9.9 10 Gbit Optical Network SFP module 850 nm B.9.10 10 Gbit Optical Network SFP module 1310 nm B.10 Local Storage B.10.1 Local storage B.11 Mainframe adapters B.11.1 G070A Torque/RPM adapter B.11.2 G072 Isolated Digital Event Adapter B.11.3 Isolated digital event adapter to marker card cable B.12...
  • Page 16 GEN17tA Perception settings G.2.1 GEN7t/GEN16t - Perception settings G.2.2 GEN3i, GEN7i, GEN3t, GEN7tA and GEN17tA - Perception settings Synchronizing GEN series and QuantumX using PTP G.3.1 GEN3i/GEN7i with single QuantumX "B" version module G.3.2 GEN3i/GEN7i with single SomatXR "B" version module G.3.3...
  • Page 17 Calculating maximum fiber cable length Wake On LAN support (WOL) H.5.1 Locating GEN3i and GEN7i MAC/Physical address H.5.2 Locating GEN3t, GEN7tA and GEN17tA MAC/Physical address Configuring an encoder with direction and reset H.6.1 From encoder to level converter H.6.2 From level converter to Digital I/O connector on the mainframe H.6.3...
  • Page 18 GEN3t BE3200 USB to Optical RS232 convertor Re-programming of the USB-RS232 (opt. 650nm) converter to work with BE3200 Legacy Information - Input Cards Basic amplifier non-isolated input cards K.1.1 GN810 Basic 200kS/s input card K.1.2 GN811 Basic 1MS/s input card...

  • Page 19: About This Manual

    GEN3t 1 About this manual Symbols used in this manual The following symbols are used throughout this manual to indicate warnings and cautions. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

  • Page 20: Manual Conventions

    GEN3t Manual conventions ® When the wording “Click Start ...” is used, this refers to the Windows Start ® ® ® button. Compared to Windows XP, Windows Vista and Windows 7, the Start Menu has undergone some significant changes. The taskbar icon is no longer labeled "Start"...

  • Page 21: Safety Messages

    GEN3t 2 Safety Messages Introduction IMPORTANT Read this section before using this product! This instrument is mains powered and protective ground connections are required (unless otherwise specified for certain parts). This manual contains information and warnings that must be observed to keep the instrument safe.
  • Page 22 GEN3t It is also essential to follow the respective legal and safety regulations for specific applications during use. The same applies to the use of accessories. Additional safety precautions must be taken in setups where malfunctions could cause major damage, loss of data or even personal injury.
  • Page 23 GEN3t Qualified personnel People entrusted with the installation, fitting, operation of the instrument and putting the unit into service must have the appropriate qualifications. The instrument may only be installed and used by qualified personnel, in strict accordance with the specifications and the safety rules and regulations. This...

  • Page 24: Fcc And General

    GEN3t FCC and general The first WARNING note below is required by the FCC (Federal Communications Commission) and relates only to the interference potential of this equipment. This message is a direct quotation. WARNING The equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, may cause interference to radio communications.

  • Page 25: Grounding

    GEN3t Grounding The instrument must be used with a protective ground connection via the protective ground conductor of the supply cable. The protective ground conductor is connected to the instrument before the line and neutral connections are made when the supply connection is made. If the final connection to the supply is made elsewhere, ensure that the ground connection is made before line and neutral connections are made.
  • Page 26 GEN3t WARNING If connection to a protective ground is not possible for any reason, then please refer to the international safety standard EN 50191:2000 I3995-3.1 en HBM: public...

  • Page 27: Instrument Symbols

    GEN3t Instrument symbols A variety of symbols can be found in the system. Below is a list of symbols and their meaning. This symbol is used to denote the measurement ground connection. This point is not a protective ground connection.

  • Page 28: Protection And Isolation

    GEN3t Protection and isolation 2.5.1 Measurement categories The international standards for test equipment safety are IEC 61010-1 and the IEC 61010-2-030. IEC 61010-1 defines three overvoltage categories (CAT II, CAT III, and CAT IV) for the power supply of an instrument.
  • Page 29 GEN3t CAT IV: This category is for measurements directly connected to the source of a low voltage mains installation. Measurements for this category are overcurrent protection devices, ripple control units, etc. This category expects that there is a minimum of one level of overcurrent protection between the transformer and connection point of the measurement circuit.

  • Page 30: Basic Insulation Versus Reinforced

    GEN3t WARNING Measurement inputs of this instrument should not be used to measure high-energy signals of measurement categories CAT II, CAT III or CAT IV (IEC 61010-2-30:2010) (e.g. mains measurements) , unless specifically stated for the specific input. 2.5.2 Basic insulation versus reinforced For reference, the basic insulation and supplementary insulation and the reinforced insulation test values for CAT II can be found below.

  • Page 31: Additional Means Of Protection For Single Fault Conditions

    GEN3t Additional means of protection for single fault conditions Accessible parts shall be prevented from becoming HAZARDOUS LIVE IN SINGLE FAULT CONDITION. The primary means of protection (see Figure 2.2) shall be supplemented by one of A, B, C or D. Alternatively, one of the single means of protection E or F shall be used.

  • Page 32: Protection

    GEN3t 2.5.3 Protection WARNING ELECTRICAL SHOCK HAZARD! Any interruption of the protective conductor inside or outside the apparatus is likely to make the apparatus dangerous. Intentional interruption is prohibited. When the apparatus is connected to its supply, terminals may be live, and the opening of covers for removal of parts is likely to expose live parts.

  • Page 33: Overvoltage/Current Protection

    GEN3t 2.5.4 Overvoltage/current protection All signal inputs are protected against overloads and transients. Exceeding the limits stated in the specifications, particularly when connected to potentially high-energy sources, can cause severe damage that is not covered by the manufacturer's warranty. WARNING Do not remove covers.

  • Page 34: Environment

    GEN3t Environment The instrument should be operated in a clean, dry environment with an ambient temperature between 0 °C and +40 °C. The instrument is specified for use in a Pollution Degree II environment, which is normally non-conductive with temporary light condensation, but it must not be operated while condensation is present.

  • Page 35: Laser Safety

    GEN3t Laser Safety Some of the GEN series cards or systems use lasers. All laser products used are classified as a Class 1 laser product. The lasers do not emit hazardous light but it is recommended to avoid direct exposure to the beam.

  • Page 36: Manual Handling Of Loads

    Should the carrier wear gloves to get a better grip and to protect hands? Contact the “Occupational Health and Safety” organization, or equivalent, in your country for more information. The GEN3t weighs approximately 12 kg with three acquisition cards plugged in (9 kg without acquisition cards) : I3995-3.1 en HBM: public...

  • Page 37: International Safety Warnings

    GEN3t International safety warnings Dansk SIKKERHEDSADVARSEL Dette instrument skal anvendes med en sikkerhedsjordforbindelse, som er tilsluttet via lysnetkablets beskyttelsesjordledning eller via en sikkerhedsjordklemme, hvis instrumentet er forsynet hermed. Hvis sikkerhedsjordforbindelsen afbrydes, inden i eller uden for instrumentet, kan instrumentet udgøre en farekilde. Sikkerhedsjordforbindelsen må ikke afbrydes.
  • Page 38 GEN3t Nederlands VEILIGHEIDSWAARSCHUWING Dit instrument mag uitsluitend worden gebruikt als een beschermde massa (aarde) is aangesloten via de beschermde massageleider van de voedingskabel, of indien het instrument daarvan is voorzien via de veiligheids- massa-aansluiting. Als de beschermde massa, binnen of buiten het instrument, wordt onderbroken, dan kan dat hierdoor uitermate gevaarlijk worden.
  • Page 39 GEN3t Suomi TURVAOHJEITA Tätä laitetta käytettäessä sen tulee olla suojamaadoitettu joko verkkojohdon suojajohtimen tai erillisen suojamaadoitusliitännän kautta, mikäli laitteeseen on sellainen asennettu. Suojamaadoituksen katkaiseminen laitteen sisä- tai ulkopuolelta tekevät siitä vaarallisen. Tahallinen katkaisu on kiellettyä. Lisäksi signaalimaa on oltava kytkettynä, jos jokin tulosignaali ylittää tehollisarvon 33 V, huippuarvon 46,7 V tai 70 V DC (IEC 61010-1:2010).
  • Page 40 GEN3t Français ATTENTION - DANGER! Lorsqu'il est en fonctionnement, cet instrument doit impérativement être mis à la masse par le conducteur de terre du câble d'alimentation ou, si l'instrument en comporte une, par la borne de terre. Il peut être dangereux en cas de coupure du circuit de terre, que ce soit à...
  • Page 41 GEN3t Deutsch WARNHINWEIS! Dieses Gerät muss mit einer Schutzerde betrieben werden, die über den Schutzleiter des Speisekabels oder über die Erdungsklemme des Gerätes (falls vorhanden) anzuschließen ist. Bei einer Unterbrechung der Schutzerde außerhalb oder innerhalb des Gerätes kann eine Gefahr am Gerät entstehen.
  • Page 42 GEN3t Italiano AVVISO DI SICUREZZA Questo strumento deve esser utilizzato con un collegamento protettivo di messa a terra tramite il filo di messa a terra del cavo di alimentazione o tramite il terminale di messa a terra in sicurezza, nel caso in cui lo strumento ne sia dotato.
  • Page 43 GEN3t Norsk ADVARSEL! Dette instrument må betjenes med beskyttelsesjord tilkoblet via beskyttelsesjordlederen til tilførselskabelen eller via beskyttelsesjordklemmen, hvis instrumentet er utstyrt med en slik. Ethvert brudd i beskyttelsesjorden inni eller utenpå instrumentet kan føre til at instrumentet blir farlig. Tiltenkt brudd er tillatt.
  • Page 44 GEN3t Português AVISO DE SEGURANÇA Este instrumento deve funcionar com uma terra de proteção conectada através do condutor da terra de proteção do cabo de alimentação ou, caso o instrumento esteja equipado com um, através do terminal da terra de proteção.
  • Page 45 GEN3t Português (Brasil) AVISO DE SEGURANÇA Este instrumento deve ser operado com um terra de proteção conectado por meio do condutor do terra de proteção do cabo de alimentação ou, se o instrumento estiver equipado com um, por meio do terminal de aterramento de segurança.
  • Page 46 GEN3t Español ADVERTENCIA SOBRE SEGURIDAD Este instrumento debe utilizarse conectado a tierra a través del conductor de puesta a tierra del cable de alimentación o de la borna de seguridad, si dicho instrumento estuviera equipado con ella. Cualquier interrupción de esta puesta a tierra, dentro o fuera del instrumento, hará...
  • Page 47 GEN3t Svenska SÄKERHETSVARNING Detta instrument måste användas med jordad anslutning via strömkabelns ledare eller, om sådan finns, via en isolerad jordterminal. Avbrott i den isolerande jordningen inuti eller utanför instrumentet kan göra instrumentet farligt. Avsiktligt avbrott är förbjudet. Dessutom måste en signaljordning anslutas om någon ingångssignal överskrider 33 V RMS, 46.7 V PEAK eller...
  • Page 48 GEN3t English SAFETY WARNING This instrument must be operated with a protective ground (earth) connection via the protective ground conductor of the supply cable or, if the instrument is fitted with one, via the protective ground terminal. Any interruption of the protective ground, inside or outside the instrument, is likely to make the instrument dangerous.
  • Page 49 GEN3t 日本語 安全上の警告 本機器の操作は、電源ケーブルの保護接地線で接地（アース）を施した上で 行ってください。また、安全接地用端子が存在する場合は、これを経由して 本機器を接地してください。機器の内部または外部にある保護接地線が遮断 されると、機器が危険な状態に陥る可能性があります。故意に保護接地線を 遮断することを禁止します。また、入力信号が33V RMS、ピーク時に46.7V RMS、または70V DCを超える場合は、信号接地線を接続してください（IEC 61010-1:2010） 。 カバーは取り外さないでください。 電源ヒューズが故障により飛んだ場合、機器のAC電源スイッチが損傷するお それがあるため、然るべき認定を受けた適任者による点検を受けてください。 本機器をAC電源から遮断するには、IECコネクターを抜きます。本機器のAC 電源スイッチは、機能上の目的のためだけに提供しています。したがって、 機器の主電源遮断用として意図されていないか、適応していません。 EN 50110-1とEN 50110-2の適用範囲に該当する測定を行う際、使用電圧が50 V AC RMSまたは120 V DCを超えるすべての基板の接続作業は、適正な資格 を持つ技術者が、または電気工学の訓練を受けた者が適正な資格を持つ技術 者の監督の下、行わなければなりませんのでご注意ください。 （適正な資格を 有する技術者とは、専門技術者に向けた訓練を受け、知識と経験を有し、該 当する規定についても熟知しているため、委託された作業の内容を評価し、 存在する可能性のあるリスクを特定することができ、雇用主により適正な資 格を有する技術者として任命されている者を指します。 ） I3995-3.1 en HBM: public...
  • Page 50 GEN3t 中文 安全警告 该仪器必须通过电源电缆的保护接地线连接到保护接地（接地） ，如果该仪器已 配备了安全接地端子，则通过该端子接地。断开仪器内外的任何保护接地可能 使设备存在危险。严禁有意断开。此外，若任何输入信号高于 33 V RMS, 46.7 V 峰或 70 V DC，则必须将信号接地 (IEC 61010-1:2010)。 不要取下保护盖。 如果电源保险丝因故障而熔断，则有可能损坏仪器的交流电源开关并应由具备 资格的工程师检查。 拔下仪器上的 IEC 接头即可断开交流电源。仪器上的交流电源开关仅用于功能 性目的。而不是用于或适用于断开设备。 对于 EN 50110-1 和 EN 50110-2 中的测量，请注意：所有工作电压高于 50 V AC RMS 或 120 V DC 的板卡只能由合格的技术人员或在由受过电气工程培训...
  • Page 51 GEN3t РУССКИЙ ПРЕДУПРЕЖДЕНИЕ Для эксплуатации данного прибора необходимо использовать защитное заземление, подключенное через проводник заземления кабеля питания или через терминал защитного заземления, если прибор оснащен таковым. В случае прерывания защитного заземления (внутри или снаружи прибора) прибор может стать травмоопасным. Преднамеренное...
  • Page 52 GEN3t 안전 경고 안전 경고 본 장비는 반드시 보안용 접지(접지)가 전원 공급 장치 케이블의 보안용 접지 도 체를 통해 연결된 상태에서 작동해야 하며, 접지가 장착된 경우에는 보안용 접지 터미널을 통해 작동해야 합니다. 장비 내부 혹은 외부적으로 접지 방해 요인이 있는 경우 사용자에게 위험할 수 있습니다. 고의적인 방해는 금지됩니다. 또한, 입력...

  • Page 53: Operation Of Electrical Installations

    GEN3t 2.10 Operation of electrical installations Working on, with, or near electrical installations implies certain dangers. These electrical installations are designed for the generation, transmission, conversion, distribution and use of electrical power. Some of these electrical installations are permanent and fixed, such as a distribution installation in a...

  • Page 54: Normative Documents And Declarations

    Even a small amount of ESD can harm circuitry, so when working with electronic devices, take measures to help protect the electronic devices, including the GEN3t Portable data recorder, from ESD harm. Although HBM has built protections against ESD into its products, ESD exists and, unless neutralized, could build up to levels that could harm the equipment.

  • Page 55: Electro-Magnetic Compatibility (Emc)

    GEN3t Grounding oneself by touching a metal surface that is at earth ground. For example, if the computer has a metal case and is plugged into a standard three-prong grounded outlet, touching the case should discharge the ESD on the body.
  • Page 56 GEN3t Immunity test: All immunity tests are done with the failure criterion being a change of the instrument's control settings. Any of these tests may produce a spurious trigger. Measurements are not valid during and immediately after the immunity tests.

  • Page 57: Environment

    GEN3t Environment WEEE - Waste Electrical and Electronic Equipment 3.2.1 Since February 2003, European Union legislation stating that EU members now restrict the use of hazardous substances in electrical and electric equipment (Directive 2002/95/EC) and promotes the collection and recycling of such electrical equipment (Directive 2002/96/EC) has been in force.

  • Page 58: Ce Declaration Of Conformity

    GEN3t CE Declaration of conformity For information about the CE Declaration of conformity, please refer to www.hbm.com/highspeed. I3995-3.1 en HBM: public...

  • Page 59: Fcc Class A Notice

    GEN3t FCC Class A Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 60: Batteries

    4 Batteries General The GEN3t has internal batteries. They are used by the system to keep the time and date, even when the system is powered down. When the system starts to loose track of the time and date, these batteries need to be replaced.

  • Page 61: Removal And Replacement

    WARNING ELECTRICAL SHOCK HAZARD! Remove all cables before proceeding. There are two CR2032 batteries located inside in a GEN3t, one in the backplane (see Figure 4.1) and one in the Battery CPU section (see Figure 4.2). To access the batteries for removal or replacement, the acquisition cards need to be removed from the GEN3t.

  • Page 62: Remove/Replace The Battery From The Backplane

    GEN3t Figure 4.2: Battery PC section A Battery in the PC section 4.2.1 Remove/replace the battery from the backplane Power off the GEN3t system and remove the power input cable. Figure 4.3: Battery - Backplane section I3995-3.1 en HBM: public...
  • Page 63 GEN3t Disconnect all cables to the acquisition cards. Remove acquisition cards/blind panels from the GEN3t. To remove the battery, simply pull it out with two fingers. Figure 4.4: Remove battery from the backplane To place the battery on the backplane, place it on the battery holder.

  • Page 64: Remove/Replace The Battery From The Pc Section

    Figure 4.6: Battery almost in its final position (backplane) 4.2.2 Remove/replace the battery from the PC section Power off the GEN3t system and remove the power input cable. Figure 4.7: Battery - PC section Disconnect all cables to the acquisition cards.
  • Page 65 GEN3t To remove the battery, push the metal lid to the left and pull the battery out of the holder. Figure 4.8: Remove battery (PC section) Metal lid To place the battery in the CPU section, place it on the battery holder.
  • Page 66 GEN3t Push the battery until the lid clicks back into position. Figure 4.10: Battery in final position (PC section) Install all removed input cards in the exact same sequence as you removed them to avoid changes in calibration results. I3995-3.1 en HBM: public...

  • Page 67: Recharging

    GEN3t Recharging The GEN3t does not use rechargeable batteries. When batteries are depleted, dispose of the batteries. I3995-3.1 en HBM: public...

  • Page 68: Disposal

    GEN3t Disposal Dispose of used batteries only in accordance with local chemical waste regulations. Always recycle. WARNING Do not dispose of batteries in a fire. For more information about waste disposal, please contact the local authorities or the dealer from whom the product was purchased.

  • Page 69: Mains Power

    The GEN3t uses up to 250 VA and operates from line voltages between 100 V AC and 240 V AC at 47-63 Hz. The power connection of the GEN3t is a standard IEC 320 EN 60320 C14, 2-pole, 3-wire (male) appliance inlet, designed for 250 V at 10 A.

  • Page 70: Connecting Power

    GEN3t from the AC supply completely, unplug the IEC connector from the instrument. Plugging in the unit will not switch on the GEN3t instrument. Use the standby button on the front panel for this purpose; see "GEN3t control" on page 114.
  • Page 71 GEN3t MAINS INPUT FUSES: 3.15AT 100-240V AC Figure 5.2: Power inlet A Protective ground B Fuses, 2 times of 3.15 A each C Power Inlet D Voltage rating I3995-3.1 en HBM: public...

  • Page 72: Fuse Requirements And Protection

    GEN3t Fuse requirements and protection GEN3t is equipped with replaceable fuses. The fuse positioning stated in this manual and on the GEN3t must be followed. Additionally for the UK, a fuse should be fitted in the line supply plug. WARNING Any interruption of the protective conductor inside or outside the apparatus is likely to make the apparatus dangerous.

  • Page 73: Fuse Replacement

    GEN3t Fuse replacement To gain access to the fuses, proceed as follows: Power off the system and remove the power cord. This will enable access to the groove on the fuse holder. Using a pocket screwdriver, insert the screwdriver in the slot under the fuse door and gently lift the door.
  • Page 74 WARNING Replace both fuses with new ones that have the correct type and rating, as indicated on GEN3t and in this manual, at the same time. The fuse holder is equipped with two identical fuses. To replace the fuses, proceed as follows: Remove the fuses from their fixture and insert new fuses of 3.15 A (slow)

  • Page 75: Introduction

    Welcome! You have made the right choice; your GEN3t Portable Data Recorder is one of the most sophisticated and powerful systems on the marketplace and demonstrates the high quality HBM has to offer. GEN3t is an all-in-one, field- ready, feature-packed unit.

  • Page 76: Mainframe Overview

    GEN3t Mainframe overview There are several different GEN series mainframes available: Model Slots Design Comments GEN3i Portable An integrated all-in-one portable data recording solution suitable for field use. Best suited for lower channel count or medium computing power applications. GEN3t...

  • Page 77: Mainframe Feature Comparison

    - GEN7T - 2, 1 - GEN16T - 2 - GEN7T - 2 and Exceptions 1 - GEN16T - 2 with IM2 1-GEN3I-2 and 1-GEN7I-2 1-GEN3t-2, 1-GEN7tA-2 and 1-GEN17tA-2 Note Grey columns are end of life systems. - GEN2I - 2, 1 - GEN5I - 2,...
  • Page 78 - GEN7T - 2 and 1 - GEN16T - 2 - GEN7T - 2 and Exceptions 1 - GEN16T - 2 with IM2 1-GEN3I-2, 1-GEN7I-2, 1-GEN3t-2, 1-GEN7tA-2 and 1-GEN17tA-2 Note Grey columns are end of life systems. I3995-3.1 en HBM: public...

  • Page 79: Hardware

    200 MB/s. Check the detailed specifications of the individual acquisition cards to see whether it uses the fast data storage bus of the GEN3t if aggregate streaming rates above 200 MB/s are required.

  • Page 80: Input Cards

    The single synchronization connector allows for the direct connection of one Slave to the GEN3t or the GEN3t to be a Slave within any Master/Slave multi mainframe setup. 6.3.4 Thermal protection Every GEN series mainframe supports a feature called Thermal Shutdown.
  • Page 81 GEN3t Automatic user warnings are initiated using the following diagram (see Figure 6.3). Thermal shutdown User warning 80°C 80°C 75 °C Reset 75 °C stops User warning User warning User warning user warning User warning repeats every repeats every minute minute Figure 6.3: Thermal protection - Automatic user warnings...

  • Page 82: Acquisition

    GEN3t Acquisition GEN3t is a multi-channel Portable data recorder. It provides real-time data for waveform and meter displays. It allows unlimited recording duration and file size at a high streaming rate. Statistics are performed in real-time. Its extreme performance signal conditioning includes both Bessel and Butterworth anti- alias filters to provide excellent response.
  • Page 83 Unlike competitive systems, the GEN3t has no need to inspect gigabytes of information just to display the last kilobyte. While zooming in, more detail is displayed while always maintaining the highest visible resolution.

  • Page 84: Signal Conditioning

    GEN3t Signal conditioning GEN3t supports common analog sensors with the highest performance signal conditioning available. All inputs are sampled simultaneously for exact time correlation, and the front ends deliver a typical maximum static error of 0.1%. Plug-and-play hardware discovery with scalability to any number of channels.

  • Page 85: Data Storage

    GEN3t Data storage In addition to mega samples of on-board RAM, record data directly to the GEN3t hard drive, or to a network attached storage over the Gigabit Ethernet. GEN3t always stores to on-board high-speed RAM. Recorded data is then automatically stored at the GEN3t defined storage location at maximum speed.

  • Page 86: Interface/Controller Section

    GEN3t Interface/Controller section GEN3t has a built-in industrial PC. This PC channels the tethered communication with the remote PC. Features include: ® Intel Core™ i5 processor (3 generation) Ivy Bridge M chipset (x77) Linux (3.x or newer) operating system 8 GB DDR3 RAM...

  • Page 87: Setting Up The Gen3T

    GEN3t 7 Setting up the GEN3t GEN3t connections GEN3t has several connections with different functions. POWER Figure 7.1: GEN3t connections PTP enabled network optical SFP slot (SFP module is optional) See chapter "Connecting the GEN series to a network" on page 88 for more details.

  • Page 88: Connecting The Gen Series To A Network

    POWER Figure 7.2: Interface/Controller connections The Interface/Controller has connections that can be used to connect other devices to the GEN3t system. PTP enabled network optical SFP slot (SFP module is optional) PTP enabled network RJ45 The GEN series can be connected in one of two ways:...

  • Page 89: Default Network Settings

    IP addresses in the range of 169.254.xxx.xxx with a subnet mask of 255.255.0.0. This is called "Automatic Private IP Addressing" and is ® also built into Microsoft Windows The default Mainframe password is "genesis" (lowercase, without the double quotation marks). 7.2.2 Connecting the GEN series directly to a PC The GEN series can be connected directly to the a PC.

  • Page 90: Connecting The Gen Series To A Company Network

    GEN3t 7.2.3 Connecting the GEN series to a company network To avoid using a PC with two Ethernet cards, the GEN series can be connected to an Ethernet port on the local network. HBM recommends adding a 1 Gigabit autosensing Ethernet switch for this purpose. Low-cost compact switches that have four to eight ports and that are sufficient for connecting a number of instruments to a PC are readily available at any computer store.
  • Page 91 GEN3t 192.168.178.111 Along with, the IP address, the computer uses a network mask. The network mask is used to identify the size of the local address range. To address a computer outside this address range, a network router is required to transfer the network messages to another address circle.

  • Page 92: Network Testing And Troubleshooting

    GEN3t WARNING When Use DHCP is set to False and when multiple mainframes are used, a different IP address must be set for each mainframe. 7.2.5 Network testing and troubleshooting If the GEN series is connected to the Ethernet correctly, the LINK LED on the front panel will illuminate within a few seconds to indicate that a hardware interface has been detected.

  • Page 93: Restore Default Network Settings

    GEN3t Restore default network settings To restore a mainframe to its default network settings, take the following steps: Turn the mainframe off and wait for five seconds. Turn the mainframe on. Wait for the three-tone sound indicating the system has started.

  • Page 94: Removing And Installing Input Cards

    (ESD). ESD damage is quite easy to induce, often hard to detect and always costly. Therefore, we must emphasize the importance of ESD preventions when handling a GEN3t system, its connections or a plug-in card. CAUTION The GEN3t Portable data recorder is factory-calibrated as delivered to the customer.

  • Page 95: Installing Cards

    7.4.2 Installing cards To install a card: Power off the GEN3t system and remove the power input cable. Ensure that the ejector levers are in the farthest outermost position, tilting away from the card. Slide the card into its guide rails until the ejectors contact the perforated metal strips on the left and right.
  • Page 96 GEN3t Tighten Screws Figure 7.7: Card ejectors with screws WARNING Screws must be locked to meet CE emissions. Figure 7.8: Blind panel (1-G009-2) WARNING Any empty slots must be covered with a blind panel with a thermal strip on the back to meet the cooling requirements of the mainframe.

  • Page 97: Handle

    GEN3t Handle The handle handles are used to carry the GEN3t system. Only carry the instrument when the handle is in the upright position. Figure 7.9: GEN3t with handle in the upright position I3995-3.1 en HBM: public...

  • Page 98: Turning The Handle

    GEN3t 7.5.1 Turning the handle You can turn the handle to act as built-in stand: 1 Put instrument on a flat surface. 2 Push in the button on both sides of the handle. Figure 7.10: Button on the handle I3995-3.1 en HBM: public...
  • Page 99 The handle will snap into one of its fixed positions (30° indexing). Figure 7.11: GEN3t multiple handle positions 3 Gently turn over the GEN3t unit so that it rests on the handle's flat surface. I3995-3.1 en HBM: public...
  • Page 100 GEN3t 4 The GEN3t unit is now supported by its handle. Figure 7.12: GEN3t supported by its handle When the handle is turned to back of the unit, it can be used to lift the front of the instrument so that it is angled more towards the user. In Figure 7.12, the angle between the display and horizontal axis is about...

  • Page 101: Feet

    GEN3t Feet GEN3t stands on four rubber feet in normal operation position. Two feet are positioned at the rear and two are at the front of the instrument. Two extra, foldable front feet can be used to lift the instrument front so the side panel angle is towards the user.

  • Page 102: Probe Calibration

    GEN3t Probe calibration The GEN3t mainframe is provided with a probe calibration output. This output can be used to calibrate probes used in combination with the Genesis High- speed measurement system. The probe calibration output drives a calibration signal with the following...
  • Page 103 GEN3t Set the trimmer of the probe so that the signal in Perception resembles the input signal. Figure 7.15 below shows how the signal should look. When the trimmer is positioned incorrectly, undershoot or overshoot is seen in the signal.

  • Page 104: Dc Power Output

    GEN3t DC power output POWER Figure 7.16: DC power output DC power output The system has a DC power output connector to power additional systems requiring a DC input power. The connection is set up to connect a QuantumX system to the GEN series mainframe directly.
  • Page 105 PIN 2 - Reserved/not connected PIN 3 - GND PIN 4 - Reserved/not connected PIN 5 - Reserved/not connected PIN 6 - Reserved/not connected PIN 7 - PWR PIN 8 - Reserved/not connected Figure 7.17: GEN3t DC power output I3995-3.1 en HBM: public...

  • Page 106: Digital Event/Timer/Counter

    Not all GEN series acquisition cards have support for the Digital Event/ Timer/Counter connector. Only the acquisition cards that have support listed in their specification sheet will be able to use this connector. (See appendix "B3772-3.1 en (GEN3t Portable Data Recorder)" on page 405 for more details). I3995-3.1 en HBM: public...
  • Page 107 GEN3t Digital Event/Timer/Counter Analog Analog Acquisition Acquisition card card Digital Digital Digital Event/ Timer/Counter Connector Backplane Figure 7.19: Digital Event/Timer/Counter block diagram Supported cards See specifications of acquisition cards Number of connectors Connector type 44 pin, female D-type connector, AMP HD-22...
  • Page 108 GEN3t Digital Event/Timer/Counter Event Inputs Number of event inputs 16 per card, 2 cards per connector Levels TTL Compatible, Low -30 V to 0.7 V, High 2 V to 30 V “1” “0” +0.7 +2 Input voltage Figure 7.20: Logic threshold voltage levels Overvoltage protection ±...
  • Page 109 GEN3t Digital Event/Timer/Counter Connector Pin Assignment PIN 1 - Event Input 1A & Reset Timer/Counter 2A PIN 23 - Event Input 11B & Direction Timer/Counter 1B PIN 2 - Event Input 2A & Direction Timer/Counter 2A PIN 24 - Event Input 12B & Clock Timer/Counter 1B PIN 3 - Event Input 3A &...

  • Page 110: Isolated Event Adapter

    GEN3t 7.9.1 Isolated event adapter 32 X Isolated Input FODM8071 To marker card 50Ω (cable not included) – 562Ω To marker card 32 X (cable not included) To mainframe shield (optional) 4 X Isolated ouput (only from mainframe digital IO) VOS617A 430Ω...

  • Page 111: Torque/Rpm Adapter

    GEN3t 7.9.2 Torque/RPM adapter Input Signal T Output RS422 RS422 Electric Level Conversion and Buffering RS422 RS422 Figure 7.23: Block diagram and image HBM's Torque and RPM sensors come standard with RS422 digital output signals. As the GEN series Digital Event/Timer/Counter inputs are TTL inputs, signal need to be converted to make both side able to work together.
  • Page 112 GEN3t Ext. Torque power in Torque/Speed A DC Power IN 18 to 30 V, 1A maximum Supply voltage ground Shunt To contr KAB149 system Torque Torque Reference Reference To contro RPM 0 RPM 0 KAB163 system RPM 90 RPM 90...
  • Page 113 GEN3t The adapter also supports a so called T-function. If the need exists to connect the output of the Torque/RPM sensor both to a GEN series mainframe and any other receiving system, the T-function output renews the original signal with an RS422 transmit buffer.

  • Page 114: Getting Started

    The GEN3t can only be controlled by Perception V6.60 or higher. Standby On GEN3t, the standby button is located on the top panel. When this button is pressed, the instrument state toggles between operating and standby mode. In standby mode, some power is consumed and the instrument is NOT disconnected from the AC supply.
  • Page 115 GEN3t When you use this standby button to power off GEN3t, the software power off the system. If the system does not respond, press the standby button for at least four seconds until the unit is forced to power off.

