REFRIGERATOR
REFRIGERATOR
FRENCH DOOR REFRIGERATOR
BASIC : RF28HD*
MODEL NAME : RF28HDEDTSR
RF28HDEDBSR
MODEL CODE : RF28HDEDTSR/AA
RF28HDEDBSR/AA
CONTENTS
1. PRECAUTIONS(SAFETY WARNINGS) ·······5
2. PRODUCT SPECIFICATIONS ······················9
3. DISASSEMBLY AND REASSEMBLY ·········26
4. TROUBLESHOOTING ································56
5. PCB DIAGRAM ·········································102
6. WIRING DIAGRAM ···································107
7. BLOCK DIAGRAM ····································108
8. MODEL CODE TABLE ······························ 110
