INSTRUCTIONMANUAL
Sparrow FPV Racer
INSTRODUCTION
The SkyRC Sparrow FPV racer is designed for both indoor and outdoor FPV experience. Its
wheelbase is 120mm with pre-installed FC, ESC, Motors, Camera and advanced 5.8G Video
Transmitter. There are 4 LED indicators on the front and rear arms (front red, rear green).
Please carefully read the manual before operating, wish you enjoy your flights!
3020 Propeller
Naze32 Rev6
Flight Controller
1105 3800KV
Brushless Motor
Mini Camera
Carbon Board
6A ESC
SAFETY PRECAUTIONS
The Sparrow FPV Racer is not a toy. It is not suitable for using by any children under 14
years of age. During the flying, the propellers of Sparrow FPV Racer could cause injury to
people, animals and property. Do not touch Sparrow FPV Racer when propellers are
spinning and wait until the propellers have completely stopped before handing it.
Do not fly your FPV Racer over any public area, such as beaches, stadiums, populated
parks, or other people's backyards and private areas. Do not fly near airport. In some
country, you need get appropriate authorisation from local government before your flying.
You are responsible for your own safety. You are responsible to take adequate precaution
by using the proper equipment and safety gear, and determining whether you have
adequate skill and experience. SkyRC disclaims all responsibility for any resulting
damage, injury, or expense. It is your responsibility to make sure that your activities
comply with applicable laws.
SK-910013
Carbon Board
Landing Arm
25/200mW
5.8G Video TX
-1-
IN THE PACKAGE
Main Body
THINGS YOU'LL NEED
3S LiPo Battery
Remote Control
or
PWM Receiver
S-BUS Receiver
or
FPV Monitor
PWM Receiver Cable
SBUS Receiver Cable
L Wrench
3020 Propeller x 8
Socket Screw x 8
LiPo Battery Charger
HD FPV Goggle
-2-