  • Page 116: Connecting Gen3T To Perception

    GEN3t Connecting GEN3t to Perception To control, set up and use GEN3t, Perception software needs to be connected to the GEN3t. Connect the GEN series system to the Perception PC and start Perception. Note Perception can be adapted to meet personal wishes. The Getting started sequence is described using the default installed selections.
  • Page 117 GEN3t Perception will continue to start. To continue, Perception will ask which job it should perform (see Figure 8.3): Figure 8.3: Perception job dialog Set up an auto-configured Experiment In the dialog select: Set up an auto-configured Experiment Let Perception search for connected acquisition hardware and create a default layout.
  • Page 118 GEN3t Figure 8.4: Mainframe selection From the list of available mainframes, select the mainframe(s) required for the experiment. Click OK to continue. When using the mainframe for the first time, the IP address should have been dynamically assigned. This ensures that the IP address matches the PC if the PC network settings are also configured dynamically.
  • Page 119 GEN3t Figure 8.5: Perception Connect dialog Description of the connection and/or configuration problem encountered by Perception. Mainframe name The name of the mainframe on which the problem was encountered. DHCP To configure for dynamic addressing (recommended default), click for the mainframe to obtain an IP address automatically, and then click Continue.
  • Page 120 GEN3t If a reboot of the system is required to apply the new network settings, this will be done automatically. The progress window (see Figure 8.6) will close automatically when the mainframe has been rebooted. Figure 8.6: Perception progress indicator for mainframe reboot...

  • Page 121: Acquisition And Storage

    9 Acquisition and Storage Introduction Data acquisition hardware within the GEN3t is based on the concept of a recorder. A recorder consists of a number of acquisition channels that share the same basic recording parameters: sample rate, sweep length and pre- and post-trigger length.

  • Page 122: Recording

    Perception software, it is advised to read this section in combination with the corresponding sections in the Perception manual. The GEN3t/Perception combination provides the following acquisition controls: ● RUN The run command starts recording of data. Now the recorder(s) record(s) data until a stop command is issued.

  • Page 123: Storage

    GEN3t Storage The GEN3t provides two storage paths, as shown in Figure 9.1 on page 121: Store data in on-board RAM at high speed Transfer data directly at reduced speed to the controlling PC or (when installed) to a local disk.

  • Page 124: More On Sweeps

    GEN3t Figure 9.3: Run - Storage: Sweeps only The basic storage modes can be combined to create more advanced storage modes: Dual In this mode, sweeps and continuous data are stored. Therefore, the end result is a recording that comprises the higher speed sweeps as well as the lower speed continuous data between the sweeps.

  • Page 125: Pre-Trigger Sweeps

    GEN3t DATA STORAGE BEGIN BEGIN Figure 9.4: Ring buffer operation of memory The physical memory therefore forms a ring buffer, into which information can be continuously added (see Figure 9.4). This process of filling the ring buffer memory terminates only when the recording logic indicates that the sweep must be ended.
  • Page 126 GEN3t DATA STORAGE BEGIN TRIGGER BEGIN END OF RECORDING Figure 9.5: Ring buffer with trigger and end-of-recording Since the trigger stops the storage, all stored information is termed pre-trigger information. When storage stops because the acquired signal has met a trigger condition, only pre-trigger information is available - information recorded before the signal met the trigger condition.

  • Page 127: More On Continuous Data Storage

    More on continuous data storage The most important difference between continuous data storage and sweeps in a GEN3t is the fact that sweeps are stored in on-board volatile RAM, while continuous storage takes place on the controlling PC's hard disk (or local hard disk when installed).
  • Page 128 GEN3t Circular The continuous mode is circular when storage is started and stopped manually AND the length of the buffer is defined. Operation is similar to standard sweep storage, but storage is on the PC hard disk and not in volatile memory. In this mode, the lead-out is specified which is basically the same as the post-trigger segment in a sweep recording.

  • Page 129: Time Base

    GEN3t Time base The power of modern data acquisition techniques is achieved by digitizing analog information. Digitizing is the conversion of the instantaneous value of an analog signal (static or dynamic) into a numeric value. When the signal varies, sampling the instantaneous amplitude at sufficiently rapid intervals converts this signal into a series of numbers that can represent the original analog signal.

  • Page 130: Time Base Settings For Ffts

    GEN3t 9.4.2 Time base settings for FFTs When doing FFTs, there are two topics that affect the acquisition: It makes life easier when the final FFT yields spectral lines with a distance ∆ f that is a "nice" value. Otherwise stated: the FFT bin size should preferably be a nice value.
  • Page 131 GEN3t In the table below, the values are in the colored cells and basically comprise the range 1.25, 2.5, 5, 10, 20. Table 9.1: Examples of FFT bin sizes TIME BASE FFT SIZE (FRAME LENGTHS) MAIN = 1.024 1024 2048...

  • Page 132: Additional Information

    GEN3t Additional information The Nyquist frequency (f/2) is the maximum frequency that can be accurately measured by a digitizer sampling at a rate of (f). Otherwise stated: a digitizer sampling at a rate of (f) cannot measure an input signal with frequency components exceeding f/2 without experiencing "aliasing"...

  • Page 133: 10 Digital Trigger Modes

    In this chapter, the trigger capabilities of the GEN3t data acquisition system will be explained in full detail. Each channel within a recorder can trigger this recorder. This functionality is realized by combining all channel triggers into a logical OR combination.

  • Page 134: Understanding Digital Triggering

    GEN3t 10.2 Understanding digital triggering Technically speaking, there are two approaches to determine the known, pre- defined situation of the signal: analog or digital. Each channel in the GEN series system is equipped with a digital trigger detector. Digital triggering has the benefit of stable vertical reference levels, no horizontal jitter, and not depending on signal frequency.
  • Page 135 GEN3t As explained later in this chapter, a signal must actually cross the preset level. This is to avoid erroneous triggering due to a small amount of noise on the signal. To make the trigger detector even more stable when noisy signals are used, the single-level trigger detector has been expanded with a hysteresis.

  • Page 136: Valid Trigger Conditions

    GEN3t 10.2.2 Valid trigger conditions Trigger detection is based on level crossing. A signal has to cross a specified level to be considered a trigger condition. As a consequence, reaching the required level is not a valid trigger condition. Since trigger detection is digital, inter-sample analog values are omitted.
  • Page 137 GEN3t Figure 10.3 shows the influence of the additional hysteresis. Fundamentally, everything is the same as described earlier. The only difference now is that a second level (H) is used to “arm” the level trigger detector. Otherwise stated, the trigger level has been expanded to be a trigger zone that spans multiple levels.

  • Page 138: Trigger Modes

    GEN3t 10.3 Trigger modes Using the various trigger modes, GEN3t data acquisition system is expanded to an extremely versatile transient recorder. The trigger circuits may be configured to trigger on many types of phenomena. In this section, the different trigger modes and their extensions are discussed in detail.

  • Page 139: Dual Trigger Mode

    GEN3t 10.3.2 Dual trigger mode In dual trigger mode two detectors are active and working simultaneously: the primary level P and the secondary level S. With two levels, it is possible to define a range that the input signal must be within. As soon as the signal becomes larger than the upper level or smaller than the lower level, the detector generates a trigger.

  • Page 140: Window Trigger Mode

    The Window trigger mode is very useful if a periodic signal is monitored and GEN3t must be triggered on peak level changes. This mode is most effective on uni-polar signals, e.g. a TTL level pulse train. For bi-polar signals, the dual- window trigger mode is more suited as described in the following section.

  • Page 141: Dual-Window Trigger Mode

    GEN3t 10.3.4 Dual-window trigger mode The dual-window trigger mode is a more sophisticated version of the window trigger mode. Now both levels are used as an arm/trigger/disarm level. This allows the trigger detector to react to a dip in both directions.

  • Page 142: Sequential Trigger Mode

    GEN3t 10.3.5 Sequential trigger mode The two level comparators are set in a sequence in this mode. One is used to arm the trigger detector while the other one is used to actually generate the trigger. If the incoming signal crosses the level of the first comparator, the second is activated (armed).

  • Page 143: Trigger Qualifier

    GEN3t 10.3.6 Trigger qualifier The trigger detectors of a channel can also be used as qualifiers. A trigger qualifier is a situation that enables (arms) the recorder trigger features. The recorder trigger features are a combination of various channel, external, between-recorders and other trigger options.

  • Page 144: Trigger Add-Ons

    GEN3t 10.4 Trigger add-ons The trigger modes mentioned can be combined with a variety of extra features, allowing triggers on almost any signal. Some of these extra features are used to fine-tune the selected trigger mode. Other extra features expand the capabilities of the basic trigger detector.

  • Page 145: Pulse Detector

    GEN3t Figure 10.10: Slope trigger Trigger Original signal Differentiated signal With the slope triggering, it is possible to trigger on a specific change in slope of the signal, for example on a spike on a repetitive signal. If the slope (or frequency) of the signal exceeds the specified level, a trigger is generated.

  • Page 146: Hold Off

    GEN3t The pulse detector operates on samples. In the Perception software, this is translated into time. Figure 10.11: Pulse detect/reject methods Trigger Width Figure 10.11: In Diagrams 1 and 2, the pulse detection is depicted. In Diagram 1, when the trigger level is crossed, the signal remains above the trigger level for a time interval larger than pulse width W.

  • Page 147: Interval Timer

    GEN3t Figure 10.12: Trigger hold off Trigger Hold off The feature is most useful in combination with the interval timer and/or the event counter. 10.4.4 Interval timer A highly sophisticated trigger add-on is the interval timer. The interval timer is used to define a time relation between two trigger events.

  • Page 148: Interval Timer - More

    GEN3t Figure 10.13: Interval timer - Less Trigger Interval The time interval is reset on the first new trigger event. For example, this feature allows additional pulses to be detected in a standard train of pulses. Interval timer - More This interval timer mode is more complicated.

  • Page 149: Interval Timer - Between

    GEN3t For example, this function allows a "missing " pulse to be detected in a standard pulse train. Interval timer - Between For the Between mode, basically two timers are used: one to set the start of a time window and a second one to set the width of the time window. The second trigger event must be within this time window.

  • Page 150: Interval Timer - Notbetween

    GEN3t The first interval timer can be compared to the trigger hold off feature described above. The second interval timer defines a period in which a trigger event must occur. If not, it is not a related trigger event. Interval timer - NotBetween The inverse function of the Between mode of the interval timer is the NotBetween mode.

  • Page 151: Event Counter

    GEN3t 10.4.5 Event counter Sometimes it is not possible to trigger on a specified condition using a selected trigger mode alone, because several events meet the required situation. So far, we have seen “filters” that can be used to narrow the range of trigger candidates, like hold off and interval timer.

  • Page 152: Recorder And System Trigger

    GEN3t 10.5 Recorder and system trigger The trigger modes and features described so far are channel-based. Each analog channel within a GEN series system has a digital trigger detector. The trigger signals of all channels of a single recorder are combined through a logical OR to generate a combined trigger.
  • Page 153 GEN3t ● External Trigger Out: The recorder trigger can be used to send a trigger signal to the outside world. The output connector is placed on the mainframe controller. Used to select active High or Low level output, all input cards in the mainframe use the same output level. Each input card can select whether to send the trigger to the external trigger output.

  • Page 154: Channel Alarm

    GEN3t 10.6 Channel alarm Each channel has the capability to generate an alarm. An alarm situation is detected with a basic dual level detector. There are two alarm modes: Basic single-level alarm. The alarm line is active for as long as the signal exceeds the level in the specified direction.

  • Page 155: 11 Interface/Controller

    GEN3t 11 Interface/Controller 11.1 Introduction The Interface/Controller uses a high-end CPU with an embedded operating system. It is used to communicate with controlling computers and supports extras storage options. Each complete mainframe houses an Interface/Controller, which enables data input and output so that the mainframes can be connected.

  • Page 156: Communication And Control

    GEN3t 11.2 Communication and control The GEN series uses standard TCP/IP protocol over Ethernet to communicate with the PC. The Interface/Controller provides access to the Ethernet network. POWER OUT 11V 1.4A max Figure 11.2: Ethernet LED indicators A Link speed LED optical network...

  • Page 157: Network Protocols And Ports

    GEN3t 11.2.1 Network protocols and ports All tethered GEN DAQ series mainframes use Ethernet protocols to communicate with the controlling PC. The following table gives an overview of the used protocols, ports, packet sizes and frequency of use on the network.

  • Page 158: Using The 1 Gbit Option Connections

    GEN3t Network protocols and ports DHCP, AutoIP When enabled on this mainframe iSCSI Default port: 3260 V2, End-to-End, 1 sync per second 11.2.2 Using the 1 Gbit option connections LC Connection Using the SFP + Option LC optical connections that...

  • Page 159: Master/Slave Synchronization

    (user software action to trigger all mainframes synchronously). Calculated channel trigger exchange (requires Perception V6.50 or higher). For detailed specification, please refer to appendix "B3772-3.1 en (GEN3t Portable Data Recorder)" on page 405. The GEN series can be operated as a fully synchronized Multi-Mainframe system with multiple mainframes using the Master/Slave synchronization connector.
  • Page 160 GEN3t The Master/Slave synchronization connector supports (please refer to chapter "Connecting the Master/Slave Synchronization connector" on page 163 and "Connecting multiple mainframes using the Master/Slave card" on page 163 for wiring details): Directly connect to one mainframe using the Master/Slave synchronization connector.
  • Page 161 GEN3t Master/Slave Synchronization connector operating modes The Master/Slave Synchronization connector has three operating modes: Master Slave Stand-alone In stand-alone mode, the Master/Slave synchronization connector is not used. Cables can be left attached, as no information is exchanged. Fiber optic cable The Master/Slave Synchronization has an optical I/O (IN/OUT) using duplex LC connectors that connects to other Master/Slave connectors.
  • Page 162 GEN3t The following table shows the function and possible combinations of the two LEDs. Table 11.2: Master/Slave card front panel LED indicators FRONT PANEL LED INDICATORS Status Description No valid characters detected/ No Link no optical signal detected Optical signal detection/...

  • Page 163: Connecting The Master/Slave Synchronization Connector

    GEN3t 11.3.1 Connecting the Master/Slave Synchronization connector With the fiber optic cable, connect the Master/Slave Synchronization connector of two mainframes. In this setup, one mainframe must be set to Master while the other mainframe must then be set to Slave. In this setup, automatically extended synchronization is used.
  • Page 164 GEN3t Maximum Master/Slave overview Option Carrier Master Output Slave Mainframes Card Card GEN3i GEN3t GEN7i GEN7tA GEN17tA GEN7i PTP1 PTP2 POWER OUT 24V 1.5A max GEN3t GEN3i GEN17tA DIGITAL EVENT/TIMER/COUNTER (AB) PTP1 GEN7tA (CD) PTP2 (EF) PTP1 PTP2 1 MW 250Vpk...
  • Page 165 GEN3t Connect one of the connectors of the Master Output Card(s) (G083) to the Master/Slave synchronization connector of the third Slave mainframe. Connect one of the connectors of the Master Output Card(s) (G083) to the Master/Slave synchronization connector of the fourth Slave mainframe.

  • Page 166: Setting The Master/Slave Operating Modes

    GEN3t 11.3.3 Setting the Master/Slave operating modes Each mainframe can be used as a Master or Slave by using the standard available Master/Slave synchronization connector. The operating modes are set up using the Perception software. In the Perception work area: Figure 11.7: Perception work area with Master/Slave...
  • Page 167 GEN3t Select the mainframe(s) that should be used as Stand-alone. Double-click on the Master/Slave mode cell to open it for modification. In the drop-down list that appears, select Stand-alone. HINT/TIP Cables do not have to be removed, as the mainframe does not use the connected cable during stand-alone mode.

  • Page 168: Setting The Master/Slave Trigger

    GEN3t 11.3.4 Setting the Master/Slave trigger When the Master/Slave card is in use, a recorder can either put the recorder trigger on the Master/Slave trigger line and/or pick up the trigger from the Master/Slave trigger line. There are four settings that can be selected in the Perception software: Disabled No trigger is transmitted to or received from other mainframes.
  • Page 169 GEN3t Figure 11.9: Perception work area with Master/Slave trigger Settings tab Trigger group Master/Slave trigger column To set the Master/Slave trigger in the Perception software, proceed as follows: Select the Settings sheet. If it is not already done, switch the Settings sheet layout modes to Advanced mode.
  • Page 170 GEN3t In the drop-down list that appears, select the setting that should be used. Figure 11.10: Master/Slave trigger list I3995-3.1 en HBM: public...

  • Page 171: Synchronizing A Master/Slave Setup To External Time Sources

    GEN3t 11.3.5 Synchronizing a Master/Slave setup to external time sources In a Master/Slave setup, all time information is recorded by the Master mainframe only. Synchronization source selection on Slaves is disabled as Slave mainframes are dedicated to follow the Master mainframe.

  • Page 172: I/O Connector

    GEN3t 11.4 I/O connector POWER OUT 11V 1.4A max Figure 11.12: Interface/Controller I/O connector (trigger in/out, clock in, event out, start/stop) The I/O connector comes with a BNC breakout cable for direct BNC cable connection to each function (see Figure 11.13).

  • Page 173: I/O Connector Input Overvoltage Protection

    GEN3t 11.4.1 I/O connector input overvoltage protection All inputs of the I/O connector are over voltage protected. All inputs use the following schematic approach. 20 kOhm From input connector To system timbase, trigger and recording control 2 kOhm Figure 11.14: I/O connector schematic inputs Due to the 20 kΩ...

  • Page 174: I/O Connector Functions And Connector Pinning

    GEN3t 11.4.2 I/O connector functions and connector pinning External Time base In PIN 1 - External Time base In This input can be used to provide another time base for the ADC rather than the internal one. This input is typically used in combination with rotating machinery in which the ADC clock is synchronized with the revolutions.
  • Page 175 GEN3t C/D External Trigger In/Out PIN 3 - External Trigger In PIN 7 - External Trigger Out This input and output are related to the recorder trigger logic. For more information, please refer to “Recorder and system trigger” on page 152.
  • Page 176 GEN3t To enable the advanced settings, right click on the table header (see Figure 11.16). Figure 11.16: Show Settings - Advanced Advanced (All Settings) The External startmode setting can be used to configure the external start input. When selecting Disabled, the signal on the input is ignored.
  • Page 177 GEN3t The External stopmode setting can be used to configure the external stop input. When selecting Disabled, the signal on the input is ignored. When selecting Rising Edge, a stop is initiated when a rising edge is detected. When selecting Falling Edge, a stop is initiated when a falling edge is detected.

  • Page 178: Network Attached Storage (Nas) Using Iscsi

    GEN3t 11.5 Network Attached Storage (NAS) using iSCSI What is iSCSI? iSCSI: Internet SCSI (Small Computer System Interface). SCSI is an older standard used by storage devices to communicate with PCs to exchange the data. iSCSI is a TCP/IP Ethernet-based communication protocol.

  • Page 179: Tcp/Ip Connection To A Nas

    GEN3t By instructing the GEN DAQ system to store its recorded data on an externally attached NAS which supports the iSCSI protocols instead on the PC, the GEN DAQ system will transfer all recorded data (without the support of the PC) directly to the NAS.

  • Page 180: Gen Data Acquisition System

    GEN3t Figure 11.18: External Storage Setup dialog GEN Data acquisition system iSCSI Host iSCSI Target This setup dialog shows the connected mainframes and their available external storage sources. If supported, these storage sources will appear here. Click on the iSCSI label to select one.

  • Page 181: Iscsi Host

    GEN3t 11.5.5 (See Figure 11.18 - B) iSCSI Host These settings are input manually and are used to locate the NAS on the network. There are two ways to find the NAS server, both of which are listed below. Select either DNS name or IP address.

  • Page 182: Target Name (Iqn)

    GEN3t Simplified, the NAS server looks like this: Network Attached Storage server (NAS) HTTP iSCSI LUN 1 Protocol iSCSI Port Target Selector Selector Protocol NETWORK Ethernet TCP/IP 3260 iSCSI ADDRESSING CHAP Protocol Logon iSCSI LUN 2 Protocol TCP/IPAddress & Netmask iSCSI LUN 3 Figure 11.19: NAS server - Overview...
  • Page 183 GEN3t Password: This is the same password that was defined during the NAS setup process. For reference, please refer to Figure I.11 "Create a new iSCSI Target dialog" on page 940. Refresh/Format the iSCSI Figure 11.20: External Storage Setup - Refresh/Format option...

  • Page 184: How To Format The Iscsi

    GEN3t 11.5.9 (See Figure 11.20 - C) How to format the iSCSI To format the iSCSI for the first time, click Format. Figure 11.21: iSCSI format option - Warning dialog A warning dialog (Figure 11.21) asking whether the iSCSI should be formatted appears.

  • Page 185: Set Up An Iscsi Nas Connected Through An Ethernet Switch

    GEN3t Status Meaning Check solution Host unreachable Cannot communicate GEN DAQ interface cable with iSCSI not connected NAS is turned off Wrong or missing default gateway DNS name did not resolve and fixed IP address is incorrect Cables connected incorrectly...
  • Page 186 GEN3t GigaBit Ethernet Switch RJ45/Standard Ethernet connections Figure 11.22: GEN DAQ with iSCSI NAS connected through an Ethernet switch Connect the equipment Connect the PC to the Ethernet switch via a standard RJ45 Ethernet connection. Connect the GEN DAQ to the Ethernet switch via a standard RJ45 Ethernet connection.
  • Page 187 GEN3t The External Storage Setup dialog: The information in this dialog must match the information defined in the configuration of the connected NAS. Refer to the appendix “Setting up the ® iSCSI using Synology NAS” on page 934 when necessary for an example ®...
  • Page 188 GEN3t (See Figure 11.23 - B) iSCSI Host DNS name/IP address: A DNS setting is not used in this setup. When DNS is not available, the IP address must be filled in. Therefore, select the IP address option and use the same IP address that was defined in the setup process of the NAS.

  • Page 189: Set Up An Iscsi Nas Connected Without An Ethernet Switch

    GEN3t Figure 11.25: Storage location with options 11.5.12 Set up an iSCSI NAS connected without an Ethernet switch This is a basic setup of a GEN DAQ system with a NAS connected directly to the GEN DAQ system. An Ethernet switch is not required. In this setup, only the GEN DAQ system can communicate with the iSCSI NAS.
  • Page 190 GEN3t Connect equipment (See Figure 11.26) Connect the PC to the optical Ethernet connector of the GEN DAQ system via an optical Ethernet connection. Connect the NAS to the GEN DAQ system via the standard RJ45 connection or, if the option is installed, use a second optical Ethernet connection.
  • Page 191 GEN3t The External Storage Setup dialog: The information in this dialog must match the information defined in the configuration of the connected NAS. Refer to the appendix “Setting up the ® iSCSI using Synology NAS” on page 934 when necessary for an example ®...
  • Page 192 GEN3t If the NAS server is connected to the optical network connector of the GEN series mainframe, then select the optical 1 Gbit Ethernet. Figure 11.29: Network interface connections/Optical 1 Gbit option (See Figure 11.23 - B) iSCSI Host DNS name/IP address A DNS setting is not used in this setup.

  • Page 193: Set Up An Iscsi Nas Connected To A Corporate Network - Basic Setup

    GEN3t Password: Enter the details that were defined during the setup process of the CHAP authentication on the NAS. If none was chosen, leave this field blank. Click Apply when done to set the new settings and then click Close.
  • Page 194 GEN3t Company Network GigaBit Ethernet Switch 3x RJ45/Standard Ethernet connections (or Optical Ethernet connection) Figure 11.31: GEN DAQ with iSCSI NAS connected through an Ethernet switch and connected to a corporate network Connect PC, NAS and GEN DAQ: The Ethernet switch should be connected to the company network.
  • Page 195 GEN3t Setup in Perception: Start Perception, navigate to the Settings menu and select External Storage Setup. The External Storage Setup dialog: The information in this dialog must match the information defined in the ® configuration of the connected NAS. For an example using Synology ®...
  • Page 196 GEN3t GEN Data acquisition system - Network (See Figure 11.32 - A) interface: Select the Standard 1 Gbit Ethernet port that is connected to the Ethernet switch. Figure 11.33: Network interface connections/Standard 1 Gbit option (See Figure 11.32 - B)

  • Page 197: Set Up An Iscsi Nas Connected To A Corporate Network - Advanced Setup

    GEN3t User name: Enter the details that were defined during the setup process of the CHAP authentication on the NAS. If none was chosen, leave this field blank. Password: Enter the details that were defined during the setup process of the CHAP authentication on the NAS.
  • Page 198 GEN3t Company Network GigaBit Ethernet Switch with optical SFP support 1 Gbit Ethernet Connection 1 Gbit optical Ethernet Connection 1 Gbit Ethernet Connection 1 Gbit Ethernet Connection Figure 11.35: GEN DAQ with iSCSI NAS connected through an Ethernet switch and connected to a corporate network (advanced setup) Connect PC, NAS and GEN DAQ (See Figure 11.35)
  • Page 199 GEN3t Setup in Perception: (See Figure 11.36) Start Perception, navigate to the Settings menu and select External Storage Setup. The External Storage Setup dialog: The information in this dialog must match the information defined in the configuration of the connected NAS. Refer to appendix “Setting up the ®...
  • Page 200 GEN3t GEN DAQ - Network interface: (See Figure 11.36 - A) If you have connected the NAS server to the RJ45 connector of the GEN series mainframe, then select the Standard 1 Gbit Ethernet. Figure 11.37: Network interface connections/Standard 1 Gbit option If you have connected the NAS server to the optical network connector of the GEN series mainframe, then select the Optical 1 Gbit Ethernet.
  • Page 201 GEN3t Use CHAP: Select Use CHAP if CHAP password protection was selected when the ® NAS server was set up. When using a Synology NAS, CHAP password protection can be selected. (For more information, please refer to Figure I.11 "Create a new iSCSI Target dialog" on page 940).

  • Page 202: Option - Solid State Drive (Ssd) 1-G073-2

    Option - Solid State Drive (SSD) 1-G073-2 11.6 GEN3t has a non-removable Solid State Drive built-in. This disk is used to store the operating system/system firmware, the permanent configuration data and the user data. Storing user data is a cost option. This local storage option needs to be enabled, either before purchase or in the field.
  • Page 203 When the GEN3t Solid State Drive is enabled, the integrity of the partition is checked on regular basis during the boot sequence. This can result in longer boot times (up to 10 s or more) before GEN3t is ready for use. This is normal behavior.
  • Page 204 GEN3t Connect to the mainframe. In the Hardware tab, select Mainframe View by right-clicking the mainframe name. Select Generate Mainframe ID File. Figure 11.42: Mainframe view with context menu Generate Mainframe ID file The following dialog appears (see Figure 11.43): Figure 11.43: Generate Licence dialog...
  • Page 205 GEN3t In the Windows Save File dialog that appears, choose a location and save the file. Send the generated file to HBM by e-mail (the file will have a “.pRequest” extension). Applying the mainframe option As soon as the request is processed by HBM, you will receive a file by e- mail (the file will have a ".pLic"...
  • Page 206 GEN3t To apply the Local Storage option, the mainframe needs to be rebooted, as described in the following steps: Disconnect the mainframe. In the main menu, select Control ► Reboot system(s)…. The following dialog appears (see Figure 11.46): Figure 11.46: Reboot System(s) dialog Select the mainframe.
  • Page 207 GEN3t Navigate to the Settings tab. Mainframe Disk 1 needs to be visible: Figure 11.48: Storage location enabled with Mainframe Disk 1 I3995-3.1 en HBM: public...

  • Page 208: Option - Optical 1 Gbit Ethernet Interface

    GEN3t Option - Optical 1 Gbit Ethernet interface 11.7 The Interface/Controller supports an optical 1 Gbit Ethernet interface by means of an SFP module. An SFP module is a small, form-factor and pluggable transceiver that supports direct optical network connections.
  • Page 209 For specifications and ordering information, please refer to "B3772-3.1 en (GEN3t Portable Data Recorder)" on page 405. For information on how to install and remove the SFP module, please refer to section "Installing a 1 Gbit SFP/10 Gbit SFP+ Module" on page 217.

  • Page 210: Option - 10 Gbit Ethernet Interface

    GEN3t Option - 10 Gbit Ethernet interface 11.8 The 10 Gbit Ethernet option is a Factory installed, ready to use Ethernet option with two available Ethernet interfaces. The 10 Gbit Ethernet card can be installed in addition to the standard on-board 1 Gbit Ethernet connection.
  • Page 211 GEN3t Connections and using the 10 Gbit Option A 10Gbit LC Connection Using the SFP+ Option 10Gbit LC optical connections need an SFP+ module to enable their use with LC connected optical cable. Note ) The 10 Gbit speed rating can be achieved with optimized settings using compatible equipment and devices of similar speed ratings.
  • Page 212 GEN3t Figure 11.51 shows the two interfaces of this option without installed SFP+ option, for further details on the SFP+ options please see the next section. Once the SFP+ option is installed in the 10 Gbit Ethernet interface, an LC optical cable can be connected.
  • Page 213 GEN3t Cable selection and lengths: Cables require different properties when they exceed certain lengths based on the properties of light in an optical fiber. Single Mode Cable is a type of cable that has a relatively small light carrying core and therefore makes fewer internal reflections so that the path of light is closer to a straight line and thus can travel further distances.
  • Page 214 GEN3t Figure 11.53: Basic setup - 10 Gbit Ethernet to PC Connecting the 10 Gbit Ethernet Option to a PC To be able to use this option you also need the correct connection or interface attached to your PC. The correct connection is not always an SFP+ module but there must be a network card or adaptor installed that supports the same specifications as the SFP+ modules used on the GENDAQ side.
  • Page 215 GEN3t Figure 11.54: Connect the 10 Gbit Ethernet Option to a PC 10 Gbit Ethernet card SFP+ modules A 10 Gbit PC network card without SFP+ modules inserted and Ethernet switch with an SC optical connection can be used to communicate with the 10 Gbit Ethernet card.
  • Page 216 GEN3t Figure 11.55: Mainframe Network Setup Optical 10 Gbit NIC1 Optical 10 Gbit NIC2 Make this the preferred network for connection with Perception In Mainframe Network Setup you can define the IP address of each individual interface if needed. If Perception finds more than one interface for Network Selection as shown in Figure 11.55, then the interface that has a Check in the box Make this the...

  • Page 217: Installing A 1 Gbit Sfp/10 Gbit Sfp+ Module

    GEN3t ® 7 - optimum settings Windows IMPORTANT To best achieve the specified 200 MB/s data transfer rating please make sure the following settings are introduced to your network adaptor via the settings in Windows. ® Windows 7 10G network adapter settings:...
  • Page 218 GEN3t Description of Electrostatic Discharge (ESD) CAUTION Electrostatic discharge (ESD) can cause damage to electronic devices if discharged into the device. Take steps to avoid such an occurrence. CAUTION HBM uses state-of-the-art electronic components in its equipment. These electronic components can be damaged by discharge of static electricity (ESD).

  • Page 219: Installation Steps

    GEN3t Installation steps First, make sure that the mainframe unit is switched off. Then locate the available SFP slot and remove the plastic plug (if inserted). POWER OUT 11V 1.4A max POWER OUT 11V 1.4A max Figure 11.56: Interface/Controller SFP location...
  • Page 220 GEN3t Grasp the module between fingers and thumb at the end with the small black removal bar. Push the back end into the available SFP slot, until you hear a click. POWER OUT 11V 1.4A max Figure 11.57: Insert device in SFP slot Insert device I3995-3.1 en HBM: public...
  • Page 221 GEN3t Embedded software detects the device and automatically connects to it when the mainframe is powered on. POWER OUT 11V 1.4A max Figure 11.58: SFP slot with device Device being inserted I3995-3.1 en HBM: public...
  • Page 222 GEN3t To remove the module from the mainframe, first make sure that the mainframe is powered off. Then grasp the small black removal bar and pull it away and out from the mainframe. The spring-loaded removal bar releases the SFP from the front panel.

  • Page 223: Option - Irig And Irig/Gps Time Synchronization

    Option - IRIG and IRIG/GPS time synchronization 11.9 The IRIG cards provide precise time and frequency reference to the GEN3t data acquisition system. Time is acquired from either the GPS satellites using an antenna / receiver (IRIG/GPS model only) or from time code signals, typical IRIG B.

  • Page 224: Gps Antenna System Rules

    GEN3t 11.9.1 GPS Antenna System Rules J1 GPS antenna connector (9-pin micro ‘DP’) J2 IRIG AM modulate Time Code In (SMB socket) J3 IRIG AM modulate Time Code Out (SMB socket) J4 IRIG DCLS time code In and Out (15-pin micro ‘DP’) SMB to BNC cable adapters included to allow standard coaxial cable connections to IRIG In and or Out SMB socket.

  • Page 225: Rule 2: Is A Gps Line Amplifier Needed

    GEN3t Lightning considerations Locate the antenna at least 15 meters away from lightning rods, towers, or structures that attract lightning. GPS antenna damage is usually not the result of a direct lightning strike, but the effects of a lightning strike on a nearby structure.

