GSM TELEPHONE
GSM TELEPHONE
SGH-L600
1.
Safety Precautions
2.
Specification
3.
Product Function
4.
Array course control
5.
Exploded View and Part List
6.
MAIN Electrical Parts List
7.
Block Diagrams
8.
PCB Diagrams
9.
Flow Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung SGH-L600

Summary of Contents for Samsung SGH-L600

  • Page 1 GSM TELEPHONE SGH-L600 GSM TELEPHONE CONTENTS Safety Precautions Specification Product Function Array course control Exploded View and Part List MAIN Electrical Parts List Block Diagrams PCB Diagrams Flow Chart of Troubleshooting 10. Reference data 11. Disassembly and Assembly Instructions...
  • Page 2 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com ⓒ This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2007. 10. Rev.1.0...

  • Page 3: Gsm General Specification

    5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl Sensitivity - 102dBm - 102dBm - 100dBm -1 00dBm TDMA M ux Cell Radius 35Km 35 Km SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 4: Gsm Tx Power Class

    11±5 dBm 8±4dBm 8±4dBm 9±5 dBm 6±4 dBm 6±4 dBm 7±5 dBm 4±4 dBm 4±4 dBm 5±5 dBm 2±5 dBm 2±5 dBm 0±5 dBm 0±5 dBm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 5 14±3 dBm 9±5 dBm 12±4 dBm 12±4 dBm 10±4 dBm 7±5 dBm 10±4 dBm 8±4dBm 5±5 dBm 8±4dBm 6±4 dBm 6±4 dBm 4±4 dBm 4±4 dBm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 6 Specification SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 7: Exploded View And Parts List

    QLC01 QVK01 QMP01 QPC01 QMI01 QAN05 QAN02 QCR79 QSH01 QCK02 QHI02 QCK01 QFL01 QRF03 QCR78 QRE01 QVO01 QSD01 QCR05 QCR05 QCR05 QRF01 QSC05 QBA01 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 8: Cellular Phone Parts List

    TAPE-LOWER SCREW CAP GH74-33615A QSD01 PMO-COVER SD GH72-39627A QSH01 ICT-COVER SHIELD GH70-02406A QSP01 MICRO SPEAKER 3001-002196 QVK01 KEY FPCB-VOLUME KEY GH59-04687A QVO01 PMO-VOLUME KEY GH72-39629A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 9 TAPE GASK-SUB PBA GH74-35889A MANUAL USERS-EU FRENCH GH68-15731A BAG PE 6902-000634 LABEL(P)-UNIT SEAL GH68-00518B LABEL(P)-OPEN MP3 GH68-11246A LABEL(R)-MAIN(XEF) GH68-15795B BOX-UNIT(EU) GH69-05804B CUSHION-CASE(EU) GH69-05805A VINYL-BOHO UPPER COVER GH74-35791A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 10: Disassembly And Assembly Instructions

    Rear. the Rear 1) Don't devote heavily the top of the Rear. 1) Be careful to break the center and both side Hooks. 11-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 1) Be careful to damage the SLIDE FPCB. 1) Don't scratch the surface of the handset. Please pay attention. 2) Be careful to damage the DOME SHEET. 11-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 2) Remove 4 point screws of the Lower 1) Don't scratch the surface of the handset. 1) Don't scratch the surface of the handset. Please pay attention. Please pay attention. 11-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 1) Separate the Speaker from the Upper. Connector. 1) Be careful to damage the Sub PCB Connector. 1) Be careful to damage the Speaker and wire. 11-4 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 1) Separate Sub PBA andL LCD from Upper 1) Be careful to damage the Sub PCB-FPCB. 1)Be careful to damage the Sub PCB and S-FPCB 11-5 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 15: Assembly Instructions

    1) Attach the Insulting tape on the Actuator. and Close the Actuator. 1) Be careful to damage the S-FPCB 1) Pay attention to the base line. 11-6 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 16 2) Attach 2 screw caps on the top of the Lower. 1) Don't scratch the surface of the handset. 1) Assemble anti-clockwise. Please pay attention. 11-7 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 1) Put in the Lower on the Fornt from Top to holes. bottom clockwise. 1) Pay attention to the direction. 1) Pay attention to gap. 11-8 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 18 Disassembly and Assembly Instructions 1) Tighten 4 Screws of the Rear orderly. 1) Don't scratch the surface of the handset. Please pay attention. 11-9 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 Disassembly and Assembly Instructions 11-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 20: Flow Chart Of Troubleshooting

