SAFETY PRECAUTIONS & WARRANTY AND SERVICE
Safety Precautions and Liability Exclusion
Sphinx FPV Racer is NOT a toy. It is not suitable for using by any children under 14
years of age. It is a race quad and not come with GPS hold, and it does require a fair
amount of skill to pilot it.
A warning that batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
The propeller can do some serious injury to human body. So when you setting up the
racer, it is highly recommended to REMOVE ALL PROPELLERS.
Keep in mind that there is always a chance that propellers spin up unexpectedly.
SkyRC accepts no responsibility or liability for any injury or damage to a person or
property caused by the use of Sphinx FPV Racer.
Warranty and Service
We guarantee this product to be free of manufacturing and assembly defects for a period of one
year from the time of purchase. The warranty only applies to material or operational defects,
which are present at the time of purchase. During that period, we will repair or replace free of
service charge for products deemed defective due to those causes.
This warranty is not valid for any damage or subsequent damage arising as a result of misuse,
modification or as a result of failure to observe the procedures outlined in this manual.
The warranty service is valid in China only.
If you need warranty service overseas, please contact your dealer in the first instance, who is
responsible for processing guarantee claims overseas. Due to high shipping cost, complicated
custom clearance procedures to send back to China. Please understand SKYRC can't provide
warranty service to overseas end user directly.
If you have any questions which are not mentioned in the manual, please feel free to send email
to info@skyrc.cn
Manufacturedby
SKYRCTECHNOLOGYCO.,LTD.
www.skyrc.com
All specifications and figures are subject to change without notice.
Printed in China
2016.11
7504-0845-01
RoHS
SPHINX
FPV RACER
Instruction Manual
[Version 1.0]
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Skyrc SPHINX
Summary of Contents for Skyrc SPHINX
- Page 1 SPHINX Safety Precautions and Liability Exclusion Sphinx FPV Racer is NOT a toy. It is not suitable for using by any children under 14 FPV RACER years of age. It is a race quad and not come with GPS hold, and it does require a fair amount of skill to pilot it.
- Page 2 IN THE PACKAGE performance quadcopter with FPV Camera, ESC, Motor and Video Transmitter. Let’s meet your Sphinx FPV Racer now. Please review the illustrations below for a full list of your Sphinx FPV Racer parts. Antenna FPV Quadcopter 5” Propeller...
- Page 3 Adjust Motors Angle Hold the motor in place with one hand, then using L-Wrench and turn in opposite direction to secure the propeller. Unique Method to Adjust Rotor Angle (0°, 5°, 10°) · 03 SPHINX FPV RACER SPHINX FPV RACER 04 ·...
- Page 4 5.945GHz It is highly recommended to understand the rules and regulations in your country before using Sphinx FPV Racer. Transmitting outside a legal band is something prohibited by authorities and may result in a fine or confiscation of equipment. Vibration-Free Camera mount for GoPro ·...
- Page 5 Connect Your Receiver Safety Precautions The Sphinx FVP Racer is not a toy. It is not suitable for using by any children under 14 years of age. During the flying, the propellers of Sphinx FVP Racer could cause injury to people, animals and property. Do not touch Sphinx FVP Racer when propellers are USB Port spinning and wait until the propellers have completely stopped before handing it.
-
Page 6: Specifications
Weight(FPV Racer) 428g(without battery) Size 222 mm Yawing (rotating towards left or right) 123 mm 173 mm 99 mm Pitching (moving onwards or backwards) Rolling (turning towards left or right) · 09 SPHINX FPV RACER SPHINX FPV RACER 10 ·...