  • Page 226: Rule 4: Interconnect Cables

    GEN3t Rule 4: Interconnect cables Cable options Symmetricom’s interconnect cables are available in various lengths. For ease of pulling antenna system cable through a conduit, or if you wish to cut the cable to an exact length, you may choose to have a connector on only one end.

  • Page 227: Option - Ethercat

    GEN3t ® Option - EtherCAT 11.10 ® EtherCAT is a state-of-the-art industrial Ethernet solution suiting the needs ® of modern industrial automation applications. EtherCAT provides ® deterministic (real-time) distributed control. What makes EtherCAT stand out when compared to other real-time Ethernet solutions are its unmatched performance, flexibility and cost effectiveness.

  • Page 228: Ethercat® Generic Principles

    GEN3t ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany. ® see ethercat.org. For more detailed information about EtherCAT 11.10.1 EtherCAT® generic principles ® ® The EtherCAT functional principle is “Ethernet on the fly”. The EtherCAT ®...

  • Page 229: Ethercat® Slave Stack

    GEN3t ® 11.10.2 EtherCAT Slave Stack ® The EtherCAT protocol stack consists of several building blocks that are grouped in OSI Model layers as shown in Figure 11.62. The OSI Model provides a layered communication approach, whereby communication layers can be ®...

  • Page 230: Physical Layer

    GEN3t ® Each EtherCAT layer consists of the building blocks as shown in Figure 11.62 Application Application Appli- HTTP, ..e.g. CiA402 Drive Profile cation FTP,.. Object Dictionary Application TCP, UDP PDO Mapping Layer RD/WR File Access (AL) Mailbox DLL Process Data Interface (µC, SSI, I/O)
  • Page 231 GEN3t ● Ports ® The Data Link Layer defines the concept of ports. One EtherCAT slave device can support two, three or four ports. All ports have a loopback ® function that makes sure that the EtherCAT control loop is always closed, no matter if ports are disconnected.

  • Page 232: Application Layer

    GEN3t Slave device Physical memory FMMU Logical address space Figure 11.64: The FMMU mapping logical and physical memory addresses ● SyncManager A SyncManager controls the access to the slave´s physical memory. Each SyncManager channel defines a consistent area of physical memory. To use the slave´s physical memory in a coordinated fashion (e.g.
  • Page 233 The master uses the Init state to initialize a set of slave configuration registers. If the slave supports mailbox communication, which Genesis systems do, the corresponding sync manager configurations are also done in the Init state. Pre-operational state In the Pre-operational state mailbox communication is active.

  • Page 234: Setting Up Ethercat® Channels In Genesis

    ® 11.10.6 Setting up EtherCAT channels in Genesis With Perception software it is possible to assign certain channels to be available ® as a PDO/SDO channel on the EtherCAT bus. The Real-Time Formula Database (RT-FDB) channels can be configured for this purpose.

  • Page 235: Selecting The Appropriate Ethercat® Configuration

    ® A typical EtherCAT slave has a “fixed” CoE object dictionary. This does not apply to a Genesis mainframe; during configuration the user can add/remove channels at will. Each change has impact on the object dictionary and ESI file. ®...

  • Page 236: Static Mode

    (e.g. ENI file), even when loading other workbenches. ® Note The Genesis EtherCAT slave does update its internal CoE with all relevant - FDB channel name changes. This means that upon a bus scan in the - FDB channel names would be available to the master.
  • Page 237 ® Use Static mode when the workflow requires a one-time EtherCAT master setup while still needing different Genesis setups at different times. Choose the proper amount of hard-coded channels necessary to capture all these different Genesis setups. I3995-3.1 en HBM: public...

  • Page 238: Dynamic Mode

    GEN3t Dynamic mode In Dynamic mode the CoE object dictionary contains an exact reflection of the ® RT-FDB channels that were selected for “EtherCAT publishing”. Dynamic mode means that the CoE exactly follows the user defined published channels. The resulting ESI file also contains exactly these channels. As consequence each change in channel name or adding/removing of published channels (e.g.

  • Page 239: Coe Object Layout

    When EtherCAT is in Static mode, all EtherCAT channels that do not have a Genesis channel mapped to it have the “Status” value set to “0”. ® A Genesis EtherCAT slave also has some hard-coded objects in its CoE object dictionary.

  • Page 240: Ethercat® Timing Aspects

    (e.g., having 100 calculations running in parallel) while still keeping ® latency for all these results to a minimum. A Genesis EtherCAT slave by default delivers all results to the bus with a fixed 1 millisecond (ms) latency. In ®...

  • Page 241: More Ethercat® Timing Aspects

    GEN3t ® 11.10.10 More EtherCAT timing aspects Certain types of RT-FDB formulas are “special” in the sense that they come with an additional Latency Increase. The reason is that some formulas only can start processing all received samples upon receiving a new zero crossing.

  • Page 242: Aligning Ethercat® Latencies Over Multiple Mainframes

    GEN3t ® 11.10.11 Aligning EtherCAT latencies over multiple mainframes As shown, some formulas introduce a latency increase. The resulting “System Latency” might then differ for multiple mainframes. If these mainframes publish ® on the same EtherCAT bus, the master would receive these samples from shifted clock domains.

  • Page 243: Supported Ethercat Masters

    L/A Link Activity LED port OUT U2: User 2 LED ® G EtherCAT port IN ® EtherCAT port OUT ® The following table outlines how the status LEDs on the EtherCAT card relate to the Genesis ESM state. I3995-3.1 en HBM: public...
  • Page 244 GEN3t Table 11.5: Genesis ESM state versus status LEDs Genesis ESM State RUN status LED L/A status LED ERR status LED Init Fast flashing Slow flashing Fast flashing Pre-operational Safe operational Slower flashing Fast flashing Operational Fast flashing Operational → Init –...
  • Page 245 ® From an EtherCAT perspective a Genesis system only provides inputs, no outputs. Since the Operational state only adds propagation of output compared to the Pre-operational state, for a Genesis system these two states have identical behavior. Limitations ® The EtherCAT...

  • Page 246: Troubleshooting

    ® Genesis EtherCAT slave. Cause: The reason for a Genesis system to transition from Operational to Init state is that its CoE Object Dictionary has changed. Solution: When Genesis is configured in Dynamic mode the EtherCAT® master must rescan the EtherCAT® fieldbus every time its CoE Object Dictionary changes.

  • Page 247: 12 Input Cards

    GEN3t 12 Input Cards 12.1 Available input cards Table 12.1: Model overview (Part 1) Model Overview Model GN401 100 M GN402 100 M GN410 16 200 k GN411 GN412 14 100 M GN413 14 25 M GN440 16 200 k...
  • Page 248 GEN3t Table 12.2: Model overview (Part 2) Model Overview Model GN401 100 M 2 GB GN402 100 M 2 GB GN410 200 k 128 MB GN411 512 MB GN412 14 100 M 2 GB GN413 25 M 128 MB GN440...
  • Page 249 GEN3t Optical Fiber Transmitter Channels Transmitter Every transmitter is a single channel unit. Every unit has an unbalanced dif- ferential input, amplifier, analog anti-alias filter and ADC with an optical data and control link to the receiver card. The receiver card has the recording logic, sample rate selection and memory.

  • Page 250: Acquisition Card Feature Comparison

    GEN3t 12.1.1 Acquisition card feature comparison - GN810 - 2/1 - GN811 - 2 - GN812 - 2 - GN813 - 2/1 - GN814 - 2 - GN1610 - 2/1 - GN1611 - 2 1-GN401-2 1-GN402-2 1-GN410-2/1-GN411-2 1-GN412-2/1-GN413-2 1-GN440-2/1-GN441-2 1-GN610-2/1-GN611-2...

  • Page 251: Isolated 1Kv Input Cards

    GEN3t 12.2 Isolated 1kV input cards 12.2.1 GN610B, Isolated 1kV 2MS/s input card with real-time formula database 6 analog channels Isolated, balanced differential inputs ± 10 mV to ± 1000 V input range 2MΩ 1kV DC CAT II 600V Basic accuracy 0.02% Basic power accuracy 0.02%...

  • Page 252: Gn611B, Isolated 1Kv 200Ks/S Input Card With Real-Time Formula Database

    GEN3t 12.2.2 GN611B, Isolated 1kV 200kS/s input card with real-time formula database 6 analog channels Isolated, balanced differential inputs ± 10 mV to ± 1000 V input range 2MΩ 1kV DC CAT II 600V Basic accuracy 0.02% Basic power accuracy 0.02% 600 V RMS CAT II reinforced isolation, tested up to 6.4 kV...

  • Page 253: Gn610, Isolated 1Kv 2Ms/S Input Card

    GEN3t 12.2.3 GN610, Isolated 1kV 2MS/s input card 6 analog channels Isolated, balanced differential inputs ± 20 mV to ± 1000 V input range 2MΩ 1kVrms CAT II 600V 600 V RMS CAT II reinforced isolation, tested up to 6.4 kV...

  • Page 254: Gn611, Isolated 1 Kv 200Ks/S Input Card

    GEN3t 12.2.4 GN611, Isolated 1 kV 200kS/s input card 6 analog channels Isolated, balanced differential inputs ± 20 mV to ± 1000 V input range 2MΩ 1kVrms CAT II 600V 600 V RMS CAT II reinforced isolation, tested up to 6.4 kV...

  • Page 255: Using The Gn610/Gn611 And Gn610B/Gn611B

    Use shielded cables. The cable should have the measurement cables paired inside a shield. Preferably, the shield should be connected to the chassis of the measurement Genesis High Speed equipment. Alternatively, the shield could also be connected to the chassis of the object under test.
  • Page 256 GEN3t HBM KAB290 cables are designed to meet this setup: Shield yellow 2 wires 0.75mm Red and black Shield Cable isolation Isolation Wire to wire Shield to wire Figure 12.2: Shielded cable setup Typical conducted immunity disturbance (10 V RMS, Clamp)
  • Page 257 GEN3t Keep all measurement cables well separated from cables connected to high switching loads or motor cables. Separate measurement equipment and cables from potentially interfering equipment like frequency inverters or wireless equipment. General cabling remark: Only use properly rated cables to measure the signal.
  • Page 258 GEN3t WARNING High voltage and qualified personnel For measurements falling within the scope of the EN 50110-1 and EN 50110-2, please note that all cards with working voltages above 50 V AC RMS or 120 V DC may only be connected by a qualified technician or a person trained in electrical engineering and supervised by a qualified technician.

  • Page 259: Understanding The Gn610/Gn611 And Gn610B/Gn611B Category Rating

    GEN3t Figure 12.5: Safe connectors 12.2.6 Understanding the GN610/GN611 and GN610B/GN611B category rating Figure 12.6: Category indication in accordance with IEC 61010-2-030:2010 Example: A measurement device is specified as 600 V CAT II, maximum input voltage 1000 V DC. - 2 - 030:2010 Table 12.3: Insulation test voltages in accordance with IEC 61010...

  • Page 260: Understanding The Gn610/Gn611 And Gn610B/Gn611B Input

    GEN3t Using the table above, it can be concluded that this specification informs the user that the device has passed the insulation tests; 5 sec at 2.210 V RMS and an impulse of 4.000 V. The maximum operating input voltage is 1000 V DC.
  • Page 261 GEN3t Looking at Figure 12.7, the GN610 specifies U IN(+), U IN(-) and |Uiso| ≤ 1 kV. Using a standard passive 10:1 probe, combined with the GN610 results in the situation shown in Figure 12.8. Passive probe IN(+) 9 MΩ...

  • Page 262: Using The High Precision Differential Probe

    GEN3t Assuming: U IN(-) = 10 * U diff U IN(+) = 0 V Results in: = 10 * U / 11M * 10M = 9.1 * U diff diff If the maximum specified U of 1 kV is considered, both U IN(-) and U diff way above the channels specification.
  • Page 263 GEN3t Standard this probe uses a divide by 10 input stage. Either use the Perception Sensor Database to apply the correct probe or use a technical unit multiplier 10 to scale the channels input sensitivity to match the attached probe.

  • Page 264: Measuring Currents

    GEN3t IMPORTANT This probe concept increases the input voltage levels while maintaining the protection of the GN610B/GN611B/GN610/GN611 acquisition cards. Care must be taken that the full isolated measurement is lost as the probe is attached to earth. It's recommended to use high impedance series resistors to keep both the current load on the device under test low as well as any potential ground loop currents low.

  • Page 265: Gn610/Gn611, Gn610B/Gn611B Isolation And Type Testing

    GEN3t All required accessories, can be found in the appendix “Card Options, to be ordered separately” on page 777. 12.2.10 GN610/GN611, GN610B/GN611B Isolation and type testing An overview of the GN610/GN611, GN610B/GN611B card isolation and input is shown below (see Figure 12.13). The isolation of the channel to chassis is 1000 V RMS and is also qualified as 600 V CAT II (or 300 V CAT III).
  • Page 266 GEN3t Isolation Input signal to chassis 1000 V RMS, 600 V CAT II (REINFORCED) Channel to chassis 1000 V RMS, 600 V CAT II (REINFORCED) Channel to channel 2000 V RMS, (BASIC) Isolated channel ±1000 V RMS 600 V CAT II Reinforced Isolated channel ±1000 V RMS...

  • Page 267: Channel To Chassis Isolation Test

    GEN3t Channel to chassis isolation test To qualify the isolation as 1000 V RMS and 600 V CAT II (REINFORCED), certain tests are performed on some cards during the engineering design qualification phase. These tests are known as type tests. These tests are described in the IEC61010-1:2010 and IEC61010-2-30:2010 standards.
  • Page 268 GEN3t 4935 V DC Isolated channel Isolated channel Chassis Figure 12.15: DC type test channel to chassis I3995-3.1 en HBM: public...

  • Page 269: Channel To Channel Isolation Test

    GEN3t Channel to channel isolation test For the channel to channel test, both the DC and AC tests below (see Figure 12.16 and Figure 12.17) are used with DC voltage √2 higher than the AC voltage. The test value meets the requirements for 600 V CAT II REINFORCED.
  • Page 270 GEN3t Isolated channel 3510 V RMS Isolated channel Chassis Figure 12.17: AC type test channel to channel I3995-3.1 en HBM: public...

  • Page 271: High Potential Test

    GEN3t High potential test The type tests are performed on a selection of cards to test the design. Every card produced undergoes a production test to verify that the card has been designed correctly and that the card is safe. The tests are called “hipot” (high potential) tests (see Figure 12.18 and Figure 12.19).
  • Page 272 GEN3t Isolated channel Chn 1, 3, 5 Isolated channel Chn 2, 4, 6 Chassis 1500 V RMS Figure 12.19: Hipot testing Channels 2, 4 and 6 I3995-3.1 en HBM: public...

  • Page 273: Engineering Tests

    GEN3t Engineering tests Besides the type tests and the production tests, HBM has also performed several engineering tests to verify the robustness of the design during the engineering design qualification phase. Component tests Every component crossing the isolation barrier is tested and/or examined to make sure it will pass the type test.

  • Page 274: Gn610/Gn611, Gn610B/Gn611B Protection Mechanisms

    GEN3t Active input switch test To guarantee the stability of the channels, the input relays are tested with the maximum input voltage (1000 V) applied. The inputs of the channels have been switched from isolated GND to DC by the input relay, resulting in the 1000 V being applied to the input as a step pulse.
  • Page 275 GEN3t Every selected input range allows a 200% overload without any change of input resistance or auto ranging. This 200% overrange is designed to allow for smaller voltage overloads without affecting the measurement. Within this 200% overload, the amplifier is also able to respond with normal rise/fall times and the signal is restored within the standard selected range.

  • Page 276: Thermal Monitor Of The Input Channels

    GEN3t Thermal monitor of the input channels Any overload results in extra heat being generated within the channel. The extra heat is the result of the extra current flowing through the input resistance. The extra heat is also caused by internal amplifier sections driving their local output to maximum levels, which creates excessive heating within the amplifier.

  • Page 277: Thermal Shutdown In Critical Conditions

    GEN3t Thermal shutdown in critical conditions This protective scheme allows for any overload that the input could be confronted with during normal operation. For any other failure that could result in excessive heat dissipation, the GEN series mainframe has a last protective stage built in.

  • Page 278: Restore Range Selected By User Automatically

    GEN3t Restore range selected by user automatically As the GEN series system is designed to measure 24 hours a day, 7 days a week, the automatic range switching has the negative side effect of reducing the sensitivity of the amplifier. During the actual overload, the channel is unable to measure the input signal.

  • Page 279: Isolated Basic/Iepe Cards

    GEN3t 12.3 Isolated Basic/IEPE cards 12.3.1 GN815, Isolated Basic/IEPE 2MS/s input card IEPE transducer support TEDS Class 1 support for IEPE 8 analog channels Isolated, unbalanced differential inputs ± 10 mV to ± 50 V input range Analog/digital anti-alias filters...

  • Page 280: Gn816, Isolated Basic/Iepe 200Ks/S Input Card

    GEN3t 12.3.2 GN816, Isolated Basic/IEPE 200kS/s input card IEPE transducer support TEDS Class 1 support for IEPE 8 analog channels Isolated, unbalanced differential inputs ± 10 mV to ± 50 V input range Analog/digital anti-alias filters 200 kS/s sample rate...

  • Page 281: Using The Gn815 And Gn816

    Use shielded cables. The cable should have the measurement cables paired inside a shield. Preferably, the shield should be connected to the chassis of the measurement Genesis High Speed equipment. Alternatively, the shield could also be connected to the chassis of the object under test.
  • Page 282 GEN3t Keep all measurement cables well separated from cables connected to high switching loads or motor cables. Separate measurement equipment and cables from potentially interfering equipment like frequency inverters or wireless equipment. General cabling remark: Only use properly rated cables to measure the signal.

  • Page 283: Understanding The Gn815 And Gn816 Isolation

    GEN3t WARNING Connectors and cables The specified ± 50 V DC voltage range of the Isolated Basic acquisition card is such that it falls below the low voltage limit as specified in IEC61010. The limit for safe voltage and currents is set in the IEC61010-1 standard in Section 6.3 –...

  • Page 284: Understanding The Gn815 And Gn816 Input

    GEN3t The isolation of the Isolated Basic card (GN815 and GN816) is in line with the limit for safe voltage and currents as mentioned above. Table 12.5: Limit for safe voltage and currents (GN815 and GN816) ± 140 V DC, 55 V RMS (low voltage...

  • Page 285: Characteristics Per Channel

    GEN3t The input channels of the GN816 and GN816 are isolated. This means that the input channel and amplifier are fully isolated from (earth) ground. In this context, fully isolated means a very high resistance and a very small capacitive coupling to ground.

  • Page 286: Gn815 And Gn816 Input Overload Protection

    GEN3t Passive HV probe Single-ended, isolated IN(+) 900 kΩ 900 kΩ Non-isolated system Isolated channel IN(-) Figure 12.29: Input channel with a high voltage 10:1 passive probe 12.3.6 GN815 and GN816 Input overload protection The input section has several methods to protect against voltage overload on the input.

  • Page 287: Thermal Monitor Of The Input Channels

    GEN3t Thermal monitor of the input channels Any overload results in extra heat being generated within the channel. The extra heat is the result of the extra current flowing through the input resistance. The extra heat is also caused by internal amplifier sections driving their local output to maximum levels, which creates excessive heating within the amplifier.

  • Page 288: Thermal Shutdown In Critical Conditions

    GEN3t Thermal shutdown in critical conditions This protective scheme allows for any overload that the input could be confronted with during normal operation. For any other failure that could result in excessive heat dissipation, the GEN series mainframe has a last protective stage built in.

  • Page 289: Gn410 And Gn411 Bridge Input Cards

    GEN3t 12.4 GN410 and GN411 Bridge input cards The GN410 and GN411 bridge input cards are suitable for strain gauges, strain-gauge based force, pressure or torque transducers and piezo-resistive accelerometers. The inputs can also be used as a general purpose low voltage differential amplifier with AC and DC coupling.
  • Page 290 GEN3t Excitation Off / Voltage / Current Sense On/Off + Sense excite - Sense excite 350 Ω 3 Wire User Ω ¼ Bridge Completion Card ½ Bridge ½ Bridge Select Shunt Ext Shunt cm Ext Shunt Rem CAL cm Rem CAL+...

  • Page 291: Input Connectors

    GEN3t 12.4.2 Input connectors The LEMO 2B316 connector pin-out is compatible with the Liberty data acquisition system. The mating male connector is LEMO P/N FGG2B316CLADxx, where xx is the desired cable collet size or a similar size. 12.4.3 Bridge completion Each bridge amplifier channel contains a pair of fixed 10 kΩ...

  • Page 292: Shielding And Driven Guard

    GEN3t Figure 12.32: Shunt calibration completion plug-in module User quarter-bridge Completion User half-bridge Completion User shunt cal - bridge completion JUMPER! Remove when installing a half 12.4.5 Shielding and driven guard When long cable runs are required, the excitation leads and signal leads are generally separately twisted and shielded within the cable to minimize the cross-coupling that would otherwise occur.

  • Page 293: Various Bridge Configurations

    GEN3t LEMO pin 7 Figure 12.33: The driven guard approach to minimize induced noise A Strain gauges B Signal conductors C Outer shield Terminated near strain gauges - Signal source D Inner shield Driven guard at +Vcm 12.4.6 Various bridge configurations The diagrams below shows possible bridge configurations.
  • Page 294 GEN3t pin 1 + V_EXC White - INPUT pin 6 Black pin 2 - V_EXC Shield (optional) pin 7 GUARD Figure 12.35: Half-bridge standard wiring + V_EXC pin 1 Green + INPUT pin 5 White - INPUT pin 6 Black...
  • Page 295 GEN3t REM CAL + pin 11 Any shunt calibration resistor White/Red can be switched into either the + Sense pin 3 positive (A-C) or negative (C-D) + V_EXC pin 1 arm of the bridge under software control. REM GAGE pin 5...

  • Page 296: Bridge Connector Reference Card

    GEN3t 12.4.7 Bridge connector reference card Make copies of this page to record and document your test setups. ISOLATED COMMON ¼ BRIDGE 350 W REMOTE CAL + REMOTE CAL - + V_EXC - V_EXC Black EXT SHUNT R + SENSE...

  • Page 297: Configuring And Using The Bridge Amplifier

    GEN3t 12.4.8 Configuring and using the bridge amplifier This section describes the procedures required when configuring and using the bridge amplifier for both the hardware as well as the software (Perception). In the Perception software, a simplified block diagram is used as reference and complementary control.

  • Page 298: Bridge Completion - Full (4/4) Bridge

    GEN3t Bridge completion - full (4/4) bridge A full bridge type sensor is a sensor that has all four bridge resistors on-board; no completion is required. +V_EXC −AMP INPUT +AMP INPUT −V_EXC BRIDGE RESISTOR BRIDGE COMPLETION Figure 12.40: Full-bridge layout At least four wires are necessary to connect a bridge such as this.

  • Page 299: Bridge Completion - Half (1/2 Or 2/4) Bridge

    GEN3t Do one of the following: In the Bridge type column of the spreadsheet style matrix, select the bridge type Full. In the simplified graphical diagram, click on the bridge icon (D in Figure 12.39 on page 297) until the full-bridge representation can be seen.
  • Page 300 GEN3t In this situation, a sensor is used with two (out of four) resistors: R4 and R3. These resistors are placed between A-C and C-D. Two additional resistors must be provided: R1 and R2. There are two ways of doing this: Use the standard 100 kΩ...

  • Page 301: Bridge Completion - Quarter (1/4) Bridge

    GEN3t Do one of the following: In the Bridge type column of the spreadsheet style matrix, select the bridge type Half. In the simplified graphical diagram, click on the bridge icon (D in Figure 12.39 on page 297) until the half-bridge representation can be seen.
  • Page 302 GEN3t In this situation, a sensor is used with only one resistor, R4. This resistor is placed between A and C. Three additional resistors must be provided: R1, R2 and R3 to complete the bridge. You do this by using the half-bridge completion as described in the previous section and then adding the additional R3 resistor between C and D.

  • Page 303: Excitation

    GEN3t Do one of the following: In the Bridge type column of the spreadsheet style matrix, select the bridge type Quarter. In the simplified graphical diagram, click on the bridge icon (D in Figure 12.39 on page 297) the quarter-bridge representation can be seen.
  • Page 304 GEN3t Excitation on/off: Provision for separately switching off the bridge voltage while the remainder of the measuring circuit remains operational. This is an important and useful feature, particularly when measuring dynamic strains. Any output observed when the bridge voltage is switched off must be due to electrical noise, as the output cannot possibly be the result of resistance changes in the measuring circuit when a bridge voltage is not present.
  • Page 305 GEN3t To switch the excitation on or off, do one of the following (this opens/closes the switch marked S2a and S2b in Figure 12.31): Double-click in the correct row(s) of the Excitation column in the spreadsheet style matrix. In the simplified graphical diagram, click on the excitation switch (I in Figure 12.39 on page 297).
  • Page 306 GEN3t Select one of the following options: Voltage: Voltage excitation. A voltage is applied between the bridge connection marked A (positive) and the bridge connection marked D (negative). To set the voltage level either: Enter the required voltage in the Excitation span column of the spreadsheet style matrix.

  • Page 307: Shunt Verification - Setup

    GEN3t Shunt verification - Setup A shunt resistor can be used to verify the sensitivity of a bridge. Connect a shunt resistor to Resistor R4 (A-C) or Resistor R3 (C-D) of the bridge and activate the shunt within Perception, an output signal that simulates strain (a deflection) is produced.
  • Page 308 GEN3t Select between internal or external shunt usage: In the Internal shunt column, enable internal to use an internal shunt or clear the option to select an external resistor. This selection operates switch S7 in Figure 12.31. Depending on the selection:...

  • Page 309: Shunt Verification - Procedure

    GEN3t Select the bridge arm to operate switch S5 in Figure 12.31 on page 290: In the sheet, use the Active gage column to select between Positive (A-C) or Negative (C-D). In the simplified block diagram, click on the Remote calibration select switch (B in Figure 12.39 on page 297) to switch between the...
  • Page 310 GEN3t Figure 12.43: Shunt verification dialog Verify command Warning settings Legend Selected channel Bridge representation Verify command G Shunt location selection Channel selection Shunt active gage selection (S5 in Figure 12.31 on page 290) Shunt verification In Perception, go to the Settings sheet.

  • Page 311: Bridge Balance

    GEN3t Bridge balance The bridge circuit is only in balance (has no output when the bridge voltage is applied) when R1 / R2 = R4 / R3. Taking the various resistance tolerances on the strain gauge(s), resistors and lead wires into account, an initial unbalance is invariably present.
  • Page 312 GEN3t Warning settings Selected channel Schematic block diagram of balance circuit To balance a bridge To balance a bridge in Perception, do the following: In Perception, go to the Settings sheet. In the task pane, select Bridge Balance in the Sensors section.

  • Page 313: Gn440 And Gn441 Universal Amplifier Input Cards

    GEN3t 12.5 GN440 and GN441 Universal amplifier input cards This unique, high-end input card with an ultra-fast amplifier serves a variety of needs, from differential and/or isolated measurements to IEPE-based vibration or shunt-based current measurements. The universal amplifier input card has four input channels. Each channel samples at a maximum speed of 200 kS/s or 1 MS/s with a 16 bit resolution.

  • Page 314: Gn412 And Gn413 High Speed - Differential Input Cards

    GEN3t GN412 and GN413 High Speed - Differential input cards 12.6 For ultra fast signals, the 25 MS/s and 100 MS/s high speed differential input cards are equipped with four channels that sample at incredibly high speeds. With selectable anti-aliasing...

  • Page 315: High Resolution Universal Input Card

    GEN3t 12.7 High resolution universal input card 12.7.1 GN840/GN1640 Universal 500 kS/s 8/16 channel input cards Quarter/Half/Full bridge Voltage excited sensors IEPE sensors Piezoelectric/Charge sensors 4 to 20 mA sensors Pt10, Pt100, Pt500, Pt1000 and Pt2000 (3 and 4 wire RTD)
  • Page 316 GEN3t For more information on the High resolution universal input card, please refer to "B4170-1.0 en (GEN series GN840B, GN1640B)" on page 675. I3995-3.1 en HBM: public...

  • Page 317: Supported Sensor Modes

    GEN3t 12.7.2 Supported sensor modes "Basic mode and cabling" on page 317 "Bridge mode and cabling" on page 318 "Basic sensor and cabling" on page 320 "Integrated Electronic Piezoelectric (IEPE) mode and cabling" on page 321 "Piezoelectric (Charge) mode and cabling" on page 322 "Resistive Temperature Detectors (RTD) mode and cabling"...

  • Page 318: Bridge Mode And Cabling

    GEN3t Bridge mode and cabling Bridge sensor Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control optional TEDS class 2/3 Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) - ¼ bridge Ω excit - ¼ bridge 120 Ω...
  • Page 319 GEN3t Bridge mode and cabling GN1640B LS 2 KAB7.5/00-2/2/2 GN840B Half bridge Drain wire Foil shield Blue Excitation Green Sense Black Excitation Grey Sense Signal White External shunt Drain wires Shunt Signal ground Foil shield Housing Earth shield Keep wire length < 5 cm...

  • Page 320: Basic Sensor And Cabling

    GEN3t Basic sensor and cabling Basic sensor Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control optional TEDS class 2/3 Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) excit Signal Sensor 10 MΩ Signal ground Signal (-) 10 MΩ...

  • Page 321: Integrated Electronic Piezoelectric (Iepe) Mode And Cabling

    GEN3t Integrated Electronic Piezoelectric (IEPE) mode and cabling IEPE sensor Signal conditioner TEDS Control optional TEDS Class 1 Amplifier Signal (+) Signal ground Figure 12.53: IEPE mode block diagram IEPE KAB173 GN1640B GN840B Shield Signal wire TEDS Class 1 Signal wire...

  • Page 322: Piezoelectric (Charge) Mode And Cabling

    GEN3t Piezoelectric (Charge) mode and cabling Signal conditioner Piezoelectric sensor Teds (+) TEDS TEDS optional Teds (-) Class 2 Control Amplifier Signal (+) Signal ground Figure 12.55: Piezoelectric mode block diagram KAB173 GN1640B Piezoelectric GN840B Shield Signal wire Signal wire...

  • Page 323: Resistive Temperature Detectors (Rtd) Mode And Cabling

    GEN3t Resistive Temperature Detectors (RTD) mode and cabling Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control TEDS class 2/3 optional Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) ¼ bridge Pt10 350 Ω -...

  • Page 324: Current Loop Mode And Cabling

    GEN3t Current loop mode and cabling Current loop sensor Signal conditioner Teds (+) TEDS TEDS optional Teds (-) Class 2 Control Signal (+) 62 Ω Signal (-) Signal ground Amplifier Figure 12.58: Current loop mode block diagram Current loop KAB4-3133.0002...

  • Page 325: Thermocouple Mode And Cabling

    GEN3t Thermocouple mode and cabling Thermo Connection Signal conditioner couple block Teds (+) TEDS Control TEDS Teds (-) Cold junction reading Class 2 Signal (+) Cold Signal (-) junction sense 10 MΩ 10 MΩ Signal ground Amplifier MAX31826 Figure 12.60: Thermocouple mode block diagram...

  • Page 326: Din Rail Breakout

    GEN3t 12.7.3 DIN rail breakout HINT/TIP For quick connect and reconnect din rail breakouts are available. Three different models exit: Generic breakout G088 Figure 12.62: DIN rail mountable breakout block (1-G088-02) The G088 supports spring/push-in connectors for all wire connection to/ from the GN840B/GN1640B card.
  • Page 327 GEN3t Thermocouple breakout G089 Figure 12.63: DIN rail mountable breakout block (1-G089-02) The G089 is specifically designed to support thermocouple input connections to/from the GN840B/GN1640B card. The built-in digital cold junction sensor is used by the GN840B/GN1640B card to compensate the thermal errors caused by the sensor to measurement junction.
  • Page 328 GEN3t Basic/IEPE/piezoelectric breakout terminal G090 Figure 12.64: DIN rail mountable breakout block (1-G090-02) The G090 is specifically designed to support BNC input connections to/from the GN840B/GN1640B card. The breakout supports two isolated metal BNCs to allow full differential input wiring.

  • Page 329: Flexible Wiring

    GEN3t 12.7.4 Flexible wiring HINT/TIP Using the different terminals, cables and other existing support material a flexible wiring setup can be created to match almost any wish list. Thermocouple GN1640B RG-58 Coax cable DIN rail breakout 1-KAB2124-3 IEPE Full bridge LS 2 KAB7.5/00-2/2/2...

  • Page 330: High Resolution Iepe And Charge Input Cards

    GEN3t 12.8 High resolution IEPE and Charge input cards 12.8.1 GN3210 IEPE and charge 250 kS/s input card The GN3210 IEPE and charge 250 kS/s input card is a no- compromise solution for high channel count data acquisition systems. This card brings:...

