- Page 1 Business² Hand dryer High Speed...
- Page 2 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual 608mm 250mm Technical Specifications Item Category Performance Data Operating Voltage 220 - 240Vac, 50 Hz, 800 watts (heater off ) 1600 watts (heater on) Warm Air Speed Output 110 m/s Display LED countdown Motor Type...
- Page 3 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual General Safety Information NOTE: Do not install dryer over wash basin. • WARNING Type Y attachment This product is intended for installation by a qualified service person. Use AWAG No.16 solid If the power supply cord is damaged, it must be conductor for wiring.
- Page 4 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual Recommended Mounting Heights From floor to bottom of dryer. Men’s Ladies Children, ages 11-17 Children, ages 3-10 Disabled 13” 11” 10” 6” 4” 350 mm 300 mm 250 mm 150 mm 100 mm Consumables...
- Page 5 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual Cleaning and Maintenance Instructions Periodic cleaning of the unit is recommended to • WARNING ensure optimum performance. • Never spray water directly onto hand dryer • Switch to service mode located on the top left side of •...
- Page 6 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual Diagram Business...
- Page 7 Surface Mounted High Speed Hand Dryer Operating Instructions and Parts Manual Parts List Description Description Bracket Cover Big pothook Fan house cover Fixing board LED light Small pothook Fan house cover Air outlet PP seal board Right fixer Eradiating screen Connector Left side board Base plate...