    Check the +VDD_GSM_CORE circuit = 1.8V? Check for the clock at C125 Check the clock generation circuit = 26MHz (related to U101) Check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 22 UCP200 pin C11 (RSTON) ="H"? Check the circuit related to reset UCP200 pin F1(R403) change UCP200 (RSTEXTn) ="H"? Check the 16bit data signal & memory CE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 24: Charging Part

    > 4.9V V_EXT_CHARGE Check the circuit related to PAM300 pin 34(AUX_ON) = "L"? AUX_ON signal Check the PAM300 pin 46 Resolder or replace PAM300 ≒ 1.2V SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 26: Sim Part

    Check the Clock pin3 of SIM300 in a few second After SIM card insert, Replace PBA SIM300 pin 2 = "H(SIM_RST)"? Check the SIM Card SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 Flow Chart of Troubleshooting SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 28: Microphone Part

    Resolder the C402, C405, R400, R402 from UCP200 to MIC Check F500 PIN 8 Check the JACK_IN signal = ' H' ? Check the MIC Replace the MIC SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 Flow Chart of Troubleshooting 9-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 U401 pin 15,17 ≒ 1.8V? Resolder U401 (When U101 operate) HDC600 pin 2,3 ≒ 1.8V? Resolder HDC700 (When U401 operate) Is Speaker working? Change the Speaker 9-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 Flow Chart of Troubleshooting 9-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 32: Key Data Input

    Check the Dome sheet & Key Pad pushed, is it displayed on LCD? When one of the keys is pushed, Replace the PBA KBIO signal is OK? 9-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 33: Receiver Part

    Flow Chart of Troubleshooting 9-8. Receiver Part Receiver does not work Resolder UCP200 or Change PBA Is Receiver working? Replace the Receiver Is Receiver working? 9-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 34 Is LCD Contrast set on high Set LCD Contrast on high level level in the Menu? Resolder HDC600 or change PBA HDC600 PIN 21 = H ? 9-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 Flow Chart of Troubleshooting 9-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 36: Key Back Light

    9-10. Key Back Light Main Key LED does not work Check the UCP200 related to "VDD_KEY" U302 pin6 = "H"? U302 pin3 = 3.3V ? Change U302 9-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 37 Flow Chart of Troubleshooting 9-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 38: Camera Part

    Reconnect the camera module connector on LCD module HDC600 Pin21 = H? Resolder HDC600 or change PBA Is there another problem? Replace the camera module 9-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 Flow Chart of Troubleshooting 9-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 40: Gsm Receiver

    25 ≥ -70dBm Check & Resolder osc100pin 16,17,29 osc100 pin 4,5,6,7 C118,C121,C123,R105 32,36 ≥2.8V ≥ 0.2Vp_p And PMU Part pin10≥1.8V Resolder U101 Check UCP200 9-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 41: Gsm Transmitter

    OK? Check VBAT or PAM control signal osc100pin U101 pin 4,5,6,7 16,17,29 ≥ 0.2Vp_p 32,36 ≥2.8V Check U101, pin10≥1.8V C118,C121,C123,R105 Resolder U101 Check UCP200 9-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 42: Dcs Receiver

    23 ≥ -70dBm Check & Resolder osc100 pin16,17,29, osc100 pin 4,5,6,7 U102, 32,36 ≥2.8V ≥ 0.2Vp_p C118,C121,C123,R105 pin 10≥1.8V And PMU Part Resolder U101 Check UCP200 9-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 43: Dcs Transmitter

    Check & Resolder osc100 pin 4,5,6,7 32,36 ≥2.8V U101, C118,C121,C123,R105 ≥ 0.2Vp_p pin 10≥1.8V And PMU Part Resolder U101 Check UCP200 9-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 44: Pcs Receiver