  • Page 331: Gn3211 Basic 20 Ks/S Input Card

    GEN3t 12.8.2 GN3211 basic 20 kS/s input card The GN3211 basic 20 kS/s input card is a no-compromise solution for high-channel-count data acquisition systems. This card offers: A cost-effective solution with 16 or 32 channels per card High precision with a 16 bit A-to-D convertor for each channel...
  • Page 332 GEN3t Front View CH 16 NEG. CH 32 NEG. RESERVED RESERVED RESERVED RESERVED CH 16 POS. CH 8 NEG. CH 32 POS. CH 24 NEG. RESERVED RESERVED CH 15 NEG. CH 31 NEG. CH 8 POS. CH 24 POS. RESERVED RESERVED CH 31 POS.

  • Page 333: Gn401 Optical Fiber Isolated 100 Ms/S Input Card

    GEN3t 12.9 GN401 Optical Fiber Isolated 100 MS/s input card 4 transmitters per receiver card Digital fiber optic connection, noise/error and drift free Cable length up to 800 m Automatic cable length phase compensation 1 isolated, unbalanced differential input per...

  • Page 334: Binary Marker Cards

    GEN3t 12.10 Binary marker cards 12.10.1 GN6470 Binary marker card The GN6470 binary marker input card is a dedicated binary input option for the GEN series instruments. It enables to record up to 64 binary input channels (marker channels) with up to 1 MS/s per channel.

  • Page 335: Gn4070 Binary Marker Hv Card

    GEN3t 12.10.2 GN4070 Binary marker HV card The GN4070 binary marker HV card is a combined electrical and optical binary marker input card. It enables to record up to 32 electrical and eight optical binary input channels (marker channels) with up to 1 MS/s per channel. The optical isolated binary makers are specifically suited for the medium/high voltage market.

  • Page 336: Connector Pinning Gn6470 And Gn4070

    GEN3t 12.10.3 Connector pinning GN6470 and GN4070 The GN6470 binary marker cards come with four 26 pin connectors. The GN4070 replaces the top two connectors with eight optical receivers and one optical transmitter. The following diagram and table provide the pinning information of each 26 pin connector.

  • Page 337: Gn6470 And Gn4070 Input Block Diagram

    GEN3t PIN # EV1-16 EV17-32 EV33-48 EV49-64 Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground +5 V +5 V +5 V +5 V +5 V +5 V +5 V +5 V (*) = Event input combined with counter/timer channel function 12.10.4...

  • Page 338: Gn6470 And Gn4070 Counter Mode Pinning

    GEN3t 12.10.5 GN6470 and GN4070 Counter mode pinning When in counter mode, Event Bits 53 through 63 are used to provide the counter functionality. These bits are located on the bottom connector as follows: xx - yy: aaa N N = channel number...

  • Page 339: Gn6470 And Gn4070 Frequency (Rpm) Mode Pinning

    GEN3t Direction The direction signal determines whether the counter is incremented (direction = “0”), or decremented (direction = “1”) on each rising edge of the counter input. Reset The reset signal resets the counter to zero. Software control determines the reset enabling as well as the active level.

  • Page 340: Gn6470 And Gn4070 Quadrature (Position) Mode Pinning

    GEN3t In the Perception software, the event bits are combined within one channel and labeled as CH1_1 through CH1_64. The counter/timer channels are referred to as CH2 through CH4. For frequency measurements, the counter/timer channels use an additional gate clock to create a time interval (gate time) in which pulses are counted. The minimum gate time is 1 μs and the maximum gate time is 10 s.
  • Page 341 GEN3t xx - yy: aaa N N = channel number aaa = function yy = event number xx = pin number 8 - 57: clk 2 7 - 58: dir 2 6 - 59: res 2 4 - 61: clk 3...

  • Page 342: Configure The Timer/Counters In Perception

    GEN3t Direction input (B) The direction signal determines whether the counter is incremented (direction = “0”), or decremented (direction = “1”) on each rising edge of the counter input. Reset The reset signal resets the counter to zero. Software control determines the reset enabling and the active level.
  • Page 343 GEN3t Configure the Timer/Counter (Perception): Figure 12.73: Configuration of the Timer/Counter connector in Perception Signal coupling mode In quadrature mode, the counter supports three ways of tracking the quadrature states defined by the signal coupling. Single precision Double precision Quad precision...
  • Page 344 GEN3t Quadrature disk Signal Signal Direction Direction ∆t ∆t ∆t ∆t ∆t: Must be > 50 ns Single precision counting Signal Direction Count Up Count Up Count Up Count Down Count Down Count Down Wheel rotates clock wise Wheel rotates counter clock wise...
  • Page 345 GEN3t Timer Counter mode: Count Quadrature -> counters monitor the transition of the four different states the signal can be in. Reset Mode: Each External Pulse -> resets the counter every time we receive a pulse in Reset input. Range from/to 0 to 360°...

  • Page 346: Gn4070 Connectors And Pinning

    GEN3t 12.10.9 GN4070 Connectors and pinning The binary marker HV card comes with nine fiber optic connectors (see Figure 12.75) and two 26 pin connectors. The lowest fiber optic connector provides the recording status output. The fiber optic input connectors provide the marker (event) channels labeled 1 through 8.

  • Page 347: 13 Option Cards

    GEN3t 13 Option Cards 13.1 Option Carrier Card (OCC) The option carrier card is used to add all kinds of additional digital interfaces to the outside world. The most typical interfaces it is designed for are synchronisation to various time sources like IRIG/GPS etc., but also faster ®...

  • Page 348: Option Cards Supported

    GEN3t 13.1.1 Option cards supported At release of this manual the following option cards are supported: Part number Function G001 IRIG synchronisation G002 IRIG and GPS synchronisation G064 10 Gbit Ethernet card, optical ® G082 EtherCAT G083 Master Output Card (Synchronize multiple slaves)

  • Page 349: Integration Card

    GEN3t 13.2 5B Integration card The Genesis data acquisition system offers a variety of standard input cards to cover the most important physical application requirements. In situations where non-standard or specific requirements are needed, for example LVDT or PT100 signals that need to be conditioned and acquired, the 5B Integration card is used.
  • Page 350 GEN3t A 5B module A 5B module offers a small footprint, defined input and output connections, isolation, and good price/performance. A 5B module is a single channel fixed- range amplifier. These modules are the standard for fixed application signal conditioning in the lab and the factory floor.
  • Page 351 GEN3t Using the 5B Integration card with Genesis series The 5B Integration card is designed to work seamlessly with the GEN series mainframes. Up to six 5B preamplifier modules can be attached to a card that supplies a range of fused supply voltages to the modules and that has enough front panel space to mount the required input and output connectors.
  • Page 352 First, check whether there are 5B modules that do the job with respect to their fixed input range and the other limitations available. The output range is very often suitable because the Genesis input cards used with the 5Bs offer a 16 bit resolution. Therefore, the modules normally have a resolution high enough for any range required.
  • Page 353 +600 °C, each module has a 0-5 V output. Connect the output (preferable BNCs mounted on the 5B Integration card front panel) to two selected Genesis input channels now acting as the “Frequency” and “TC” channels. Set sensitivity to 0-5 Volt (or whatever the 5B modules that are used deliver as Full Scale value) in these channels.
  • Page 354 The card alone does not serve any function and must be combined with 5B series signal conditioners. Proper connectors have to be mounted, internal card wiring (input/ output/power) has to be implemented and additional Genesis input channels have to be used to receive the 5B series output signal. HBM's Basic input cards series (GN810, GN811, GN815 or GN816) are most suited for this task.
  • Page 355 GEN3t Ordering information Article Description Order No. GEN DAQ 5B Integration card - Uses one 5B Integration card 1-G028-2 GEN DAQ slot, holds up to six 5B modules. Note 5B modules, I/O Connectors and cabling not included. Basic card required for acquisition.

  • Page 356: 14 Gen Series Synchronization Methods

    GEN3t 14 GEN series Synchronization Methods 14.1 14.1.1 PTP technology background ® (1) Source: Wikipedia the free encyclopedia The Precision Time Protocol (PTP) is a protocol used to synchronize clocks throughout a computer network. On a local area network, it achieves clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems.

  • Page 357: Ptp Protocol Details

    GEN3t 14.1.2 PTP Protocol details Synchronization and management of a PTP system is achieved through the exchange of messages across the communications medium. To this end, PTP uses the following message types. Sync, Delay_Req, Follow_Up and Delay_Resp messages are used by ordinary and boundary clocks and communicate time-related information used to synchronize clocks across the network.

  • Page 358: Best Master Clock Algorithm (Bmc)

    GEN3t 14.1.3 Best master clock algorithm (BMC) The best master clock (BMC) algorithm performs a distributed selection of the best candidate clock based on the following clock properties: Identifier A universally unique numeric identifier for the clock. This is typically constructed based on a device's MAC address.
  • Page 359 GEN3t IEEE 1588-2008 uses a hierarchical selection algorithm based on the following properties, in the indicated order: Priority 1 Class Accuracy Variance Priority 2 Unique identifier (tie breaker) (1) “PTP technology background”, “PTP Protocol details” and “Best master ® clock algorithm”: Source: Wikipedia...

  • Page 360: Ptp Switch Types

    GEN3t 14.2 PTP switch types Within the PTP specification, two types of switches are defined: Boundary clock switches Transparent clock switches Boundary clock Boundary clocks are defined within a PTP system to be integrated in place where standard network switches or routers are used. Boundary clocks are defined as PTP clocks with more than a single PTP port, with each port providing access to a separate PTP communication path.

  • Page 361: Switches Using Boundary Clocks

    GEN3t Grand master Grand master clock clock Transparant clock Boundary clock switch switch System 1 System 1 System 2 System 2 System 3 System 3 Boundary clock operation Transparent clock operation Figure 14.1: Boundary clock versus transparent clock switch synchronization mode 14.2.1...

  • Page 362: Switches Using Transparent Clocks

    GEN3t 14.2.2 Switches using transparent clocks Switches using transparent clocks forward the master clock synchronization message to every port of the switch. The time required to transfer the message from the incoming port to the outgoing port must be measured and transferred together with the original synchronization message.
  • Page 363 GEN3t Master Master Slave Slave time time time time Sync (t1) Sync t-ms t-ms Follow_Up (t1) Delay_Req Delay_Req t-sm t-sm Delay_Resp (t4) Delay_Resp (t4) One-Step clock synchronization Two-Step clock synchronization Figure 14.2: One-Step versus Two-Step clock synchronization HBM systems are designed to work with End-to-End Two-Step PTP protocol only.

  • Page 364: Transparent Clock Switch Synchronization

    GEN3t 14.3 Transparent clock switch synchronization The operation of PTP relies on a measurement of the communication path delay between the time source, referred to as a master, and the receiver, referred to as a slave. This process involves a message transaction between the master and slave where the precise moments of transmit and receive are measured - preferably at the hardware level.
  • Page 365 GEN3t Master Slave time time Timestamps known by slave Sync t-ms Follow_Up Delay_Req t-sm Delay_Resp (t4) Figure 14.3: Master/Slave offset measurement The message exchange process is as follows: The master sends a Sync message to the slave and notes the time, t , at which it was sent.
  • Page 366 GEN3t After this message exchange, the slave has four timestamps from which both the slave offset (time offset by which the slave clock leads or lags the master) and the network delay (the time taken for packets to traverse the network link between the two nodes) can be determined.

  • Page 367: Switch Delays

    GEN3t If two sets of Sync and Follow up messages are sent, then the drift between the two clocks (the phase change rate) can be found by comparing the Δtime between the successive sync messages. Drift = HINT/TIP Grand masters might have a setting to control the number of synchronization events sent per second time interval.

  • Page 368: Common Terms Used In Ieee

    GEN3t 14.4 Common terms used in IEEE 1588 (source www.nist.gov/el/isd/ieee/terms1588.cfm) Boundary clock: A boundary clock is a clock with more than a single PTP port, with each PTP port providing access to a separate PTP communication path. Boundary clocks are used to eliminate fluctuations produced by routers and similar network elements.
  • Page 369 GEN3t Synchronized clocks: Two clocks are synchronized to a specified uncertainty if they have the same epoch and measurements of any time interval by both clocks differ by no more than the specified uncertainty. The timestamps generated by two synchronized clocks for the same event differ by no more than the specified uncertainty.

  • Page 370: Gen Series Synchronization Methods Compared

    GEN3t 14.5 GEN series synchronization methods compared GEN series systems support four different synchronization methods. Each method has its own advantages and disadvantages. It is mostly the customer's application use that determines the correct choice. Synchronization overview Master/Slave PTP IRIG...

  • Page 371: Trigger Synchronization

    GEN3t HINT/TIP As a square wave has an instantaneous transition by definition, it is not possible to establish phase shifts smaller than a single sample period. A complex but more accurate phase shift measurement uses a sine wave with a period time that is ten times lower than the specified phase shift.
  • Page 372 GEN3t It is important to know that sweeps are shown with the trigger aligned at t . The net effect is that triggers received with a time delay are actually time shifted in the software, as if these triggers had happened 100% synchronous in time. If triggers are not 100% synchronous in all systems, signal phase shifts are introduced by this effect.

  • Page 373: Absolute Time Of Day Synchronization

    GEN3t 14.5.3 Absolute time of day synchronization The relevancy of this synchronization is a pure user application requirement. GEN series systems are synchronized to the controlling PC when Perception makes the first connection to the mainframe. If the PC is connected to the...

  • Page 374: Start/Stop Synchronization

    GEN3t Satellite GPS signal GPS receiver 1 GPS receiver 2 PTP1 POWER OUT PTP2 24V 1.5A max GEN series system 1 GEN series system 2 Figure 14.7: Typical GPS absolute time of day setup 14.5.4 Start/Stop synchronization When using multiple mainframes in continuous mode, expectations are typically that the first sample of each channel aligns.
  • Page 375 GEN3t When in Single sweep, Multiple sweep or Slow-Fast Sweep mode, the start and stop synchronization of the recording is irrelevant. The entire recorded sweep data is determined by the trigger origin with a fixed pre- and post-trigger time frame. In sweep-based recordings, the acquisition system is typically started first.

  • Page 376: Synchronization Specification Overview

    GEN3t 14.5.5 Synchronization specification overview Mainframe1 Transferred Trigger Trigger origin Mainframe 2 Transferred Trigger Mainframe N start phase trigger stop Figure 14.9: Synchronization specification overview Master to (4) (5) QuantumX phase start stop trigger Slave and Support Slave to Slave tim-...
  • Page 377 GEN3t (1) t Maximum phase difference between signals. (This specification phase is not affected by any of the other specifications). (2) t Maximum delay between start of recording of each mainframe. start (3) t Maximum delay between stop of recording of each mainframe.

  • Page 378: 15 Understanding Inputs And Usage Of Probes

    GEN3t 15 Understanding Inputs and Usage of Probes 15.1 GEN series inputs Note Every manufacturer uses different names for similar or even identical types of inputs. Some of the terminology used is described in this section. Balanced Vs Unbalanced A balanced input describes an input stage where both input terminals exhibit the same electrical behavior, such as resistance and capacitance.

  • Page 379: Single-Ended Input

    GEN3t 15.1.1 Single-ended input A single-ended input is not isolated and uses unbalanced inputs. 900 k (–) Figure 15.1: Single-ended amplifier One input is connected to ground Resistance / Capacitance from each terminal to ground is different Amplifier is typically found in oscilloscopes...
  • Page 380 GEN3t 900 k 10 * U (–) Figure 15.2: Single-ended amplifier with passive probe An inline resistor acts as a voltage divider using the input resistance of the amplifier The amplifier itself measures only U ; the total input range is 10 * U...

  • Page 381: Balanced Differential Input

    GEN3t 15.1.2 Balanced differential input A balanced differential input is not isolated and uses balanced inputs. 900 k diff (–) in– (–) 900 k Figure 15.3: Balanced differential amplifier Resistance / Capacitance from each terminal to ground is identical There is NO ISOLATION...

  • Page 382: Isolated Single-Ended Or Isolated Unbalanced Differential Input

    GEN3t 15.1.3 Isolated single-ended or Isolated unbalanced differential input Non-isolated system 900 k diff (–) (–) Isolation Barrier Figure 15.4: Isolated single-ended or Isolated unbalanced differential amplifier Also referred to as unbalanced, isolated or unbalanced differential amplifier None of the inputs are connected to ground for safety and to avoid ground...
  • Page 383 GEN3t Non-isolated system 900 k 10 * U diff diff (–) (–) (–) Isolation Barrier Figure 15.5: Isolated single-ended or Isolated unbalanced differential amplifier with passive probe Also referred to as unbalanced, isolated or unbalanced differential amplifier with probe None of the inputs are connected to ground...

  • Page 384: Isolated Balanced Differential Input

    GEN3t 15.1.4 Isolated balanced differential input An isolated balanced differential input is isolated and uses balanced inputs. Isolated measurement ground is not often available. Non-isolated system 900 k Isolated GND diff (–) in– (–) 900 k Figure 15.6: Isolated balanced differential amplifier...
  • Page 385 GEN3t Different amplifiers – Pros and Cons Single-ended (to ground) amplifiers Cost effective and small High bandwidth Easy to use with probes Potential ground problems No safety problems No CMRR and no CMV Single-ended isolated amplifier – unbalanced differential Can perform differential measurements...

  • Page 386: Gen Series Voltage Probe Types

    GEN3t 15.2 GEN series voltage probe types HBM offers a variety of probes. Which probe is needed depends on the application and which instrument is being used. It is important to match the compensation of the probe to the instrument.

  • Page 387: Passive, Single-Ended Voltage Probes

    GEN3t 15.2.1 Passive, single-ended voltage probes Voltage probes divide a single-ended input signal by a specific factor. Passive Probe 900K 10 * U in U in Single-ended amplifier Figure 15.7: Typical example of a voltage probe Theoretically, voltage probes are simply passive in-line resistors in series with the positive input of a single-ended amplifier.
  • Page 388 GEN3t Table 15.1: Voltage probes overview table 7 - 75 pF 1 ± 2% 1.2 m 12 MHz 55 V RMS 1-G901-2 10 ± 2% 200 MHz 300 V RMS 7 - 75 pF 1 ± 2% 12 MHz 55 V RMS 1-G902-2 10 ±...
  • Page 389 GEN3t - ended voltage probe overview Table 15.2: Passive, single Input card GN110/GN111 GN112/GN113 GN114 GN410/GN411 GN412/GN413 GN440/GN441 GN610/GN611 GN610B/GN611B GN810/GN811 GN812/GN813/GN814 GN815/GN816 GN840B GN1610/GN1611 GN1640B GN3210/GN3211 GENIS-1T/GENIS-1TM I3995-3.1 en HBM: public...

  • Page 390: Passive, Single-Ended Isolated Voltage Probes

    GEN3t 15.2.2 Passive, single-ended isolated voltage probes Passive, single-ended isolated voltage probes divide an isolated input signal by a specific factor. They are designed in an “isolated way” (like plastic BNCs to prevent users from touching the connection) so they can be used in series with an isolated unbalanced amplifier.
  • Page 391 GEN3t Table 15.3: Voltage probes for ISOLATED amplifiers overview table 30 - 70 pF 100 ± 2% 1.2 m 50 MHz 3.5 kV RMS 1-G057-2 1 kV RMS CAT II 600 V RMS CAT III See "High accuracy voltage probes for isolated amplifiers overview table" on page 393 for the overview matrix of this probe.

  • Page 392: High Accuracy Passive, Single-Ended Isolated Voltage Probes

    GEN3t 15.2.3 High accuracy passive, single-ended isolated voltage probes High accuracy passive, single-ended isolated voltage probes divide an isolated input signal by a specific factor. They are designed in an “isolated way" so that they can be used in series with an isolated unbalanced amplifier. They are called “isolated voltage probes”, although the amplifier and not the probe adds...
  • Page 393 GEN3t Table 15.4: High accuracy voltage probes for isolated amplifiers overview table 10 ± 0.1% 250 kHz 1 kV DC 1.2 m 1-G041-2 DC Coupled 1 ± 0.1% 1.2 m 250 kHz 1 kV DC 100 V 1-G042-2 AC coupled - ended isolated voltage probe overview Table 15.5: Passive, single...

  • Page 394: Passive, Differential Matched Isolated Voltage Probes

    GEN3t 15.2.4 Passive, differential matched isolated voltage probes Passive, differential matched isolated voltage probes are used in series with differential amplifiers and divide a differential input signal by a specific factor. Passive probe 900K 10 x U diff U diff...
  • Page 395 GEN3t Table 15.6: Passive differential voltage probes overview table 200 ± 2% 100 – 140 pF 3 m 20 MHz 2.8 kV RMS 1-G025-2 4 kV DC 10 ± 2% 105 – 140 pF 3 m 100 MHz 400 V RMS...

  • Page 396: Active Differential Voltage Probes

    GEN3t 15.2.5 Active differential voltage probes Active differential voltage probes are battery-powered, differential amplifiers in series with any input amplifier in single-ended mode. Figure 15.11: Typical example of an active differential voltage probe The achievable input range and accuracy depends on which active differential probe is used.

  • Page 397: Lds Probe Part Number Reference Table

    GEN3t 15.2.6 LDS probe part number reference table Type Part number Part number Passive voltage 869-923900 1-G901-2 Passive voltage 869-924900 1-G902-2 Passive voltage 869-925000 1-G903-2 Passive voltage 117-901600 1-G904-2 Passive voltage 085-953700 1-G906-2 Isolated 1-G057-2 Isolated 846-948000 1-G041-2 Isolated, AC only...

  • Page 398: Probe Accessories

    GEN3t 15.2.7 Probe accessories Probe accessories 1-G910-2 (LDS 040-747900) Probe tip adapters with 4 mm safety- shrouded banana plugs. Include tip and ground lead adapters and two alligator clips with 1" jaw opening. Use on probes G901 and G902 only.

  • Page 399: Probes Master List

    GEN3t 15.2.8 Probes master list Table 15.9: Genesis Highspeed Probes MASTER list with part number and vendor list HBM Part number Type Vendor Vendor type name passive, single- 1-G901-2 PMK 869-923900 ended, switchable passive, single- 1-G902-2 PMK 869-924900 ended, switchable...

  • Page 400: Probe Bandwidth Calibration

    GEN3t 15.3 Probe bandwidth calibration A probe makes a physical and electrical connection between a test point or signal source and the instrument. Depending on the measurement needs, this connection can be made with something as simple as a length of wire or with something as sophisticated as an active differential probe.
  • Page 401 GEN3t V IN Frequency Figure 15.13: Frequency response with 1X probe Example: Assuming that the voltage source has a 1 MΩ resistance and the 1X probe has a 50 pF capacitance (a 1X probe has no resistance by itself ), the universal amplifier input would have a 1 MΩ...

  • Page 402: Probes

    GEN3t 15.3.2 10X Probes 10X probes (also called 10:1 probes, divider probes, or attenuating probes) have a resistor and capacitor (in parallel) inserted into the probe. Figure 15.14 shows the circuit diagram for the 10X probe connected to a high- impedance input of an instrument.

  • Page 403: Probes And Differential Measurements

    GEN3t IMPORTANT To perform the compensation correctly, both impedances must have the same value, i.e. R . In practice, R will never be equal to , but the values can be approximated. The probe’s compensation capacitor is usually adjustable somewhere between 10 pF and 50 pF to compensate for the instrument’s input capacitance.

  • Page 404: Current Shunt Measurements

    GEN3t 15.4 Current shunt measurements Special care must be taken with shunt measurements. Typical shunt measurements generate signals with an amplitude of only a few volts or even mV. To prevent interference from higher voltage signals (up to 100 V), the following guidelines apply: Use only coaxial cables for all measurements.

  • Page 405: A Specifications

    Solid State Drive or it can store recorded data directly on an external Network Attached Storage (NAS) device. To synchronize the absolute time to other systems, GEN3t supports the PTP protocol on both 1 Gbit/s Ethernet ports. Full transparent time and trigger synchronization on multiple GEN DAQ systems can be done using the standard optical Master/Slave synchronization connector.
  • Page 406 GEN3t Acquisition System System Time Base and Synchronization Central time base for all acquisition cards ± 3.5 ppm; aging after 10 years ± 10 ppm Accuracy Base Binary, Decimal or External Synchronization sources IEEE1588:2008 PTP V2 (Precision Time Protocol) using a Two-Step master, End-to-End protocol Master/Slave synchronization;...
  • Page 407 GEN3t Connection Overview Enabled Enabled DC Power Mains Power Network Network Output Supply Optical RJ45 Connector Digital Event/ Power Power LED Master/Slave Probe Calibration Timer/Counter Indicator button Synchronization Figure A.2: Connection overview I3995-3.1 en HBM: public...
  • Page 408 GEN3t 1 Gbit Network Interface GEN3t supports an electrical and optional optical 1 Gbit Ethernet connector PTP Enabled Network Optical PTP Enabled Network RJ45 Figure A.3: Electrical and optical 1 Gbit network interface Standard Ethernet 1000BASE-T; 1 Gbit, Cat 5e UTP or STP (RJ-45 connector) Optical Ethernet 1000BASE-SX or 1000BASE-LX;...
  • Page 409 GEN3t GEN3t Recorded Data Storage Overview GEN series mainframes support different ways of storing data. Continuous streaming throughput is tested by using 48 hours of circular recordings at specified data rates. GEN DAQ Mainframe Storage SSD G073 (Built-in/not visible) Perception PC Storage...
  • Page 410 GEN3t Streaming Compression Ratio Acquisition cards Sample width Compression ratio 16 bit storage 32 bit storage 64 bit storage GN401, GN402 14 bits 1 : 1 GN410, GN411 16 bits 1 : 1 GN412, GN413 14 bits 1 : 1...
  • Page 411 GEN3t Master/Slave Synchronization GEN series mainframes support a standard Master/Slave synchronization connector. The connector can be used as a single Master output or as a Slave input. The Master output function can be extended using the Master output card (G083).
  • Page 412 GEN3t Synchronization Specification Overview Mainframe1 Transferred Trigger Trigger origin Mainframe 2 Transferred Trigger Mainframe N start phase trigger stop Figure A.6: Synchronization specification overview Master to Slave and Slave to Slave timing (4) (5) phase start stop trigger Synchronization source Master/Slave ≤...
  • Page 413 GEN3t I/O Connector Signal PIN 1 - External Time base In PIN 2 - External Event Out PIN 3 - External Trigger In PIN 4 - Ground PIN 5 - Ground PIN 6 - External Start In PIN 7 - External Trigger Out...
  • Page 414 GEN3t I/O Connector External Event Out Levels TTL compatible; 0 V < Low < 0.6 V; 2 V < High < 5 V Function Alarm or Recording Active output; software selectable Active level High/Low for Alarm output; software selectable Recording active High output...
  • Page 415 GEN3t Digital Event/Timer/Counter Event Inputs Number of event inputs 16 per card, 2 cards per connector TTL Compatible, Low -30 V to 0.7 V, High 2 V to 30 V Levels “1” “0” +0.7 +2 Input voltage Figure A.9: Logic threshold voltage levels ±...
  • Page 416 PIN 4 - Reserved/not connected PIN 5 - Reserved/not connected PIN 6 - Reserved/not connected PIN 7 - PWR PIN 8 - Reserved/not connected Figure A.11: GEN3t DC power output Probe Calibration Pins 2; Signal and ground Signal ~1 kHz square wave Signal amplitude 0 V to 2 V using 1 MΩ...
  • Page 417 4 mm Banana plug Casing Aluminum/Plastic cover Accessories Soft carry case with strap for transportation included. The case has a hardened front and back for protection, and storage pouch 436 mm (17.2”) 186 mm (7.3”) Figure A.12: GEN3t dimensions I3995-3.1 en HBM: public...
  • Page 418 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 419 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...
  • Page 420 GEN3t Supported Acquisition Cards GN401 Multi Mode Optical Fiber 100 MS/s 2 GB standard GN402 Single Mode Optical Fiber 100 MS/s 2 GB standard GN410 Bridge/Differential 200 kS/s 16 bit 128 MB standard GN411 Bridge/Differential 1 MS/s 16 bit 512 MB...
  • Page 421 GEN3t Perception Versions Features True 64 bit support Basic review, y/t and x/y displays Horizontal, vertical and slope cursors Trace and display markers Interactive waveform calculator Interactive user keys with macros ® Quick report to Microsoft Word and Excel Automation and log-file...
  • Page 422 GEN3t Application Programming Interfaces (API) PNRF Reader (Free of Charge) Functions Read PNRF, NRF and LRF recording files directly in your own application COM interface The PNRF reader comes as a COM interface and can be used from any application or...

