Antunes, AJ UTX-200 Manual

A.J. Antunes & Co.
Manufacturing number 9210800 & 9210802
Place this manual in the toaster section
of your Equipment Manual.
Manufactured exclusively for
McDONALD'S ®
A.J. ANTUNES & CO.
180 KEhOE BLvD.
CAROL STREAM, ILLINOIS 60188, U.S.A.
PhONE: 1-630-784-1000
TOLL FREE: 1-877-392-7854
FAX: 1-630-784-1650
www.ajantunes.com
C
owner information .....................................................2
General ......................................................................2
Warranty Information .................................................2
Service/Technical Assistance ....................................2
specifications .............................................................3
Electrical Specifications & Plug Configuration ..........3
Dimensions ................................................................3
important safety information ....................................4
installation ...................................................................5
operation .....................................................................7
Operating Instructions ...............................................7
Switching between Muffin and Bagel Mode ..............7
Breakfast to Lunch Change-over...............................8
Product Labels and Toasting Product .......................9
The Antunes Food Service Equipment Division of A.J. Antunes & Co. provides the following limited warranty to the original purchaser of all McDonald's Equipment.
All components are warranted against Manufacturer's defects in the material and workmanship for a period of two (2) years from date of original installation not to
exceed 30 months from the date of shipment from our factory.
If any part becomes defective during the period of this Warranty, Antunes Food Service will pay negotiated straight time labor costs to an Authorized Service Agent
to replace the part, plus travel expenses up to 100 miles/160 km, 2 hours round trip.
WarrantY eXClUsions
• The cost of Installation.
• Equipment that has been damaged due to shipment. Purchaser should
make damage claim directly upon carrier.
• Alteration, misuse, abuse.
• Improper storage or handling.
• Improper maintenance.
• Failure to follow proper Installation instructions, including electrical
connection.
• Improper or unauthorized repairs.
Antunes Food Service reserves the right to make changes in design or add improvements on any products. The right is always reserved to modify Equipment
because of factors beyond our control and government regulation. Changes to Equipment do not constitute a warranty charge.
This warranty is exclusive and is in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or fitness for a particular
purpose, each of which is expressly disclaimed. The remedies described above are exclusive, and in no event shall A.J. Antunes & Co. or any of its Divisions be
liable for special consequential or incidental damages for the breach or delay in the performance of this warranty.
this manual is for the exclusive use of licensees and employees of Mcdonald's systems, inc..
P/N 1010904 Rev. B 03/12
McDonald's
Universal toaster
Model UtX-200
BY
US
CM

table of Contents

liMited WarrantY
© Mcdonald's Corporation all rights reserved
Universal ToasTer UTX-200
Bun Thickness Compression Control Knob Settings 10
Adjusting Toasting Quality .......................................10
viewing the Program Mode Settings .......................11
Universal Toaster Settings .......................................11
UTX-200 Unit Status Mode .....................................12
Purging Products from the Toaster ..........................12
Shutting down the UTX-200 ....................................13
Maintenance ..............................................................14
DAILY: Cleaning the Accessories,
Release Sheet, and vertical Conveyor Belt ............14
troubleshooting .......................................................16
replacement Parts ...................................................18
notes .......................................................................19
• Scheduled Maintenance procedures as outlined in your MRC Card.
• This Warranty does not cover Consumable items.
• Water pressure problems or contamination problems such as foreign material
in water lines or inside solenoid valves due to an incoming water source.
• Overtime or Holiday charges.
• Mileage over 100 miles/160 km round-trip, or travel time over two (2) hours.
• Freight, foreign, excise, municipal or other sales or use taxes.
• Consequential damages such as loss of profit, loss of time, the cost of
repairing or replacing other property which is damaged, or any other
incidental damage of any kind.
1
A.J. Antunes & Co.
