Controls - NewTek TriCaster TCXD300 User Manual

13.2.3 Controls

Transport controls and playback settings are located directly below the Playlist and Scrub-Bar.
Figure 152
TIME DISPLAY
Figure 153
During playback, a timecode field in the transport controls area displays the Current Time for the
currently displayed playlist item.
Left-click the field to type in a timecode, then press Enter to jump to that point in the file. If you
right-click the timecode field, a menu allows you to choose to between showing current time and
remaining time (Reverse Direction), as well as enabling or disabling Warning Colors.
Hint: With Warning Colors enabled, the time display provides visual indication that the playback
is nearing its end. Ten seconds before the end of play for the current item, the digits in the time
display turn amber. When only five seconds are left, the numbers are shown in red.
SINGLE
Figure 154
Media player playback normally conforms to typical playlist practice – each item in the playlist
playing back in orderly succession. When Single mode is enabled, playback stops when the Out
Page | 176