  • Page 423: B2629-2.1 En (Gen Series Gn401)

    GEN3t B2629–2.1 en (GEN series GN401) Capabilities Overview Receiver model GN401 Transmitter models GN110, GN111, GN112 and GN113 Maximum sample rate per channel 100 MS/s (ADC and DAC) GN111 and GN113 have a maximum 25 MS/s sample rate Memory per receiver...
  • Page 424 GEN3t Block Diagram Analog Channel Amplifier Anti-Alias Filter AC/DC/GND Not isolated 1010 GN112 and GN113 only GN110 and GN111 only 100 MS/s Removable 12 V Protective Li-ion Amplifier Settings Ground Smart Battery Synchronization Removable Optical Power 12 V Li-ion Management...
  • Page 425 GEN3t Analog Input GN110, GN111, GN112 and GN113 (Transmitter) Channels Connector 1; metal BNC Input type Isolated, unbalanced differential inputs (BNC connected to isolated common) Input Coupling Coupling modes AC / DC / GND 1.6 Hz (±10%); - 3 dB AC coupling frequency 1.6 Hz AC coupling response [dB]...
  • Page 426 GEN3t Analog Input GN110, GN111, GN112 and GN113 (Transmitter) Input overload protection Overvoltage impedance change The activation of the overvoltage protection system results in a reduced input impedance. The overvoltage protection is not active for as long as the input voltage remains less than 200% of the selected input range or 250 V, whichever value is the smallest.
  • Page 427 GEN3t Anti-Alias Filters Using different filter selections (Wideband/Bessel/Bessel IIR) or different filter bandwidths can result in phase mismatches between channels. FLASH ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure A.15: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter in front of the Analog to Digital Converter (ADC).
  • Page 428 GEN3t Wideband (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Wideband bandwidth Between 27 MHz and 36 MHz (-3 dB) DC to 1 MHz 0.1 dB passband flatness...
  • Page 429 GEN3t Bessel and Bessel IIR filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs...
  • Page 430 GEN3t Bessel and Bessel IIR filter (Digital Anti-Alias) ± 0.2 V Overview ± 0.2 V Passband flatness 2.33 10.0 1.15 -10.0 -20.0 -30.0 -0.1 -1.14 -40.0 -2.28 -0.2 -50.0 0.01 0.01 Frequency [MHz] Frequency [MHz] ± 2 V Overview ± 2 V Passband flatness 2.33...
  • Page 431 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel/Bessel IIR) or different filter bandwidths results in phase mismatches between channels. Maximum ± 10 ns Channel to channel phase difference Fiber cable length compensation Yes, automatic when optical communication is established Optical cable delay is compensated to phase match standard GEN DAQ channels.
  • Page 432 GEN3t Triggering Analog channel trigger modes Basic POS or NEG crossing; single level Dual level One POS and one NEG crossing; Two individual levels, OR-ed Window Arm/trigger and a disarm level; Trigger on peak level changes in a uni-polar signal Dual Window Arm/trigger/disarm per level;...
  • Page 433 GEN3t Acquisition Modes Dual Combination of Multiple sweeps and Continuous; recorder type streaming to hard disk with simultaneously triggered sweeps in on-board memory. Aggregate sample rate limitations depend on Ethernet speed, PC used and data storage media used. In Dual mode the RT-FDB calculators sample based results are only calculated for the sweep sections of the recorded data.
  • Page 434 GEN3t Multiple Sweeps Sweep storage rate Determined by the total number of selected channels and mainframes, mainframe type, Ethernet speed, PC storage medium and other PC parameters. For details, please refer to the mainframe datasheet. Exceeding sweep storage rate Trigger event markers are stored in a recording. No sweep data is stored. New sweep data is recorded as soon as enough internal memory is available to capture a full sweep when a trigger occurs.
  • Page 435 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 436 GEN3t Analog Output GN401 (Receiver) Channels 4; 1 per transmitter channel (GN110, GN111, GN112 and GN113) Connector 4; Metal BNC, one BNC per channel on receiver front panel Conversion 100 MS/s D-to-A converter per channel DAC Resolution 14 bit (0.006%)
  • Page 437 GEN3t Physical, Weight and Dimensions GN110 and GN111 Weight 4.6 kg (10 lb) including two batteries Dimensions including handles 175 mm (6.89") x 277 mm (10.91") x 119 mm (4.69") (W x D x H) Battery carrier 2 (batteries need to be ordered separately) Shielding and casing Single metal shielding in plastic housing.
  • Page 438 GEN3t Environmental Specifications Temperature Range GN110 and GN111: -15 °C to +50 °C (+5 °F to +122 °F) Operational GN112 and GN113: 0 °C to +40 °C (+32 °F to +104 °F) GN401: 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F)
  • Page 439 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 440: B2633-2.1 En (Gen Series Gn410)

    GEN3t B2633–2.1 en (GEN series GN410) Capabilities Overview Model GN410 Maximum sample rate per channel 200 kS/s Memory per card 128 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 16 bit...
  • Page 441 GEN3t Block Diagram Channel 1 to 4 Excitation Off / Voltage / Current Sense On/Off Sense (+) Excitation (+) Sense (-) Excitation (-) 350 Ω 3 Wire User Ω ¼ Bridge Completion Card ½ Bridge ½ Bridge Select Shunt Ext Shunt cm...
  • Page 442 GEN3t Analog Input Section Channels Connectors 16 pin Lemo with connector chassis grounded, 1 per channel Lemo EGG.2B.316.CYM Mating connector Lemo FGG.2B.316.CLAD52 Input type Analog, isolated balanced differential 2 * 10 MΩ ± 1% // 130 pF ± 10% Input impedance...
  • Page 443 GEN3t Bridge Mode Supported sensors Quarter/half/full bridge; strain gauge based sensors: load cells, force transducers, torque transducers and pressure transducers 3 wire support; the 3rd wire keeps the measurement wire current free, eliminating wire Quarter-bridge completion resistance errors in the measurement wire Built-in quarter-bridge completion resistor 350 Ω, 0.11%, 0.6 ppm/...
  • Page 444 GEN3t Basic Sensor Mode Supported sensors Strain gauge bridge sensors using voltage or current excitation Force, Pressure, MEMS- type Accelerometers and Potentiometric Displacement transducers, PT100 and PT1000 Sensor excitation modes User selectable Off, constant voltage or constant current Constant voltage excitation Bipolar ±...
  • Page 445 GEN3t Isolation Isolated channel Isolated channel Chassis Figure A.27: Isolation schematic 33 V RMS, ± 50 V DC Channel to chassis (earth) 33 V RMS, ± 70 V DC Channel to channel (Isolated GND to isolated GND) 55 V RMS, ± 100 V DC...
  • Page 446 GEN3t Anti-Alias Filters Using different filter selections (Bessel IIR/FIR/etc.) or different filter bandwidths can result in phase mismatches between channels. SAR ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure A.28: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter in front of the Analog to Digital Converter (ADC).
  • Page 447 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.29: Digital Bessel IIR filter...
  • Page 448 GEN3t FIR (Fc @ -0.1 dB) Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs : Stopband attenuation ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp = ωc ωs Frequency [kHz] Figure A.31: Digital FIR (Fc @ -0.1 dB) filter...
  • Page 449 GEN3t FIR (Fc @ -3 dB) Filter (Digital Anti-Alias) δp : Passband ripple + δp - δp δs : Stopband attenuation -3 dB ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp ωc ωs...
  • Page 450 GEN3t On-board Memory Per card 128 MB (64 MS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 451 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Manual trigger (Software) Supported External Trigger In Selection per card...
  • Page 452 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 453 GEN3t Recording Mode Details Single Sweep Multiple Sweeps Slow-Fast Sweep Continuous Dual Rate Enabled channels Enabled channels Enabled channels 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch Max. sweep memory...
  • Page 454 GEN3t Slow-Fast Sweep Maximum number of sweeps 1 per recording Maximum slow sample rate Fast sample rate divided by two or 50 kS/s per channel, whichever is the smallest sample rate Maximum sample rate switches 20, sample rate switching always stops when sweep ends Minimum time between sample rate switches 2.5 ms...
  • Page 455 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 456 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 457 GEN3t Harmonized standards for CE compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 458: B2639-2.1 En (Gen Series Gn411)

    GEN3t B2639–2.1 en (GEN series GN411) Capabilities Overview Model GN411 Maximum sample rate per channel 1 MS/s Memory per card 512 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 16 bit...
  • Page 459 GEN3t Block Diagram Channel 1 to 4 Excitation Off / Voltage / Current Sense On/Off Sense (+) Excitation (+) Sense (-) Excitation (-) 350 Ω 3 Wire User Ω ¼ Bridge Completion Card ½ Bridge ½ Bridge Select Shunt Ext Shunt cm...
  • Page 460 GEN3t Analog Input Section Channels Connectors 16 pin Lemo with connector chassis grounded, 1 per channel Lemo EGG.2B.316.CYM Mating connector Lemo FGG.2B.316.CLAD52 Input type Analog, isolated balanced differential 2 * 10 MΩ ± 1% // 130 pF ± 10% Input impedance...
  • Page 461 GEN3t Bridge Mode Supported sensors Quarter/half/full bridge; strain gauge based sensors: load cells, force transducers, torque transducers and pressure transducers 3 wire support; the 3rd wire keeps the measurement wire current free, eliminating wire Quarter-bridge completion resistance errors in the measurement wire Built-in quarter-bridge completion resistor 350 Ω, 0.11%, 0.6 ppm/...
  • Page 462 GEN3t Basic Sensor Mode Supported sensors Strain gauge bridge sensors using voltage or current excitation Force, Pressure, MEMS- type Accelerometers and Potentiometric Displacement transducers, PT100 and PT1000 Sensor excitation modes User selectable Off, constant voltage or constant current Constant voltage excitation Bipolar ±...
  • Page 463 GEN3t Isolation Isolated channel Isolated channel Chassis Figure A.41: Isolation schematic 33 V RMS, ± 50 V DC Channel to chassis (earth) 33 V RMS, ± 70 V DC Channel to channel (Isolated GND to isolated GND) 55 V RMS, ± 100 V DC...
  • Page 464 GEN3t Anti-Alias Filters Using different filter selections (Wideband/Bessel IIR/FIR/etc.) or different filter bandwidths can result in phase mismatches between channels. SAR ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure A.42: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter in front of the Analog to Digital Converter (ADC).
  • Page 465 GEN3t Wideband Filter (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Bandwidth Between 120 kHz and 160 kHz (-3 dB) all ranges < 100mV Between 450 kHz and 520 kHz (-3 dB) all ranges ≥...
  • Page 466 GEN3t Digital Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.44: Digital Bessel IIR Filter...
  • Page 467 GEN3t Digital FIR (Fc @ -0.1 dB) Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs : Stopband attenuation ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp = ωc ωs Frequency [kHz] Figure A.46: Digital FIR (Fc @ -0.1 dB) filter...
  • Page 468 GEN3t Digital FIR (Fc @ -3 dB) Filter (Digital Anti-Alias) δp : Passband ripple + δp - δp δs : Stopband attenuation -3 dB ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp ωc...
  • Page 469 GEN3t On-board Memory Per card 512 MB (256 MS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 470 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Manual trigger (Software) Supported External Trigger In Selection per card...
  • Page 471 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 472 GEN3t Recording Mode Details Single Sweep Multiple Sweeps Slow-Fast Sweep Continuous Dual Rate Enabled channels Enabled channels Enabled channels 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch Max. sweep memory...
  • Page 473 GEN3t Slow-Fast Sweep Maximum number of sweeps 1 per recording Maximum slow sample rate Fast sample rate divided by two or 50 kS/s per channel, whichever is the smallest sample rate Maximum sample rate switches 20, sample rate switching always stops when sweep ends Minimum time between sample rate switches 2.5 ms...
  • Page 474 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 475 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 476 GEN3t Harmonized standards for CE compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 477: B2627-2.1 En (Gen Series Gn412)

    GEN3t B2627-2.1 en (GEN series GN412) Capabilities Overview Model GN412 Maximum sample rate per channel 100 MS/s Memory per card 2 GB (1 GS) Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with a range of fixed bandwidth digital AA-filter...
  • Page 478 GEN3t Block Diagram Digital Filter & Channel 1 to 4 Amplifier Analog Anti-Alias Filter Sample Rate selection Σ 1010 AC/DC/GND 100 MHz Probe Power + 8 V Sample Rate 100 MHz Communication Channel & & Memory & Synchronization Card Trigger Recording control &...
  • Page 479 GEN3t Analog Input Channels Connector 2 per channel; Metal BNC Input type Balanced differential inputs Input coupling Single-ended positive, single-ended negative and differential Signal input coupling Coupling modes AC / DC / GND 1.6 Hz (±10%); - 3 dB AC coupling frequency 1.6 Hz AC coupling response [dB]...
  • Page 480 GEN3t Analog to Digital Conversion Sample rate per channel 1 S/s to 100 MS/s ADC resolution; one ADC per channel 14 bit ADC Type CMOS pipelined multistep converter, LTC2254 Defined by mainframe: ± 3.5 ppm ; aging after 10 years ± 10 ppm...
  • Page 481 GEN3t Wideband (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Wideband bandwidth Between 26 MHz and 33 MHz (-3 dB) DC to 1 MHz 0.1 dB passband flatness...
  • Page 482 GEN3t Bessel Filter (Analog Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.54: Bessel Filter...
  • Page 483 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.56: Digital Bessel IIR Filter...
  • Page 484 GEN3t On-Board Memory Per card 2 GB (1 GS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 485 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Manual trigger (Software) Supported External Trigger In Selection per card...
  • Page 486 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 487 GEN3t Single Sweep 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 488 GEN3t Continuous Continuous modes supported Standard, Circular recording, Specified time and Stop on trigger Standard User starts and stops recording. Recording is stopped when the storage media is full Circular recording User specified recording history on storage media. All recorded data is stored on the storage media as quickly as possible.
  • Page 489 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 490 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 491 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 492: B4160-1.1 En (Gen Series Gn413)

    GEN3t B4160-1.1 en (GEN series GN413) Capabilities Overview Model GN413 Maximum sample rate per channel 25 MS/s Memory per card 200 MB (100 MS) Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with a range of fixed bandwidth digital AA-filter...
  • Page 493 GEN3t Block Diagram Digital Filter & Channel 1 to 4 Amplifier Analog Anti-Alias Filter Sample Rate selection Σ 1010 AC/DC/GND 100 MHz Probe Power + 8 V Sample Rate 100 MHz Communication Channel & & Memory & Synchronization Card Trigger Recording control &...
  • Page 494 GEN3t Analog Input Channels Connector 2 per channel; Metal BNC Input type Balanced differential inputs Input coupling Single-ended positive, single-ended negative and differential Signal input coupling Coupling modes AC / DC / GND 1.6 Hz (±10%); - 3 dB AC coupling frequency 1.6 Hz AC coupling response [dB]...
  • Page 495 GEN3t Analog to Digital Conversion Sample rate per channel 1 S/s to 25 MS/s ADC resolution; one ADC per channel 14 bit ADC Type CMOS pipelined multistep converter, LTC2254 Defined by mainframe: ± 3.5 ppm ; aging after 10 years ± 10 ppm...
  • Page 496 GEN3t Bessel Filter (Analog Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.62: Bessel Filter...
  • Page 497 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.64: Digital Bessel IIR Filter...
  • Page 498 GEN3t On-board Memory Per card 200 MB (100 MS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 499 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Manual trigger (Software) Supported External Trigger In Selection per card...
  • Page 500 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 501 GEN3t Single Sweep 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 502 GEN3t Continuous Continuous modes supported Standard, Circular recording, Specified time and Stop on trigger Standard User starts and stops recording. Recording is stopped when the storage media is full Circular recording User specified recording history on storage media. All recorded data is stored on the storage media as quickly as possible.
  • Page 503 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 504 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 505 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 506: B2631-2.0 En (Gen Series Gn440)

    GEN3t B2631-2.0 en (GEN series GN440) Capabilities Overview Model GN440 Maximum sample rate per channel 200 kS/s Memory per card 128 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 16 bit...
  • Page 507 GEN3t Block Diagram IEPE Digital Filter & Channel 1 to 4 Amplifier Analog Anti-Alias Filter Isolation Sample Rate selection Σ 1010 Current AC/DC/GND 1.0 or 1.024 MHz Sample Rate 1.0 or 1.024 MHz Communication Channel & & Memory & Synchronization...
  • Page 508 GEN3t Analog Input Section Channels Connectors 2 isolated (plastic) BNCs per channel Input type Analog, isolated balanced differential 2 * 1 MΩ ± 1% // 100 pF ± 10% Input impedance Input coupling Coupling modes Current, AC, DC, GND 0.16 Hz, ± 10%; -3 dB AC coupling frequency 0.16 Hz AC coupling response [dB]...
  • Page 509 GEN3t IEPE Sensor ± 10 mV, ± 20 mV, ± 50 mV, ± 0.1 V, ± 0.2 V, ± 0.5 V, ± 1 V, ± 2 V, ± 5 V, ± 10 V, ± 20 V Input ranges - 1 V of Full Scale...
  • Page 510 GEN3t Analog to Digital Conversion Sample rate per channel 0.1 S/s to 200 kS/s ADC resolution; one ADC per channel 16 bit ADC Type Successive Approximation Register (SAR); TI ADS8401IB Defined by mainframe: ± 3.5 ppm ; aging after 10 years ± 10 ppm...
  • Page 511 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.71: Digital Bessel IIR filter...
  • Page 512 GEN3t FIR (Fc @ -0.1 dB) Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs : Stopband attenuation ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp = ωc ωs Frequency [kHz] Figure A.73: Digital FIR (Fc @ -0.1 dB) filter...
  • Page 513 GEN3t FIR (Fc @ -3 dB) Filter (Digital Anti-Alias) δp : Passband ripple + δp - δp δs : Stopband attenuation -3 dB ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp ωc ωs...
  • Page 514 GEN3t On-board Memory Per card 128 MB (64 MS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 515 GEN3t Triggering Trigger hold off Disable channel trigger for 1 to 65 535 samples after trigger detected Maximum hold off time depends on sample rate Interval timer Modes Less than, trigger when rate is too low More than, trigger when rate is too high...
  • Page 516 GEN3t Recording Mode Details Single Sweep Multiple Sweeps Slow-Fast Sweep Continuous Dual Rate Enabled channels Enabled channels Enabled channels 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch Max. sweep memory...
  • Page 517 GEN3t Slow-Fast Sweep Maximum number of sweeps 1 per recording Maximum slow sample rate Fast sample rate divided by two or 50 kS/s per channel, whichever is the smallest sample rate Maximum sample rate switches 20, sample rate switching always stops when sweep ends Minimum time between sample rate switches 2.5 ms...
  • Page 518 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 519 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 520 GEN3t Harmonized standards for CE compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 521: B2631-2.0 En (Gen Series Gn441)

    GEN3t B2631-2.0 en (GEN series GN441) Capabilities Overview Model GN441 Maximum sample rate per channel 1 MS/s Memory per card 512 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 16 bit...
  • Page 522 GEN3t Block Diagram IEPE Digital Filter & Channel 1 to 4 Amplifier Analog Anti-Alias Filter Isolation Sample Rate selection Σ 1010 Current AC/DC/GND 1.0 or 1.024 MHz Sample Rate 1.0 or 1.024 MHz Communication Channel & & Memory & Synchronization...
  • Page 523 GEN3t Analog Input Section Channels Connectors 2 isolated (plastic) BNCs per channel Input type Analog, isolated balanced differential 2 * 1 MΩ ± 1% // 100 pF ± 10% Input impedance Input coupling Coupling modes Current, AC, DC, GND 0.16 Hz, ± 10%; -3 dB AC coupling frequency 0.16 Hz AC coupling response [dB]...
  • Page 524 GEN3t IEPE Sensor ± 10 mV, ± 20 mV, ± 50 mV, ± 0.1 V, ± 0.2 V, ± 0.5 V, ± 1 V, ± 2 V, ± 5 V, ± 10 V, ± 20 V Input ranges - 1 V of Full Scale...
  • Page 525 GEN3t Analog to Digital Conversion Sample rate per channel 0.1 S/s to 1 MS/s ADC resolution; one ADC per channel 16 bit ADC Type Successive Approximation Register (SAR); TI ADS8401IB Defined by mainframe: ± 3.5 ppm ; aging after 10 years ± 10 ppm...
  • Page 526 GEN3t Wideband Filter (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Bandwidth Between 290 kHz and 330 kHz (-3 dB) all ranges < 200 mV Between 490 kHz and 550 kHz (-3 dB) all ranges ≥...
  • Page 527 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.82: Digital Bessel IIR filter...
  • Page 528 GEN3t FIR (Fc @ -0.1 dB) Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs : Stopband attenuation ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp = ωc ωs Frequency [kHz] Figure A.84: Digital FIR (Fc @ -0.1 dB) filter...
  • Page 529 GEN3t FIR (Fc @ -3 dB) Filter (Digital Anti-Alias) δp : Passband ripple + δp - δp δs : Stopband attenuation -3 dB ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp ωc ωs...
  • Page 530 GEN3t On-board Memory Per card 512 MB (256 MS) Organization Automatic distribution amongst enabled channels Memory diagnostics Automatic memory test when system is powered on but not recording Storage sample size 16 bits, 2 bytes/sample Digital Events/Timer/Counter Digital event inputs...
  • Page 531 GEN3t Triggering Trigger hold off Disable channel trigger for 1 to 65 535 samples after trigger detected Maximum hold off time depends on sample rate Interval timer Modes Less than, trigger when rate is too low More than, trigger when rate is too high...
  • Page 532 GEN3t Recording Mode Details Single Sweep Multiple Sweeps Slow-Fast Sweep Continuous Dual Rate Enabled channels Enabled channels Enabled channels 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch 1 Ch 2 Ch 4 Ch Max. sweep memory...
  • Page 533 GEN3t Slow-Fast Sweep Maximum number of sweeps 1 per recording Maximum slow sample rate Fast sample rate divided by two or 50 kS/s per channel, whichever is the smallest sample rate Maximum sample rate switches 20, sample rate switching always stops when sweep ends Minimum time between sample rate switches 2.5 ms...
  • Page 534 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 535 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 536 GEN3t Harmonized standards for CE compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 537: B3618-4.2 En (Gen Series Gn610)

    GEN3t B3618-4.2 en (GEN series GN610) Capabilities Overview Model GN610 Maximum sample rate per channel 2 MS/s Memory per card 2 GB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 18 bit...
  • Page 538 GEN3t Analog Input Section Channels Connectors Fully isolated 4 mm banana plugs (plastic), 2 per channel (red and black) Input type Analog, isolated balanced differential 2 * 1 MΩ ± 1% // 33 pF ± 10% ranges larger than ± 5 V. All other ranges 57 pF ± 10%...
  • Page 539 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 10 V Larger than or equal to ± 10 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 540 GEN3t Isolation Isolated channel ±1000 V RMS 600 V CAT II Reinforced Isolated channel ±1000 V RMS 600 V CAT II Reinforced Chassis Figure A.91: Isolation 1kV card overview CAT II CAT III Channel to chassis (earth) 1000 V RMS...
  • Page 541 GEN3t Anti-Alias Filters Note on phase matching channels. Every filter characteristic and/or filter bandwidth selection comes with it's own specific phase response. Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can result in phase mismatches between channels.
  • Page 542 GEN3t Wideband (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Wideband bandwidth Between 900 kHz and 1500 kHz (-3 dB) DC to 160 kHz 0.1 dB passband flatness...
  • Page 543 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.95: Representative Bessel IIR examples...
  • Page 544 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.97: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 545 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.99: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 546 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. All specifications are typical static values and measured using a 100 kHz sine wave and 2 MS/s sample rate.
  • Page 547 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 548 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 549 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 550 GEN3t Timer/Counter Mode Angle In angle measurement mode the counter will use a user defined maximum angle and revert back to zero when this count value is reached. Using the reset input the measured angle can be synchronized to the mechanical angle. The real-time calculators can extract the RPM from the measured angle independent from the mechanical synchronization.
  • Page 551 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.105: Uni- and Bi-directional count timing Inputs...
  • Page 552 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 553 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 554 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.106: Real-time cycle based calculators...
  • Page 555 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 556 GEN3t Single Sweep Sweep stretch User selectable On/Off When enabled, any new trigger event occurring in the post-trigger segment of the sweep restarts the post-trigger length. If, upon the detection of a new trigger, the extended post- trigger does not fit within the sweep memory, sweep stretch does not happen. The maximum sweep stretch rate is 1 sweep stretch per 2.5 ms.
  • Page 557 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 558 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 559 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 560: B4374-1.2 En (Gen Series Gn610B)

    GEN3t A.10 B4374-1.2 en (GEN series GN610B) Capabilities Overview Model GN610B Maximum sample rate per channel 2 MS/s Memory per card 2 GB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 561 GEN3t Note The typical and maximum specification given in this data sheet are based on respectively 1 σ (68.27%) and 5 σ (99.9999%) statistical evaluations of calibration results. Cards exceeding the maximum specifications are ± 2 °C, unless specified differently.
  • Page 562 GEN3t Analog Input Section Input overload protection Overvoltage impedance change The activation of the overvoltage protection system results in a reduced input impedance. The overvoltage protection is not active for as long as the input voltage remains less than 200% of the selected input range or 1250 V, whichever value is the smallest.
  • Page 563 GEN3t DC Gain DC Gain error (% of reading) Typical Maximum Wideband 0.1% of Full Scale 0.1% of Full Scale All filters 0.1% of Full Scale 0.1% of Full Scale Wideband Typical [%] Maximum [%] DC gain error (Wideband) ± 0.01 V 0.10...
  • Page 564 GEN3t DC Offset DC Offset error (% of Full Scale) Typical Maximum 0.01% of Full Scale ± 400 μV 0.02% of Full Scale ± 600 μV Wideband 0.01% of Full Scale ± 10 μV All filters 0.01% of Full Scale...
  • Page 565 GEN3t RMS noise RMS Noise (50 Ω terminated) Typical Maximum 0.02% of Full Scale ± 50 μV 0.03% of Full Scale ± 70 μV Wideband 0.01% of Full Scale ± 20 μV 0.02% of Full Scale ± 20 μV All filters...
  • Page 566 GEN3t Basic Power Accuracy The GN610B is calibrated and checked at 53 Hz voltage and current inputs using burden resistors. During calibration burden resistors are attached to three voltage channels to enable current measurements. Specifications are given for the 2.5 Ω burden. Using the 1.0 Ω or 10.0 Ω burden will give different current ranges but identical results.
  • Page 567 GEN3t Isolation Isolated channel ±1000 V RMS 600 V CAT II Reinforced Isolated channel ±1000 V RMS 600 V CAT II Reinforced Chassis Figure A.116: Isolation 1kV card overview CAT II CAT III Channel to chassis (earth) 1000 V RMS...
  • Page 568 GEN3t Analog to Digital Conversion Sample rate; per channel 0.1 S/s to 2 MS/s ADC resolution; one ADC per channel 18 bit ADC type Successive Approximation Register (SAR); Analog Devices AD7986BCPZ Defined by mainframe: ± 3.5 ppm; aging after 10 years ± 10 ppm...
  • Page 569 GEN3t Wideband (No Anti-Alias protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Wideband bandwidth Between 900 kHz and 1500 kHz (-3 dB) 0.1 dB passband flatness...
  • Page 570 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.120: Representative Bessel IIR examples...
  • Page 571 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.122: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 572 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.124: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 573 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. All specifications are typical static values and measured using a 100 kHz sine wave and 2 MS/s sample rate.
  • Page 574 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 575 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 576 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 577 GEN3t Timer/Counter Mode Angle In angle measurement mode the counter will use a user defined maximum angle and revert back to zero when this count value is reached. Using the reset input the measured angle can be synchronized to the mechanical angle. The real-time calculators can extract the RPM from the measured angle independent from the mechanical synchronization.
  • Page 578 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.130: Uni- and Bi-directional count timing Inputs...
  • Page 579 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 580 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 581 GEN3t Real-Time Cycle Based Calculators Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.131: Real-time cycle based calculators Cycle Source...
  • Page 582 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) The real-time formula database (RT-FDB) option offers an extensive set of math routines to enable almost any real-time mathematical challenge. The database structure enables the user to define a list of mathematical equations similar to the Perception review formula database.
  • Page 583 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) Operation Sample based results Cycle based results Storage in PNRF Published on ® synchronous asynchronous recording EtherCAT Cycle based calculations CycleArea CycleCount CycleEnergy CycleFundamentalPhase CycleFrequency CycleMax CycleMean CycleMin CyclePeak2Peak CyclePhase...
  • Page 584 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 585 GEN3t Single Sweep 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 586 GEN3t Continuous Continuous modes supported Standard, Circular recording, Specified time and Stop on trigger Standard User starts and stops recording. Recording is stopped when the storage media is full Circular recording User specified recording history on storage media. All recorded data is stored on the storage media as quickly as possible.
  • Page 587 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 588 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 589: B3716-4.2 En (Gen Series Gn611)

    GEN3t A.11 B3716-4.2 en (GEN series GN611) Capabilities Overview Model GN611 Maximum sample rate per channel 200 kS/s Memory per card 200 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 590 GEN3t Analog Input Section Channels Connectors Fully isolated 4 mm banana plugs (plastic), 2 per channel (red and black) Input type Analog, isolated balanced differential 2 * 1 MΩ ± 1% // 33 pF ± 10% ranges larger than ± 5 V. All other ranges 57 pF ± 10%...
  • Page 591 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 10 V Larger than or equal to ± 10 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 592 GEN3t Isolation Isolated channel ±1000 V RMS 600 V CAT II Reinforced Isolated channel ±1000 V RMS 600 V CAT II Reinforced Chassis Figure A.136: Isolation 1kV card overview CAT II CAT III Channel to chassis (earth) 1000 V RMS...
  • Page 593 GEN3t Anti-Alias Filters Using different filter selections (Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can result in phase mismatches between channels. SAR ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure A.138: Combined analog and digital anti-alias filter block diagram...
  • Page 594 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.139: Digital Bessel IIR Filter...
  • Page 595 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.141: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 596 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.143: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 597 GEN3t Channel to Channel Phase Match Using different filter selections (Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. All specifications are typical static values and measured using a 10 kHz sine wave and 200 kS/s sample rate.
  • Page 598 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 599 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 600 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 601 GEN3t Timer/Counter Mode Angle In angle measurement mode the counter will use a user defined maximum angle and revert back to zero when this count value is reached. Using the reset input the measured angle can be synchronized to the mechanical angle. The real-time calculators can extract the RPM from the measured angle independent from the mechanical synchronization.
  • Page 602 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.149: Uni- and Bi-directional count timing Inputs...
  • Page 603 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 604 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 605 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.150: Real-time cycle based calculators...
  • Page 606 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 607 GEN3t Single Sweep Sweep stretch User selectable On/Off When enabled, any new trigger event occurring in the post-trigger segment of the sweep restarts the post-trigger length. If, upon the detection of a new trigger, the extended post- trigger does not fit within the sweep memory, sweep stretch does not happen. The maximum sweep stretch rate is 1 sweep stretch per 2.5 ms.
  • Page 608 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 609 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 610 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 611: B4375-1.1 En (Gen Series Gn611B)

    GEN3t A.12 B4375-1.1 en (GEN series GN611B) Capabilities Overview Model GN611B Maximum sample rate per channel 200 kS/s Memory per card 200 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 612 GEN3t Note The typical and maximum specification given in this data sheet are based on respectively 1 σ (68.27%) and 5 σ (99.9999%) statistical evaluations of calibration results. Cards exceeding the maximum specifications are ± 2 °C, unless specified differently.
  • Page 613 GEN3t Analog Input Section Input overload protection Overvoltage impedance change The activation of the overvoltage protection system results in a reduced input impedance. The overvoltage protection is not active for as long as the input voltage remains less than 200% of the selected input range or 1250 V, whichever value is the smallest.
  • Page 614 GEN3t DC Gain DC Gain error Typical Maximum All filters 0.1% of Full Scale 0.1% of Full Scale All filters Typical [%] Maximum [%] DC gain error (all filters) ± 0.01 V 0.10 0.10 ± 0.02 V 0.10 0.10 0.10 ±...
  • Page 615 GEN3t DC Offset DC Offset error Typical Maximum 0.01% of Full Scale ± 10 μV All filters 0.01% of Full Scale All Filters Typical Maximum Offset error (all filters) Detail offset error (all filters) 0.07 ± 0.01 V 0.010 0.060 0.015...
  • Page 616 GEN3t Basic Power Accuracy The GN610B is calibrated and checked at 53 Hz voltage and current inputs using burden resistors. During calibration burden resistors are attached to three voltage channels to enable current measurements. Specifications are given for the 2.5 Ω burden. Using the 1.0 Ω or 10.0 Ω burden will give different current ranges but identical results.
  • Page 617 GEN3t Isolation Isolated channel ±1000 V RMS 600 V CAT II Reinforced Isolated channel ±1000 V RMS 600 V CAT II Reinforced Chassis Figure A.160: Isolation 1kV card overview CAT II CAT III Channel to chassis (earth) 1000 V RMS...
  • Page 618 GEN3t Analog to Digital Conversion Sample rate per channel 0.1 S/s to 200 kS/s ADC resolution; one ADC per channel 18 bit ADC type Successive Approximation Register (SAR); Analog Devices AD7986BCPZ Defined by mainframe: ± 3.5 ppm; aging after 10 years ± 10 ppm...
  • Page 619 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.163: Digital Bessel IIR Filter...
  • Page 620 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.165: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 621 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.167: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 622 GEN3t Channel to Channel Phase Match Using different filter selections (Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. All specifications are typical static values and measured using a 10 kHz sine wave and 200 kS/s sample rate.
  • Page 623 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 624 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 625 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 626 GEN3t Timer/Counter Mode Angle In angle measurement mode the counter will use a user defined maximum angle and revert back to zero when this count value is reached. Using the reset input the measured angle can be synchronized to the mechanical angle. The real-time calculators can extract the RPM from the measured angle independent from the mechanical synchronization.
  • Page 627 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.173: Uni- and Bi-directional count timing Inputs...
  • Page 628 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 629 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 630 GEN3t Real-Time Cycle Based Calculators Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.174: Real-time cycle based calculators Cycle Source...
  • Page 631 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) The real-time formula database (RT-FDB) option offers an extensive set of math routines to enable almost any real-time mathematical challenge. The database structure enables the user to define a list of mathematical equations similar to the Perception review formula database.
  • Page 632 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) Operation Sample based results Cycle based results Storage in PNRF Published on ® synchronous asynchronous recording EtherCAT Cycle based calculations CycleArea CycleCount CycleEnergy CycleFundamentalPhase CycleFrequency CycleMax CycleMean CycleMin CyclePeak2Peak CyclePhase...
  • Page 633 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 634 GEN3t Single Sweep 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 635 GEN3t Continuous Continuous modes supported Standard, Circular recording, Specified time and Stop on trigger Standard User starts and stops recording. Recording is stopped when the storage media is full Circular recording User specified recording history on storage media. All recorded data is stored on the storage media as quickly as possible.
  • Page 636 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 637 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 638: B3997-1.1 En (Gen Series Gn815)

    GEN3t A.13 B3997-1.1 en (GEN series GN815) Capabilities Overview Model GN815 Maximum sample rate per channel 2 MS/s Memory per card 2 GB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 639 GEN3t Note The specifications listed are valid for cards that have been calibrated and are used in the same mainframe and slots as they were at the time of calibration. When the card is removed from its original location and placed in another slot and/or mainframe, the Offset error, Gain error and MSE specifications are expected to increase (up to double the original specification) due to thermal differences within the configurations.
  • Page 640 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 2 V Larger than or equal to ± 2 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 641 GEN3t Isolation Isolated channel Isolated channel Chassis Figure A.179: Isolation schematic 33 V RMS, ± 70 V DC Channel to chassis (earth) 33 V RMS, ± 70 V DC Channel to channel (Isolated GND to isolated GND) 55 V RMS, ± 140 V DC...
  • Page 642 GEN3t Anti-Alias Filters Note on phase matching channels. Every filter characteristic and/or filter bandwidth selection comes with it's own specific phase response. Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can result in phase mismatches between channels.
  • Page 643 GEN3t Wideband (No Anti-Alias Protection) When wideband is selected, there is neither an analog anti-alias filter nor any digital filter in the signal path. Therefore, there is no anti-alias protection when wideband is selected. Wideband bandwidth Between 950 kHz and 1300 kHz (-3 dB) 0.1 dB passband flatness...
  • Page 644 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.182: Digital Bessel IIR Filter...
  • Page 645 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.184: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 646 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.186: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 647 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. Wideband 100 kHz Sine wave 800 kHz Sine wave Channels on card 0.5 deg (14 ns) 2.0 deg (7 ns) GN815 Channels within mainframe 0.5 deg (14 ns)
  • Page 648 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 649 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 650 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 651 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.189: Real-time cycle based calculators...
  • Page 652 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 653 GEN3t Single Sweep Sweep stretch User selectable On/Off When enabled, any new trigger event occurring in the post-trigger segment of the sweep restarts the post-trigger length. If, upon the detection of a new trigger, the extended post- trigger does not fit within the sweep memory, sweep stretch does not happen. The maximum sweep stretch rate is 1 sweep stretch per 2.5 ms.
  • Page 654 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 655 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 656 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 657: B3998-1.1 En (Gen Series Gn816)

    GEN3t A.14 B3998-1.1 en (GEN series GN816) Capabilities Overview Model GN816 Maximum sample rate per channel 200 kS/s Memory per card 200 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 658 GEN3t Note The specifications listed are valid for cards that have been calibrated and are used in the same mainframe and slots as they were at the time of calibration. When the card is removed from its original location and placed in another slot and/or mainframe, the Offset error, Gain error and MSE specifications are expected to increase (up to double the original specification) due to thermal differences within the configurations.
  • Page 659 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 2 V Larger than or equal to ± 2 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 660 GEN3t Isolation Isolated channel Isolated channel Chassis Figure A.193: Isolation schematic 33 V RMS, ± 70 V DC Channel to chassis (earth) 33 V RMS, ± 70 V DC Channel to channel (Isolated GND to isolated GND) 55 V RMS, ± 140 V DC...
  • Page 661 GEN3t Anti-Alias Filters Using different filter selections (Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can result in phase mismatches between channels. SAR ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure A.194: Combined analog and digital anti-alias filter block diagram...
  • Page 662 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.195: Digital Bessel IIR Filter...
  • Page 663 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.197: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Butterworth IIR filter.
  • Page 664 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.199: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital Elliptic IIR filter.
  • Page 665 GEN3t Channel to Channel Phase Match Using different filter selections (Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. Bessel IIR, Filter frequency 20 kHz @ 200 kS/s; 10 kHz Sine wave Channels on card 0.5 deg (0.14 μs) GN816 Channels within mainframe 0.5 deg (0.14 μs)
  • Page 666 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 667 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 668 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 669 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.202: Real-time cycle based calculators...
  • Page 670 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 671 GEN3t Single Sweep Sweep stretch User selectable On/Off When enabled, any new trigger event occurring in the post-trigger segment of the sweep restarts the post-trigger length. If, upon the detection of a new trigger, the extended post- trigger does not fit within the sweep memory, sweep stretch does not happen. The maximum sweep stretch rate is 1 sweep stretch per 2.5 ms.
  • Page 672 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 673 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F)
  • Page 674 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 10 V RMS @ channel, both using clamp: performance...

