- Page 1 Repair Manual Polaview HR2500 LCD Panel September 1996 Americas Business Center Technical Services 201 Burlington Road Bedford MA 01730 TEL: 1.781.386.5309 FAX: 1.781.386.5988...
-
Page 2: Table Of Contents
The manual serves as a guide for the replacement of such elements when the unit needs servicing. Board level repair may only be performed by the company : COMPANY Polaroid REFERENCE as authorized by ASK. Any unauthorized repair that is performed outside the scope of this document will violate any warranties and could potentially damage the unit. -
Page 3: Tools
BOARD LEVEL POLAVIEW HR 2000 TOOLS You need a the following tools for board level repair : TOOL Pozidrive no.2 screwdriver Opening housing, replacing elements 5 mm nutdriver Fastening the COMPUTER connector 8 mm open-end wrench Replacing cooling fan SYSTEM STRUCTURE The display system consists of the following main elements : PART # ITEM DESCRIPTION... -
Page 4: Replacing Systems Elements
BOARD LEVEL POLAVIEW HR 2000 Replacing systems elements All system elements described on the previous page are replaceable in the field. The repair of the display unit at the board level is described below. The other elements (such as electronics) are not serviceable and should therefore be replaced if they fail. -
Page 5: Servicing The Display Unit
BOARD LEVEL POLAVIEW HR 2000 SERVICING THE DISPLAY UNIT All maintenance of the unit shall be performed at a static-free workstation. Work in a dust free environment if possible, and have access to a high pressure air blower to remove dust when assembling the unit. The unit must be disconnected from the power supply and computer before opening. -
Page 6: Replacing The Fan [15 Min]
BOARD LEVEL POLAVIEW HR 2000 Replacing the fan [15 min] The fan (13) is mounted in the housing top by four nuts. Remove the controller board and the four nuts holding the fan. Be careful not to break the mounting studs. Replace with a new fan, reversing the above procedure. - Page 7 BOARD LEVEL POLAVIEW HR 2000...
