Lincoln Electric AC-225-S Operator's Manual page 18

P-65-B.1.a
# Indicates a Change This Printing
ITEM DESCRIPTION
This Page for Codes Above 11600:
2 Fan Motor & Blade, Includes:
Fan
2 Fan Motor & Blade, Includes:
Fan
5 Case
6 Nameplate (Codes 11602 & 11604)
6 Nameplate (Code 11603)
6 Nameplate (Code 11674)
Fastener Button (Black)
8 Handle Assembly
9A Lead Clamp
11 Line Switch
12 Transformer & Base
15A Lower Case Back
15B Upper Case Back
16 Electrode Cable
17 Electrode Holder
18 Ground Cable
20 Ground Clamp
Undercarriage Kit, Includes:
21 Wheel
22 Mounting Kit, Includes:
22A Plain Washer
22B Push Nut
22C 3/8-16 x 2.00 HHCS
23 Axle
29 Power Input Cable (Codes 11602 & 11604) S15599-1
29 Power Input Cable (Code 11603 & 11674) S18021
30 Warning Decal (Not Shown)
31 Electrode Selection Decal (Not Shown)
32 Wiring Diagram (Not Shown) (Codes 11602 & 11604)
32 Wiring Diagram (Not Shown) (Code 11603)
32 Wiring Diagram (Not Shown) (Code 11674)
33 Warranty Decal (Not Shown)
*
Undercarriage Kit Optional on all Codes - Standard where indicated.
NSS - Not Sold Separately
Use only the parts marked "X" in the column under the
heading number called for in the model index page.
PART NO. QTY. 1 2 3 4 5 6 7 8 9 10 11 12 13 14
M13539-1 1 X • X •
M13525 1 X • X •
M13539-2 1 • X • X
M13525-1 1 • X • X
L3786-14 1 X X X X
M22165 1 X • X •
M15727 1 • X •
M22167 1 • • • X
T14659-1 1 X X X X
T13990-1 1 X X X X
S15761 1 X X X X
S18815 1 X X X X
NSS 1 X X X X
L4595-2 1 X X X X
G1395 1 X X X X
S11609-4 1 X X X X
K909-1 1 X X X X
S11609-3 1 X X X X
M12033 1 X X X X
*
K761 • • X •
S11662-3 2 • • X •
T14160 1 • • X •
S9262-1 2 • • X •
T12570 2 • • X •
CF000071 1 • • X •
M8809-61 1 • • X •
1 X • X •
1 • X • X
M14330-3 1 X X X X
M14331 1 X X X X
S15621 1 X • X •
S16671 1 • X •
S28364 1 • • • X
S22127-1 1 • X •
P-65-B.1.a
•
•
•
04-19-2010