  • Page 675: B4170-1.0 En (Gen Series Gn840B, Gn1640B)

    GEN3t A.15 B4170-1.0 en (GEN series GN840B, GN1640B) Capabilities Overview Model GN840B, GN1640B Maximum sample rate per channel 500 kS/s Memory per card 2 GB Analog channels 8 for GN840B and 16 for GN1640B Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter...
  • Page 676 GEN3t Block diagram Sample Rate Amplifier Sigma Delta ADC Isolation selection & Digital Filter Channel 1 to 8/16 Thermo Strain Σ Current Charge TEDS IEPE 1010 500 or 512 kS/s Sample Rate 500 or 512 kS/s Event Timer Communication Channel &...
  • Page 677 GEN3t Analog Input Section Input type Analog isolated balanced differential Input coupling Single-ended positive, single-ended negative and differential Signal input coupling Coupling modes AC/DC/GND 1.6 Hz ± 10%; -3 dB AC coupling frequency 1.6 Hz AC coupling response [dB] 1.6 Hz AC coupling response [%] 0.001...
  • Page 678 GEN3t Voltage Maximum Static Error (MSE) Voltage maximum static error (MSE) Typical Maximum 0.003% of Full Scale ± 3 μV 0.01% of Full Scale ± 10 μV Wideband Range Typical Maximum Voltage MSE (Wideband) Detail voltage MSE (Wideband) 0.020 ± 1 mV 0.510...
  • Page 679 GEN3t Voltage DC Offset Error Voltage DC Offset error (% of Full Scale) Typical Maximum 0.0002% of Full Scale ± 2 µV 0.001% of Full Scale ± 10 µV Wideband Range Typical Maximum Voltage offset error (Wideband) Detail voltage offset error (Wideband) 0.012...
  • Page 680 GEN3t Basic Mode Basic voltage Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control AC/DC/GND optional Signal (+) 10 MΩ Signal ground 10 MΩ Signal (-) Amplifier Figure A.212: Basic mode block diagram Input type Analog isolated balanced differential...
  • Page 681 GEN3t Bridge Mode Bridge sensor Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control optional TEDS class 2/3 Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) - ¼ bridge Ω excit - ¼ bridge 120 Ω...
  • Page 682 GEN3t Bridge Wiring Diagrams GN1640B Full bridge LS 2 KAB7.5/00-2/2/2 GN840B Drain wire Foil shield Blue Excitation Green Sense Black Excitation Grey Sense White Signal (+) Signal (-) Drain wires Signal ground Foil shield Earth shield Housing Keep wire length < 5 cm Use double shielded wires to reduce high frequency noise Figure A.215: Recommended 6 wire full bridge connection...
  • Page 683 GEN3t Basic Sensor Mode Basic sensor Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control optional TEDS class 2/3 Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) excit Signal Sensor 10 MΩ Signal ground Signal (-) 10 MΩ...
  • Page 684 GEN3t Integrated Electronic PiezoElectric (IEPE) IEPE sensor Signal conditioner TEDS Control optional TEDS Class 1 Amplifier Signal (+) Signal ground Figure A.220: IEPE mode block diagram ± 1 mV, ± 10 mV, ± 100 mV, ± 1 V, ± 10 V...
  • Page 685 GEN3t Voltage IEPE Gain Voltage IEPE gain error (% of reading) Typical Maximum 0.02% of Full Scale ± 5 µV 0.05% of Full Scale ± 20 µV Wideband Range Typical Maximum Voltage gain IEPE (Wideband) Detail voltage gain IEPE (Wideband) 0.10...
  • Page 686 GEN3t Piezoelectric (Charge) Mode Signal conditioner Piezoelectric sensor Teds (+) TEDS TEDS optional Teds (-) Class 2 Control Amplifier Signal (+) Signal ground Figure A.223: Piezoelectric mode block diagram ± 1 nC, ± 10 nC, ± 100 nC, ± 1 µC, ± 10 µC Input ranges ±...
  • Page 687 GEN3t Resistive Temperature Detectors (RTD) Signal conditioner Teds (+) TEDS TEDS Teds (-) Class 2 Control optional TEDS class 2/3 Sense (-) TEDS Class 3 Excitation (-) Excitation Sense (+) Excitation (+) ¼ bridge Pt10 350 Ω - excit Pt100...
  • Page 688 GEN3t RTD Wire Diagram LS 2 GN1640B GN840B RTD / Pt1000 KAB4-3133.0002 Shield Blue Excitation ( + ) Green ( + ) Sense Excitation Connect Sense White 350 Ω - ¼ bridge Signal Shield Signal ground Keep wire length < 5 cm...
  • Page 689 GEN3t Current Maximum Static Error (MSE) Current maximum static error (MSE) Typical Maximum 0.005% of Full Scale ± 200 nA 0.01% of Full Scale ± 300 nA Wideband Range Typical Maximum Detail current MSE error (Wideband) Current MSE error (Wideband) 0.020...
  • Page 690 GEN3t Current Offset Error Current offset error (% of Full Scale) Typical Maximum 0.0001% of Full Scale ± 200 nA 0.001% of Full Scale ± 300 nA Wideband Range Typical Maximum Current offset error (Wideband) Detail current offset error (Wideband) 0.010...
  • Page 691 GEN3t Thermocouple Mode Thermo Connection Signal conditioner couple block Teds (+) TEDS Control TEDS Teds (-) Cold junction reading Class 2 Signal (+) Cold Signal (-) junction sense 10 MΩ 10 MΩ Signal ground Amplifier MAX31826 Figure A.234: Thermocouple mode block diagram...
  • Page 692 GEN3t Isolation Chassis Isolated channel Isolated channel Figure A.236: Isolation schematic 33 V RMS, ± 70 V DC Channel to chassis (earth) 33 V RMS, ± 70 V DC Channel to channel (Isolated GND to isolated GND) 55 V RMS, ± 100 V DC Input signal-to-input signal I3995-3.1 en HBM: public...
  • Page 693 GEN3t GN1640B/GN840B Connector and Pinning Mating connector ODU SX2B0C-P14MFG0-0001 (female) Connectors HBM 1-CON-P1007; ODU GX2B0C-P14QF00-0002 (male) GN1640B/GN840B Pin number KAB183 colors Black Excitation (-) / TEDS class 3 (-) Excitation (+) Blue Not used White/Black Signal ground Red/Black External shunt...
  • Page 694 GEN3t Anti-Alias Filters Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can lead to phase mismatches between channels. Anti-Alias Sigma Delta ADC Digital Filter (Anti-Alias) Sample rate selection 1 out of N Analog input Σ 1010 Figure A.238: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter integrated inside the Sigma Delta Analog to Digital Converter (ADC) always sampling at a fixed sample rate.
  • Page 695 GEN3t Sigma Delta Wideband (Analog Anti-Alias) When Sigma Delta wideband is selected there is always the anti-alias filter built-in the Sigma Delta ADC (no digital filter) in the signal path. Therefore there is always anti-alias protection when Sigma Delta wideband is selected.
  • Page 696 GEN3t Bessel IIR filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.240: Representative Bessel IIR examples...
  • Page 697 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.242: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of the anti-alias filter built-in the Sigma Delta ADC and a digital Butterworth IIR filter.
  • Page 698 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.244: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of the anti-alias filter built-in the Sigma Delta ADC and a digital Elliptic IIR filter.
  • Page 699 GEN3t Elliptic IIR Band Pass Filter (Digital Anti-Alias) 1 + δp 1 - δp δp: Passband ripple δs: Stopband attenuation ωp: Passband frequency High Pass Band Pass Low Pass Stopband Passband Stopband ωc: Corner frequency -δs ωs: Stopband frequency ω...
  • Page 700 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths results in phase mismatches between channels. Specifications valid for channel to channel and card to card, all specifications are typical statistical values and measured using a 500 kS/s sample rate with sine wave ranging from 100 Hz to 100 kHz or filter frequency, whichever is reached first.
  • Page 701 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 702 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.249: Uni- and Bi-directional count timing Inputs...
  • Page 703 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 704 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 705 GEN3t Timer/Counter Mode Angle In angle measurement mode the counter will use a user defined maximum angle and revert back to zero when this count value is reached. Using the reset input the measured angle can be synchronized to the mechanical angle. The real-time calculators can extract the RPM from the measured angle independent from the mechanical synchronization.
  • Page 706 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred...
  • Page 707 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 708 GEN3t Real-Time Cycle Based Calculators Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.253: Real-time cycle based calculators Cycle Source...
  • Page 709 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) The real-time formula database (RT-FDB) option offers an extensive set of math routines to enable almost any real-time mathematical challenge. The database structure enables the user to define a list of mathematical equations similar to the Perception review formula database.
  • Page 710 GEN3t Real-time Formula Database Calculators (Option to be ordered separately) Operation Sample based results Cycle based results Storage in PNRF Published on ® synchronous asynchronous recording EtherCAT Cycle based calculations CycleArea CycleCount CycleEnergy CycleFundamentalPhase CycleFrequency CycleMax CycleMean CycleMin CyclePeak2Peak CyclePhase...
  • Page 711 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 712 GEN3t Single Sweep 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 713 GEN3t Continuous Continuous modes supported Standard, Circular recording, Specified time and Stop on trigger Standard User starts and stops recording. Recording is stopped when the storage media is full Circular recording User specified recording history on storage media. All recorded data is stored on the storage media as quickly as possible.
  • Page 714 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 715 GEN3t Flexible Wire Diagram Using the KAB2124, DIN rail breakouts (G088, G089 and/or G090) allow flexible connections to the GN1640B or GN840B. Thermocouple GN1640B RG-58 Coax cable DIN rail breakout 1-KAB2124-3 IEPE LS 2 Full bridge KAB7.5/00-2/2/2 Figure A.255: Flexible wire diagram...
  • Page 716 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 717 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 718: B3240-3.1 En (Gen Series Gn3210)

    GEN3t A.16 B3240-3.1 en (GEN series GN3210) Capabilities Overview Model GN3210 Maximum sample rate per channel 250 kS/s Memory per card 2 GB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 719 GEN3t Note The specifications listed are valid for cards that have been calibrated and are used in the same mainframe and slots as they were at the time of calibration. When the card is removed from its original location and placed in another slot and/or mainframe, the Offset error, Gain error and MSE specifications are expected to increase (up to double the original specification) due to thermal differences within the configurations.
  • Page 720 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 2 V Larger than or equal to ± 2 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 721 GEN3t IEPE Sensor In IEPE mode the negative input of each channel is internally grounded. Best measurement results can be obtained if the negative input pin of each channel is used for the coaxial ground/shield. The return current then flows straight to the channel ground and not to the common card ground.
  • Page 722 GEN3t Channel Earthing Chassis Non-isolated channel Non-isolated channel Figure A.259: Earthing schematic Analog to Digital Conversion Sample rate; per channel 1 S/s to 250 kS/s ADC resolution; one ADC per channel 24 bit ADC type Sigma Delta (Σ-Δ) ADC; Analog Devices AD7764BRUZ Defined by mainframe: ±...
  • Page 723 GEN3t Anti-Alias Filters Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths can lead to phase mismatches between channels. Anti-Alias Sigma Delta ADC Digital Filter (Anti-Alias) Sample rate selection 1 out of N Analog input Σ 1010 Figure A.260: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter integrated inside the Sigma Delta Analog to Digital Converter (ADC) always sampling at a fixed sample rate.
  • Page 724 GEN3t Sigma Delta Wideband (Analog Anti-Alias) When Sigma Delta wideband is selected there is always the built-in anti-alias filter of the Sigma Delta ADC (no digital filter) in the signal path. Therefore there is always anti-alias protection when wideband is selected. Care must be taken as this filter introduces slight overshoots on square wave or pulse response signals.
  • Page 725 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.262: Digital Bessel IIR Filter...
  • Page 726 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.264: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of the built-in anti-alias filter of the Sigma Delta ADC and a digital Butterworth IIR filter.
  • Page 727 GEN3t Elliptic IIR Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure A.266: Digital Elliptic IIR Filter When Elliptic IIR filter is selected, this is always a combination of the built-in anti-alias filter of the Sigma Delta ADC and a digital Elliptic IIR filter.
  • Page 728 GEN3t Elliptic IIR Band Pass Filter (Digital Anti-Alias) 1 + δp 1 - δp δp: Passband ripple δs: Stopband attenuation ωp: Passband frequency High Pass Band Pass Low Pass Stopband Passband Stopband ωc: Corner frequency -δs ωs: Stopband frequency ω...
  • Page 729 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths will lead to phase mismatches between channels. Wideband 10 kHz Sine wave Channels on card 0.1 deg (30 ns) GN3210 Channels within mainframe 0.1 deg (30 ns)
  • Page 730 GEN3t Digital Event/Timer/Counter The Digital Event/Timer/Counter input connector is located on the mainframe. For exact layout and pinning see mainframe data sheet. Digital input events 16 per card Levels TTL input level, user programmable invert level Inputs 1 pin per input, some pins are shared with Timer/Counter inputs ±...
  • Page 731 GEN3t Timer/Counter Mode Uni- and Bi-directional Count Counter mode is typically used for tracking movement of device under test. When possible use the quadrature modes as these are less sensitive to counting errors. ∆w ∆w Signal Direction ∆s ∆h Reset ∆s ∆h...
  • Page 732 GEN3t Timer/Counter Mode Bi-directional Quadrature Count Typically used for tracking rotating/moving devices using a decoder with two signals that are always 90 degree phase shifted. E.g. allow for direct interfacing to HBM torque and speed transducers. Quadrature disk Reset Signal...
  • Page 733 GEN3t Timer/Counter Mode: Uni- and Bi-directional Frequency/RPM Measurement Used to measure any kind of frequency like engine RPM, or active sensors with proportional frequency output signal. ∆w ∆w Signal Direction ∆s ∆h Figure A.272: Uni- and Bi-directional count timing Inputs...
  • Page 734 GEN3t Triggering Channel trigger/qualifier 1 fully independent per channel either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred Manual trigger (Software)
  • Page 735 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 736 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.273: Real-time cycle based calculators...
  • Page 737 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 738 GEN3t Multiple Sweeps 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 739 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 740 GEN3t Connector Pin Assignment Connector type POSITRONIC HDC50F5R8N0X/AA Mating connector type Harting part number 9670505615 (Metal shell 61030010019, cable clamp 61030000145, blanking piece 61030000041) 5 V ± 20% Output voltage Output current 0.3 A maximum (all output pins internally connected) Front View CH 16 NEG.
  • Page 741 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 742 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 743: B3264-3.1 En (Gen Series Gn3211)

    GEN3t A.17 B3264-3.1 en (GEN series GN3211) Capabilities Overview Model GN3211 Maximum sample rate per channel 20 kS/s Memory per card 200 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution...
  • Page 744 GEN3t Note The specifications listed are valid for cards that have been calibrated and are used in the same mainframe and slots as they were at the time of calibration. When the card is removed from its original location and placed in another slot and/or mainframe, the Offset error, Gain error and MSE specifications are expected to increase (up to double the original specification) due to thermal differences within the configurations.
  • Page 745 GEN3t Analog Input Section Common mode (referred to system ground) Less than ± 2 V Larger than or equal to ± 2 V Ranges Rejection (CMR) > 80 dB @ 80 Hz (100 dB typical) > 60 dB @ 80 Hz (80 dB typical)
  • Page 746 GEN3t Channel Earthing Chassis Non-isolated channel Non-isolated channel Figure A.278: Earthing schematic Analog to Digital Conversion Sample rate; per channel 1 S/s to 20 kS/s ADC resolution; one ADC per channel 24 bit, only 16 bit recorded ADC type Sigma Delta (Σ-Δ) ADC; Analog Devices AD7764BRUZ Defined by mainframe: ±...
  • Page 747 GEN3t Anti-Alias Filters Using different filter selections (Wideband/Bessel IIR/Butterworth IIR) or different filter bandwidths can lead to phase mismatches between channels. Anti-Alias Sigma Delta ADC Digital Filter (Anti-Alias) Sample rate selection 1 out of N Analog input Σ 1010 Figure A.279: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter integrated inside the Sigma Delta Analog to Digital Converter (ADC) always sampling at a fixed sample rate.
  • Page 748 GEN3t Sigma Delta Wideband (Analog Anti-Alias) When Sigma Delta wideband is selected there is always the built-in anti-alias filter of the Sigma Delta ADC (no digital filter) in the signal path. Therefore there is always anti-alias protection when wideband is selected. Care must be taken as this filter introduces slight overshoots on square wave or pulse response signals.
  • Page 749 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.281: Digital Bessel IIR Filter...
  • Page 750 GEN3t Butterworth IIR Filter (Digital Anti-Alias) 1 + δp δp: Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp ωc ωs Frequency [kHz] Figure A.283: Digital Butterworth IIR Filter When Butterworth IIR filter is selected, this is always a combination of the built-in anti-alias filter of the Sigma Delta ADC and a digital Butterworth IIR filter.
  • Page 751 GEN3t Channel to Channel Phase Match Using different filter selections (Wideband/Bessel IIR/Butterworth IIR/etc.) or different filter bandwidths will lead to phase mismatches between channels. Wideband 1 kHz Sine wave Channels on card 0.01 deg (30 ns) GN3211 Channels within mainframe 0.01 deg (30 ns)
  • Page 752 GEN3t Triggering Channel trigger/qualifier 1 fully independent per channel either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Maximum delayed trigger 1000 seconds after a trigger occurred Manual trigger (Software)
  • Page 753 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 754 GEN3t Real-Time Cycle Based Calculators (Perception V6.72 and higher) Timer Cycle Source Cycle Cycle Detect Cycle Count Level Crossing Measured Channels Cycle Based Calculator Calculated Channels Source Trigger Detector Selectable To Channel & Math Card Trigger Figure A.285: Real-time cycle based calculators...
  • Page 755 GEN3t Acquisition Modes Single sweep Triggered acquisition to on-board memory without sample rate limitations; for single transients or intermittent phenomena. No aggregate sample rate limitations. Multiple sweeps Triggered acquisition to on-board memory without sample rate limitations; for repetitive transients or intermittent phenomena. No aggregate sample rate limitations.
  • Page 756 GEN3t Multiple Sweeps 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 757 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 758 GEN3t Connector Pin Assignment Connector type POSITRONIC HDC50F5R8N0X/AA Mating connector type Harting part number 9670505615 (Metal shell 61030010019, cable clamp 61030000145, blanking piece 61030000041) 5 V ± 20% Output voltage Output current 0.3 A maximum (all output pins internally connected) Front View CH 16 NEG.
  • Page 759 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 760 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 761: B3246-1.0 En (Gen Series Gn4070)

    GEN3t A.18 B3246-1.0 en (GEN series GN4070) General Specifications Analog Input Section Component Unit Description Value Channels Fiber optic isolated marker (event) inputs Non-isolated marker (event) inputs Fiber optic isolated ARM output Type TTL, active low with pull-up resistor to enable activation by relays or...
  • Page 762 GEN3t Digital Input Section Component Unit Description Value Figure A.288: Fiber optic cables Conditional functionality Modes Trigger, Qualifier, Alarm Trigger Modes Off, rising edge active, falling edge active Combination Logic condition: Event trigger OR any other trigger source Qualifier Modes...
  • Page 763 GEN3t Digital Input Section Component Unit Description Value Reset to “0” Manual by user At start of recording By reset pin once after start of recording By reset pin always RPM mode Count size 64 bits Maximum frequency 10 MHz...
  • Page 764 GEN3t Miscellaneous Component Unit Description Value Output power Typical @ 20 °C (ambient PCB) 5 V @ 0.5 A Typical @ 60 °C (ambient PCB) 5 V @ 0.35 A I3995-3.1 en HBM: public...

  • Page 765: B3245-1.0 En (Gen Series Gn6470)

    GEN3t A.19 B3245-1.0 en (GEN series GN6470) Analog to Digital Conversion Component Unit Description Value Sample rate Maximum 1 MS/s Type TTL, active low with pull-up resistor to enable activation by relays or short-circuit to ground Digital Input Section Component...
  • Page 766 GEN3t Digital Input Section Component Unit Description Value Sample size 64 Bits (8 Bytes) Operation modes Counter Quadrature counter Frequency Counter mode Count size 64 bits Maximum frequency 10 MHz Direction External Up/down Reset to “0” Manual by user At start of recording...
  • Page 767 GEN3t Acquisition Modes Component Description Sweeps Triggered acquisition to RAM with no sample rate limitations; for single or repetitive transients or intermittent phenomena. Continuous Direct storage to a PC or mainframe hard disk with no file size limitations; triggered or un-triggered; for long-duration recorder-type applications with up to 1 MS/s rate per channel (the maximum aggregate rate depends on the mainframe configuration and PC).

  • Page 768: B Options, To Be Ordered Separately

    GEN3t B Options, to be ordered separately Batteries and battery chargers B.1.1 Rechargeable Li-ion SM202 battery G034, G301: Rechargeable Li-ion SM202 Battery (Option, to be ordered separately) Option G034 is battery only. Option G301 is a combination of the battery (G034) and the battery carrier (see Figure B.1) Note Shipment regulations don't allow HBM to import batteries to all countries.

  • Page 769: Li-Ion Battery Charger

    GEN3t B.1.2 Li-ion battery charger G109, G033: Li-ion Battery Charger (Option, to be ordered separately) Li-ion ten-bay and two-bay battery chargers Smart battery support SmBus Level 3 Maximum charge current 3 A, or limited by smart battery Battery recalibration SmBus 1.2 A @ 12 V Charge strategy Simultaneous for two batteries.

  • Page 770: Breakout Cables And Panels

    GEN3t Breakout cables and panels B.2.1 Breakout cables KAB171, KAB172: Breakout Cables (Option, to be ordered separately) Figure B.3: KAB171/KAB172 breakout cable Cable length 1.5 m Cable type Multiple coax cables bundled in a sleeve to minimize crosstalk between cables...
  • Page 771 GEN3t KAB183: Push-Pull Sensor Cable Black Yellow/Black Grey Blue White Green White/Black Grey/Black Red/Black Brown Green/Black Pink/Black Yellow Figure B.5: Pin number and wire colors KABXXX: Breakout Cable (Option, to be ordered separately) Figure B.6: Eight channel breakout cable Cable length 3.0 m (9.9 ft)

  • Page 772: Breakout Panels

    GEN3t B.2.2 Breakout panels G056, G058: Breakout Panels (Option, to be ordered separately) Figure B.7: G056/G058 Breakout panel Rackmount 19-inch, 1U height Panel connector Metal BNC, female in to female out, not isolated from panel Panel connection Direct connections with KAB171 and KAB172...

  • Page 773: Din Rail Breakouts

    GEN3t B.2.3 DIN rail breakouts 1-G088-2: Generic breakout DIN rail breakout block push-in connector DIN rail mountable breakout block. Converts ODU input connector to 12 pin spring/push-in connector. Figure B.10: DIN rail mountable breakout block (1-G088-02) 1-G089-2: Thermocouple breakout DIN rail thermocouple with cold juntion and TEDS DIN rail mountable breakout block.
  • Page 774 GEN3t 1-G090-2: Basic/IEPE/piezoelectric breakout terminal DIN rail BNC breakout DIN rail mountable breakout block. Converts ODU input connector to dual BNC differential output. Figure B.12: DIN rail mountable breakout block (1-G090-02) G088, G089 and G090 card breakouts assembled on a 19" DIN rail For the GN840B and GN1640B card breakouts are created that can be assembled on a 19"...

  • Page 775: Bridge Articles

    GEN3t Bridge articles B.3.1 Bridge completion pack 1-G021-2: Bridge completion pack (Option, to be ordered separately) GEN DAQ Bridge completion/shunt cal resistor cards, 4 additional pieces (4 pieces included in both GN410 and GN411) Figure B.14: Shunt calibration completion plug-in module B.3.2...

  • Page 776: Burden Resistor

    GEN3t Burden resistor B.4.1 High precision burden resistor Gxxx: High Precision Burden Resistor (Option, to be ordered separately) Low ohmic, 1 W, 0.02% high precision, low thermal drift burden resistor. Uses 4 wire connection to reduce inaccuracy caused by the currents running to the burden resistor.

  • Page 777: Card Adapters

    GEN3t Card adapters B.5.1 Artificial star adapter G068: Artificial Star Adapter (Option, to be ordered separately) The artificial star adapter creates an artificial star point to measure 3 phase signals Maximum input voltage 1000 V DC (707 V RMS) between each of the phases Inputs 3;...

  • Page 778: Artifical Star Adapter Wiring Diagram

    GEN3t B.5.2 Artifical star adapter wiring diagram Artifical Star Adapter Wiring Diagram L1 Out Phase to L2 Out Artificial Star Voltages L3 Out Warning : N* (Artificial Star Point) DC-AC is not ground or earth. Power This pin should be left unconnected.

  • Page 779: Option Carrier Card Extensions

    Not supported. Use Master/Slave synchronization connector of mainframe for Slave mode. Maximum mainframes GEN3i and GEN3t : 16 Slave mainframes, 17 including Master mainframe GEN7i and GEN7tA : 48 Slave mainframes, 49 including Master mainframe GEN17tA : 128 Slave mainframes, 129 including Master mainframe...
  • Page 780 GEN3t G083: Master Output Card (Option, to be ordered separately) Extended synchronization Calculated channel trigger exchange Synchronously exchanges real-time calculated (RTC) channel triggers between mainframes. Separate exchange required due to the longer internal delays of RTC channel triggers that were caused by the mathematics prior to establishing a trigger.

  • Page 781: Option Carrier Card

    Maximum option carrier cards All mainframe slots can be used with an option carrier card. Each mainframe needs at least one acquisition card. Supported mainframes GEN3i, GEN3t, GEN7i, GEN7tA and GEN17tA Requires a fast data streaming bus Option card types PMC/XMC cards...

  • Page 782: Irig And Gps Card

    GEN3t B.6.3 IRIG and GPS card G001, G002: IRIG, IRIG/GPS Card (Options, to be ordered separately) Supports IRIG A and B or GPS time synchronization (one card per mainframe, option carrier card required) GPS Antenna Cable 1-G002-2 only (1-G002-2 only)
  • Page 783 GEN3t G001, G002: IRIG, IRIG/GPS Card (Options, to be ordered separately) GEN DAQ series functions Capture start of recording time Synchronize master time base oscillator frequency GPS localization time 2 to 15 minutes Time required to full synchronization after GPS localization completed...

  • Page 784: 10Gbit Ethernet Card, Optical

    GEN3t B.6.4 10Gbit Ethernet card, optical G064: 10Gbit Ethernet Card, Optical (Option, to be ordered separately) Supports up to two 10Gbit Ethernet connections using SFP+ modules with optical LC connectors (option carrier card required) SFP+ SFP+ Dual Channel Carrier Module...

  • Page 785: 10Gbit Ethernet Card, Electrical

    GEN3t B.6.5 10Gbit Ethernet card, electrical G084: 10Gbit Ethernet Card, Electrical (Option, to be ordered separately) Supports up to two 10Gbit Ethernet connections using RJ45 connectors (option carrier card required) Dual Channel 10 Gbit CAT6A Ethernet Controller 1-G084-2 Figure B.27: Block diagram 10Gbit Ethernet card, electrical...

  • Page 786: Ethercat® Card

    GEN3t B.6.6 ® Ethercat card G082: EtherCAT Card (Option, to be ordered separately) ® ® Supports one EtherCAT Slave using RJ45 connectors (option carrier card required) EtherCAT Controller Input Clock 2 * Shielded CAT5E Output Control 1-G082-2 ® Figure B.28: Block diagram EtherCAT...

  • Page 787: Current Clamps

    GEN3t Current clamps B.7.1 AC/DC Current Clamp i30s G912: AC/DC Current Clamp i30s (Option, to be ordered separately) To be used with single-ended isolated or non-isolated amplifiers or with differential isolated or non-isolated amplifiers in single-ended mode 71 mm 25 mm (2.79")
  • Page 788 GEN3t G912: AC/DC Current Clamp i30s (Option, to be ordered separately) Figure B.30: AC/DC Current Clamp i30s I3995-3.1 en HBM: public...

  • Page 789: Ac Current Clamp Sr661

    GEN3t B.7.2 AC Current Clamp SR661 G913: AC Current Clamp SR661 (Option, to be ordered separately) To be used with single-ended isolated or non-isolated amplifiers or with differential isolated or non-isolated amplifiers in single-ended mode 111 mm (4.37") 101 mm (3.98")
  • Page 790 GEN3t G913: AC Current Clamp SR661 (Option, to be ordered separately) Figure B.32: SR661 AC Current Clamp I3995-3.1 en HBM: public...

  • Page 791: Ac Current Clamp M1V-20-2

    GEN3t B.7.3 AC Current Clamp M1V-20-2 G914: AC Current Clamp M1V-20-2 (Option, to be ordered separately) To be used with single-ended isolated or non-isolated amplifiers or with differential isolated or non-isolated amplifiers in single-ended mode 23.11 mm (0.91") 42.92 mm (1.69")

  • Page 792: Current Transducers And Accessories

    GEN3t Current transducers and accessories B.8.1 Current transducers Gxxx: Current Transducers (Option, to be ordered separately) Current loop (compensated) current transducers (CT) using an extremely accurate zero flux detector with excellent linearity and low temperature drift. Electrostatic shield between primary and secondary circuit, with low insertion loss and high immunity to electrostatic and magnetic fields.

  • Page 793: Connection Cable Lem Ct To Mcts

    GEN3t Gxxx: Current Transducers (Option, to be ordered separately) Front view Top view Cable diameter Width Figure B.36: Dimensions B.8.2 Connection cable LEM CT to MCTS Connection cable LEM CT to MCTS (Option, to be ordered separately) Connection cable between LEM current transducer and MCTS power supply. Available in lengths of 2.5 m (8.20 ft), 5 m (16.40 ft) and 10 m (32.81 ft).

  • Page 794: Power Supply For Current Transducer

    GEN3t B.8.3 Power supply for current transducer Gxxx: Power Supply for Current Transducer (Option, to be ordered separately) Empty modular 19” rack with 1 to maximum 6 channel CT support. Housing for the modular power supply and control for LEM current transducers.

  • Page 795: Current Transducer (Ct) Wire Diagram

    GEN3t B.8.4 Current transducer (CT) wire diagram Current Transducer (CT) Wire Diagram KAB290 Cable KAB290 Cable Current Transducer Burden SIGNALTEC Power POWER Power Supply PTP1 PTP2 Channel 6 Channel 5 Channel 4 Channel 3 Channel 2 Channel 1 Resistor Burden Resistor HBR x...

