Night Stick NSR-9854XL Instruction Manual

Instruction Manual
NSR-9854XL
THANK YOU FOR SELECTING THE NIGHTSTICK NSR-9854XL!

PLEASE SAVE THESE INSTRUCTIONS

Please read these instructions before using your 9854XL. They include
important safety and operation information. Be sure to charge the 9854XL
fully before the first use. A battery is fully charged when the charger light is
green.
Included in the box - Compris dans la boîte - Incluido en la caja

WARNINGS

y Lithium-ion batteries must be used and charged properly. Improper use
can result in serious injury, fire, or death.
y NOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product
in explosive atmospheres, near flammable liquids, or where explosion proof
or intrinsically safe lighting is required.
y DO NOT use this product in the proximity of vehicles or equipment when
there is a risk of flammable liquids coming into contact with the flashlight.
y Light can become hot while on. To prevent damage DO NOT cover or
place next to any potentially flammable materials while in use.
y Do not leave the battery in direct sunlight or use or store the battery inside
cars in hot weather.
y Do not expose the battery to water or salt water, or allow the battery to
get wet.
y Do not store the battery with metallic objects that may cause a short circuit.
y Immediately discontinue use of the battery if the battery emits an unusual
smell, feels hot, changes color, changes shape or appears abnormal in any
way.
y Keep out of the reach of children.
Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.mynightstick.com

INITIAL USE

y Fully charge the 9854XL before the first use, or if the battery is new or
has been unused for several months. The maximum charge time required
is approximately 6 hours.

DAILY USE

y Use only the supplied Nightstick USB cable, battery and AC or DC adapter.
For best performance, charge the 9854XL when the flashlight beam starts
to dim.
y Connect the USB cable into either the AC or DC power adapter.
y With the flashlight facing upward, remove the rubber USB port cover, and
plug the micro USB into the flashlights micro USB port.
y The LED indicator changes to constant red indicating the 9854XL is
properly inserted into the charger and is in fact charging. The LED indicator
remains red until the battery is fully charged. At full charge, the LED indicator
turns green.
y The total time to full charge the 9854XL varies depending on the remaining
charge in the battery pack.

CR-123 BATTERY CARRIER

The CR123 battery carrier converts the 9854XL from rechargeable
Lithium-ion to non-rechargeable Lithium battery operation.
Load two CR-123 Lithium batteries with the positive terminals pointing in
the direction of the arrow. NOTE: The flashlight cannot be charged with the
CR-123 CARRIER installed.

OPERATION

The 9854XL has seven light modes: momentary flashlight, full
brightness flashlight,
flashlight, floodlight, dual-light and strobe. The 9854XL has a unique tail-
switch that operates both the flashlight and floodlight in one configuration.

Momentary Flashlight Mode

Lightly press the upper raised portion of the tail switch (without clicking the
flashlight on) for momentary operation. Release the switch to turn the light off.

Constant-on

Fully press the upper raised portion of the tail switch until it clicks and
then release for constant-on in high-brightness mode. Press and release the
switch to turn the light off.

Select Brightness Level

Press and hold down the upper raised portion of the tail switch. The light
INS-9854XL-16
medium brightness flashlight, low brightness
