Page 2: Quick Confi Guration Guide
Thank you for purchasing the AP58V2. This manual will instruct you how to configure and manage this Wireless Access Point, enable you to use it in a perfect status. After installed the AP58V2, you will be able to enjoy the surfing freely. - Page 3 P 1 AP58V2's Interface Reset: Press it for 10-15 seconds, the AP58V2 will restore to factory default. Wan: Connect with internet cable LAN: Connect the AP58V2 with computer by LAN cable. DC: For Power supply, the DC’s electronic standard is 12V/24V.
- Page 4 PoE Power and AP58V2 configuration Please make sure our AP58V2 working with included Power adapter or PoE adapter, and under right connection way, or the Attention device will be damaged. :AP58V2 Start and Log in 1) Power the AP58V2 as P2 show 2) Configure the Computer’s IP Address : Set the computer’s IP...
- Page 5 P3 Configure the computer’s IP address by wired...
- Page 6 General and Advanced after right click Wireless Network Connection and select Properties, but no Wireless Network Configuration in Window Log in the AP58V2: Open your web browser, type in 192.168.188.253 in the address bar, enter the username/Passwords: preset as admin/admin,...
- Page 7 P8 Log in r d : Setup Wizard After successful login, you can see web management page of the AP58V2, Please go to Wizard on the top menu...
- Page 8 : Repeater Operation Mode Repeater: AP58V2's LAN Port, WAN Port and Wifi will bridge together, AP58V2 will broadcast an SSID outward simultaneously. Users access into AP58V2 through LAN port or Wifi, then get the IP address from AP or WLAN station.
- Page 9 The AP58V2's default operation mode is Wireless ISP, the two RJ45 port are LAN ports and PoE port under this Instruction mode. LAN Port AP or WLAN station AP58V2 P 10 diagram of Bridge How to Set in Repeater Mode...
- Page 10 Please note that the AP58V2's system will reboot in 1 minute after choose Repeater and Apply 2 Connect to AP or WLAN Station Click Wireless, scan AP, then will pop up a window as P12, take YUNLINK for example, click choose AP and enter into a new web page P13: If your PC can’t pop up the page of P11, Please check your Browser and...
- Page 11 P 13 Wireless AP Connection This page show wireless AP connection status, including SSID, MAC, AP Signal Strength, Link Quality and so on, if there is password in Wireless AP, input the passwords, then Apply, the AP58V2 will reboot to connect with Wireless AP.
-
Page 12: Troubleshooting
Please scan several times more if haven’t find the target SSID in scan list. If can’t find it still, Please make sure the AP58V2 support the channel of WLAN station or AP. For example: AP’s channel is Channel 14, but AP58V2 support Channel 13. - Page 13 Run, then ping 192.168.0.1 Restore the AP58V2 to factory default to login Make sure there isn’t any equipment take IP address 192.168.0.1 in AP58V2's networking Check your computer and network cable to avoid any problem, recommend to use unshielded twisted pair 10/100M Ethernet cable.