  • Page 796: Fiber Optic Cables And Sfps

    GEN3t Fiber optic cables and SFPs B.9.1 Standard fiber optic duplex cable KAB277: Fiber Cables (Option, to be ordered separately) Standard fiber optic duplex cable (1-KAB277-xxx) Tight buffered fiber Aramid yarn Outer jacket LC - SCRJ Connector type Glass rating OM2;...

  • Page 797: Heavy Duty Fiber Optic Duplex Patch Cable

    GEN3t KAB278: Fiber Cables (Option, to be ordered separately) Control Room Test Area Transmitter LC Receiver on GEN series IP67 Panel Mount 1-KAB278-xxx Duplex Cable(s) GEN series Figure B.41: Application area of a fiber optic duplex cable (Example 1) B.9.3...

  • Page 798: Standard Zipcord Fiber Optic Duplex Multi Mode Patch Cable

    GEN3t B.9.4 Standard zipcord fiber optic duplex Multi Mode patch cable KAB280: Fiber Cable Standard MM LC-LC (Option, to be ordered separately) Standard zipcord fiber optic duplex Multi Mode patch cable Tight buffered fiber Aramid yarn Outer jacket Figure B.42: Block diagram and image...

  • Page 799: Standard Zipcord Fiber Optic Duplex Single Mode Patch Cable

    GEN3t B.9.5 Standard zipcord fiber optic duplex Single Mode patch cable KAB288: Fiber Cable Standard SM LC-LC (Option, to be ordered separately) Standard zipcord fiber optic duplex Single Mode patch cable Tight buffered fiber Aramid yarn Outer jacket Figure B.43: Block diagram and image...

  • Page 800: Heavy Duty Fiber Optic Duplex Single Mode Cable

    GEN3t B.9.6 Heavy duty fiber optic duplex Single Mode cable KAB289: Fiber Cable Heavy Duty SM LC-LC (Option, to be ordered separately) Heavy duty fiber optic duplex Single Mode cable Polyurethane outer jacket Aramid strenght member 500 µm optical fiber 900 µm elastomeric tight buffer...

  • Page 801: Gbit Optical Network Sfp Module 850 Nm

    GEN3t B.9.7 1 Gbit Optical Network SFP module 850 nm 1-G062-2: 1 Gbit Optical Network SFP module 850 nm (Option, to be ordered separately) GEN DAQ 1 Gbit Ethernet SFP, 850 nm Multi Mode, up to 500 m optical cable length supported, LC connector support.

  • Page 802: 10 Gbit Optical Network Sfp Module 1310 Nm

    GEN3t B.9.10 10 Gbit Optical Network SFP module 1310 nm 1-G066-2: 10 Gbit Optical Network SFP module 1310 nm (Option, to be ordered separately) GEN DAQ 10 Gbit Ethernet SFP+, 1310 nm Single Mode, up to 10 km optical cable length supported, LC connector support.

  • Page 803: Local Storage

    GEN3t B.10 Local Storage B.10.1 Local storage G073: Local Storage (Option, to be ordered separately) Built inside the GEN DAQ series mainframes to secure data storage in the best way possible. Recorded data can be copied to a permanent archive using Perception software.

  • Page 804: Mainframe Adapters

    GEN3t B.11 Mainframe adapters B.11.1 G070A Torque/RPM adapter Connect up to two torque transducers Connect to T12/T40B using standard cables RS422 differential input signals for highest immunity Connect to GEN DAQ mainframe using standard cable Dual signal output for dual use with test cell control system...
  • Page 805 GEN3t Torque/RPM Adapter Block Diagram Ext. Torque power in Torque/Speed A DC Power IN 18 to 30 V, 1A maximum Supply voltage ground Shunt To contr KAB149 system Torque Torque Reference Reference To contro RPM 0 RPM 0 KAB163 system...
  • Page 806 GEN3t Torque/RPM Adapter Connects a T12, T40 or similar torque transducer to GEN2i, GEN3i, GEN3t, GEN7i and GEN7tA Digital Event/Timer/Counter connector Torque sensor connection Number of torque sensors Torque interface support Torque and Shunt (A-Txx CON1 Torque IN & B-Txx CON1 Torque IN) Speed interface support RPM, Direction and Reference (A-Txx CON2 Speed IN &...
  • Page 807 GEN3t Torque/RPM Adapter Connector Layout Figure B.51: G070A front view Front side connectors Sensor A input Torque and Speed Sensor A output Torque and Speed Sensor A power input Optional sensor A power, supplied on Torque input connector Event input All remaining events not used for sensor A and B torque and RPM measurements Figure B.52: G070A back view...
  • Page 808 GEN3t Torque Sensor Connector Pin Assignment Pin 5 : Supply voltage ground (not connected to ground) Pin 6 : Supply voltage 18 V to 30 V Pin 8: Ground Pin 12: + Torque Signal 2 3 4 5 6 Pin 13: - Torque Signal...
  • Page 809 GEN3t Digital Event/Timer/Counter Connector Pin Assignment PIN 1 - Event Input 1A & Reset Timer/Counter 2A PIN 16 - Event Input 4B PIN 31 - Event Input 15B & External Stop B PIN 2 - Event Input 2A & Direction Timer/Counter 2A PIN 17 - Event Input 5B PIN 32 - Event Input 16B &...
  • Page 810 Figure B.58: External powered torque transducer connected to GEN DAQ Note GEN series connection supported for GEN3i, GEN3t, GEN7i (shown), GEN7tA or GEN17tA. Example 1: Connection of a single Torque transducer with torque and speed to GEN DAQ input A using the G070A adapter; Torque transducer powered directly;...
  • Page 811 Figure B.59: G070A powered torque transducer connected to GEN DAQ and control system Note GEN series connection supported for GEN3i, GEN3t, GEN7i (shown), GEN7tA or GEN17tA. Example 2: Connection of a single Torque transducer with torque and speed to GEN DAQ (input A); Torque transducer powered using G070A;...
  • Page 812 Figure B.60: Two torque transducer connected to GEN DAQ and control system Note GEN series connection supported for GEN3i, GEN3t, GEN7i (shown), GEN7tA or GEN17tA. Example 3: Connection of two torque transducers connecting torque and speed to GEN DAQ (input A and B); both torque transducers powered using G070A;...
  • Page 813 Figure B.61: Torque transducer and speed encoder connected to GEN DAQ and control system Note GEN series connection supported for GEN3i, GEN3t, GEN7i (shown), GEN7tA or GEN17tA. Example 4: Connection of a single torque transducer with torque only to GEN DAQ (input A); torque transducer powered using G070A; separate incremental encoder used for speed, encoder directly powered;...
  • Page 814 GEN3t Physical, Weight and Dimensions Weight Mainframe 0.75 kg (1.65 lbs) Dimensions Height 5.46 cm (2.15”) Width 171.6 cm (6.76") Depth 123.6 cm (4.86") Grounding Using shield of GEN DAQ cable connection Casing Aluminum Accessories Cable to connect adapter to GEN DAQ mainframe event connector, included with Torque/RPM adapter 171.6 mm (6.76”)
  • Page 815 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Relative humidity 0% to 80%; non-condensing; operational Protection class IP20 Altitude Maximum 2000 m (6562 ft) above sea level; operational...
  • Page 816 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 150 kHz to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance...

  • Page 817: G072 Isolated Digital Event Adapter

    GEN3t B.11.2 G072 Isolated Digital Event Adapter 32 digital event input channels 4 digital event output channels 230 V RMS event channel isolation Full channel to channel isolation Removable screw terminals for quick cable connections Direct interface to GEN DAQ mainframe event connector...
  • Page 818 GEN3t Isolated Digital Event Adapter Block Diagram 32 X Isolated Input FODM8071 To marker card 50Ω (cable not included) – 562Ω To marker card 32 X (cable not included) To mainframe shield (optional) 4 X Isolated output (only from mainframe digital IO) VOS617A 430Ω...
  • Page 819 GEN3t Event Inputs Inputs 32 event channels (Anode (A), Cathode (C) optocoupler with 562 Ω series resistor ) Isolation voltage 230 V AC RMS or DC (channel to channel and channel to chassis/earth) Isolation device Fairchild FOD8071 optocoupler (or comparable) Switching frequency 10 MHz input block signal tested.
  • Page 820 GEN3t Event Outputs Output channels 4 digital isolated output channels (open Collector, Emitter) Only supported by Digital Event/Timer/Counter connector Isolation device Vishay VOS617A optocoupler (or comparable) Output frequency 170 kHz output signal tested. Maximum useable frequency for the system is limited by the Isolated Digital Event Adapter or acquisition system, whichever is the slowest.
  • Page 821 GEN3t Adapter Front Connector Pinning OUTPUT Vce max : 80 V Vec max : 7 V lc max : 50 mA OUTPUT INPUT Vce max : 80 V Vin low : < 0.8 V Isolation : 230 V RMS 562Ω...
  • Page 822 GEN3t Adapter Rear Connector Pinning DIGITAL EVENT/TIMER/COUNTER DIGITAL MARKER GROUP B DIGITAL MARKER GROUP A 1-G072-2 HBM inc. Marlborough, MA, USA ISO Event IO Adapter Figure B.70: G072 rear connectors PIN 1 - Event Input 1A & Reset Timer/Counter 2A PIN 16 - Event Input 4B PIN 31 - Event Input 15B &...
  • Page 823 GEN3t Isolated Input Application Examples Isolated Input FODM8071 external Rext 50Ω – 562Ω Data Figure B.73: Isolated input switched to negative input Isolated Input FODM8071 Data external Rext 50Ω – 562Ω Figure B.74: Isolated input switched to positive input I3995-3.1 en HBM: public...
  • Page 824 GEN3t Isolated Output Application Examples (Only supported by Digital Event/Timer/Counter connectors) Isolated Output (only from mainframe digital IO) VOS617A control Rext 430Ω – Data Figure B.75: Isolated output switched to negative output Isolated Output (only from mainframe digital IO) Data/U...
  • Page 825 GEN3t Physical, Weight and Dimensions Weight Adapter 0.75 kg (1.65 lbs) Dimensions Height 54.6 mm (2.15”) Width 171.6 mm (6.76") Depth 130.14 mm (4.86") Grounding Uses shield for GEN DAQ cable connection Casing Aluminum OUTPUT INPUT Vce max : 80 V Vin low : <...
  • Page 826 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Relative humidity 0% to 80%; non-condensing; operational Protection class IP20 Altitude Maximum 2000 m (6562 ft) above sea level; operational...

  • Page 827: Isolated Digital Event Adapter To Marker Card Cable

    GEN3t B.11.3 Isolated digital event adapter to marker card cable 1-KAB2116-1.5: Isolated digital event adapter to marker card cable (Option, to be ordered separately) Set of two cables to connect the digital marker A and digital marker B output connectors of the G072 isolated digital event adapter to either a GN6470 or a GN4070 marker card.

  • Page 828: Measurement Cables

    GEN3t B.12 Measurement cables B.12.1 Shielded 2 Wire 600 V RMS CAT II cable KAB290: Shielded 2 Wire 600 V RMS CAT II Cable (Option, to be ordered separately) This cable is specially designed to be used with the GN610, GN611 and GN610B, GN611B cards. Significantly reduces signal disturbance pickup by using two identical signal wires with earthed shield.

  • Page 829: Test Leads And Clips

    GEN3t KAB290: Shielded 2 Wire 600 V RMS CAT II Cable (Option, to be ordered separately) Typical conducted immunity disturbance (10 V RMS, Clamp) Typical conducted immunity disturbance (10 V RMS, Clamp) Frequency [MHz] Frequency [MHz] 2 Lead Wire 2 Lead Wire...

  • Page 830: Rack Mount Kit

    Rack Mount Kit (Option, to be ordered separately) Figure B.82: GEN3t Rack Mount Kit Rack Mount Kit Mounting GEN3t mainframe in a standard 19” rack. Requires no additional mounting materials. User installed option. 5 units, 222.5 mm (8.76") height I3995-3.1 en HBM: public...

  • Page 831: Removable Solid State Drive (Ssd)

    1-G073-2 : Solid State Drive (Option, to be ordered separately) GEN3t Solid State Drive option. Internal SSD in GEN3t mainframe, 400 GB capacity, 200 MB/s continuous streaming rate. Sweep storage rate depends on sweep length and number of channels. Short sweeps are stored more slowly due to administration overhead.

  • Page 832: Shipping Case

    GEN3t B.15 Shipping case B.15.1 Shipping case G054: Shipping Case (Option, to be ordered separately) 325 mm (12.8”) 675 mm (26.6”) Handle Handle extended: +400 mm (15.7”) Figure B.84: Reusable hardcover shipping case with wheels and transport handle Outside Dimensions 60.0 cm (23.6") x 32.5 cm (12.8") x 67.5 cm (26.5") (HxWxD)

  • Page 833: Software

    GEN3t B.16 Software B.16.1 Perception standard software DAQ software, Perception standard software included with GEN3i (Option, to be ordered separately) Perception standard software package. Refer to the Perception data sheet for details. B.16.2 Perception professional 1-PERC-PRO-01-2: DAQ software options, Perception Professional (Option, to be ordered...

  • Page 834: Voltage Probes

    GEN3t B.17 Voltage probes B.17.1 Passive, single-ended voltage probes G027: Passive, Single-Ended Voltage Probe (Option, to be ordered separately) To be used with single-ended non-isolated amplifiers or with differential non-isolated amplifiers in single-ended mode Passive probe 900K 10:1 10 * U in...
  • Page 835 GEN3t G901, G902: Passive, Single-Ended Voltage Probe (Option, to be ordered separately) To be used with single-ended non-isolated amplifiers or with differential non-isolated amplifiers in single-ended mode Passive probe 900K 10:1 10 * U in U in Single-ended amplifier Figure B.87: Block diagram passive, single-ended voltage probe...
  • Page 836 GEN3t G903: Passive, Single-Ended Voltage Probe (Option, to be ordered separately) To be used with single-ended amplifiers or with differential amplifiers in single-ended mode Passive probe 900K 100 * U in U in Single-ended amplifier Figure B.89: Block diagram passive, single-ended voltage probe...
  • Page 837 GEN3t G904: Passive, Single-Ended Voltage Probe (Option, to be ordered separately) To be used with single-ended amplifiers or with differential amplifiers in single-ended mode Passive probe 49.5M 900K 100 * U in U in Single-ended amplifier Figure B.91: Block diagram passive, single-ended voltage probe...
  • Page 838 GEN3t G906: Passive, Single-Ended Voltage Probe (Option, to be ordered separately) To be used with single-ended amplifiers or with differential amplifiers in single-ended mode Passive probe 49.5M 4.5M 900K 100 * U in U in Single-ended amplifier Figure B.93: Block diagram passive, single-ended voltage probe...

  • Page 839: Passive, Single-Ended Isolated Probes

    GEN3t B.17.2 Passive, single-ended isolated probes G057: Passive, Single-Ended Isolated Voltage Probe (Option, to be ordered separately) To be used with single-ended amplifiers or with differential amplifiers in single-ended mode Non-isolated system 900K 10 * U diff U diff Isolation...

  • Page 840: Passive, Differential Matched Isolated Voltage Probes

    GEN3t B.17.3 Passive, differential matched isolated voltage probes G025: Passive, Differential Matched Isolated Voltage Probe (Option, to be ordered separately) To be used with differential isolated or non-isolated amplifiers Probe 1 Non-isolated system 49 M 900 k 50 * U Isolated GND (–)
  • Page 841 GEN3t G026: Passive, Differential Matched Isolated Voltage Probe (Option, to be ordered separately) To be used with differential isolated or non-isolated amplifiers Probe 1 Non-isolated system 900 k 50 * U Isolated GND (–) Probe 2 (–) (–) 50 * U in–...
  • Page 842 GEN3t G907: Passive, Differential Matched Voltage Probe (Option, to be ordered separately) To be used with differential isolated or non-isolated amplifiers Passive probe 900K 10 x U diff U diff 900K Differential amplifier Figure B.102: Block diagram passive, differential matched isolated voltage probe...

  • Page 843: Active, Differential Voltage Probe

    GEN3t B.17.4 Active, differential voltage probe G909: Active, Differential Voltage Probe (Option, to be ordered separately) To be used with differential isolated or non-isolated amplifiers Active probe Single-ended amplifier Coax cable U in 900K Power External DC supply Figure B.104: Block diagram active, differential voltage probe...

  • Page 844: High Precision Differential Probe

    GEN3t B.17.5 High precision differential probe Gxxx: 1 kV DC High Precision Differential Probe (Option, to be ordered separately) High precision 10 MΩ differential probe (HDP) to be used in combination with GN610, GN611, GN610B and GN611B acquisition cards. Reduces the resistive/current load on the device under test by increasing the input impedance to 10 MΩ...
  • Page 845 GEN3t Gxxx: 5 kV RMS High Precision Differential Probe (Option, to be ordered separately) 5 kV RMS, 20 MΩ, 50:1, 0.2% high precision, differential probe to be used in combination with GN610, GN611, GN610B and GN611B acquisition cards. The built-in earthing monitor system increases safety of the user and protects the GEN series inputs for isolation overloads.

  • Page 846: C Maintenance

    GEN3t C Maintenance Preventive maintenance Regularly scheduled HBM preventive maintenance services that include cleaning, adjusting, inspection and calibration will help to: Assure that the instrument is available whenever it is needed Maintain optimum performance Avoid expensive unplanned downtime and repair Also, regularly scheduled maintenance is a predictable expenditure.

  • Page 847: Preventive Drive Replacement

    GEN3t Preventive drive replacement When installed in the instrument, the drive is the "data center" of the instrument. It contains all of the programs and recorded data. The CPU may be the "brain" of the system, but the drive is its memory and personality; it is what makes the instrument what it is.
  • Page 848 GEN3t CAUTION Do not to exceed the drives warranty period. Contact HBM service for more details. I3995-3.1 en HBM: public...

  • Page 849: Cleaning

    To clean the instrument, disconnect all power sources. Lightly wipe the surfaces with a clean, soft cloth dampened with water. The GEN3t does not require additional routine cleaning. If the cooling inlets on the side of the instrument become clogged with dust, use a small brush and/or vacuum cleaner to remove the dust.

  • Page 850: D Service Information

    GEN3t D Service Information General - Service Information HBM offers comprehensive factory servicing for all HBM Data Acquisition products. Extended warranties for calibration, repair or both are available. Installation, on-site or factory training are also available. Contact the factory or local sales person for more information.

  • Page 851: Calibration/Verification

    GEN3t Calibration/verification The GEN series Data Acquisition System is factory calibrated when delivered to the customer. Swapping, replacing or removing the cards may result in minor deviations to the original calibration. HBM recommends that the GEN series system should be tested and, if necessary, calibrated once a year or after any major event that may affect calibration.

  • Page 852: E Trouble Shooting

    GEN3t E Trouble Shooting GEN3t is not detected E.g.: Ethernet connected mainframe not found on network If the mainframe is not detected by Perception, follow the steps below to determine the cause of the problem and follow-up measures. Each numbered item in the flowchart (see Figure E.1) is explained in detail later.
  • Page 853 GEN3t Mainframe shown in autoconfiguration Rescanning shows the mainframe Mainframe shown in hardware navigator Rescanning Mainframe now shows starts the mainframe Insert cards one by Check power: one until system - Fuse does not start. The Mainframe starts - Power cable...
  • Page 854 GEN3t Detailed description about the numbered items: Mainframe shown in auto-configure mainframe connection dialog. Figure E.2: Mainframe selection dialog 1a Press the Rescan button on the dialog above (see Figure E.2) to initiate a new network search for the mainframe. Typically, the mainframe should appear within a few seconds.
  • Page 855 GEN3t 2a If the mainframe is not shown in the list of unused hardware, make sure it is powered on. Use the right click menu on Unused Hardware and select Scan for Mainframes. Figure E.4: Unsed hardware context menu To determine if the mainframe starts, turn the unit off and back on. Then...
  • Page 856 13 For more information, please refer to the I2689 Perception User manual: Chapter “Data Sources navigation”, topic “To add an unlisted system” 14 To restore a GEN3t to its default network settings, follow the steps in chapter "Restore default network settings" on page 93.

  • Page 857: Embedded Software Upgrades

    GEN3t Embedded Software upgrades When a new version of Perception is installed, the embedded software of the mainframes is automatically updated when Perception connects to the mainframe. Note Some upgrades may take more than ten minutes. IMPORTANT Do not power-off the mainframe, do not disconnect network cables and do not shut down Perception during an embedded software upgrade.
  • Page 858 GEN3t When instructed to use the minimum boot mode switch: Power off the mainframe and remove the power cord. Remove all acquisition cards to allow access to the mainframes backplane See "Removing and installing input cards" on page 94 for more details.
  • Page 859 GEN3t To enable the recovery mode, use a pointy object (e.g. screwdriver) and move the lever to the side labeled Min. Figure E.6: Lever to switch the boot mode Lever Re-insert all acquisition cards. Insert the power cord and power on the mainframe.

  • Page 860: Unexpected Mainframe Shutdown

    GEN3t Unexpected mainframe shutdown If the mainframe has shut down unexpectedly, this can have several causes: Power interruption Check if the mains cable is still firmly connected. Check if other devices on the same mains group have experienced a power interruption.

  • Page 861: The Master/Slave Connection Does Not Synchronize

    GEN3t The Master/Slave connection does not synchronize If this happens, check the following: Check whether the Master/Slave mode setting for each mainframe matches the role of that mainframe. There should be one (and only one) Master and one or more Slave(s).

  • Page 862: The Irig/Gps Does Not Synchronize

    GEN3t The IRIG/GPS does not synchronize Verify the settings. Is the correct synchronization source selected? For IRIG, does the IRIG mode (such as “IRIG B AM”) match the IRIG signal? Check whether the connections are correct. For more information, please refer to the corresponding chapter.

  • Page 863: Optical Network (Sfp)

    GEN3t Optical Network (SFP) If no connection is present on the fiber optic channel, first check the following: Check whether the cable wavelength and SFP module wavelength are the same. Check the wavelength printed on the label of the SFP module with the specification of the cable used.

  • Page 864: Master/Slave Synchronization Verification Procedure

    Using the fiber optic cable, connect any Master/Slave card's connector of the master mainframe to Master/Slave card's top connector, labelled M/S IN, of the slave mainframes (For GEN2i/GEN3i/GEN3t/GEN7i/GEN7tA and GEN17tA use the Master/Slave synchronisation connector). Check if both LEDs on both Master/Slave cards are illuminated green. (For GEN2i/GEN3i/GEN3t/GEN7i/GEN7tA and GEN17tA, check the LEDs near the Master/Slave synchronisation connector).
  • Page 865 GEN3t The synchronization status will first be Synchronizing for up to three minutes before becoming Synchronized. Figure E.7: MASTER SLAVE Synchronizing Figure E.8: MASTER SLAVE Synchronized In the Settings sheet, go to the Trigger group in the task pane and select Channel.
  • Page 866 GEN3t 14 In the drop-down list that comes up, select Transceive for all recorders. Figure E.10: Master/Slave trigger list 15 Set the filter mode of both channels to "Wideband". 16 Set up a display with the first channel of the first recorder card in the master mainframe and the first channel of the first recorder card in the slave mainframe.

  • Page 867: F Rack Mount Instructions

    Equipment designed to be placed in a rack is described as rack-mount or a rack-mounted system. The GEN3t by itself cannot directly be mounted into a 19-inch rack. For this, you need to use the optional 19-inch rack mount kit.
  • Page 868 GEN3t There are only two screws that fastened to the upper portion of both sides of the brackets as shown in Figure F.2. Figure F.2: GEN3t with installed 19-inch brackets Screw location I3995-3.1 en HBM: public...

  • Page 869: Gptp Synchronisation

    GEN3t G PTP synchronisation Mainframe PTP connections G.1.1 GEN2i and GEN5i (No PTP support) Within the GEN series mainframes, the GEN2i and GEN5i have no support for PTP time synchronization. G.1.2 GEN7t and GEN16t The GEN7t and GEN16t only support PTP time synchronization when using an Interface/Controller module IM2.

  • Page 870: Gen7I

    GEN3t G.1.3 GEN7i Figure G.2: GEN7i PTP enabled ports PTP enabled network RJ45 PTP enabled network optical SFP slot (SFP module is optional) I3995-3.1 en HBM: public...

  • Page 871: Gen7Ta

    GEN3t G.1.4 GEN7tA Figure G.3: GEN7tA PTP enabled ports PTP enabled network RJ45 PTP enabled network optical SFP slot (SFP module is optional) I3995-3.1 en HBM: public...

  • Page 872: Gen3I And Gen3T

    GEN3t G.1.5 GEN3i and GEN3t Figure G.4: GEN3i/GEN3t PTP enabled ports PTP enabled network RJ45 PTP enabled network optical SFP slot (SFP module is optional) I3995-3.1 en HBM: public...

  • Page 873: Gen17Ta

    GEN3t G.1.6 GEN17tA Figure G.5: GEN17tA PTP enabled ports PTP enabled network RJ45 PTP enabled network optical SFP slot (SFP module is optional) I3995-3.1 en HBM: public...

  • Page 874: Perception Settings

    GEN3t Perception settings GEN7t/GEN16t - Perception settings G.2.1 As the GEN7t and GEN16t only have 1 PTP port, set “Sync Source“ to PTP1: Figure G.6: Perception - Sync source option (PTP 1) Sync source option PTP 1 I3995-3.1 en HBM: public...

  • Page 875: Gen3I, Gen7I, Gen3T, Gen7Ta And Gen17Ta - Perception Settings

    GEN3t GEN3i, GEN7i, GEN3t, GEN7tA and GEN17tA - Perception settings G.2.2 Set "Sync Source“ to PTP1 (RJ45) or to PTP2 (optical): Figure G.7: Perception - Sync source option (PTP 1) or (PTP 2) Sync source option PTP 1 PTP 2...

  • Page 876: Synchronizing Gen Series And Quantumx Using Ptp

    GEN3t Synchronizing GEN series and QuantumX using PTP G.3.1 GEN3i/GEN7i with single QuantumX "B" version module Figure G.8: GEN3i with single MX1609KB/MX1609TB - Overview Note Setup only shows GEN3i. GEN3i can be replaced by GEN7i. Note Setup only shows MX1609KB, MX471B (CAN) could also be used.

  • Page 877: Gen3I/Gen7I With Single Somatxr "B" Version Module

    GEN3t G.3.2 GEN3i/GEN7i with single Somat "B" version module MX1609KB-R - Overview Figure G.9: GEN3i with single Somat Note Setup only shows GEN3i. GEN3i can be replaced by GEN7i. I3995-3.1 en HBM: public...

  • Page 878: Gen3I/Gen7I With Up To Three Quantumx "B" Version Modules

    GEN3t G.3.3 GEN3i/GEN7i with up to three QuantumX "B" version modules Figure G.10: GEN3i with a mix of three QuantumX "B" version modules Note Setup only shows GEN3i. GEN3i can be replaced by GEN7i. Note * All modules must be “B“ versions; one module must set to “clock master“ and connected to the GEN3i PTP Ethernet.

  • Page 879: G.3.4 Gen3I/Gen7I With Standard Network Switch And Four Or More Of Quantumx "B" Version Modules

    GEN3t G.3.4 GEN3i/GEN7i with standard network switch and four or more of QuantumX "B" version modules Figure G.11: GEN3i with multiple QuantumX "B" version modules Note Setup only shows GEN3i. GEN3i can be replaced by GEN7i. Note * Multiple QuantumX modules requires more than one power supply; see QuantumX documentation.
  • Page 880 GEN3t Background network details If the network ports are configured for DHCP setup, each of the connections using the APIPA protocol to find a free IP address. As the two network ports are not linked together the APIPA protocol on the PTP port does not detect the address used any of the network devices on the second network port.

  • Page 881: Gen3I/Gen7I With Ptp Network Switch And Four Or More Of Quantumx "B" Version Modules

    GEN3t G.3.5 GEN3i/GEN7i with PTP network switch and four or more of QuantumX "B" version modules Figure G.12: GEN3i with multiple MX1609KB/MX1609TB - Using PTP switch Note Setup only shows GEN3i. GEN3i can be replaced by GEN7i. Note * Multiple QuantumX modules requires more than one power supply; see QuantumX documentation.

  • Page 882: Gen3T/Gen7Ta/Gen17Ta With Single Quantumx "B" Version Module

    GEN3t G.3.6 GEN3t/GEN7tA/GEN17tA with single QuantumX "B" version module Figure G.13: GEN7tA with single QuantumX "B" version module Note Setup only shows GEN7tA. GEN7tA can be replaced by GEN3t or GEN17tA. I3995-3.1 en HBM: public...

  • Page 883: Gen7Ta With Multiple Quantumx "B" Version Modules

    GEN7tA with multiple QuantumX "B" version modules Figure G.14: GEN7tA with multiple MX1609KB/MX1609TB - Using PTP switch Note Setup only shows GEN7tA. GEN7tA can be replaced by GEN3t or GEN17tA. Note * Multiple QuantumX modules requires more than one power supply; see QuantumX documentation.

  • Page 884: Gen7T/Gen16T With Single Quantumx "B" Version Module

    GEN3t G.3.8 GEN7t/GEN16t with single QuantumX "B" version module Figure G.15: GEN7t with single QuantumX "B" version module Note Setup only shows GEN7t. GEN7t can be replaced by GEN16t. I3995-3.1 en HBM: public...

  • Page 885: Gen7T With Multiple Quantumx "B" Version Modules

    GEN3t G.3.9 GEN7t with multiple QuantumX "B" version modules Figure G.16: GEN7t with multiple MX1609KB/MX1609TB - Using PTP switch Note Setup only shows GEN7t. GEN7t can be replaced by GEN16t. Note * Multiple QuantumX modules requires more than one power supply; see QuantumX documentation.

  • Page 886: Genesis And Quantumx Setup Using Irig-To-Ptp Bridge

    GEN3t G.3.10 Genesis and QuantumX Setup using IRIG-to-PTP Bridge Figure G.17: Setup of IRIG-to-PTP Bridge Note GEN7tA can be replaced by GEN3t/GEN7t/GEN17tA/GEN3i/GEN7i Settings in Perception ● Use the RJ45 connector for PTP support (PTP 1). I3995-3.1 en HBM: public...

  • Page 887: Ptp Grandmasters

    GEN3t G.3.11 PTP Grandmasters IRIG or GPS to PTP bridge ® Successfully tested Symmetricom SyncServer S350 Equivalent model Symmetricom Xli GPS receiver (Model 1510-713) Figure G.18: Symmetricom Xli GPS receiver www.microsemi.com/ For more information please refer to: GPS to PTP Bridge Successfully tested OTMC 100i Grand Master Clock www.omicron-lab.com/...

  • Page 888: Ptp Capable Switch

    GEN3t G.3.12 PTP capable switch Successfully tested Siemens scalance xr324-12m Figure G.19: Siemens scalance xr324-12m For more information, please refer to: www.support.automation.siemens.com/CN/ I3995-3.1 en HBM: public...

  • Page 889: Using Ptp And Master/Slave In Combined Setup

    Master/Slave setup and PTP Synchronization. Set GEN3i as Master and GEN3t as Slave Figure G.20: Example of correct PTP usage Note GEN3i can be replaced by GEN7i.The GEN3t can be replaced by GEN7t/ GEN7tA/GEN16t as slave. I3995-3.1 en HBM: public...

  • Page 890: Ptp Configuration Errors

    GEN3t G.3.14 PTP configuration errors Figure G.21: Example of incorrect PTP usage This is not possible! Set "Sync Source“ to PTP1 (RJ45) to PTP2 (optical) Both at the same time is not possible: we don’t “bridge” PTP1 to PTP2 I3995-3.1 en HBM: public...

  • Page 891: H Application Specific Usage

    GEN3t H Application Specific Usage Rotational External Clock GEN DAQ systems allow extensive setups for rotating external clock measurements. This document explains how to use the settings to get the job done. H.1.1 GEN DAQ settings explained All settings shown in this document can be found in the Perception software.
  • Page 892 GEN3t Switch the settings sheet to show the advanced (dark grey) settings by using the Settings menu item Settings ► Show Settings ► Advanced (All settings) Figure H.2: Settings menu Advanced (All Settings) I3995-3.1 en HBM: public...

  • Page 893: Memory And Time Base

    GEN3t H.1.2 Memory and Time base Mainframe In the settings sheet, select Memory & Time base ► Mainframe. The Mainframe setting sheet should look like Figure H.3. Figure H.3: Memory and Time base Memory and time base settings Clock base...
  • Page 894 GEN3t Unit scaling = 360 Clock Scaling = 1500 The result is shown in the read-only “Scale result”: 240 mDegrees/Clock pulse Clock shift: (TDC position) This setting can be used to shift the position of the 0 degree indication on screen automatically.