    21 ≥ -70dBm Check & Resolder osc100pin16,17,29, osc100 pin 4,5,6,7 U101, 32,36 ≥2.8V ≥ 0.2Vp_p C118,C121,C123,R105 pin 10≥1.8V And PMU Part Resolder U101 Check UCP200 9-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 45: Pcs Transmitter

    32,36 ≥2.8V U101,C118,C121,C123,R105 U102, C120,L123,C124126 C118,C121,C123,R105 ≥ 0.2Vp_p pin 10≥1.8V And PMU Part And PMU Part And PMU Part Resolder U102 Check UCP200 Check UCP201 9-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 46 Flow Chart of Troubleshooting 9-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 47 Resolder ANT or L109 -4dB Resolder c127,c130 c127,c130(+position) or PMU Part is >1.8 osc101 pin is Resolder osc101 or c146,c147,or113 26Mhz(1.4V p_p) Check UCP200 9-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 48 Flow Chart of Troubleshooting 9-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 49: Radio Part

    Flow Chart of Troubleshooting 9-19. Radio part Radio does not work Resolder R107,C137 and R107, C137 check the PMU part >= 2.9V Check UCP200 9-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 50 Flow Chart of Troubleshooting 9-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 Flow Chart of Troubleshooting 9-32 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 52: Array Course Control

    4. Array course control 4-1. Software Adjustments Test Jig (GH80-03306A) Test Cable (GH39-00499A) Serial Cable(CSA LL64151-A) Power Supply Cable SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 53: Software Downloading

    - if the binary file wanted, check only 'BIN' - if the tfs file wanted, check only 'TFS' - if all the files wanted, check 'BIN+TFS' SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54 Array course control 3 . Select the file(s) what you want to download SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55 Array course control SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 59: Pcb Diagrams

    8. PCB Diagrams SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 60 PCB Diagrams Bottom SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 61: Main Electrical Parts List

    2203-000359 C145 C-CER,CHIP 2203-006842 C146 C-CER,CHIP 2203-000278 C147 C-CER,CHIP 2203-000278 C200 C-CER,CHIP 2203-006399 C201 C-CER,CHIP 2203-005482 C202 C-CER,CHIP 2203-005482 C203 C-CER,CHIP 2203-006123 C204 C-CER,CHIP 2203-005482 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 2203-006423 C330 C-CER,CHIP 2203-006208 C331 C-CER,CHIP 2203-006361 C332 C-CER,CHIP 2203-006824 C333 C-CER,CHIP 2203-006474 C334 C-CER,CHIP 2203-006048 C335 C-CER,CHIP 2203-006562 C336 C-CER,CHIP 2203-000425 C400 C-CER,CHIP 2203-001437 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 63 F505 FILTER-EMI SMD 2901-001413 F506 FILTER-EMI SMD 2901-001413 HDC600 HEADER-BOARD TO BOARD 3711-005933 IFC500 SOCKET-INTERFACE 3710-002499 L100 INDUCTOR-SMD 2703-002314 L103 INDUCTOR-SMD 2703-002608 L104 INDUCTOR-SMD 2703-002608 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 64 2007-000148 R217 R-CHIP 2007-007137 R218 R-CHIP 2007-007137 R223 R-CHIP 2007-000148 R300 R-CHIP 2007-008055 R301 R-CHIP 2007-000171 R302 R-CHIP 2007-000162 R303 R-CHIP 2007-007573 R305 R-CHIP 2007-008354 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 65 2007-009168 R603 R-CHIP 2007-009112 R604 R-CHIP 2007-008055 RFS100 CONNECTOR-COAXIAL 3705-001421 SC100 ICT SHIELD-CAN CLIP GH70-02640A SC101 ICT SHIELD-CAN CLIP GH70-02640A SC102 ICT SHIELD-CAN CLIP GH70-02640A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 66 DIODE-TVS 0406-001201 ZD606 DIODE-TVS 0406-001208 ZD607 DIODE-TVS 0406-001208 Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 67: Product Function

    - Bluetooth V2.0 EDR - Multimedia Message Service (MMS) - External Memory - Java / WAP2.0 - Tri-band(900/1800/1900MHz) - FM Radio - Stereo / Speaker Phone SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 68 Product Function SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 69: Reference Data

    ― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 70 Reference data 10-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 71: Safety Precautions

    ― Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 72 ― You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
