- Page 1 OPERATION MANUAL Plasma Cutting Machine Serial Number: _________________________________ Where Purchase: _________________________________ Date of purchased: _________________________________...
-
Page 3: Table Of Contents
5. Installation & Operation ......................6 Installation ........................6 5.1. Operation ........................7 5.2. 6. Safety precaution ........................8 Installation ........................8 6.1. Safety ........................... 8 6.2. 7. Maintenance ..........................9 8. Troubleshooting & Service ......................9 P40 Plasma Cutting Machine P a g e... -
Page 4: Safety
Do not weld enclosed tanks or containers Prohibit to use welder to unfrozen. Have a fire extinguisher readily available. Hot parts can lead to burn P40 Plasma Cutting Machine P a g e... - Page 5 The people with heart-pacemaker should be away from the welding arc. Rotating parts may be dangerous Far away from rotating parts. (like fan) Keep the parts of machine in the safe position. P40 Plasma Cutting Machine P a g e...
-
Page 6: Electrical Principle Drawing
2. Electrical principle drawing P40 Plasma Cutting Machine P a g e... -
Page 7: Specifications
Severance cut for Carbon Steel (MM) ≤18 Carbon Steel ≤14 Stainless Steel ≤14 Capacity (MM) Aluminum ≤12 Copper ≤6 Compress air Pressure(Psi) 29-58(0.2-0.4Mpa), recommend 43.5(0.3MPa) Protection class IP23 Insulation class Net weight (kg) Dimensions (MM) 420*136*210 P40 Plasma Cutting Machine P a g e... -
Page 8: Operation Control And Connectors
Avoid transport in invert or side position. (2) Tightly connect the power cable to electrical socket outlet (refer to “technology parameters” for the input voltage) P40 Plasma Cutting Machine P a g e... -
Page 9: Operation
AUTION P40 CUTTING MACHINES ARE CONTACT-START, THE PLASMA ARC IGNITED IMMEDIATELY AFTER START SWITCH CLOSED. ALWAYS HOLD THE HAND TORCH AWAY FROM YOUR BODY AS A PRECAUTION AGAINST ACCIDENTAL TORCH FIRING. -
Page 10: Safety Precaution
Stop welding immediately and wait until welder cool down. (6) Welding machine should not work in a flammable and toxic environment, avoid moisture, rain, and do not directly expose to sun. P40 Plasma Cutting Machine P a g e... -
Page 11: Maintenance
The following operations require the operator has sufficient electrical expertise and comprehensive safety knowledge, the operator can demonstrate its capacity to be held valid qualifications and knowledge Documents. Common Faults and exclusion method: P40 Plasma Cutting Machine P a g e... - Page 12 Low cutting output Faulty components in unit, return for repair or have qualified technician repair. Worn torch parts (consumables), shut off input Difficult Starting power. Remove and inspect torch shield cup, tip, P40 Plasma Cutting Machine 10 | P a g e...
- Page 13 1/8 inch (3 mm) from clean surface while purging and observe oil or moisture buildup (do not activate torch). If there are contaminants in the gas, additional filtering is required. P40 Plasma Cutting Machine 11 | P a g e...
- Page 14 NOTES P40 plasma cutting power source P40 plasma cutting machine 12 | P a g e...
- Page 16 WELDKING ONLINE STORE 271, Amber Street, Unit#10, Markham, ON L3R 3J7 Tel: 1 866 686 5088 Fax: 1 866 686 5090 Website: www.weldkingstore.com Printed May 26, 2016...