  • Page 895: Recorder/Time Base Groups

    GEN3t Recorder/Time base groups Note Perception V6.20 and earlier version use recorder settings for the next setting. In later version of Perception, these recorder settings have been replaced by Time base group settings. The basic behavior of the “External Clock Divider” is identical.

  • Page 896: Perception Display Settings Explained

    GEN3t Note One way to overcome exceeding the maximum external sample rate of the card of choice might be to use the “External Clock Divider”. The maximum external clock rate of the GEN DAQ mainframe is 2 MS/s. Using an “External Clock Divider”...
  • Page 897 GEN3t In the Setup of Display dialog, select the Annotation & Grid tab. For external time base recordings, select the X-Annotation scaling to Position. In this mode, there are three ways to show the X-axis. Figure H.5: Display Setup dialog - Annotation & Grid...

  • Page 898: Cylinder Pressure Analysis Option Package

    GEN3t Rotational, 720 degrees per cycle The X position is expressed by 720 degrees cycles and the number of remaining degrees. E.g. 1200 degrees will show as 1:480, which means 1 cycle and 480 degrees. Perception will use the TDC setup process to determine the proper 0 degree point.

  • Page 899: Cylinder Pressure Analysis Customer Evaluation

    GEN3t H.1.6 Cylinder Pressure Analysis customer evaluation HBM offers a 30 day evaluation version of this special software to see if this meets the requirements. Special wishes can be adapted as cost option after consulting our CSI programmer. H.1.7 Cylinder Pressure Analysis and TDC settings The Cylinder Pressure Analysis application is able to use all of the available TDC settings.

  • Page 900: Dy/Dt Triggering

    GEN3t dY/dT Triggering Basic setting definitions: The result of subtracting two ADC values Specifies the time between the two samples subtracted These two setting values are independent of each other. The user therefore needs to specify both settings explicitly for the trigger unit to do a correct job.
  • Page 901 GEN3t Example: dY set to -4 V dT set to 2 ms Basic trigger Falling edge Figure H.8: Example of a dY/dT triggering In the next images, the two cursors are set to 2 ms. This means the difference between the blue and the red cursor will be the value sent to the trigger unit.
  • Page 902 GEN3t Next sample recorded (sample of blue cursors, see Figure H.9) Difference is -2.451 V dY not met, no trigger Figure H.9: Sample recording 1 Next sample recorded (sample of blue cursors, see Figure H.10) Difference now is -3.81633 V dY not met, no trigger Figure H.10: Sample recording 2...
  • Page 903 GEN3t Next sample recorded (sample of blue cursors, see Figure H.11) Difference now is -4.49867 V dY met As previous dY was higher value, this is a falling edge: trigger Figure H.11: Sample recording 3 Note Trigger edge in this case is the edge of the differentiated signal, not the signal itself.

  • Page 904: External Start/Stop On Digital Event/Timer/Counter Connector

    GEN3t External Start/Stop on Digital Event/Timer/Counter connector HINT/TIP The External Start/Stop signals on the Digital Event/Timer/Counter are only present for backward compatibility and will not be supported on all future acquisition cards. It is recommended to use the External Start/Stop signals on the mainframe's I/O connector whenever possible.
  • Page 905 GEN3t This setting enables both Start and Stop control at the same time. The external Start/Stop inputs are edge-sensitive. As the Start/Stop signals are shared event input bits, the active edge is selected by means of the invert setting of Event channels 15 and 16 of the corresponding card (see Figure H.14).
  • Page 906 GEN3t POWER PIN 31 - Event Input 15B & External Stop B PIN 32 - Event Input 16B & External Start B PIN 33 - Event Input 13A PIN 34 - Event Input 14A PIN 35 - Event Input 15A & External Stop A PIN 36 - Event Input 16A &...
  • Page 907 GEN3t As the Start/Stop event are software processed events, there is a response time before the Start/Stop is executed. After an event is received, a 100 ms “disable” time period starts. During the disable time period, the same event will not be detected.

  • Page 908: Calculating Maximum Fiber Cable Length

    GEN3t Calculating maximum fiber cable length Maximum optical fiber length is determined by two major factors: optical loss and bandwidth limit. These types of optical fiber performance and quality are defined in the ISO standard ISO/IEC 11801. OMx/OCx = ISO/...
  • Page 909 GEN3t This formula also applies to Single Mode systems For example, if two couplers are used in the cable, c = 2, the maximum length would be L = 1 km optical The second limiting factor for cable length is fiber cable bandwidth.

  • Page 910: Wake On Lan Support (Wol)

    GEN3t Wake On LAN support (WOL) Several of the GEN series mainframes support Wake On LAN features (WOL). WOL is only supported on copper or optical networks. WOL is not supported by wireless networks. At the time of this manual's release, the following mainframes support WOL:...
  • Page 911 GEN3t WAN (Wide Area Network) support As the name WOL indicates (Wake on LAN), there is no direct support outside the boundaries of your LAN (Local Area Network). A LAN typically ends as soon as routers or layer 3 switches are used to transfer network data from point A to point B.

  • Page 912: Locating Gen3I And Gen7I Mac/Physical Address

    GEN3t H.5.1 Locating GEN3i and GEN7i MAC/Physical address For GEN3i and GEN7i, the MAC/Physical address can be found in ® Windows in the following manner: Connect the required network port. ® Go to Windows Network and Sharing Center. Select Local Area Connection (A).
  • Page 913 GEN3t The Local Area Connection Status dialog opens. Select Details. Figure H.17: Local Area Connection Status I3995-3.1 en HBM: public...

  • Page 914: Locating Gen3T, Gen7Ta And Gen17Ta Mac/Physical Address

    Network Connection Details dialog as a twelve character string. H.5.2 Locating GEN3t, GEN7tA and GEN17tA MAC/Physical address For GEN3t, GEN7tA and GEN17tA, the MAC/Physical address can be found in Perception in the following manner: Start the Perception software Connect to either GEN3t, GEN7tA or GEN17tA.
  • Page 915 GEN3t Open the Hardware window. Select the target mainframe (A). Right click on the mouse to open the context menu. Select Mainframe view (B). Figure H.19: Hardware window in Perception Target mainframe Mainframe view The MAC/Physical address of the selected network connection is displayed in the Properties window as a twelve character string.

  • Page 916: Configuring An Encoder With Direction And Reset

    GEN3t Configuring an encoder with direction and reset Pins and Connectors: Figure H.21: Connecting Encoders with reset and direction options to a GEN3t The following descriptions shows how to configure the encoder: ● Pins and connectors from encoder to level converter (see chapter "From encoder to level converter"...
  • Page 917 GEN3t 2 3 4 5 6 10 11 12 13 14 Top view T12 speed Txx adapter speed Plug pin Assignment adapter Speed Rotational speed measurement signal Pin 12 (pulse string, 5 V; 0°) Reference signal (1 pulse/revolution, 5 V)
  • Page 918 GEN3t The signal from the encoder has the following characteristics: PIN 1 PIN 6 90° PIN 3 PIN 7 PIN 2 Reset PIN 4 -2500.Ous 2500.Ous Edge CH5 Normal 1 2.40V Figure H.22: Rotational speed signals at level converter I3995-3.1 en HBM: public...

  • Page 919: From Level Converter To Digital I/O Connector On The Mainframe

    H.6.2 From level converter to Digital I/O connector on the mainframe This cable is included with the level converter (1-G070-2). Figure H.23: Connecting a GEN3t from level converter to a digital I/O connector H.6.3 Activate Digital I/O channels with Perception In order to activate the Digital I/O channels, including the counter/timer channels, a module that supports the Digital I/O connector must be installed.
  • Page 920 GEN3t The Timer/Counter channels that are active depend on which pins of the Digital I/O connector are used: PIN 1 - Event Input 1A & Reset Timer/Counter 2A PIN 22 - Event Input 10B & Reset Timer/Counter 1B PIN 2 - Event Input 2A & Direction Timer/Counter 2A PIN 23 - Event Input 11B &...
  • Page 921 GEN3t For this example, connect one B-Txx CON2 Speed and wire it to the Ch B9 counter (Pins 13, 14, 15 on the digital input connector). Note Perception allows you to view each of the inputs individually as an event channel in addition to seeing the counter result.

  • Page 922: To Activate Channel 8 Or Channel 9 In Perception

    GEN3t To activate Channel 8 or Channel 9 in Perception Change the resolution of Recorder B to 18 bit Figure H.26: Activating Channel 8 or Channel 9 in Perception Recorder B with 18 bit resolution Configure the B-Txx CON2 in Ch B9 (Perception): Figure H.27: Configuration of the B-Txx CON2 connector in Perception...
  • Page 923 GEN3t Quadrature disk Signal Signal Direction Direction ∆t ∆t ∆t ∆t ∆t: Must be > 50 ns Single precision counting Signal Direction Count Up Count Up Count Up Count Down Count Down Count Down Wheel rotates clock wise Wheel rotates counter clock wise...
  • Page 924 GEN3t Timer Counter mode: Count Quadrature -> counters monitor the transition of the four different states the signal can be in. Reset Mode: Each External Pulse -> resets the counter every time we receive a pulse in Reset input. Range from/to 0 to 360°...
  • Page 925 GEN3t Another possibility is to configure the counter channel using the Perception Sensor Database: Figure H.29: Perception Sensor Database (Configuring the counters channel) A Sensor goups/Counters: F1 + F2 Quadrature B General information/Name: F1 + F2 Quadrature Assign the sensor F1+F2_Quadrature sensor to Channel Ch B9.
  • Page 926 GEN3t Figure H.30: Configuration of the B-Txx CON2 connector in Perception A Sensor B Invert reset pin The settings of the the frequencies F1+, F1-, reset and the counter signal on ChB9 are displayed in the following window (see Figure H.31)
  • Page 927 GEN3t Figure H.31: F1+, F1- , Reset Angular variation (Perception) Reset Angular variation I3995-3.1 en HBM: public...

  • Page 928: I Disk Storage Technology

    GEN3t I Disk Storage Technology Most used RAID modes RAID (Redundant Array of Independent Disks) is a technology that is used to increase the performance and/or reliability of data storage. A RAID system consists of two or more disks working as a single logical unit for the purposes of data redundancy or performance improvement.
  • Page 929 GEN3t RAID 0 RAID 1 RAID 5 RAID 10 Minimum no. of disks required Required no. of disks to extend array Maximum Sum of Disks One disk size Sum Of Sum of Disks -1 volume size Disks /2 Redundant 100%...

  • Page 930: Raid 0 - Striping

    GEN3t I.1.1 RAID 0 – Striping In a RAID 0 system, storage is split into blocks that are written split across all the drives in the array. Using more disks in one RAID 0 system offers higher storage rates. The performance also depends on the RAID controller used.

  • Page 931: Raid 1 - Mirroring

    GEN3t I.1.2 RAID 1 – Mirroring In a RAID 1 system, data is stored twice by writing to both a (set of) data disk(s) and a (set of) mirror disk(s). If one disk fails, the controller uses either the data disk or the mirror disk for data recovery and continues operation.

  • Page 932: Raid 5 - Striping With Parity

    GEN3t I.1.3 RAID 5 – Striping with parity RAID 5 arrays require at least three disks. Data blocks are subdivided (striped) and written to two (or more) drives. Parity for the stored data blocks is calculated and stored on an additional drive. Parity is not stored on a dedicated drive but spread across all the drives in the array.

  • Page 933: Raid Level 10 - Combining Raid 0 & Raid

    GEN3t I.1.4 RAID level 10 – Combining RAID 0 & RAID 1 RAID 10 combines RAID 0 and RAID 1 in one single system. It provides security by mirroring all data on a secondary set of disks (Disk 2 and 4 in the drawing below) while using striping across each set of disks to speed up data transfers.

  • Page 934: Setting Up The Iscsi Target Using Synology® Nas

    GEN3t ® Setting up the iSCSI target using Synology For further tutorials, please refer to: www.synology.com/tutorials/tutorials.php Equipment needed: ® Synology assistant iSCSI NAS GEN DAQ system with Ethernet Make sure the network is set up and correctly connected to the NAS storage device.
  • Page 935 GEN3t A login screen may appear, depending on whether or not the NAS has been set up before. You should not need to log in for the first time when setting up a NAS. If you see a login screen, you need to log in with the details that were used to set up the NAS the first time it was used.
  • Page 936 GEN3t When logged in and on the home screen, click the main-menu icon (A) as shown in Figure I.7. Figure I.7: Home screen Main-menu icon I3995-3.1 en HBM: public...
  • Page 937 GEN3t A quick launch window will open. Figure I.8: Quick launch window Storage Manager Click the Storage Manager icon. I3995-3.1 en HBM: public...
  • Page 938 GEN3t The Storage Manager dialog opens. Figure I.9: Storage Manager dialog iSCSI LUN iSCSI Target First, set up an iSCSI Target or iSCSI LUN. In Perception, this information will be used in the External Storage Setup: iSCSI Target dialog box.
  • Page 939 GEN3t Click the tab iSCSI Target: Figure I.10: iSCSI Target window dialog Create tab Edit tab This tab shows the available iSCSI Target disks and their details. To create a new iSCSI Target, click Create. I3995-3.1 en HBM: public...
  • Page 940 GEN3t The following iSCSI Creation Wizard dialog appears: Figure I.11: Create a new iSCSI Target dialog Name IQN number Enable CHAP CHAP Name: CHAP Password: CHAP Confirm Password: G Enable Mutual CHAP The dialog in Figure I.11 asks for your IQN (B) number and a Target Name (A).
  • Page 941 GEN3t IQN: Enter the actual iSCSI IQN name here. Recommended Format: iqn.yyyy-mm.domain:device.ID This IQN name is the same name used in the Perception dialog External storage setup: iSCSI Target - Target name (see chapter “Interface/Controller Module” in the GEN series Data Acquisition System”...
  • Page 942 GEN3t 10 When setting up an iSCSI Target, you also need to set up an iSCSI LUN as follows. Figure I.12: Create a new iSCSI LUN target dialog From the Storage Manager window, select Create new iSCSI LUN when no LUNs are yet available. If LUNs are available, then you may select Map existing iSCSI LUNs.
  • Page 943 GEN3t 11 Create a new iSCSI LUN Figure I.13: Create a new iSCSI LUN target - Choose a LUN type dialog iSCSI LUN (Regular Files) iSCSI LUN (Block-Level) - Single LUN on RAID iSCSI (Block-Level) - Multiple LUNs on RAID Select iSCSI LUN (Block-level) - Single LUN on RAID (B).
  • Page 944 GEN3t 12 The Create a new iSCI target - Choose disks dialog appears. Figure I.14: Create a new iSCSI LUN target - Choose disks dialog Choose one or more physical discs to use as a LUN target and click Next.
  • Page 945 GEN3t 13 The Create a new iSCI target - Choose RAID type dialog appears. Figure I.15: Create a new iSCSI LUN target - Choose a RAID type Select the RAID configuration you require. A number of configurations are possible, depending on the available setup.
  • Page 946 GEN3t 14 The Create a new iSCI target - Perform disk check dialog appears. Figure I.16: Create a new iSCSI LUN target - Perform disk check dialog Follow the on screen dialog and select your preference. Disk checking will take a long time and depends on the size of the disk being checked.
  • Page 947 GEN3t 15 The Create a new iSCI target - Confirm Settings dialog appears. Figure I.17: Create a new iSCSI LUN target - Confirm Settings dialog A summary of the information used to create the new iSCSI LUN/Target is presented. Make sure the information is correct and then click Apply.

  • Page 948: Jbe3200 Usb To Optical Rs232 Convertor

    GEN3t J BE3200 USB to Optical RS232 convertor Re-programming of the USB-RS232 (opt. 650nm) converter to work with BE3200 Download the “FT-Prog“ from: www.ftdichip.com/Support/Utilities.htm“ This is required to re-program the internal EEPROM in the converter to support inverted TX/RX lines (required to work with BE3200).
  • Page 949 GEN3t In Device Tree in the left-hand column, expand the Hardware Specific node and select the Invert RS232 Signals (see Figure J.2). In the Property column, select Invert TXD and Invert RXD check boxes (see Figure J.2): Figure J.2: FTDI ˗ FT Prog (Part2)

  • Page 950: K Legacy Information - Input Cards

    GEN3t K Legacy Information - Input Cards Basic amplifier non-isolated input cards K.1.1 GN810 Basic 200kS/s input card 8 analog channels Single-ended inputs ± 1 V to ± 50 V input range User selectable digital Bessel and FIR filters 200 kS/s sample rate...

  • Page 951: Gn811 Basic 1Ms/S Input Card

    GEN3t K.1.2 GN811 Basic 1MS/s input card 8 analog channels Single-ended inputs ± 1 V to ± 50 V input range User selectable digital Bessel and FIR filters 1 MS/s sample rate 16 bit resolution 256 MB memory Single metal BNC for each channel...

  • Page 952: Gn812 Basic Iso 1Ms/S Input Card

    GEN3t GN812 Basic ISO 1MS/s input card 8 analog channels Unbalanced differential inputs ± 1 V to ± 50 V input range 250 V DC Isolation User selectable digital Bessel and FIR filters 1 MS/s sample rate 16 bit resolution...

  • Page 953: Basic Extended Isolated Amplifier Card

    GEN3t Basic Extended Isolated amplifier card K.3.1 GN813 Basic XT ISO 1 MS/s input card 8 analog channels Unbalanced differential inputs ± 2 V to ± 100 V input range 250 V DC channel to channel isolation User selectable digital Bessel and FIR filters...

  • Page 954: Gn814 Basic Xt Iso 200Ks/S Input Card

    GEN3t K.3.2 GN814 Basic XT ISO 200kS/s input card 8 analog channels Unbalanced differential inputs ± 2 V to ± 100 V input range 250 V DC isolation User selectable digital Bessel and FIR filters 200 kS/s sample rate 16 bit resolution...

  • Page 955: Optional G041 1Kv Dc Probe

    This uses up a single height unit and holds up to sixteen 1kV DC probes. Each probe comes with a fixed output connection cable with a double isolated coax cable. This connects directly into the Genesis Isolated Basic amplifier. CAUTION As the probe rack specifies the maximum voltages per input pin, the 1kV DC and AC probes are not to be mixed in one probe rack.
  • Page 956 GEN3t CAUTION The coaxial cable attached to the 1kv DC probe adds a capacitive load to the output of the probe. Every cm length added or removed changes the capacitive load. By design, the cable length of the 1kV DC probe is fixed and cannot be changed.

  • Page 957: Optional G042 1Kv Ac Probe

    This uses up a single height unit and holds up to sixteen 1kV AC probes. Each probe comes with a fixed output connection cable with a double isolated coax cable. This connects directly into the Genesis Isolated Basic amplifier. CAUTION As the probe rack specifies the maximum voltages per input pin, the 1kV DC and AC probes are not to be mixed in one probe rack.
  • Page 958 GEN3t 1kV AC-Probe (1-G042-2) Schematic input diagram GN813/814 Coax cable 1 MΩ Figure K.4: 1kV DC probe 1-G042-2 The probes have no calibration points. As the probe is fixed AC coupled, no DC inaccuracy is specified. The AC high pass bandwidth inaccuracy is designed to meet its specification based on the input impedance of the basic extended isolated amplifiers.
  • Page 959 GEN3t Bandwidth overview Passband flatness -0.5 -1.0 -1.5 -2.0 -2.5 -3.0 0.0001 0.001 0.01 0.0005 0.001 0.01 1000 Frequency [kHz] Frequency [kHz] Vdb (WB) Vdb (Butterworth) Vdb (Bessel) Vdb (WB) Vdb (Butterworth) Vdb (Bessel) Figure K.5: Typical 1kV AC probe bandwith...

  • Page 960: High Resolution Iepe And Charge Input Cards

    GEN3t High Resolution IEPE and Charge input cards K.4.1 GN1610 250 kS/s input card The GN1610 charge 250 kS/s input cards are a no-compromise solution for high channel count data acquisition systems. This card brings: A cost-effective solution with 16 channels per card...
  • Page 961 GEN3t Front View CH 16 NEG. RESERVED RESERVED CH 16 POS. CH 8 NEG. RESERVED CH 15 NEG. CH 8 POS. RESERVED CH 15 POS. CH 7 NEG. RESERVED CH 14 NEG. CH 7 POS. RESERVED CH 14 POS. CH 6 NEG.

  • Page 962: Gn1611 Basic 20 Ks/S Input Card

    GEN3t K.4.2 GN1611 basic 20 kS/s input card The GN1611 20 kS/s input card is a no-compromise solution for high-channel-count data acquisition systems. This card offers: A cost-effective solution with 16 channel per card High precision with a 16 bit A-to-D convertor for each channel...
  • Page 963 GEN3t Front View CH 16 NEG. RESERVED RESERVED CH 16 POS. CH 8 NEG. RESERVED CH 15 NEG. CH 8 POS. RESERVED CH 15 POS. CH 7 NEG. RESERVED CH 14 NEG. CH 7 POS. RESERVED CH 14 POS. CH 6 NEG.

  • Page 964: Master/Slave Card (G040)

    GEN3t Master/Slave card (G040) The GEN series can be operated as a fully synchronized Multi-Mainframe system with multiple mainframes using the Master/Slave card. With the Master/Slave card you can: connect one GEN series “Master” to up to eight “Slaves” fully synchronize up to nine mainframes...

  • Page 965: Master/Slave Card Operations

    GEN3t In Slave mode: the top connector is configured as slave input, all other connectors are unused all received signals are transferred to a bus for internal distribution internal slave trigger signals are transferred to the outside In Stand-alone mode: Stand-alone mode is OFF: the Master/Slave card does not communicate with other Master/Slave cards.
  • Page 966 GEN3t Figure K.8: Master/Slave card In Master mode, all connectors M function as master output (OUT 1 to OUT 8). In Slave mode, the top connector S functions as a slave input (IN), all other connectors are unused. ® Figure K.9: Example of a duplex LC connector I3995-3.1 en HBM: public...

  • Page 967: Led Indicators

    GEN3t LED indicators On the front panel of the Master/Slave card two LEDs indicate the status of the link. icon is used to identify the signal detect function. icon is for data/synchronization identification. Figure K.10: LED indicators icon icon The following table shows the function and possible combinations of the two LEDs.
  • Page 968 GEN3t In the GEN series tower model the Master/Slave card is installed on the left- hand side of the Interface/Controller module. TB-A RESET Figure K.11: GEN series tower model with Master/Slave card installed Master/Slave card Interface/Controller module I3995-3.1 en HBM: public...
  • Page 969 GEN3t In the GEN series 19” rack model the Master/Slave card is installed into Slot A on the right-hand side of the Interface/Controller module. MENU SELECT DOWN MAINS POWER TB-A RESET Figure K.12: GEN series 19” rack model with Master/Slave card installed...

  • Page 970: Installing And Removing The Master/Slave Card

    GEN3t K.5.2 Installing and removing the Master/Slave card The Master/Slave card is easily inserted into the GEN series mainframe and is automatically recognized by the Perception software. The card is removed and installed in the same way as all the acquisition cards.
  • Page 971 GEN3t The built-in laser complies with laser product standards set by government agencies for Class 1 laser products: In the USA, the Master/Slave card is certified as a Class 1 laser product conforming to the requirements contained in the Department of Health and Human Services (DHHS) regulation CDRH 21 CFR, Chapter I Subchapter J Part 1040.10.
  • Page 972 GEN3t Slide the card into its guide rails until the ejectors contact the perforated metal strips at top and bottom. Figure K.13: Slide in the card I3995-3.1 en HBM: public...
  • Page 973 GEN3t Press both ejectors inwards to seat the card. They act as levers to gently push the card into its backplane sockets. Figure K.14: Press ejectors inwards I3995-3.1 en HBM: public...
  • Page 974 GEN3t Fasten the small set screw on both ejectors on the card. Figure K.15: Ejector set screw The Master/Slave card is installed. Removing the Master/Slave card To remove the Master/Slave card: Power off the GEN series and remove the power input cable.
  • Page 975 GEN3t Press the inner grey button on each ejector to release the catch. Figure K.17: Inner grey button on ejector I3995-3.1 en HBM: public...
  • Page 976 GEN3t Press both ejectors outwards to release the card. They act as levers to gently pull the card from its backplane sockets. Figure K.18: Press ejectors outwards I3995-3.1 en HBM: public...
  • Page 977 GEN3t Slide the card out of the GEN series unit. Figure K.19: Remove the card I3995-3.1 en HBM: public...

  • Page 978: Connecting The Master/Slave Card

    GEN3t K.5.3 Connecting the Master/Slave card With the fiber optic cable, connect the Master/Slave card labelled M, OUT of the master mainframe to the top connector labelled M/S IN of the Master/Slave card of the slave mainframes. TB-A TB-A RESET RESET Figure K.20: Connecting the Master/Slave...

  • Page 979: Example Of A Master/Slave Configuration (Legacy)

    GEN3t K.5.4 Example of a Master/Slave configuration (legacy) The following diagram shows an example of a Master/Slave configuration with a master driving six slave mainframes. GEN7t TB-A RESET GEN7t GEN16t MENU SELECT DOWN MAINS POWER TB-A RESET TB-A RESET GEN3t...

  • Page 980: Using Legacy And New Mainframes In Master/Slave Setup

    GEN3t Connect the connector labelled M/S, OUT 1 of the Master mainframe to the top connector labelled M/S IN of the first Slave mainframe. Connect the connector labelled M, OUT 2 of the Master mainframe to the top connector labelled M/S IN of the second Slave mainframe.
  • Page 981 GEN3t IMPORTANT The optional Master/Slave card is not supported in the GEN3i, GEN3t, GEN7i or GEN7tA. Therefore, this setup requires a GEN7t, GEN16t, GEN5i or GEN2i with a Master/Slave card installed as a Master unit. In this setup, one of the mainframes with a Master/Slave card must be set to Master while the other mainframes must all be set to Slave.
  • Page 982 GEN3t GEN7t TB-A RESET GEN7t GEN16t MENU SELECT DOWN MAINS POWER TB-A RESET TB-A RESET GEN3t GEN3i GEN7i GEN7tA PTP1 POWER OUT PTP2 PTP1 PTP2 24V 1.5A max 1 MW 250Vpk 1 MW 250Vpk 1 MW 250Vpk 1 MW 250Vpk...
  • Page 983 GEN3t Connect the connector labelled M, OUT 3 of the Master mainframe to the Master/Slave synchronization connector of the third Slave mainframe. Connect the connector labelled M, OUT 4 of the Master mainframe to the Master/Slave synchronization connector of the fourth Slave mainframe.

  • Page 984: L Legacy Information - Specifications

    GEN3t L Legacy Information - Specifications B2632-3.1 en (GEN series GN810) Capabilities Overview Model GN810 Maximum sample rate per channel 200 kS/s Memory per card 128 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter...
  • Page 985 GEN3t Block Diagram Digital Filter & Amplifier Analog Anti-Alias Filter Sample Rate selection Channel 1 to 8 DC/GND Σ 1010 1.0 or 1.024 MS/s Sample Rate 1.0 or 1.024 MS/s Communication Channel & & Memory & Synchronization Card Trigger Recording control &...
  • Page 986 GEN3t Analog Input Section Channels Connectors Metal BNC, 1 per channel Input type Analog single-ended Input coupling DC, GND 1 MΩ ± 1% // 65 pF ± 10% Impedance ± 1 V, ± 2 V, ± 5.0 V, ± 10 V, ± 20 V, ± 50 V Ranges Each fixed range supports a variable gain with 1000 steps (0.1%).
  • Page 987 GEN3t Anti-Alias Filters Using different filter selections (Bessel IIR/FIR/etc.) or different filter bandwidths can result in phase mismatches between channels. SAR ADC Digital Filter (Anti-Alias) Sample Rate Selection Analog Anti-Alias Filter 1 out of N Σ Analog Input 1010 Figure L.2: Combined analog and digital anti-alias filter block diagram Anti-aliasing is prevented by a steep, fixed frequency analog anti-alias filter in front of the Analog to Digital Converter (ADC).
  • Page 988 GEN3t Bessel IIR Filter (Digital Anti-Alias) 1 + δp δp : Passband ripple 1 - δp δs: Stopband attenuation -3 dB ωp : Passband frequency ωc : Corner frequency Passband Stopband δs ωs : Stopband frequency ωp ωc ωs Frequency [kHz] Figure L.3: Digital Bessel IIR Filter...
  • Page 989 GEN3t FIR (Fc @ -0.1 dB) Filter (Digital Anti-Alias) δp: Passband ripple 1 + δp 1 - δp δs: Stopband attenuation ωp: Passband frequency ωc: Corner frequency Passband Stopband δs ωs: Stopband frequency ωp=ωc ωs Frequency [kHz] Figure L.5: Digital FIR (Fc @ -0.1 dB) filter When FIR (Fc @ -0.1 dB) filter is selected, this is always a combination of an analog Butterworth anti-alias filter and a digital FIR (Fc @ -0.1...
  • Page 990 GEN3t FIR (Fc @ -3 dB) Filter (Digital Anti-Alias) δp : Passband ripple + δp - δp δs : Stopband attenuation -3 dB ωp : Passband frequency Passband Stopband ωc : Corner frequency δs ωs : Stopband frequency ωp ωc ωs...
  • Page 991 GEN3t Channel to Channel Phase Match Using different filter selections (Bessel IIR/FIR/etc.) or different filter bandwidths results in phase mismatches between channels. Bessel IIR (Fc @ -3 dB), 20 kHz Filter frequency; 10 kHz sine wave Channels on card 0.4 deg (0.1 µs) GN810 Channels within mainframe 0.4 deg (0.1 µs)
  • Page 992 GEN3t Triggering Channel trigger/qualifier 1 per channel; fully independent per channel, software selectable either trigger or qualifier 0 to full memory Pre- and post-trigger length Maximum trigger rate 400 triggers per second Manual trigger (Software) Supported External Trigger In Selection per card...
  • Page 993 GEN3t Alarm Output Selection per card User selectable On/Off Alarm modes Basic or Dual Basic Above or below level check Dual (level) Outside or within bounds check Alarm levels Levels Maximum 2 level detectors Resolution 16 bit (0.0015%) for each level...
  • Page 994 GEN3t Recording Mode Details Single Sweep Multiple Sweeps Slow-Fast Sweep Continuous Dual Rate Enabled channels Enabled channels Enabled channels 1 Ch 2 Ch 8 Ch 1 Ch 2 Ch 8 Ch 1 Ch 2 Ch 8 Ch Max. sweep memory...
  • Page 995 GEN3t Slow-Fast Sweep Maximum number of sweeps 1 per recording Maximum slow sample rate Fast sample rate divided by two or 50 kS/s per channel, whichever is the smallest sample rate Maximum sample rate switches 20, sample rate switching always stops when sweep ends Minimum time between sample rate switches 2.5 ms...
  • Page 996 GEN3t Dual Dual Sweep Specification 0% to 100% of selected sweep length Pre-trigger segment If trigger occurs before the pre-trigger segment is recorded, the pre-trigger segment is truncated to recorded data only. Delayed trigger Maximum 1000 seconds after a trigger occurred. The sweep is recorded immediately after a delayed trigger time with 100% post-trigger after this time point.
  • Page 997 GEN3t Environmental Specifications Temperature Range Operational 0 °C to +40 °C (+32 °F to +104 °F) -25 °C to +70 °C (-13 °F to +158 °F) Non-operational (Storage) Thermal protection Automatic thermal shutdown at 85 °C (+185 °F) internal temperature User warning notifications at 75 °C (+167 °F) (Supported by Perception V6.30 or higher)
  • Page 998 GEN3t Harmonized Standards for CE Compliance, According to the Following Directives Low Voltage Directive (LVD): 2014/35/EU Electromagnetic Compatibility Directive (EMC): 2014/30/EU EN 61000-4-6 Immunity to conducted disturbances, induced by radio-frequency fields 0.15 to 80 MHz, 1000 Hz AM; 10 V RMS @ mains, 3 V RMS @ channel, both using clamp: performance criteria A...

  • Page 999: B2640-3.1 En (Gen Series Gn811)

    GEN3t B2640-3.1 en (GEN series GN811) Capabilities Overview Model GN811 Maximum sample rate per channel 1 MS/s Memory per card 256 MB Analog channels Anti-alias filters Fixed bandwidth analog AA-filter combined with sample rate tracking digital AA-filter ADC resolution 16 bit...
  • Page 1000 GEN3t Note The specifications listed are valid for cards that have been calibrated and are used in the same mainframe and slots as they were at the time of calibration. When the card is removed from its original location and placed in another slot and/or mainframe, the Offset error, Gain error and MSE specifications are expected to increase (up to double the original specification) due to thermal differences within the configurations.
