Turn Signal Lamp - Jiangsu Niu Electric Technology N1S Operation & Maintenance Manual

Component Front
name headlight
PIN Color
1 Blue
2 White
3 Black
Red and
4 white

Turn signal lamp

Front turn signal lamp
The turn signal lamp does not illuminate or the lighting is weak.
Check the following components:
- Whether the light bulb is burnt or there is weld missing on the bulb
- Whether the connection circuit connector is loose
- Whether the light switch is in a bad contact
Component Left turn signal
name
PIN
1
2
Component interface
Interface
number
Interface definition
Definition
High beam
Low beam
Ground wire
Power cord (12V)
Legend
Harness interface
Interface
lamp number
Interface definition
Color
Yellow
Black
Legend
J13-A
Wire length
20cm
J7-B
Definition
Left turn signal lamp
Ground wire
