Rhino
®
Hydraulic Core Drill
HCD 1-4
HCD 2-14
Revised 6.14.2016
Rhino Tool Co. Inc.
620 Andrews Ave.
Kewanee, IL 61443
Tel: 309.853.5555
Tel: 866.707.1808
Fax: 309.856.5905
info@rhino.com
www.rhinotool.com
1
Prior to Operation
We thank you for choosing a
®
Rhino
core drill.
To ensure smooth operation
and long-lasting performance of
your new core drill, we re-
commend you to study this
operating manual carefully and
pay special attention to the
chapters about
Safety and Service
Precautions
We are confident you will be
satisfied with your new Rhino
core drill.
Best regards
Rhino
Tool Company
®
®
000386.08.25.16
Advertisement
Table of Contents
Related Manuals for RHINO HCD 1-4
Summary of Contents for RHINO HCD 1-4
-
Page 1: Prior To Operation
Revised 6.14.2016 Safety and Service Precautions Rhino Tool Co. Inc. We are confident you will be 620 Andrews Ave. Kewanee, IL 61443 satisfied with your new Rhino ® core drill. Tel: 309.853.5555 Tel: 866.707.1808 Fax: 309.856.5905 Best regards Rhino Tool Company ®... -
Page 2: Table Of Contents
Contents Page Safety Precautions ....................2 Oil Flow and Pressure ..................4 Useful information regarding the use of core drill ..........4 Starting Instructions .................... 6 Technical Data ....................7 Performance Chart ....................8 Dimensions ......................9 Connection to Hydraulic Power Sources .............. 10 Service and Maintenance ................... -
Page 3: Safety Precautions
• Make sure that the core bit is firmly fastened in the drill • For handheld drilling, always use core bits approved for this purpose. ® • The Rhino core drill is supplied with a trigger lock. This may only be used when drilling in a rig. - Page 4 • Always make sure that the core drill labels and warning signs are legible. ® • Always use hoses, couplings and spares as such recommend by Rhino • Repairs may only be carried out by experienced personnel. • Make sure that all couplings are cleaned before connection.
-
Page 5: Oil Flow And Pressure
As handheld drilling is possible for all jobs, the operator saves a lot of time as he does not have ® to mount a drilling rig prior to operation. For rig drilling, the Rhino core drill can be mounted in the most common drilling rigs with a diameter of 2.36” (60 mm). - Page 6 ® The utility values of your Rhino core drill are numerous, and we are confident that you will be very pleased with your investment.
-
Page 7: Starting Instructions
Starting Instructions START • Mount a core bit in the drill • Connect hoses – clean couplings before connection. Connect water supply. • Set the power source on ”ON”. • Get a good footing, adjust the front handle and lock it. Keep it locked during drilling. •... -
Page 8: Technical Data
Technical Data HCD 1-4 HCD 2-14 Weight w/o hoses, core bit and adaptor 16.75lbs (7.6 kg) 16.75lbs (7.6 kg) Oil supply 5 g.p.m. (20 l.p.m.) 5 g.p.m. (20 l.p.m.) Working pressure nominal 1450 psi (100 bar) 1450 psi (100 bar) -
Page 9: Performance Chart
Performance Chart HCD 1-4 Core Drill Performance loss with different lengths of hoses: 3/4" hose 5/8" hose 1/2" hose 3/8" hose 100% 50ft (15 m) 65 ft (20 m) 82 ft (25 m) 98 ft (30 m) 115 ft (35 m) 131 ft (40 m) 148ft (45m) 164ft (50m) 180ft (55m) 197ft (60m) 213 ft (65 m) 230 ft (70 m) 246 ft (75 m) 262 ft (80m) Hose Length - Pressure from power pack: 2175 p.s.i. -
Page 10: Dimensions
Dimensions 000386.08.25.16... -
Page 11: Connection To Hydraulic Power Sources
® • or you can choose one of our Rhino powerpacks. Your dealer can guide you in choosing the right powerpack. ® In case of doubt, please contact your dealer or Rhino 000386.08.25.16... -
Page 12: Service And Maintenance
Check bearing for clearance IMPORTANT- At service/repair it is important to mount the hoses correctly. Oil Types ® The Rhino core drill uses standard hydraulic oil, i.e. all types of mineral oil and biodegradable oil, which comply with the following values: Recommended viscosity... - Page 13 (12) months with regard to all other components, excluding the Honda 13 HP engine and Vanguard 18 HP engine for which Rhino provides no warranty and for which the warranty is provided by American Honda Motor Co., Inc and by Briggs and Stratton Corporation respectively and the shall be the sole warranty applicable thereto.
